德瑞克振动筛 FLC2000-4

Derrick德瑞克振动电机联系人黄工151-06098633QQ158-5545553CASCADE2000德瑞克振动筛FLC2000-4•Component based system•(Flo-Line Primer mounted above a Flo-Line Cleaner2000)•Top deck(Flo-Line Primer)effectively removes hydrated clays(gumbo)and large drilled cuttings•Bottom deck(FLC2000)provides solids removal capabilitiesThe Cascade2000combines the benefits of Derrick's revolutionary Flo-Line Primer with the time-proven solids removal capabilities of the Flo-Line Cleaner2000into a single,compact unit.The top Primer deck utilizes a variable speed conveyor belt to effectively remove hydrated clays(gumbo)and large drilled cuttings.These sticky solids are difficult to remove with any type of vibratory motion;thus they are removed before reaching the linear motionshaker below.The bottom deck of the Cascade2000is powered by two Derrick Super G vibrating motors which produce an industry leading high G linear vibratory force of over7.0G’s. This deck consists of an FLC2000three-panel shaker which is capable of handling thetoughest drilling applications.The bottom deck also features an AWD(Adjustable while Drilling)mechanism which enables the screen basket to be raised or lowered from-1°to+5°without interrupting production flow.This allows for precise fluid endpoint control.The Cascade2000is a component based system which allows the two modules to be runindependently if desired.Derrick Announces New Hyperpool High Capacity ShakerHouston,Texas(April30,2012).Derrick Equipment Company announced today the introduction of its new Hyperpool four-panel shale shaker designed for land-based oilfield drilling operations. The Hyperpool can be configured in any of three ways:primary shaker,mud cleaner,or as a secondary drier for drilled cuttings.The Hyperpool shaker is equipped with an adjustable while drilling(AWD)deck angle adjustment, which permits the operator to optimize shaker performance without interrupting operation.The AWD permits the screen deck angle to be lowered and raised within a range of+3°to+8°, respectively.The standard power source for the Hyperpool shaker consists of two Derrick Super G®vibratory motors,which applies over8G’s to the screen frame.The greased-for-life bearing system in these motors eliminates the need for any additional lubrication,thereby reducing maintenance requirements and repair costs.Continuous sound output of the motors is81dBA.Optional Super G2®motors are also available for the Hyperpool shaker.These motors feature a continuous oil-bath lubrication system at a reduced sound output of78dBA.The standard Super G motors are warranted for two years,and the optional Super G2motors carry a three-year warranty.The Hyperpool shaker offers up to35percent increased capacity over the Derrick FLC503shaker within the same footprint.Fluid Centering Technology maximizes fluid throughput by the machine’s concave screen bed design.The larger non-blanked API screen area increases capacity over conventional shakers,potentially reducing the number of shakers required.Easily installed, hardware-free,oil-resistant bed cushions fully seal the screen panels.The single-side screen compression system is available in either left or right side operation.The system reduces screen panel replacement time to less than45seconds per panel,permitting complete shaker screen changes in less than three minutes.The manually operated compression system drives retention pins that drive the screen panel downward against the concave screen bed, producing positive and uniform screen-to-deck sealing.The screen compression system increases screen life,improves conveyance,and prevents solids from passing under screen panels.Derrick offers a weir feeder(bypass or non-bypass)or a top feeder for the Hyperpool machine. The45gallon weir feeder permits the mud to flow evenly over a weir onto the shaker basket for uniform distribution across the shaker deck.Either feeder can be coupled with the Derrick flow divider,which evenly divides the feed between multiple shakers.The flow divider can be integrated into the Hyperpool installation where space and flow line elevation are concerns.In addition to single units,the Hyperpool is available in dual and triple units on a single skid and configured with an integral flow divider,which provides even distribution of both liquid and solids between each shaker,and center cement bypass with gate valve.Standard features of dual and triple units are Super G vibratory motors,single-side screen compression system,and AWD deck angle adjustment.For more information,contact:Sam Bridges,Technical Product ManagerDerrick Equipment Company15630Export Plaza DriveHouston,Texas14225Phone:281.590.3003E-Mail:derrick@DownloadDerrick Hyperpool BrochureClick here for more Hyperpool information。
