量具中英文对照
量具中英文对照
量具中英文对照量具 Measuring Tools板规 plate gauge比例规 proportional dividers标准规 standard gauge齿轮规 gear tooth gauge丁字尺 T-square分线规 divider;dividers钢尺 steel rule工作量规 working gauge厚薄规 feeler(gauge)角尺 angle square角规 angle gauge金属卷尺 metallic tape卡尺 calipers;caliper刻度尺 graduation ruler块规 gauge(block)量规 gauge螺距规 screw pitch gauge螺纹千分尺 screw micrometer内径千分尺 micrometer inside caliper;inside micrometer 内卡钳 inside caliper皮尺 tape(/measure)平面规 surface gauge千分表 dial indicator千分尺 micrometer曲尺carpenter’s square三角尺 set square深度千分尺 micrometer depth gauge; depth micrometer椭圆规 ellipsograph外径千分尺 outside micrometer外卡钳 outside caliper隙规 gap(/clearance) gauge线规 wire gauge斜角规 bevel square游标卡尺 vernier caliper圆规 compasses折尺 folding pocket measure(/ruler)直尺 straight edge中心规 centre gauge锥度规 taper gauge组合角尺 combination set可调的磁力架----Magnetic stand with fine adjustment点接触杠杆千分表 ---Lever dial indicator point contact length 卡钳式内径千分尺－Internal quick caliper dial gauge孔的轮廓量规－Bore profile gauge KT磁性吸座－－Magnetic stand花岗岩平台（精度1极）Granite table, accuracy 1外径千分尺标准棒――micrometer standard装有T型槽的平台-Tenon and T-slot incl. installation。
测量工具中英文对照表大全
测量工具中英文对照表大全测量工具中英文对照表heodolite 经纬仪Water Level 水位仪Level Ruler 水平尺Casing gradienterCoating thicknessMeasurer 涂层测厚仪Ultrasonic thicknessmeasurer 超声波测厚仪Ultrasonic crackdetector 超声波裂纹测试仪Digital thermometer 数字温度计radiation thermometer 辐射温度计Gradient Reader 坡度读数器Volometer 万用表MegaOhmmeter 兆欧表Earthing resistanceReader 接地电阻读数表Plug gauge 圆柱塞规Magnifying glass 放大镜Plummet 铅锤Profile projector 投影仪Pin Gauge 针规(不知道和plug gauge 的区别在哪里,知道的请指正)Gauge block 块规Bore gauge 百分表A vernier caliper 游标卡尺Coordinate Measureing Machine(CMM) 三尺元Pressure gague寸压力计电度厚度测试仪(Electroplating THK.Tester)转(扭)力仪(Twisting Meter)螺纹规(Thread Gauge)块规(Block Gauge)环规(Ring Gauge)力矩计(Torque Meter)塞规(Plug gage)高度仪(Altitude gauge)塞尺/间隙规(Clearance gauge)千分卡尺(Micrometer Calipers )“过” -- “不过” 验规(通-止规) [go-no-go gauge]游标卡尺(Vernier Caliper)电子卡尺(Digital caliper)深度千分尺(Depth Micrometer)销(针)规(Pin Gauge)投影仪(Projector )数字高度测量仪(Digital Height Gauge)表面处理测试仪(Surface Finish Tester)内/外径千分尺(Inside/outer Micrometer)洛(威)氏硬度仪[(HRC/HV) Hardness Tester)]温度计(Thermometer)孔规(Bore Gauge)电子称(Electric/digital Balance)三坐标测试仪 (CMM)万用表(Multimeter)1.刀口型直尺:knife straigjht edge2.刀口尺: knife straigjht edge3.三棱尺three edges straigjht edge4.四棱尺four edges straigjht edge5.条式和框式水平仪bar form and square levels6.合像水平仪 imaging level meter7铸铁平板 cast iron surface plate 8.岩石平板 granite surface plate9.铸铁平尺cast iron straigjht edge10.钢平尺和岩石平尺steel and granite straigjht edge11.圆度仪 roundness measuring instrument12.电子水平仪electronic level meter13.表面粗糙度比较样块铸造表面roughness comparison specimens cast surface14.表面粗糙度比较样块磨、车、铣、插及刨加工表面roughness comparisonspecimens-ground,turned,bored,mi lled,shape and planed15.表面粗糙度比较样块电火花加工表面roughness comparison specimens spark-erostion machining surfaces16.表面粗糙度比较样块抛光加工表面roughness comparison specimens pollshed surfaces17.接触式仪器的标称特性18.轮廓profiles19.轨迹轮廓 traced profile20.基准轮廓 reference profile21.总轮廓 total profile22.原始轮廓 primary profile23.残余轮廓residual profile24.触针式仪器stylus instrument25.感应位移数字存储触针式量仪displacement sensitive,digitally storing stylus instrument26.触针式仪器的部件stylus instrument components27.测量环measurement loop28.导向基准renfence guide29.驱动器drive unit30.测头(传感器)probe(pick-up)31.拾取单元tracing element32.针尖stylus tip33.转换器transducer34.放大器amplifier35.模/数转换器analog-to-digital converter36.数据输入data input37.数据输出data output38.轮廓滤波和评定profilefiltering and evaluation39.轮廓记录器profile recorder40.仪器的计量特性metrological characteristics of the instrument41.静测力的变化change of static measuring force 42.静态测力 static measuring force43.动态测量力 dynamic measuring force44.滞后hysteresis45.测头的测量范围 transmission function for the sine waves46.仪器的测量范围measuring range of the instrument47.模数转换器的量化步距quantization step of the ADC48.仪器分辨力 instrument resolution49.量程分辨力比range-to-resolution ratio50.测头线性偏差probe linearity deviation51.短波传输界限short-wave transmission limitation52.轮廓垂直成分传输 vertical profile component transmission53表面粗糙度比较样块抛丸、喷砂加工表面roughness comparison specimens shot blasted and blasted surfaces54产品结构几何量计术规范（GPS）geometrical productspecifications(GPS)55表面结构 surface texture56接触式仪器的标称特性 nominal characteristics of contact instruments57公法线千分尺micrometer for mearsuring root tangent lenghths of gear teeth58最大允许误差 maximum permissible error59圆柱直齿渐开线花键量规 gauges for straight cylindrical involute splines60齿厚游标卡尺 Gear tooth verniercalipers61齿轮渐开线样板the involute master of gear62齿轮螺旋线样板 the helix master of gear63矩形花键量规 gauges for straight –sided splines64测量蜗杆 master worm65万能测齿仪 universal gear measuring instrument66万能渐开线检查仪universal involute measuring instrument67齿轮齿距测量仪gear circular pictch measuring instrument68万能齿轮测量机 Universal gear measuring machine69齿轮螺旋线测量仪gear helix measuring instrument 70便携式齿轮齿距测量仪 manual gear circular pitch measuring instrument71便携式齿轮基节测量仪manual gear base pitch measuring instrument72立式滚刀测量仪vertical hob measuring instrument73齿轮双面啮合综合测量仪Gear dual-flank measuring instrument74齿轮单面啮合整体误差测量仪Gear single-flank meshing integrated error measuring instrument75梯形螺纹量规 gauges for metric trapezoidal screw threads76工作螺纹量规work gauges for metric trapezoidal screw threads77校对螺纹量规check gauges for metric trapezoidal screw threads78.梯形螺纹量规型式与尺寸 Types and dimensions of metric trapezoidal screw threads79.普通螺纹量规型式与尺寸 Types and dimensions of gauges purpose screw threads80.非螺纹密封的管螺纹量规 Gauges for pipe threads prcessure-tight joints are not made on the threads81.螺纹千分尺Screw thread micrometer82.最大允许误差 maximum permissible error83.间隙螺纹量规 Clearance screw gauge84.量针Bar gauge85.螺纹样板 Screw thread template86.用螺纹密封的管螺纹量规Gauges for pipe threads where pressure-tight joints are made on the threads87.刀具预调测量仪? 精度Accuracy of the presetting instrument88.薄膜式气动量仪Membrane type pneumatic measuring instrument89.光栅线位移测量系统Grating linear displacement measuring system90.光栅角位移测量系统Grating angular displacement measuring system91.磁栅线位移测量系统Magnet-grid linear displacement measuring system92.量块附件Accessories for gauge blocks93.V形架Vee blocks94.比较仪座Comparator stand95.磁性表座Magnetic stand96.万能表座Universal stand for dial indicator一般术语：1.几何量 geometrical product2.量值value(of a quantity)3.真值true value(of a quantity)4.约定真值 conventional true value(of a quantity)5.单位unit(of measurement)6.测量measurement7.测试measurement and test8.检验inspecte9.静态测量static measurement10.动态测量dynamic measurement11.测量原理principle of measurement12.测量方法method of measurement13.测量程序measurement procedure14.被测量measurand15.影响量influence quantity16.变换值transformed value(of a measurand)17.测量信号measurement signal18.直接测量法direct method of measurement19.间接测量法indirect method of measurement20.定义测量法definitive method of measurement21.直接比较测量法direct-comparison method of measurement22.替代测量法substitution method of measurement23.微差测量法differential method of measurement24.零位测量法nulll method of measurement25.测量结果result of a measurement26.测得值measured value27.实际值actual value28.未修正结果uncorrected result （of a measurement）29.已修正结果corrected result(ofa measurement)30.测量的准确度accuracy of measurement 31.测量的重复性repeatability of measurement32.测量复现性reproducibility of measurements33.实验标准偏差experimental standard deviation34.测量不确定度uncertainty of measurement35.测量绝对误差 absolute error of measurement36.相对误差 relative error37.随机误差random error38.系统误差 systematic error39.修正值correction40.修正系数correction factor41.人员误差personal error42.环境误差environmental error43.方法误差error of method44.调整误差adjustment error45.读数误差reading error46.视差parallax error47.估读误差 interpolation error48.粗大误差parasitic error49.检定verification50.校准calibration51.调准gauging52.调整adjustment几何量测量器具术语1.几何量具测量器具dimensional measuring instruments2.长度测量器具length measuring instruments3.角度测量器具angle measuring instruments4.坐标测量机coordinate measuring machine5.形状和位置误差测量器具form and position error measuring instruments6.表面质量测量器具surface quality measuring instruments7.齿轮测量器具gear measuring instruments8.实物量具（简称“量具”）material measure9.测量仪器（简称“量仪”）measuring instruments10.测量链measuring chain11.测量装置measuring system12.指示式测量仪器indicating(measuring )instrument13.记录式测量仪器recording （measuring）instrument14.累计式测量仪器totalizing(measuring)instrument 15.积分式测量仪器integrating(measuring)instrument16.模拟式测量仪器analogue(measuring)instrument17.数字式测量仪器digital(measuring)instrument18.测量变换器measuring transducer19.传感器sensor20.指示装置indicating device21.记录装置recording device22.记录载体recording medium23.标尺标记scale mark24.指示器index25.标尺scale26.度盘dail测量器具术语1.标称值nominal value2.示值indication(of a measuring instrument)3.标尺范围scale range4.标称范围nominal range5.标尺长度scale length6.标尺分度scale division7.分度值value of a scale division8.标尺间距scale spacing9.线性标尺linear scale10.非线性标尺non-linear scale11.标尺标数scale numbering12.测量仪器的零位zero of a measuring instrument13.量程span14.测量范围measuring range15.额定工作条件vated operating conditions16.极限条件reference condition17.标准条件reference condition18.仪器常数instrument constant19.响应特性response characteristic20.灵敏度senstivity21.鉴别力discrimination22.分辨力resolution（of an indicating device）23.死区dead band24.准确度accuracy of a measuring instruments25.准确度等级accuracy class26.重复性repeatability of a measuring instrument27.示值变动性varation of indication28.稳定度stability 29.可靠性reliability30.回程hysteresis31.漂移drift32.响应时间response time33.测量力（简称“测力”）measuring force测量器具术语1.实物量具示值误差error of indication of a material measure2.测量仪器示值误差error of indication of a measuring instrument3.重复性误差repeatability error of a measuring instrument4.回程误差hysteresis error5.测量力变化variation of measuring force6.测量力落差hysteresis of measuring force7.偏移误差bias error (of a measuring instrument)8.允许误差maximum permissible errors(of measuring instruments)9.跟踪误差tracking error (of a measuring instrument)10.响应率误差response-law error (of a measuring instrument)11.量化误差quantization error (ofa measuring instrument)12.基值误差datum error (of a measuring instrument)13.零值误差zero error (of a measuring instrument)14.影响误差influence error15.引用误差fiducial error16.位置误差position error17.线性误差linear error18.响应特性曲线response characteristic curve19.误差曲线error curve20.校准曲线calibration curve21.修正曲线correction curve长度测量器具量具类1.量块gauge block2.光滑极限量规plain limit gauge3.塞规plug gauge4.环规ring gauge卡规snap gauge5.塞尺feeler gauge6.钢直尺steel gauge7.精密玻璃线纹尺precision glass linear scale8.精密金属线纹尺precision metal linear scale9.半径样板radius template卡尺类1.游标卡尺vernier caliper2.带表卡尺dial caliper3.电子数显卡尺calliper with electronic digital display4.深度标游卡尺depth vernier caliper5.电子数显深度卡尺depth caliper with electronic digital display6.带表高度卡尺dial height calliper7.高度游标卡尺height vernier caliper8.电子数显高度卡尺height caliper with electronic digital display9.焊接检验尺calliper for welding inspection千分尺类1.测微头micrometer head2.外径千分尺external micrometer3.杠杆千分尺micrometer with dial comparator4.带计数器千分尺micrometer with counter5.电子数显外径千分尺micrometer with electronic digital display6.小测头千分尺small anvil micrometer7.尖头千分尺point micrometer8.板厚千分尺sheet metal micrometer9.壁厚千分尺tube micrometer10.叶片千分尺blade micrometer11.奇数沟千分尺odd fluted micrometer12.深度千分尺depth micrometer13.内径千分尺internal micrometer14.单杆式内径千分尺single-body internal micrometer15.表式内径千分尺 dail internal micrometer16.三爪式内径千分尺three point internal micrometer17.电子数显三爪式内径千分尺three point internal micrometer18.内测千分尺inside micrometer 指示表类1.指示表 dial indicator2.深度指示表depth dial indicator3.杠杆指示表dial test indicator4.内径指示表bore dial indicator5.涨弹簧式指示表 expanding head bore dial indicator6.钢球式内径指示表ball type bore dial indicator7.电子数显指示表dial indicator with electronic digital display8.杠杆卡规indicating snap gauge9.带表卡规dial snap gauge10.带表外卡规outside dial snap gauge11.带表内卡规inside dial snap gauge12.测厚规thickness gauge13.扭簧比较仪microcator14.杠杆齿轮比较仪mechanical dial comparator15.电子量规electronic gauge16.电感式传感器inductance type transducer17.指示装置indicating device18.电感测微仪inductance micrometer19.峰值电感测微仪peak inductance micrometer个20.电感内径比较仪inductance bore comparator21.瞄准传感器aiming transducer页脚内容11。
量具中英文对照资料讲解
量具中英文对照量具 Measuring Tools 计量Gauging卡尺――Caliper 0.02游标卡尺－――Vernier Caliper数显卡尺――Digital Caliper带表卡尺――Digital Slide Caliper CA=Calipers卡尺深度尺――depth gauge 0.02数显深度尺――Digital depth gauge 外径深度尺――depth micrometerDI=Depth Indicator深度测试仪千分尺 micrometer 0.01外径千分尺――external micrometer, 外径千分尺 outside micrometer内径千分尺――Internal micrometer内径千分尺 micrometer inside caliper;inside micrometer 深度千分尺 micrometer depth gauge; depth micrometer卡钳式内径千分尺－Internal quick caliper dial gauge外径千分尺标准棒――micrometer standard外径千分尺架子――micrometer stand带表外径千分尺――Indicator dial micrometer MI=Micrometer千分尺千分表-Dial indicator数显千分表-Digital indicator千分表外径规―――Dial indicator snap gauges平面规 surface gauge磁性吸座－－Magnetic stand孔的轮廓量规－Bore profile gauge KT点接触杠杆千分表 ---Lever dial indicator point contact length可调的磁力架----Magnetic stand with fine adjustment高度尺height gauge 0.02游标高度尺 ---Vernier height gauge数显游标高度尺Digital height gaugeMH=Height tester高度测试仪尺规\刀规－Straight edge板规 plate gauge中心规 centre gauge锥度规 taper gauge比例规 proportional dividers标准规 standard gauge齿轮规 gear tooth gauge分线规 divider;dividers工作量规 working gauge厚薄规 feeler(gauge)角规 angle gauge块规 gauge(block)量规 gauge螺距规 screw pitch gauge螺纹千分尺 screw micrometer内卡钳 inside caliper外卡钳 outside caliper圆规 compasses椭圆规 ellipsograph隙规 gap(/clearance) gauge线规 wire gauge斜角规 bevel square折尺 folding pocket measure(/ruler)曲尺 carpenter’s square钢尺――steel rule刻度尺 graduation ruler丁字尺 T-square三角尺 set square直尺 straight edge皮尺 tape(/measure)卷尺Locking tape measure金属卷尺 metallic tape角尺――angle square组合角尺 combination set花岗岩平台（精度1极）Granite table, accuracy 1装有T型槽的平台-Tenon and T-slot incl. InstallationGage计量器Dial Bore 3 Point Gauge 0.01 三点内径百分表Plug 止通棒Go No/Go Plug PG=pin Gauge针规VISUAL 目测BARE-EYEDial Caliper刻度卡尺Dial Indicator 0.01百分表ID Groove Gage内沟槽尺Thread Gage螺纹止通规Plug Guage塞规TRIMIC三点内测千分尺CMM三坐标检测ROUGHNESS GAGE粗糙度样板R=Rough of surface tester表面粗糙测试仪Profile Projector投影仪PJ=Profile projector侧面投影仪CM=Coordinate measuring machine协调测量机器VM=Vision measuring machine目测机器TM=Tool microscope显微镜EW=Electron Weigh电子称。
常用量具中英文对照.
常用量具中英文对照及检查比例序号量具名(中文)量具名(英文)测量精度车床检查比例FQC检查比例1三座标CMM1pcs/6hours C=0,AQL:0.42数字比较仪DIGITAL COMPARATOR5pcs/2hours C=0,AQL:0.43TESA SCANPLUS TESA2pcs/6hours C=0,3pcs/lot4镭射(LASER MICROMETER)0.25m m5pcs/2 Hours C=0,AQL:0.45基准尺SNAP MICROMETER1m m5pcs/2 Hours C=0,AQL:0.46电子千分尺MICROMETER3m m5pcs/4 Hours C=0,AQL:1.07坑卡BLADE MICROMETER10m m5pcs/4 Hours C=0,AQL:1.08深度表DEPTH GAUGE3m m5pcs/4 Hours&2pcs/6Hours C=0,AQL:1.0&C=0,10pcs/lot 9高度尺HEIGHT GAUGE2m m5pcs/4 Hours C=0,AQL:1.010塞规PIN GAUGE 5pcs/4 Hours C=0,AQL:1.011六角塞规HEX GAUGE5pcs/4 Hours C=0,AQL:1.012气动测位仪 AIR GAUGE0.1/0.2/0.5/1m m5pcs/2 Hours C=0,AQL:0.413内径量表BORE GAUGE10m m5pcs/4 Hours C=0,AQL:1.014内径千分尺INSIDE MICROMETER3m m5pcs/4 Hours C=0,AQL:1.015槽规GAUGE BLOCK5pcs/4 Hours C=0,AQL:1.016内牙规THREAD PLUG GAUGE5pcs/4 Hours C=0,30pcs/lot17外牙规THREAD RING GAUGE5pcs/4 Hours C=0,30pcs/lot18同轴度仪CONCENTRICITY GAUGE1m m5pcs/4 Hours C=0,10pcs/lot19专用治具FIXTURE5pcs/4 Hours C=0,30pcs/lot20圆度仪ROUNDNESS TESTER±0.1m m1pcs/6hours C=0,3pcs/lot21投影PROJECTOR15m m2pcs/6hours&1pcs/12hours C=0,3pcs/lot22锯开投影PROJECTOR(CUTTING)1pcs/12hours-23轮廓仪CONTRACER±0.1m m1pcs/12hours-24锯开轮廓仪CONTRACER(CUTTING)1pcs/12hours-25光洁度仪SURFACE ROUGHESS±0.1m m2pcs/6hours&1pcs/6hours C=0,3pcs/lot26工具显微镜MICROSCOPE1pcs/6hours主要测量部位三座标主要用于测量那些体积较大而形状又不规则的零件.只要是用离散性取点来组成线,面(包括曲面),所以只要是可以用点,线,面关联起来的尺寸基本都可以量数字比较仪测量原理与量基准尺一样,不同的是它除了量外径之外还可以测深度,两者都需要与被测尺寸相接近的基准做比较,且基准越接近被测尺寸越好.当然所有测量还得在外径/外牙牙中径和牙底径外径(公差小于等于0.002)外径(公差0.002~0.005)外径(公差大于0.005)外径(槽宽0.7~3.0之间的外径)深度(0~25之间)深度(25以上)内孔(不用做CPK)六角内孔内孔(要做CPK,且公差比较小)内孔(要做CPK)内孔(要做CPK)槽宽内牙外牙h j r bc所有形位公差都可用圆度仪内倒角/公差小的外倒角/孔内无法测量的用轮廓仪测不到的光洁度Ra,Rz,Ry量还得在量具测量量程之内方可.。
量具检具英文对照
51 调准 gauging52 调整 adjustment量"具"类1.量块gauge block2.光滑极限量规plain limit gauge3.塞规plug gauge4.环规ring gauge卡规snap gauge5.塞尺feeler gauge6.钢直尺steel gauge7.精密玻璃线纹尺precision glass linear scale8.精密金属线纹尺precision metal linear scale9.半径样板radius template卡尺类1.游标卡尺vernier caliper2.带表卡尺dial caliper3.电子数显卡尺calliper with electronic digital display4.深度标游卡尺depth vernier caliper5.电子数显深度卡尺depth caliper with electronic digital display6.带表高度卡尺dial height calliper7.高度游标卡尺height vernier caliper8.电子数显高度卡尺height caliper with electronic digital display9.焊接检验尺calliper for welding inspection千分尺类1.测微头micrometer head2.外径千分尺external micrometer3.杠杆千分尺micrometer with dial comparator4.带计数器千分尺micrometer with counter5.电子数显外径千分尺micrometer with electronic digital display6.小测头千分尺small anvil micrometer7.尖头千分尺point micrometer8.板厚千分尺sheet metal micrometer9.壁厚千分尺tube micrometer10.叶片千分尺blade micrometer11.奇数沟千分尺odd fluted micrometer12.深度千分尺depth micrometer13.内径千分尺internal micrometer14.单杆式内径千分尺single-body internal micrometer15.表式内径千分尺 dail internal micrometer16.三爪式内径千分尺three point internal micrometer17.电子数显三爪式内径千分尺three point internal micrometer18.内测千分尺inside micrometer指示表类1.指示表 dial indicator2.深度指示表depth dial indicator3.杠杆指示表dial test indicator4.内径指示表bore dial indicator5.涨弹簧式指示表 expanding head bore dial indicator6.钢球式内径指示表ball type bore dial indicator7.电子数显指示表dial indicator with electronic digital display8.杠杆卡规indicating snap gauge9.带表卡规dial snap gauge10.带表外卡规outside dial snap gauge11.带表内卡规inside dial snap gauge12.测厚规thickness gauge13.扭簧比较仪microcator14.杠杆齿轮比较仪mechanical dial comparator15.电子量规electronic gauge16.电感式传感器inductance type transducer17.指示装置indicating device18.电感测微仪inductance micrometer19.峰值电感测微仪peak inductance micrometer20.电感内径比较仪inductance bore comparator21.瞄准传感器aiming transducer角度测量器具1.角度块angle block gauge2.正多面棱体regular polygon mirror3.刀具角度样板cutter angular template4.直角尺square5.平行直角尺parallel square6.宽座直角尺wide-stand square7.刀口形直角尺edge square8.矩形直角尺square square9.三角形直角尺three angle square10.圆柱直角尺cylinder square11.方形角尺square guage12.万能角度尺universal bevel protractor13.游标式万能角度尺vernier universal bevel protractor14.表式万能角度尺dial universal bevel protractor15.光学分度头optical dividing head16.目镜式光学分度头optical dividing head with microscope reading17.投影式光学分度尺optical dividing head with projection reading18.光电分度头optical-electronic dividing head19.多齿分度台multi-tooth division table20.分度转台division rotary table21.正炫规sine bar22.普通正炫规general sine bar23.铰链式正炫规hinge type sine bar24.双向正炫规dual-directional sine bar25.圆锥量规cone gauge26.圆锥塞规plug cone gauge27.圆锥环规ring cone gauge28.直角尺测量仪square measuring instrument形位误差测量器具1.平晶optical flat2.单面平晶optical flat3.双面平晶parallel optical flat4.刀口形直尺knife straight edge5.刀口尺knife straight edge6.三棱尺three edges straight edge7.四棱尺four edges straight edge8.平尺straight edge9.矩形平尺square straight edge10.工字形平尺i-beam straight edge11.角形平尺angle straight edge12.桥形平尺bridge type straight edge13.平板surface plate14.铸铁平板cast iron surface plate15.岩石平板granite surface plate16.方箱square box17.水准器式水平仪level meter18.条式水平仪bar level meter19.框式水平仪frame level meter20.合像水平仪imaging level meter21.光学倾斜仪optical inclinometer22.电子水平仪electronic level meter23.指针式电子水平仪electronic level meter with indicator24.数显式电子水平仪electronic level meter with digital display25.平直度测量仪straightness measuring instrument26.光学式平直度测量仪optical straightness measuring instrument27.光电式平直度测量仪photoelectrical straightness measuring instrument28.圆度测量仪roundness measuring instrument29.转轴式圆度测量仪spindle-rotating type roundness measuring instrument30.转台式圆度测量仪table-rotating type roundness measuring instrument表面质量测量器具表面粗糙度比较样块surface roughness comparison specimen铸造表面粗糙度比较样块surface roughness comparison specimen for cast surface磨、车、镗、铣、插及刨加工表面粗糙度比较样块surface roughness comparison specimen for ground,turned,bored,milled,shaped and planed surface电火花加工表面粗糙度比较样块surface roughness comparison specimen for spark-erosion machined surface抛（喷）丸、喷砂加工表面粗糙度比较样块surface roughness comparison specimen for shot blasted and grit blasted surface抛光加工表面粗糙度测量仪portable surface roughness comparison specimen for polished surface 便携式表面粗糙度测量仪portable surface roughess measuring instrument驱动箱driving box台式表面粗糙度测量仪bench type surface roughness measuring instrumentNose bridge 鼻中 Tip 脚套Temple 脚丝 Plating 电镀Printing 印字 Lase 镭射Spectacle frames 眼镜架 Sunglasses 太阳眼镜Sports spectacles 运动眼镜 kid's eyewear 儿童眼镜Reading glasses 老花镜 Contact lens 隐形眼镜Glass optical lenses 玻璃镜片 Plastic optical lenses 塑胶镜片Sunglasses lenses, sun clips 太阳镜片、镜夹 Progressive lenses 渐进多焦点镜片 Photochromic lenses 变色镜片 Othro k lenses 角膜矫形接确镜片Optical blanks 镜片毛胚 Accessories for contact lens 隐形眼镜附件Spectacle spare parts and accessories 眼镜零件及配件 Components of frames 镜架组件 Spectacle cases & accessories 眼镜盒及附件 Eyecare products and solution for lenses and contace lenses 眼睛护理产品及隐形眼镜洁液Spectacle cases & accessories 眼镜盒及其它配件 Lens demisting cloths and solutions 镜片除雾喷剂及清洁布Spectacle assembling & adjusting tools 眼镜加工、装配、调较工具 Visual test equipment 验眼设备Edger 磨边机 Eyeglasses and frame making machinery 眼镜架制造机械Lens manufacturing and processing machinery 镜片造机械及加工机械 Contact lens processing machinery 隐形眼镜加工机械Lathe 车床 Coating machine 镀膜机Coating materials 镀膜原料 Electroplating equipment, welding machine 电镀机械、焊接机械 Price labeling, stamp printing and screen printing mahcinery 标签机、移印机、丝网印刷 Ultrasonic cleaning equipment 超声波清洁仪器Ophthalmic products 眼科用品 Concentrates for ultrasonic cleaning 超声波清洁剂Lens grinding and polishing filtration systems 镜片研磨及抛光过滤系统 Optical processing equipmentand materials 光学加工设备及原料Measurement instrucments for optical elements and systems 光学用品及系统之测量仪器 Store and workshop fitting and furniture 眼镜店及工场设备及家具Moulds for ophthalmic lenses 镜片模具 Raw materials for frames 眼镜原料Raw materials for lenses 镜片原料 Lens abrasive and polishing materials 打磨镜片原料 Electroplating, welding materials 电镀、焊接原材料 Opto-laser equipment and instruments 激光科技设备和仪器机械英语单词冲床punching machine机械手robot油压机hydraulic machine车床 lathe刨床planer |'plein?|铣床miller磨床grinder（钻床）driller线切割linear cutting金属切削 metal cutting机床 machine tool金属工艺学 technology of metals 刀具 cutter摩擦 friction联结 link传动 drive/transmission轴 shaft弹性 elasticity频率特性 frequency characteristic 误差 error响应 response定位 allocation机床夹具 jig动力学 dynamic运动学 kinematic静力学 static分析力学 analyse mechanics拉伸 pulling压缩 hitting剪切 shear扭转 twist弯曲应力 bending stress强度 intensity三相交流电 three-phase AC磁路 magnetic circles 变压器 transformer异步电动机 asynchronous motor几何形状 geometrical精度 precision正弦形的 sinusoid交流电路 AC circuit机械加工余量 machining allowance变形力 deforming force变形 deformation应力 stress硬度 rigidity热处理 heat treatment退火 anneal正火 normalizing脱碳 decarburization渗碳 carburization电路 circuit半导体元件 semiconductor element反馈 feedback发生器 generator直流电源 DC electrical source门电路 gate circuit逻辑代数 logic algebra外圆磨削 external grinding内圆磨削 internal grinding平面磨削 plane grinding变速箱 gearbox离合器 clutch绞孔 fraising绞刀 reamer螺纹加工 thread processing螺钉 screw铣削 mill铣刀 milling cutter功率 power工件 workpiece齿轮加工 gear mechining齿轮 gear主运动 main movement主运动方向 direction of main movement进给方向 direction of feed进给运动 feed movement合成进给运动 resultant movement of feed合成切削运动 resultant movement of cutting合成切削运动方向 direction of resultant movement of cutting 切削深度 cutting depth前刀面 rake face刀尖 nose of tool前角 rake angle后角 clearance angle龙门刨削 planing主轴 spindle主轴箱 headstock卡盘 chuck加工中心 machining center车刀 lathe tool车床 lathe钻削 镗削 bore车削 turning磨床 grinder基准 benchmark钳工 locksmith锻 forge压模 stamping焊 weld拉床 broaching machine拉孔 broaching装配 assembling铸造 found流体动力学 fluid dynamics流体力学 fluid mechanics加工 machining液压 hydraulic pressure切线 tangent机电一体化 mechanotronics mechanical-electrical integration 气压 air pressure pneumatic pressure稳定性 stability介质 medium液压驱动泵 fluid clutch液压泵 hydraulic pump阀门 valve失效 invalidation强度 intensity载荷 load应力 stress安全系数 safty factor可靠性 reliability螺纹 thread螺旋 helix键 spline销 pin滚动轴承 rolling bearing滑动轴承 sliding bearing弹簧 spring制动器 arrester brake十字结联轴节 crosshead联轴器 coupling链 chain皮带 strap精加工 finish machining粗加工 rough machining变速箱体 gearbox casing腐蚀 rust氧化 oxidation磨损 wear耐用度 durability随机信号 random signal离散信号 discrete signal超声传感器 ultrasonic sensor集成电路 integrate circuit挡板 orifice plate残余应力 residual stress套筒 sleeve扭力 torsion冷加工 cold machining电动机 electromotor汽缸 cylinder过盈配合 interference fit热加工 hotwork摄像头 CCD camera倒角 rounding chamfer优化设计 optimal design工业造型设计 industrial moulding design有限元 finite element滚齿 hobbing插齿 gear shaping伺服电机 actuating motor铣床 milling machine钻床 drill machine镗床 boring machine步进电机 stepper motor丝杠 screw rod导轨 lead rail组件 subassembly可编程序逻辑控制器 Programmable Logic Controller PLC 电火花加工 electric spark machining电火花线切割加工 electrical discharge wire - cutting 相图 phase diagram热处理 heat treatment固态相变 solid state phase changes有色金属 nonferrous metal陶瓷 ceramics合成纤维 synthetic fibre电化学腐蚀 electrochemical corrosion车架 automotive chassis悬架 suspension转向器 redirector变速器 speed changer板料冲压 sheet metal parts孔加工 spot facing machining车间 workshop工程技术人员 engineer气动夹紧 pneuma lock数学模型 mathematical model画法几何 descriptive geometry机械制图 Mechanical drawing投影 projection视图 view剖视图 profile chart标准件 standard component零件图 part drawing装配图 assembly drawing尺寸标注 size marking技术要求 technical requirements刚度 rigidity内力 internal force位移 displacement截面 section疲劳极限 fatigue limit断裂 fracture塑性变形 plastic distortion脆性材料 brittleness material刚度准则 rigidity criterion垫圈 washer垫片 spacer直齿圆柱齿轮 straight toothed spur gear 斜齿圆柱齿轮 helical-spur gear直齿锥齿轮 straight bevel gear运动简图 kinematic sketch齿轮齿条 pinion and rack蜗杆蜗轮 worm and worm gear虚约束 passive constraint曲柄 crank摇杆 racker凸轮 cams范成法 generation method毛坯 rough游标卡尺 slide caliper千分尺 micrometer calipers攻丝 tap光学仪器类 △Topslit illumination 裂隙灯 diopter 屈光度 sphere 球镜cylinder 柱镜 prism 棱镜 magnification 放大倍率diameter 直径 dimensions 尺寸 light spot 光斑fixation lamp 固视灯 led 发光二极管 filter 滤色片lensmeter 焦度计 metal rim 金属圈 PD meter 瞳距仪Pupil Distance 瞳距 Vertex Distance 顶点距 Chart 视标View tester 验光仪 Cutting device 切割刀 Pattern maker 制模机Cutting needle 划针 Layout blocker 中心仪 Hand edger 手动磨边机Lens groover 开槽机 Polisher 抛光机 Polishing stick 抛光膏Drilling machine 钻孔机 Bench drilling machine 台式钻孔机 Drill bit 钻头Lock opener 锁开 Milling cutting 铣刀 Fuse 保险丝Handle 手柄 Center locator 中心定位器 Drill chuck 钻夹头Dial 刻度盘 Frame heater（warmer） 烘架机 Heating coil 发热丝Ultrasonic cleaner 清洗机 Combined table 验光组合台 Optometry box 验光盘Grinding wheel 砂轮 Trial lens set 验光镜片箱 Refractometer 验光仪Chart projector 投影仪 Keratometer 角膜曲率仪 Welding machine 焊接机Spray cleaning machine 喷淋清洗机材料配件类 △TopMonel 锰料 Stainless Steel 不锈钢 pure Titanium 纯钛Titanium Alloy 钛合金 B-Ti B钛 Elongation 伸长率Tensile strenghth 抗拉强度 high nickel copper alloy 高镍合金 nickelfree alloy 无镍合金 nicklfree stainless steel 无镍不锈钢 annealing temperture 退火温度 percent 含量 density 密度 melting point 熔点 solidus 固相点liquidus 液相点 physical properties 物理性能 chemical composition 化学组成hinge 铰链 rim wire 框线 round wire 圆线cylinding grinding wheels 筒形砂轮 flaring cup wheels 碗形砂轮 diamod plain wheels 平形砂轮 grinding ccoolant 切削液 lens coating liquid 护镜液 polishing powder 抛光粉polishing liquid 抛光液 polishing wheel 抛光轮 plating case 电镀盒plastic case 塑料盒 alumium oxide case 氧化铝盒 rocket screwdrivers 六角螺丝刀mini ring wrenches/nutdrivers 微型戒指扳手 radian apparatus 弧度表 thickness apparatus 厚度表 adhesive tape 粘片 calipers 量具 nut driver 套筒files set 锉刀 drill bits 钻咀 screwdrivers blades 螺丝刀头镜片类 △Tophard resin lens 树脂镜片 round-top bifocal lens 圆顶双关镜片 flat-top bifocal lens 平顶双光镜片aspheric hard resin lens 非球面树脂镜片 Non-coated lens 基片 （NC） hard coated lens 加硬镜片 （HC）Hard & Multi-coated 加硬加膜片 （HMC） Hard & Multi-coated,EMI Defending Coating 加硬加膜防辐射片（HMC+EMI） RX Lens-High Index 高散光片color shade 色差 deformation 变形 shrinkage 缩水light transmission 透光率 de-lamination 分裂脱层 abbe value 阿贝数raw material 原材料 catalysis 催化作用 polymerization 聚合作用tinted lens 染色镜片 photochromic lens 变色镜片 spherical 球面的autocollimator 自动准直机bench comparator 比长仪block gauge 块规bore check 精密小测定器calibration 校准caliper gauge 卡规check gauge 校对规clearance gauge 间隙规clinoretee 测斜仪comparator 比测仪cylinder square 圆筒直尺depth gauge 测深规dial indicator 针盘指示表dial snap gauge 卡规digital micrometer 数位式测微计feeler gauge 测隙规gauge plate 量规定位板height gauge 测高规inside calipers 内卡钳inside micrometer 内分测微计interferometer 干涉仪leveling block 平台limit gauge 限规micrometer 测微计mil 千分之一寸monometer 压力计morse taper gauge 莫氏锥度量规nonius 游标卡尺optical flat 光学平晶optical parallel 光学平行passimeter 内径仪position scale 位置刻度profile projector 轮廓光学投影仪protractor 分角器radius 半径ring gauge 环规sine bar 正弦量规snap gauge 卡模square master 直角尺stylus 触针telescopic gauge 伸缩性量规working gauge 工作量规。
各种量具中英文简写对照表
中文
材质 外观 外径 内径 直径 半径 宽度 长度 深度 高度 螺纹 角度 沟 沟宽 沟径 沟位置 倒角 圆角 面粗度 同轴度 平行度 直线度 垂直度 圆度 平面度 位置度 跳动度 对称度 距离 技术要求 钝化 镀镍 镀铬
塞尺
英文
material appearance out diameter inside diameter diameter radius width length depth height thread angle groove groove wide groove diameter groove position chamfer fillet surface roughness concentricity parallelism straightness perpendicularity roundness flatness position runout symmetry distance Note passivation nickle plating chrome plating feeler gauge
英文
英文简写
VIS C. H.C Cen.L.C OFF.C MIC. B.MIC I. MIC O.MIC G.T.MIC GRO.M D.T.IND. D.D.IND S.P.G S.R.G P.G S.P.GUGE C-G R-G ANG.G B.G S.G CER.B D.C.G THR.W V-B CMM L.H.G R.T SUR.T MIC.S D.H.G ANOD. d.c.g
英文简写
M APP O.D I.D D. R. W. L. DEP. H. THR ANG. GRO. G.W G.D G.P C FIL Surf. R. CON PAR STR PER ROU FLA POS RUN SYM DIS. NOTE PAS. NIC. CHR.P 目视
量具量仪中英文对照汇总
量具量仪中英文对照汇总（很齐全）2.刀口尺: knife straight [streɪt] edge[edʒ]7铸铁平板cast iron surface plate[pleɪt]8.岩石平板granite['grænɪt] surface plate9.铸铁平尺cast iron straight edge18.轮廓profiles['prəʊfaɪl]19.轨迹轮廓traced[treɪs] profile20.基准轮廓reference profile21.总轮廓total profile22.原始轮廓primary profile30.测头(传感器)probe[prəʊb] (pick-up)31.拾取单元tracing element32.针尖stylus['staɪləs] tip82.最大允许误差maximum permissible[pə'mɪsɪb(ə)l] error83.间隙螺纹量规Clearance screw gauge95.磁性表座Magnetic[mæg'netɪk]；有磁性的stand96.万能表座Universal[juːnɪ'vɜːs(ə)l]普遍的stand for dial ['daɪəl]indicator['ɪndɪkeɪtə]指示器一般术语：1. 几何量geometrical[dʒɪə'metrɪkl] product2. 量值value(of a quantity['kwɒntɪtɪ量])3. 真值true value(of a quantity)5. 单位unit(of measurement)6. 测量measurement7. 测试measurement and test8. 检验inspect9. 静态测量static['stætɪk] measurement10. 动态测量dynamic[daɪ'næmɪk] measurement11. 测量原理principle ['prɪnsɪp(ə)l]of measurement12. 测量方法method of measurement13. 测量程序measurement procedure[prə'siːdʒə]程序14. 被测量measurand18. 直接测量法direct method of measurement19. 间接测量法indirect method of measurement25. 测量结果result of a measurement26. 测得值measured value27. 实际值actual value30. 测量的准确度accuracy['ækjʊrəsɪ] of measurement31. 测量的重复性repeatability [ri'pi:tə'biliti]of measurement32. 测量复现性reproducibility [riprə,dju:sə'biliti]of measurements33. 实验标准偏差experimental[ɪk,sperɪ'ment(ə)l; ek-] standard deviation49. 检定verification[,verɪfɪ'keɪʃ(ə)n]50. 校准calibration[kælɪ'breɪʃ(ə)n]52. 调整adjustment测量器具术语1. 标称值nominal ['nɒmɪn(ə)l]名义上的value2. 示值indication[ɪndɪ'keɪʃ(ə)n]指示(of a measuring instrument['ɪnstrʊm(ə)nt])仪器3. 标尺范围scale[skeɪl] range4. 标称范围nominal range5. 标尺长度scale length6. 标尺分度scale division7. 分度值value of a scale division13. 量程span14. 测量范围measuring range20. 灵敏度senstivity21. 鉴别力discrimination22. 分辨力resolution[rezə'luːʃ(ə)n]（of an indicating device）23. 死区dead band24. 准确度accuracy of a measuring instruments28. 稳定度stability29. 可靠性reliability长度测量器具量具类1. 量块gauge block2. 光滑极限量规plain[pleɪn][pleɪn]limit gauge3. 塞规plug[plʌg]插头gauge4. 环规ring gauge卡规snap[snæp] gauge5. 塞尺feeler['fiːlə] gauge6. 钢直尺steel gauge9. 半径样板radius template卡尺类1. 游标卡尺vernier['vɜːnɪə] caliper['kælɪpə]卡尺2. 带表卡尺dial['daɪəl] caliper3. 电子数显卡尺calliper with electronic digital display数字显示4. 深度标游卡尺depth[depθ] vernier caliper5. 电子数显深度卡尺depth caliper with electronic digital display6. 带表高度卡尺dial height calliper7. 高度游标卡尺height vernier caliper8. 电子数显高度卡尺height caliper with electronic digital display 千分尺类2. 外径千分尺external micrometer[maɪ'krɒmɪtə]千分尺3. 杠杆千分尺micrometer with dial comparator4. 带计数器千分尺micrometer with counter5. 电子数显外径千分尺micrometer with electronic digital display12. 深度千分尺depth micrometer13. 内径千分尺internal micrometer16. 三爪式内径千分尺three point internal micrometer17. 电子数显三爪式内径千分尺three point internal micrometer18. 内测千分尺inside micrometer指示表类1. 指示表dial indicator14. 表式万能角度尺dial universal bevel protractor15. 光学分度头optical dividing head16. 目镜式光学分度头optical dividing head with microscope reading17. 投影式光学分度尺optical dividing head with projection reading18. 光电分度头optical-electronic dividing head19. 多齿分度台multi-tooth division table20. 分度转台division rotary table21. 正炫规sine bar22. 普通正炫规general sine bar23. 铰链式正炫规hinge type sine bar24. 双向正炫规dual-directional sine bar25. 圆锥量规cone gauge26. 圆锥塞规plug cone gauge27. 圆锥环规ring cone gauge28. 直角尺测量仪square measuring instrument表面质量测量器具表面粗糙度比较样块surface roughness comparison[kəm'pærɪs(ə)n] specimen['spesɪmɪn]。
计量器具中英文对照
1. 量块gaugeblock2. 光滑极限量规plainlimit gauge3. 塞规pluggauge4. 环规ringgauge卡规snap gauge5. 塞尺feelergauge6. 钢直尺steelgauge7. 精密玻璃线纹尺precision glass linear scale8. 精密金属线纹尺precision metal linear scale9. 半径样板radiustemplate卡尺类1. 游标卡尺verniercaliper2. 带表卡尺dialcaliper3. 电子数显卡尺calliperwith electronic digital display4. 深度标游卡尺depthvernier caliper5. 电子数显深度卡尺depthcaliper with electronic digital display6. 带表高度卡尺dialheight calliper7. 高度游标卡尺heightvernier caliper8. 电子数显高度卡尺heightcaliper with electronic digital9. 焊接检验尺calliperfor welding inspection千分尺类1. 测微头micrometerhead2. 外径千分尺externalmicrometer3. 杠杆千分尺micrometer with dial comparator4. 带计数器千分尺micrometer with counter5. 电子数显外径千分尺micrometer with electronic digital display6. 小测头千分尺smallanvil micrometer7. 尖头千分尺pointmicrometer8. 板厚千分尺sheetmetal micrometer9. 壁厚千分尺tubemicrometer10. 叶片千分尺blademicrometer11. 奇数沟千分尺oddfluted micrometer12. 深度千分尺depthmicrometer13. 内径千分尺internalmicrometer14. 单杆式内径千分尺single-body internal micrometer15. 表式内径千分尺dailinternal micrometer16. 三爪式内径千分尺threepoint internal micrometer17. 电子数显三爪式内径千分尺three point internal micrometer18. 内测千分尺insidemicrometer指示表类1. 指示表dialindicator2. 深度只是表depthdialindicator3. 杠杆指示表dialtestindicator4. 内径指示表boredialindicator5. 涨弹簧式指示表expanding head bore dial indicator6. 钢球式内径指示表balltype bore dial indicator7. 电子数显指示表dialindicator with electronic digital display8. 杠杆卡规indicatingsnap gauge9. 带表卡规dialsnapgauge10. 带表外卡规outsidedial snap gauge11. 带表内卡规insidedial snap gauge12. 测厚规thicknessgauge13. 扭簧比较仪microcator14. 杠杆齿轮比较仪mechanical dial comparator15. 电子量规electronicgauge16. 电感式传感器inductance type transducer17. 指示装置indicatingdevice18. 电感测微仪inductance micrometer19. 峰值电感测微仪peakinductance micrometer20. 电感内径比较仪inductance bore comparator21. 瞄准传感器aimingtransducer角度测量器具1. 角度块angleblockgauge2. 正多面棱体regularpolygon mirror3. 刀具角度样板cutterangular template4. 直角尺square5. 平行直角尺parallelsquare6. 宽座直角尺wide-stand square7. 刀口形直角尺edgesquare8. 矩形直角尺squaresquare9. 三角形直角尺threeangle square10. 圆柱直角尺cylindersquare11. 方形角尺squareguage12. 万能角度尺universalbevel protractor13. 游标式万能角度尺vernier universal bevel protractor14. 表式万能角度尺dialuniversal bevel protractor15. 光学分度头opticaldividing head16. 目镜式光学分度头optical dividing head with microscope reading17. 投影式光学分度尺optical dividing head with projection reading18. 光电分度头optical-electronic dividing head19. 多齿分度台multi-tooth division table20. 分度转台divisionrotary table21. 正炫规sinebar22. 普通正炫规generalsine bar23. 铰链式正炫规hingetype sine bar24. 双向正炫规dual-directional sine bar25. 圆锥量规conegauge26. 圆锥塞规plugconegauge27. 圆锥环规ringconegauge28. 直角尺测量仪squaremeasuring instrument 计量器具中英文对照汇总表-形位误差测量器具1. 平晶opticalflat2. 单面平晶opticalflat3. 双面平晶paralleloptical flat4. 刀口形直尺knifestraight edge5. 刀口尺knifestraight edge6. 三棱尺threeedgesstraight edge7. 四棱尺fouredgesstraight edge8. 平尺straightedge9. 矩形平尺squarestraight edge10. 工字形平尺i-beamstraight edge11. 角形平尺anglestraight edge12. 桥形平尺bridgetypestraight edge13. 平板surfaceplate14. 铸铁平板castironsurface plate15. 岩石平板granitesurface plate16. 方箱squarebox17. 水准器式水平仪levelmeter18. 条式水平仪barlevelmeter19. 框式水平仪framelevel meter20. 合像水平仪imaginglevel meter21. 光学倾斜仪opticalinclinometer22. 电子水平仪electronic level meter23. 指针式电子水平仪electronic level meter with indicator24. 数显式电子水平仪electronic level meter with digital display25. 平直度测量仪straightness measuring instrument26. 光学式平直度测量仪optical straightness measuring instrument27. 光电式平直度测量仪photoelectrical straightnessmeasuringinstrument28. 圆度测量仪roundnessmeasuring instrument29. 转轴式圆度测量仪spindle-rotating type roundnessmeasuringinstrument30. 转台式圆度测量仪table-rotating type roundnessmeasuringinstrument计量器具中英文对照汇总表1.刀口型直尺:knifestraigjht edge2.刀口尺: knife straigjht edge3.三棱尺three edges straigjht edge4.四棱尺four edges straigjht edge5.条式和框式水平仪bar form and square levels6.合像水平仪imaging level meter7铸铁平板cast iron surface plate8.岩石平板granite surface plate9.铸铁平尺cast iron straigjht edge10.钢平尺和岩石平尺steel and granite straigjht edge11.圆度仪roundness measuring instrument12.电子水平仪electronic level meter13.表面粗糙度比较样块铸造表面roughness comparison specimens castsurf ace14.表面粗糙度比较样块磨、车、铣、插及刨加工表面roughness comparison specimens-ground,turned,bored,milled,shapeandpla ned15.表面粗糙度比较样块电火花加工表面roughness comparison specimens spark-erostion machiningsurfaces16.表面粗糙度比较样块抛光加工表面roughness comparison specimens pollshed surfaces17.接触式仪器的标称特性18.轮廓profiles19.轨迹轮廓traced profile20.基准轮廓reference profile21.总轮廓total profile22.原始轮廓primary profile23.残余轮廓residual profile24.触针式仪器stylus instrument25.感应位移数字存储触针式量仪displacement sensitive,digitally storin gstylusinstrument26.触针式仪器的部件stylus instrument components27.测量环measurement loop28.导向基准renfence guide29.驱动器drive unit30.测头(传感器)probe(pick-up)31.拾取单元tracing element32.针尖stylus tip33.转换器transducer34.放大器amplifier35.模/数转换器analog-to-digital converter36.数据输入data input37.数据输出data output38.轮廓滤波和评定profile filtering and evaluation39.轮廓记录器profile recorder40.仪器的计量特性metrological characteristics of the instrument41.静测力的变化change of static measuring force42.静态测力static measuring force43.动态测量力dynamic measuring force44.滞后hysteresis45.测头的测量范围transmission function for the sine waves46.仪器的测量范围measuring range of the instrument47.模数转换器的量化步距quantization step of the ADC48.仪器分辨力instrument resolution49.量程分辨力比range-to-resolution ratio50.测头线性偏差probe linearity deviation51.短波传输界限short-wave transmission limitation52.轮廓垂直成分传输vertical profile component transmission53表面粗糙度比较样块抛丸、喷砂加工表面roughness comparison specimens shot blasted and blastedsurfaces54产品结构几何量计术规范（GPS）geometricalproduct specifications(GPS) 55表面结构surface texture56接触式仪器的标称特性nominal characteristics of contact instruments 57公法线千分尺micrometer for mearsuring root tangent lenghths of gear teeth58最大允许误差maximum permissible error59圆柱直齿渐开线花键量规gauges for straight cylindricalinvolute splines60齿厚游标卡尺Gear tooth verniercalipers61齿轮渐开线样板the involute master of gear62齿轮螺旋线样板the helix master of gear63矩形花键量规gauges for straight –sided splines64测量蜗杆master worm65万能测齿仪universal gear measuring instrument66万能渐开线检查仪universal involute measuring instrument67齿轮齿距测量仪gear circular pictch measuring instrument68万能齿轮测量机Universal gear measuring machine69齿轮螺旋线测量仪gear helix measuring instrument70便携式齿轮齿距测量仪manual gear circular pitch measuring instrument 71便携式齿轮基节测量仪manual gear base pitch measuring instrument72立式滚刀测量仪vertical hob measuring instrument73齿轮双面啮合综合测量仪Gear dual-flank measuring instrument74齿轮单面啮合整体误差测量仪Gear single-flank meshing integratederrormeasuring instrument75梯形螺纹量规gauges for metric trapezoidal screw threads76工作螺纹量规work gauges for metric trapezoidal screw threads77校对螺纹量规check gauges for metric trapezoidal screw threads78.梯形螺纹量规型式与尺寸Types and dimensions of metric trapezoidalscrewthreads79.普通螺纹量规型式与尺寸Types and dimensions of gauges purposescrewthreads80.非螺纹密封的管螺纹量规Gauges for pipe threadsprcessure-tight joints arenot made on the threads81.螺纹千分尺Screw thread micrometer82.最大允许误差maximum permissible error83.间隙螺纹量规Clearance screw gauge84.量针Bar gauge85.螺纹样板Screw thread template86.用螺纹密封的管螺纹量规Gauges for pipe threads where pressure-tight joints are made onthethreads 87.刀具预调测量仪精度Accuracy of the presetting instrument88.薄膜式气动量仪Membrane type pneumatic measuring instrument89.光栅线位移测量系统Grating linear displacement measuring system90.光栅角位移测量系统Grating angular displacement measuring system91.磁栅线位移测量系统Magnet-grid linear displacement measuring system92.量块附件Accessories for gauge blocks93.V形架Vee blocks94.比较仪座Comparator stand95.磁性表座Magnetic stand96.万能表座Universal stand for dial indicator计量器具中英文对照汇总表一般术语：1. 几何测量geometrical product2. 量值value(ofaquantity)3. 真值truevalue(ofa quantity)4. 约定真值conventional true value(of aquantity)5. 单位unit(ofmeasurement)6. 测量measurement7. 测试measurementand test8. 检验inspecte9. 静态测量staticmeasurement10. 动态测量dynamicmeasurement11. 测量原理principleof measurement12. 测量方法methodofmeasurement13. 测量程序measurement procedure14. 被测量measurand15. 影响量influencequantity16. 变换值transformedvalue(of a measurand)17. 测量信号measurement signal18. 直接测量法directmethod of measurement19. 间接测量法indirectmethod of measurement20. 定义测量法definitive method of measurement21. 直接比较测量法direct-comparison method of measurement22. 替代测量法substitution method of measurement23. 微差测量法differential method of measurement24. 零位测量法nulllmethod of measurement25. 测量结果result ofameasurement26. 测得值measuredvalue27. 实际值actualvalue28. 未修正结果uncorrected result（ofameasurement）29. 已修正结果correctedresult(of a measurement)30. 测量的准确度accuracyof measurement31. 测量的重复性repeatability of measurement32. 测量复现性reproducibility of measurements33. 实验标准偏差experimental standard deviation34. 测量不确定度uncertainty of measurement35. 测量绝对误差absoluteerror of measurement36. 相对误差relativeerror37. 随机误差randomerror38. 系统误差systematicerror39. 修正值correction40. 修正系数correctionfactor41. 人员误差personalerror42. 环境误差environmental error43. 方法误差errorofmethod44. 调整误差adjustmenterror45. 读数误差readingerror46. 视差parallaxerror47. 估读误差interpolation error48. 粗大误差parasiticerror49. 检定verification50. 校准calibration51. 调准gauging52. 调整adjustment计量器具中英文对照汇总表-几何量测量器具术语1. 几何量具测量器具dimensional measuring instruments2. 长度测量器具lengthmeasuring instruments3. 角度测量器具anglemeasuring instruments4. 坐标测量机coordinate measuring machine5. 形状和位置误差测量器具form and position error measuring instruments6. 表面质量测量器具surface quality measuring instruments7. 齿轮测量器具gearmeasuring instruments8. 实物量具（简称“量具”）materialmeasure9. 测量仪器（简称“量仪”）measuringinstruments10. 测量链measuringchain11. 测量装置measuringsystem12. 指示式测量仪器indicating(measuring )instrument13. 记录式测量仪器recording（measuring）instrument14. 累计式测量仪器totalizing(measuring)instrument15. 积分式测量仪器integrating(measuring)instrument16. 模拟式测量仪器analogue(measuring)instrument17. 数字式测量仪器digital(measuring)instrument18. 测量变换器measuringtransducer19. 传感器sensor20. 指示装置indicatingdevice21. 记录装置recordingdevice22. 记录载体recordingmedium23. 标尺标记scalemark24. 指示器index25. 标尺scale26. 度盘dail计量器具中英文对照汇总表-测量器具术语1. 标称值nominalvalue2. 示值indication(of a measuring instrument)3. 标尺范围scalerange4. 标称范围nominalrange5. 标尺长度scalelength6. 标尺分度scaledivision7. 分度值value ofascale division8. 标尺间距scalespacing9. 线性标尺linearscale10. 非线性标尺non-linear scale11. 标尺标数scalenumbering12. 测量仪器的零位zeroofa measuring instrument13. 量程span14. 测量范围measuringrange15. 额定工作条件vatedoperating conditions16. 极限条件referencecondition17. 标准条件referencecondition18. 仪器常数instrumentconstant19. 响应特性responsecharacteristic20. 灵敏度senstivity21. 鉴别力discrimination22. 分辨力resolution（ofanindicating device）23. 死区deadband24. 准确度accuracyofa measuring instruments25. 准确度等级accuracyclass26. 重复性repeatability of a measuring instrument27. 示值变动性varationof indication28. 稳定度stability29. 可靠性reliability30. 回程hysteresis31. 漂移drift32. 响应时间responsetime33. 测量力（简称“测力”）measuringforce计量器具中英文对照汇总表-测量器具术语1. 实物量具示值误差errorof indication of a material measure2. 测量仪器示值误差errorof indication of a measuring instrument3. 重复性误差repeatability error of a measuring instrument4. 回程误差hysteresiserror5. 测量力变化variationof measuring force6. 测量力落差hysteresis of measuring force7. 偏移误差biaserror(of a measuring instrument)8. 允许误差maximumpermissible errors(of measuringinstruments)9. 跟踪误差trackingerror (of a measuring instrument)10. 响应率误差response-law error (of a measuring instrument)11. 量化误差quantization error (of a measuring instrument)12. 基值误差datumerror(of a measuring instrument)13. 零值误差zeroerror(of a measuring instrument)14. 影响误差influenceerror15. 引用误差fiducialerror16. 位置误差positionerror17. 线性误差linearerror18. 响应特性曲线responsecharacteristic curve19. 误差曲线errorcurve20. 校准曲线calibration curve21. 修正曲线correctioncurve计量器具中英文对照汇总表-表面质量测量器具表面粗糙度比较样块surface roughness comparison specimen铸造表面粗糙度比较样块surface roughness comparison specimen forcastsurface磨、车、镗、铣、插及刨加工表面粗糙度比较样块surface roughness comparison specimenforground,turned,bored,milled,shaped andplanedsurface电火花加工表面粗糙度比较样块surface roughness comparison specimenforspark-erosion machined surface抛（喷）丸、喷砂加工表面粗糙度比较样块surface roughness comparison specimen forshotblasted and grit blasted surface抛光加工表面粗糙度测量仪portable surface roughness comparison specimenforpolished surface便携式表面粗糙度测量仪portable surface roughessmeasuringinstrument驱动箱drivingbox台式表面粗糙度测量仪bench type surface roughnessmeasuringinstrument。
常用量具中英文对照表
序号 量具中文名称
量具英文名称
量具中文名称
量具英文名称
量具中文名称
量具英文名称
1 目测
Visual
通止规
2 卡尺
Caliper (0.01)
专用检具
3 高度尺
Height gauge (0.01)
螺纹规
4 轮廓仪
Profilometer
扭力板手
5 三坐标测量机
CMM
角度尺
6 投影仪
Hardness scale
Point micrometer
Three point internal micrometer
Projecter
深度尺
7 半径规
Radius gauge
光滑极限塞规
8 百(千)分表
Dial indicator
塞尺
9 偏摆仪
Deflectionmeter
漆膜测厚仪
10 粗糙度对比样块 Roughness contrast sample 块规
11 粗糙度仪
Roughness tester
金相显微镜
12 外计
13 内径千分尺
Internal micrometer
尖头千分尺
Go/no go gage
三爪式内径千分尺 Three point internal micrometer
Special gage
盐雾试验箱
Salt spray device
Thread gage
钢尺
Steel rule
Torque wrench
气动量仪
Air gauge
Angle gage
Depth gauge
常用量具中英文对照
常用量具中英文对照
序号 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 中文名称 外观 目视 电子千分尺 千分尺 高度儀 坑位千分尺 中径千分尺 內徑千分尺（三爪） 內卡規 電子卡尺 卡尺 高度卡尺（高度尺） 螺紋檢測英文 螺纹塞规 螺纹环规 光滑塞规 六角量具 梅花量具 投影儀 三次元 二次元 剖貨 测长仪 雷射仪 粗糙度儀 同軸度儀 鹽霧測試儀 扭力计 镀层测试仪 洛氏硬度计 維氏硬度计 金相测试仪 圆度仪 气动量仪 显微镜 轮廓度仪 英文名称
量具量仪中英文对照
2. 量值value(of a quantity)
3. 真值true value(of a quantity)
4. 约定真值 conventional true value(of a quantity)
5. 单位unit(of measurement)
17. 测量信号measurement signal
18. 直接测量法direct method of measurement
19. 间接测量法indirect method of measurement
20. 定义测量法definitive method of measurement
89.光栅线位移测量系统
Grating linear displacement measuring system
90.光栅角位移测量系统
Grating angular displacement measuring system
91.磁栅线位移测量系统
Magnet-grid linear displacement measuring system
78.梯形螺纹量规型式与尺寸 Types and dimensions of metric trapezoidal screw threads
79.普通螺纹量规型式与尺寸 Types and dimensions of gauges purpose screw threads
80.非螺纹密封的管螺纹量规 Gauges for pipe threads prcessure-tight joints are not made on the threads
量具名称中英文对照表
Full Description Coordinate Measuring Machine Optical Gaging Product
Chinese Name 三坐标测量机 三维全自动投影仪 硬度仪 数显外径千分尺 数显内径千分尺 数显卡尺 游标卡尺 高度尺 螺纹规 数显测径器 粗糙度仪 膜厚仪 塞规 半径规 目视 深度尺 内径表 块规 量角器 气动量仪 标准块 百分表/千分表 内窥镜 大理石平台 直角尺 轮廓度仪 齿轮测试仪 全自动园度仪 塞尺 分光仪 弹簧测试仪 测长仪
S/N 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 tion CMM OGP HT DEM DIM DC VC HG TG DCG RT FTT PG RG VS DG DBG GB DP AG SS DI SE MT PS OMM GMM ART FG SPH ST LMI
Hardness Tester Digital Exterior Diameter Micrometer Digital Interior Diameter Micrometer Digital Caliper Vernier Caliper Height Gage Thread Gage Digimatic Caliper Gage Roughness Tester Film Thickness Tester Pin Gage Radius Gage Visual Depth Gage Dial Bore Gage Block Gage Digital Protractor Air Gage Standard Specimen Dial Indicator Sophisticated Endoscope Marble Table Precision Square Outline Measuring Machine Gear Measuring Machine Automatic Rounness tester Feeler's Gage Spectrograph Spring Tester Length Measuring Instrument
量具中英文对照
量具中英文对照量具中英文对照卡尺类1.游标卡尺vernier caliper2.带表卡尺dial caliper3.电子数显卡尺calliper with electronic digital display4.深度标游卡尺depth vernier caliper5.电子数显深度卡尺depth caliper with electronic digital display6.带表高度卡尺dial height calliper7.高度游标卡尺height vernier caliper8.电子数显高度卡尺height caliper with electronic digital display9.焊接检验尺calliper for welding inspection 千分尺类1.测微头micrometer head2.外径千分尺external micrometer3.杠杆千分尺micrometer with dial comparator4.带计数器千分尺micrometer with counter5.电子数显外径千分尺micrometer with electronic digital display6.小测头千分尺small anvil micrometer7.尖头千分尺point micrometer8.板厚千分尺sheet metal micrometer9.壁厚千分尺tube micrometer10.叶片千分尺blade micrometer11.奇数沟千分尺odd fluted micrometer12.深度千分尺depth micrometer13.内径千分尺internal micrometer14.单杆式内径千分尺single-body internal micrometer15.表式内径千分尺dail internal micrometer16.三爪式内径千分尺three point internal micrometer17.电子数显三爪式内径千分尺three point internal micrometer18.内测千分尺inside micrometer长度测量器具量具类1.量块gauge block2.光滑极限量规plain limit gauge3.塞规plug gauge4.环规ring gauge 卡规snap gauge5.塞尺feeler gauge6.钢直尺steel gauge7.精密玻璃线纹尺precision glass linear scale8.精密金属线纹尺precision metal linear scale9.半径样板radius template测量器具术语1.实物量具示值误差error of indication of a material measure2.测量仪器示值误差error of indication of a measuring instrument3.重复性误差repeatability error of a measuring instrument4.回程误差hysteresis error5.测量力变化variation of measuring force6.测量力落差hysteresis of measuring force7.偏移误差bias error (of a measuring instrument)8.允许误差maximum permissible errors(of measuring instruments)9.跟踪误差tracking error (of a measuring instrument)10.响应率误差response-law error (of a measuring instrument)11.量化误差quantization error (of a measuring instrument)12.基值误差datum error (of a measuring instrument)13.零值误差zero error (of a measuring instrument)14.影响误差influence error15.引用误差fiducial error16.位置误差position error17.线性误差linear error18.响应特性曲线response characteristic curve19.误差曲线error curve20.校准曲线calibration curve21.修正曲线correction curve测量器具术语1.标称值nominal value2.示值indication(of a measuring instrument)3.标尺范围scale range4.标称范围nominal range5.标尺长度scale length6.标尺分度scale division7.分度值value of a scale division8.标尺间距scale spacing9.线性标尺linear scale10.非线性标尺non-linear scale11.标尺标数scale numbering12.测量仪器的零位zero of a measuring instrument13.量程span14.测量范围measuring range15.额定工作条件vated operating conditions16.极限条件reference condition17.标准条件reference condition18.仪器常数instrument constant19.响应特性response characteristic20.灵敏度senstivity21.鉴别力discrimination22.分辨力resolution（of an indicating device）23.死区dead band24.准确度accuracy of a measuring instruments25.准确度等级accuracy class26.重复性repeatability of a measuring instrument27.示值变动性varation of indication28.稳定度stability29.可靠性reliability30.回程hysteresis31.漂移drift32.响应时间response time33.测量力（简称“测力”）measuring force几何量测量器具术语1.几何量具测量器具dimensional measuring instruments2.长度测量器具length measuring instruments3.角度测量器具angle measuring instruments4.坐标测量机coordinate measuring machine5.形状和位置误差测量器具form and position error measuring instruments6.表面质量测量器具surface quality measuring instruments7.齿轮测量器具gear measuring instruments8.实物量具（简称“量具”）material measure9.测量仪器（简称“量仪”）measuring instruments10.测量链measuring chain11.测量装置measuring system 12.指示式测量仪器indicating(measuring ) instrument13.记录式测量仪器recording（measuring）instrument14.累计式测量仪器totalizing(measuring) instrument15.积分式测量仪器integrating(measuring) instrument16.模拟式测量仪器analogue(measuring)instrument17.数字式测量仪器digital(measuring)instrument18.测量变换器measuring transducer19.传感器sensor20.指示装置indicating device21.记录装置recording device22.记录载体recording medium23.标尺标记scale mark24.指示器index25.标尺scale26.度盘dail一般术语：1.几何量 geometrical product2.量值value(of a quantity)3.真值true value(of a quantity)4.约定真值conventional true value(of a quantity)5.单位unit(of measurement)6.测量measurement7.测试measurement and test8.检验inspecte9.静态测量static measurement10.动态测量dynamic measurement11.测量原理principle of measurement12.测量方法method of measurement13.测量程序measurement procedure14.被测量measurand15.影响量influence quantity16.变换值transformed value(of a measurand)17.测量信号measurement signal18.直接测量法direct method of measurement19.间接测量法indirect method of measurement20.定义测量法definitive method of measurement 21.直接比较测量法direct-comparison method of measurement22.替代测量法substitution method of measurement23.微差测量法differential method ofmeasurement24.零位测量法nulll method of measurement25.测量结果result of a measurement26.测得值measured value27.实际值actual value28.未修正结果uncorrected result（of a measurement）29.已修正结果corrected result(of a measurement)30.测量的准确度accuracy of measurement31.测量的重复性repeatability of measurement 32.测量复现性reproducibility of measurements 33.实验标准偏差experimental standard deviation 34.测量不确定度uncertainty of measurement 35.测量绝对误差absolute error of measurement 36.相对误差relative error37.随机误差random error38.系统误差systematic error39.修正值correction40.修正系数correction factor41.人员误差personal error42.环境误差environmental error43.方法误差error of method44.调整误差adjustment error45.读数误差reading error46.视差parallax error47.估读误差interpolation error48.粗大误差parasitic error49.检定verification50.校准calibration51.调准gauging52.调整adjustment1.刀口型直尺:knife straigjht edge2.刀口尺: knife straigjht edge3.三棱尺three edges straigjht edge4.四棱尺four edges straigjht edge5.条式和框式水平仪bar form and square levels6.合像水平仪imaging level meter7铸铁平板cast iron surface plate8.岩石平板 granite surface plate9.铸铁平尺cast iron straigjht edge10.钢平尺和岩石平尺steel and granite straigjht edge11.圆度仪 roundness measuring instrument12.电子水平仪electronic level meter13.表面粗糙度比较样块铸造表面roughness comparison specimens cast surface 14.表面粗糙度比较样块磨、车、铣、插及刨加工表面Roughness comparisonspecimens-ground,turned, bored,milled,shape and planed15.表面粗糙度比较样块电火花加工表面roughness comparison specimens spark-erostion machining surfaces16.表面粗糙度比较样块抛光加工表面roughness comparison specimens pollshed surfaces17.接触式仪器的标称特性18.轮廓profiles19.轨迹轮廓 traced profile20.基准轮廓 reference profile21.总轮廓 total profile22.原始轮廓 primary profile23.残余轮廓residual profile24.触针式仪器stylus instrument25.感应位移数字存储触针式量仪displacement sensitive,digitally storing stylus instrument 26.触针式仪器的部件stylus instrument components27.测量环measurement loop28.导向基准renfence guide29.驱动器drive unit30.测头(传感器)probe(pick-up)31.拾取单元tracing element32.针尖stylus tip33.转换器transducer34.放大器amplifier35.模/数转换器analog-to-digital converter36.数据输入data input37.数据输出data output38.轮廓滤波和评定profile filtering and evaluation39.轮廓记录器profile recorder40.仪器的计量特性metrological characteristics of the instrument 41.静测力的变化change of static measuring force42.静态测力 static measuring force43.动态测量力dynamic measuring force44.滞后hysteresis45.测头的测量范围transmission function for the sine waves46.仪器的测量范围measuring range of the instrument47.模数转换器的量化步距quantization step of the ADC48.仪器分辨力 instrument resolution49.量程分辨力比range-to-resolution ratio50.测头线性偏差probe linearity deviation51.短波传输界限short-wave transmission limitation52.轮廓垂直成分传输vertical profile component transmission53表面粗糙度比较样块抛丸、喷砂加工表面roughness comparison specimens shot blasted and blasted surfaces 54产品结构几何量计术规范（GPS）geometrical product specifications(GPS) 55表面结构surface texture56接触式仪器的标称特性nominal characteristics of contact instruments57公法线千分尺micrometer for mearsuring root tangent lenghths of gear teeth58最大允许误差maximum permissible error59圆柱直齿渐开线花键量规gauges for straight cylindrical involute splines60齿厚游标卡尺Gear tooth vernier calipers61齿轮渐开线样板the involute master of gear62齿轮螺旋线样板the helix master of gear63矩形花键量规gauges for straight –sided splines64测量蜗杆 master worm65万能测齿仪universal gear measuring instrument66万能渐开线检查仪universal involute measuring instrument67齿轮齿距测量仪gear circular pictch measuring instrument68万能齿轮测量机Universal gear measuring machine69齿轮螺旋线测量仪gear helix measuring instrument70便携式齿轮齿距测量仪manual gear circular pitch measuring instrument71便携式齿轮基节测量仪manual gear base pitch measuring instrument 72立式滚刀测量仪vertical hob measuring instrument73齿轮双面啮合综合测量仪Gear dual-flank measuring instrument74齿轮单面啮合整体误差测量仪Gear single-flank meshing integrated error measuring instrument75梯形螺纹量规gauges for metric trapezoidal screw threads76工作螺纹量规work gauges for metric trapezoidal screw threads77校对螺纹量规check gauges for metric trapezoidal screw threads78.梯形螺纹量规型式与尺寸Types and dimensions of metric trapezoidal screw threads79.普通螺纹量规型式与尺寸 Types and dimensions of gauges purpose screw threads80.非螺纹密封的管螺纹量规Gauges for pipe threads prcessure-tight joints are not made on the threads81.螺纹千分尺Screw thread micrometer82.最大允许误差maximum permissible error83.间隙螺纹量规Clearance screw gauge84.量针Bar gauge85.螺纹样板 Screw thread template86.用螺纹密封的管螺纹量规Gauges for pipe threads where pressure-tight joints are made on the threads87.刀具预调测量仪精度Accuracy of the presetting instrument88.薄膜式气动量仪Membrane type pneumatic measuring instrument 89.光栅线位移测量系统Grating linear displacement measuring system 90.光栅角位移测量系统Grating angular displacement measuring system 91.磁栅线位移测量系统Magnet-grid linear displacement measuring system92.量块附件Accessories for gauge blocks93.V形架Vee blocks94.比较仪座Comparator stand95.磁性表座Magnetic stand96.万能表座Universal stand for dial indicator1.刀口型直尺:knife straigjht edge2.刀口尺: knife straigjht edge3.三棱尺three edges straigjht edge4.四棱尺four edges straigjht edge5.条式和框式水平仪bar form and square levels6.合像水平仪imaging level meter7铸铁平板cast iron surface plate8.岩石平板granite surface plate9.铸铁平尺cast iron straigjht edge10.钢平尺和岩石平尺steel and granite straigjht edge11.圆度仪roundness measuring instrument12.电子水平仪electronic level meter13.表面粗糙度比较样块铸造表面roughness comparison specimens cast surface14.表面粗糙度比较样块磨、车、铣、插及刨加工表面roughness comparison specimens-ground,turned,bored,milled,shape and planed 15.表面粗糙度比较样块电火花加工表面roughness comparison specimens spark-erostion machining surfaces16.表面粗糙度比较样块抛光加工表面roughness comparisonspecimens pollshed surfaces17.接触式仪器的标称特性18.轮廓profiles19.轨迹轮廓traced profile20.基准轮廓reference profile21.总轮廓total profile22.原始轮廓primary profile23.残余轮廓residual profile24.触针式仪器stylus instrument25.感应位移数字存储触针式量仪displacement sensitive,digitally storing stylus instrument 26.触针式仪器的部件stylus instrument components27.测量环measurement loop28.导向基准renfence guide29.驱动器drive unit30.测头(传感器) probe(pick-up)31.拾取单元tracing element 32.针尖stylus tip33.转换器transducer34.放大器amplifier35.模/数转换器analog-to-digital converter36.数据输入data input37.数据输出data output38.轮廓滤波和评定profile filtering and evaluation39.轮廓记录器profile recorder40.仪器的计量特性metrological characteristics of the instrument41.静测力的变化change of static measuring force42.静态测力static measuring force43.动态测量力dynamic measuring force44.滞后hysteresis45.测头的测量范围transmission function for the sine waves46.仪器的测量范围measuring range of the instrument47.模数转换器的量化步距quantization step of the ADC48.仪器分辨力instrument resolution49.量程分辨力比range-to-resolution ratio50.测头线性偏差probe linearity deviation51.短波传输界限short-wave transmission limitation52.轮廓垂直成分传输vertical profile component transmission139表面粗糙度比较样块抛丸、喷砂加工表面roughness comparison specimens shot blasted and blasted surfaces 40产品结构几何量计术规范(GPS)geometrical product specifications(GPS)41表面结构surface texture42接触式仪器的标称特性nominal characteristics of contact instruments43公法线千分尺micrometer for mearsuring root tangent lenghths of gear teeth44最大允许误差maximum permissible error45圆柱直齿渐开线花键量规gauges for straight cylindrical involute splines46齿厚游标卡尺Gear tooth vernier calipers47齿轮渐开线样板the involute master of gear62齿轮螺旋线样板the helix master of gear63矩形花键量规gauges for straight–sided splines64测量蜗杆master worm65万能测齿仪universal gear measuring instrument66万能渐开线检查仪universal involute measuring instrument67齿轮齿距测量仪gear circular pictchmeasuring instrument68万能齿轮测量机Universal gear measuring machine69齿轮螺旋线测量仪gear helix measuring instrument70便携式齿轮齿距测量仪manual gear circular pitch measuring instrument71便携式齿轮基节测量仪manual gear base pitch measuring instrument72立式滚刀测量仪vertical hob measuring instrument73齿轮双面啮合综合测量仪Gear dual-flank measuring instrument74齿轮单面啮合整体误差测量仪Gear single-flank meshing integrated error measuring instrument75梯形螺纹量规gauges for metric trapezoidal screw threads 76工作螺纹量规work gauges for metric trapezoidal screw threads77校对螺纹量规check gauges for metric trapezoidal screw threads76.梯形螺纹量规型式与尺寸Types and dimensions of metric trapezoidal screw threads77.普通螺纹量规型式与尺寸Types and dimensions of gauges purpose screw threads78.非螺纹密封的管螺纹量规Gauges for pipe threads prcessure-tight joints are not made on the threads79.螺纹千分尺Screw thread micrometer80.最大允许误差maximum permissible error81.间隙螺纹量规Clearance screw gauge82.量针Bar gauge83.螺纹样板Screw thread template84.用螺纹密封的管螺纹量规Gauges for pipe threads where pressure-tight joints are made on the threads85.刀具预调测量仪精度Accuracy of the presetting instrument 88.薄膜式气动量仪Membrane type pneumatic measuring instrument 89.光栅线位移测量系统Grating linear displacement measuring system 90.光栅角位移测量系统Grating angular displacement measuring system 91.磁栅线位移测量系统Magnet-grid linear displacement measuring system92.量块附件Accessories for gauge blocks93.V形架Vee blocks94.比较仪座Comparator stand95.磁性表座Magnetic stand96.万能表座Universal stand for dial indicator。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
量具中英文对照卡尺类1.游标卡尺vernier caliper2.带表卡尺dial caliper3.电子数显卡尺calliper with electronic digital display4.深度标游卡尺depth vernier caliper5.电子数显深度卡尺depth caliper with electronic digital display6.带表高度卡尺dial height calliper7.高度游标卡尺height vernier caliper8.电子数显高度卡尺height caliper with electronic digital display9.焊接检验尺calliper for welding inspection千分尺类1.测微头micrometer head2.外径千分尺external micrometer3.杠杆千分尺micrometer with dial comparator4.带计数器千分尺micrometer with counter5.电子数显外径千分尺micrometer with electronic digital display6.小测头千分尺small anvil micrometer7.尖头千分尺point micrometer8.板厚千分尺sheet metal micrometer9.壁厚千分尺tube micrometer10.叶片千分尺blade micrometer11.奇数沟千分尺odd fluted micrometer12.深度千分尺depth micrometer13.内径千分尺internal micrometer14.单杆式内径千分尺single-body internal micrometer15.表式内径千分尺 dail internal micrometer16.三爪式内径千分尺three point internal micrometer17.电子数显三爪式内径千分尺three point internal micrometer18.内测千分尺inside micrometer长度测量器具量具类1.量块gauge block2.光滑极限量规plain limit gauge3.塞规plug gauge4.环规ring gauge 卡规snap gauge5.塞尺feeler gauge6.钢直尺steel gauge7.精密玻璃线纹尺precision glass linear scale8.精密金属线纹尺precision metal linear scale9.半径样板radius template测量器具术语1.实物量具示值误差error of indication of a material measure2.测量仪器示值误差error of indication of a measuring instrument3.重复性误差repeatability error of a measuring instrument4.回程误差hysteresis error5.测量力变化variation of measuring force6.测量力落差hysteresis of measuring force7.偏移误差bias error (of a measuring instrument)8.允许误差maximum permissible errors(of measuring instruments)9.跟踪误差tracking error (of a measuring instrument)10.响应率误差response-law error (of a measuring instrument)11.量化误差quantization error (of a measuring instrument)12.基值误差datum error (of a measuring instrument)13.零值误差zero error (of a measuring instrument)14.影响误差influence error15.引用误差fiducial error16.位置误差position error17.线性误差linear error18.响应特性曲线response characteristic curve19.误差曲线error curve20.校准曲线calibration curve21.修正曲线correction curve测量器具术语1.标称值nominal value2.示值indication(of a measuring instrument)3.标尺范围scale range4.标称范围nominal range5.标尺长度scale length6.标尺分度scale division7.分度值value of a scale division8.标尺间距scale spacing9.线性标尺linear scale10.非线性标尺non-linear scale11.标尺标数scale numbering12.测量仪器的零位zero of a measuring instrument13.量程span14.测量范围measuring range15.额定工作条件vated operating conditions16.极限条件reference condition17.标准条件reference condition18.仪器常数instrument constant19.响应特性response characteristic20.灵敏度senstivity21.鉴别力discrimination22.分辨力resolution（of an indicating device）23.死区dead band24.准确度accuracy of a measuring instruments25.准确度等级accuracy class26.重复性repeatability of a measuring instrument27.示值变动性varation of indication28.稳定度stability29.可靠性reliability30.回程hysteresis31.漂移drift32.响应时间response time33.测量力（简称“测力”）measuring force几何量测量器具术语1.几何量具测量器具dimensional measuring instruments2.长度测量器具length measuring instruments3.角度测量器具angle measuring instruments4.坐标测量机coordinate measuring machine5.形状和位置误差测量器具form and position error measuring instruments6.表面质量测量器具surface quality measuring instruments7.齿轮测量器具gear measuring instruments8.实物量具（简称“量具”）material measure9.测量仪器（简称“量仪”）measuring instruments10.测量链measuring chain11.测量装置measuring system12.指示式测量仪器indicating(measuring )instrument 13.记录式测量仪器recording（measuring）instrument14.累计式测量仪器totalizing(measuring)instrument15.积分式测量仪器integrating(measuring)instrument16.模拟式测量仪器analogue(measuring)instrument17.数字式测量仪器digital(measuring)instrument18.测量变换器measuring transducer19.传感器sensor20.指示装置indicating device21.记录装置recording device22.记录载体recording medium23.标尺标记scale mark24.指示器index25.标尺scale26.度盘dail一般术语：1.几何量 geometrical product2.量值value(of a quantity)3.真值true value(of a quantity)4.约定真值conventional true value(of a quantity)5.单位unit(of measurement)6.测量measurement7.测试measurement and test8.检验inspecte9.静态测量static measurement10.动态测量dynamic measurement11.测量原理principle of measurement12.测量方法method of measurement13.测量程序measurement procedure14.被测量measurand15.影响量influence quantity16.变换值transformed value(of a measurand)17.测量信号measurement signal18.直接测量法direct method of measurement19.间接测量法indirect method of measurement20.定义测量法definitive method of measurement21.直接比较测量法direct-comparison method of measurement22.替代测量法substitution method of measurement23.微差测量法differential method of measurement24.零位测量法nulll method of measurement25.测量结果result of a measurement26.测得值measured value27.实际值actual value28.未修正结果uncorrected result （of a measurement）29.已修正结果corrected result(of a measurement)30.测量的准确度accuracy of measurement31.测量的重复性repeatability of measurement32.测量复现性reproducibility of measurements33.实验标准偏差experimental standard deviation34.测量不确定度uncertainty of measurement35.测量绝对误差 absolute error of measurement36.相对误差 relative error37.随机误差random error38.系统误差 systematic error39.修正值correction40.修正系数correction factor41.人员误差personal error42.环境误差environmental error43.方法误差error of method44.调整误差adjustment error45.读数误差reading error46.视差parallax error47.估读误差 interpolation error48.粗大误差parasitic error49.检定verification50.校准calibration51.调准gauging52.调整adjustment1.刀口型直尺:knife straigjht edge2.刀口尺: knife straigjht edge3.三棱尺three edges straigjht edge4.四棱尺four edges straigjht edge5.条式和框式水平仪bar form and square levels6.合像水平仪 imaging level meter7铸铁平板 cast iron surface plate8.岩石平板 granite surface plate9.铸铁平尺cast iron straigjht edge10.钢平尺和岩石平尺steel and granite straigjht edge11.圆度仪 roundness measuring instrument12.电子水平仪electronic level meter13.表面粗糙度比较样块铸造表面roughness comparison specimens cast surface 14.表面粗糙度比较样块磨、车、铣、插及刨加工表面Roughness comparisonspecimens-ground, turned, bored,milled,shape and planed 15.表面粗糙度比较样块电火花加工表面roughness comparison specimens spark-erostion machining surfaces16.表面粗糙度比较样块抛光加工表面roughness comparison specimens pollshed surfaces17.接触式仪器的标称特性18.轮廓profiles19.轨迹轮廓 traced profile20.基准轮廓 reference profile21.总轮廓 total profile22.原始轮廓 primary profile23.残余轮廓residual profile24.触针式仪器stylus instrument25.感应位移数字存储触针式量仪displacement sensitive,digitally storing stylus instrument26.触针式仪器的部件stylus instrument components27.测量环measurement loop28.导向基准renfence guide29.驱动器drive unit30.测头(传感器)probe(pick-up)31.拾取单元tracing element32.针尖stylus tip33.转换器transducer34.放大器amplifier35.模/数转换器analog-to-digital converter36.数据输入data input37.数据输出data output38.轮廓滤波和评定profile filtering and evaluation39.轮廓记录器profile recorder40.仪器的计量特性metrological characteristics of the instrument41.静测力的变化change of static measuring force42.静态测力 static measuring force43.动态测量力 dynamic measuring force44.滞后hysteresis45.测头的测量范围transmission function for the sine waves46.仪器的测量范围measuring range of the instrument47.模数转换器的量化步距quantization step of the ADC48.仪器分辨力 instrument resolution49.量程分辨力比range-to-resolution ratio50.测头线性偏差probe linearity deviation51.短波传输界限short-wave transmission limitation52.轮廓垂直成分传输vertical profile component transmission53表面粗糙度比较样块抛丸、喷砂加工表面roughness comparison specimens shot blasted and blasted surfaces54产品结构几何量计术规范（GPS）geometrical product specifications(GPS) 55表面结构 surface texture56接触式仪器的标称特性 nominal characteristics of contact instruments57公法线千分尺micrometer for mearsuring root tangent lenghths of gear teeth58最大允许误差 maximum permissible error59圆柱直齿渐开线花键量规 gauges for straight cylindrical involute splines60齿厚游标卡尺 Gear tooth vernier calipers61齿轮渐开线样板the involute master of gear 62齿轮螺旋线样板 the helix master of gear63矩形花键量规gauges for straight –sided splines64测量蜗杆 master worm65万能测齿仪universal gear measuring instrument66万能渐开线检查仪universal involute measuring instrument67齿轮齿距测量仪gear circular pictch measuring instrument68万能齿轮测量机Universal gear measuring machine69齿轮螺旋线测量仪gear helix measuring instrument70便携式齿轮齿距测量仪manual gear circular pitch measuring instrument 71便携式齿轮基节测量仪manual gear base pitch measuring instrument72立式滚刀测量仪vertical hob measuring instrument73齿轮双面啮合综合测量仪Gear dual-flank measuring instrument74齿轮单面啮合整体误差测量仪Gear single-flank meshing integrated error measuring instrument75梯形螺纹量规gauges for metric trapezoidal screw threads 76工作螺纹量规work gauges for metric trapezoidal screw threads 77校对螺纹量规check gauges for metric trapezoidal screw threads78.梯形螺纹量规型式与尺寸 Types and dimensions of metric trapezoidal screw threads79.普通螺纹量规型式与尺寸 Types and dimensions of gauges purpose screw threads80.非螺纹密封的管螺纹量规Gauges for pipe threads prcessure-tight joints are not made on the threads81.螺纹千分尺Screw thread micrometer82.最大允许误差 maximum permissible error83.间隙螺纹量规 Clearance screw gauge84.量针Bar gauge85.螺纹样板 Screw thread template86.用螺纹密封的管螺纹量规Gauges for pipe threads where pressure-tight joints are made on the threads87.刀具预调测量仪精度Accuracy of the presetting instrument88.薄膜式气动量仪Membrane type pneumatic measuring instrument 89.光栅线位移测量系统Grating linear displacement measuring system 90.光栅角位移测量系统Grating angular displacement measuring system 91.磁栅线位移测量系统Magnet-grid linear displacement measuring system 92.量块附件Accessories for gauge blocks93.V形架Vee blocks94.比较仪座Comparator stand95.磁性表座Magnetic stand96.万能表座Universal stand for dial indicator1.刀口型直尺:knife straigjht edge2.刀口尺: knife straigjht edge3.三棱尺three edges straigjht edge4.四棱尺four edges straigjht edge5.条式和框式水平仪bar form and square levels6.合像水平仪imaging level meter7铸铁平板cast iron surface plate8.岩石平板granite surface plate9.铸铁平尺cast iron straigjht edge10.钢平尺和岩石平尺steel and granite straigjht edge11.圆度仪roundness measuring instrument12.电子水平仪electronic level meter13.表面粗糙度比较样块铸造表面roughness comparison specimens cast surface14.表面粗糙度比较样块磨、车、铣、插及刨加工表面roughness comparison specimens-ground,turned,bored,milled,shape and planed15.表面粗糙度比较样块电火花加工表面roughness comparison specimens spark-erostion machining surfaces16.表面粗糙度比较样块抛光加工表面roughness comparison specimens pollshed surfaces17.接触式仪器的标称特性18.轮廓profiles19.轨迹轮廓traced profile20.基准轮廓reference profile21.总轮廓total profile22.原始轮廓primary profile23.残余轮廓residual profile24.触针式仪器stylus instrument25.感应位移数字存储触针式量仪displacement sensitive,digitally storing stylus instrument26.触针式仪器的部件stylus instrument components27.测量环measurement loop28.导向基准renfence guide29.驱动器drive unit30.测头(传感器) probe(pick-up)31.拾取单元tracing element32.针尖stylus tip33.转换器transducer34.放大器amplifier35.模/数转换器analog-to-digital converter36.数据输入data input37.数据输出data output38.轮廓滤波和评定profile filtering and evaluation39.轮廓记录器profile recorder40.仪器的计量特性metrological characteristics of the instrument 41.静测力的变化change of static measuring force42.静态测力static measuring force43.动态测量力dynamic measuring force44.滞后hysteresis45.测头的测量范围transmission function for the sine waves46.仪器的测量范围measuring range of the instrument47.模数转换器的量化步距quantization step of the ADC48.仪器分辨力instrument resolution49.量程分辨力比range-to-resolution ratio50.测头线性偏差probe linearity deviation51.短波传输界限short-wave transmission limitation52.轮廓垂直成分传输vertical profile component transmission153表面粗糙度比较样块抛丸、喷砂加工表面roughness comparison specimens shot blasted and blasted surfaces54产品结构几何量计术规范(GPS)geometrical product specifications(GPS)55表面结构surface texture56接触式仪器的标称特性nominal characteristics of contact instruments57公法线千分尺micrometer for mearsuring root tangent lenghths of gear teeth58最大允许误差maximum permissible error59圆柱直齿渐开线花键量规gauges for straight cylindrical involute splines60齿厚游标卡尺Gear tooth vernier calipers61齿轮渐开线样板the involute master of gear 62齿轮螺旋线样板the helix master of gear63矩形花键量规gauges for straight–sided splines64测量蜗杆master worm65万能测齿仪universal gear measuring instrument 66万能渐开线检查仪universal involute measuring instrument67齿轮齿距测量仪gear circular pictchmeasuring instrument68万能齿轮测量机Universal gear measuring machine69齿轮螺旋线测量仪gear helix measuring instrument70便携式齿轮齿距测量仪manual gear circular pitch measuring instrument 71便携式齿轮基节测量仪manual gear base pitch measuring instrument72立式滚刀测量仪vertical hob measuring instrument73齿轮双面啮合综合测量仪Gear dual-flank measuring instrument74齿轮单面啮合整体误差测量仪Gear single-flank meshing integrated error measuring instrument 75梯形螺纹量规gauges for metric trapezoidal screw threads76工作螺纹量规work gauges for metric trapezoidal screw threads77校对螺纹量规check gauges for metric trapezoidal screw threads78.梯形螺纹量规型式与尺寸Types and dimensions of metric trapezoidal screw threads79.普通螺纹量规型式与尺寸Types and dimensions of gauges purpose screw threads80.非螺纹密封的管螺纹量规Gauges for pipe threads prcessure-tight joints are not made on the threads81.螺纹千分尺Screw thread micrometer82.最大允许误差maximum permissible error83.间隙螺纹量规Clearance screw gauge84.量针Bar gauge85.螺纹样板Screw thread template86.用螺纹密封的管螺纹量规Gauges for pipe threads where pressure-tight joints are made on the threads87.刀具预调测量仪精度Accuracy of the presetting instrument88.薄膜式气动量仪Membrane type pneumatic measuring instrument 89.光栅线位移测量系统Grating linear displacement measuring system 90.光栅角位移测量系统Grating angular displacement measuring system 91.磁栅线位移测量系统Magnet-grid linear displacement measuring system92.量块附件Accessories for gauge blocks93.V形架Vee blocks94.比较仪座Comparator stand95.磁性表座Magnetic stand96.万能表座Universal stand for dial indicator。
