本特利振动速度变送器

Specifications and Ordering InformationPart Number 177232-01Rev. NC (06/07)Product DescriptionSpecificationsElectricalSensitivity –Main loop(Signal One)0.0 to 25.4 mm/s (0 to 1.0 in/s)± 10%, Broadband R.M.S (rootmean square)[4 mA equals 0.0 mm/s and20 mA equals 25.4 mm/s] Output Format,Ref: Pin A toPin B4 to 20 mA (Current loop),Velocity vibrationExcitationVoltage12 to 30 Vdc (current limited to 40mA)Note: This product is used with PLCs, DCSand SCADA systems that have internalpower supply that are typically currentlimited in the range of 30 mA to 35 mA. Settling Time< 15 seconds (with in 2% of value) ConnectorWiringConventionPin A: 4-20 mA Positive LoopPin B: 4-20 mA Negative Loop andcommon for Dynamic SignalC Pin: Dynamic Signal (in voltage,un-buffered)FrequencyResponse10 Hz to 1 kHz (600 cpm to 60kcpm) ± 10%Sensitivity –Dynamic Signal(Signal Two)10.2 mV/m/s2 (100 mV/g) ± 5% Output Format,Ref: Pin C toPin BVoltage,Acceleration vibration FrequencyResponse2.5 Hz to 10 kHz (150 cpm to 600kcpm) ± 10%Linearity±1%Output Bias(referenced topin-B)2.5v±0.1vFull Scale Range196m/s2 (20 gs) peakVelocity Range420 mm/s (16.5 in/s) peak MountedResonantFrequencyGreater than 12 kHz TransverseSensitivityLess than 5% of sensitivity SensingElement TypeCeramic / ShearSpecifications and Ordering InformationEnvironmental LimitsOperatingTemperatureRange-40 °C to +85 °C(-40 °F to +185 °F)ElectricalIsolation> 108 ohmsIsolationBreakdownVoltage600 Vrms (with less then 1 mAleakage current)ShockSurvivability9,810m/s2 (1,500 g peak),maximum (i.e. drop testNote:: This part is typically mounteddirectly to the machine via a stub. Thisdevice can be used with a mag-base, butcare must be taken to ensure that the unitis not snapped-on to the machine. Thissnapping action can create a very largespike signal that can damage theelectronics. Rolling the mag-base onto themachine greatly reduces this destructivesignal and the unit should not have anyissues.Sensor SealHermetically sealedRelativeHumidity ofTransmitterTo 100% non-submerged Magnetic FieldSensitivity<20 µm/s/gauss (<790µin/s/gauss) peak<14.7 mm/s2 /gauss (< 150 µg/gauss) peak[base on 50 gauss, 50 - 60 Hz] PhysicalWeight131 grams (4.6 ounces), typical Diameter25.4 mm (1.0 in)Height66.0 mm (2.6 in)Case Material304L stainless steelConnector3-pin MIL-C-5015, stainless steel Mounting Holein Body¼-28 UNFMountingThreadsM6 x 1 (SI version)¼-28 UNF (English version) MountingTorque4 to 7 N-m (3 to5 in-lbf) ConnectorWiringConventionPin A: 4-20 mA Positive Loop (withreference to Pin B)Pin B: 4-20 mA Negative Loop andcommon for Dynamic SignalC Pin: Dynamic Signal (in voltage,un-buffered and with reference toPin B)CE Mark DirectivesEMC Directives 89/336/EEC – with amendments Declaration of Conformity available online –/prod/products/certs/certificates.htmIEC/EN61326Radiated EmissionsCISPR 11 Criteria BSpecifications and Ordering InformationESD ImmunityEN 61000-4-2 Criteria BRadiated ImmunityEN 61000-4-3 Criteria BFast Transient ImmunityEN 61000-4-4 Criteria BSurge ImmunityEN 61000-4-5 Criteria AConducted ImmunityEN 61000-4-6 Criteria AMagnetic ImmunityEN 61010-1 Criteria ASafety:Explosive Atmosphere GeneralEN50014Explosive Atmosphere Intrinsic SafetyEN50020CE Product SafetyIEC/EN 61010-1ApprovalsATEXPending, LCIE 05 ATEX 6154 XSpecifications and Ordering InformationSpecifications and Ordering InformationOrdering InformationThe GE Seismic transmitter can be private labeled for our OEM customers. Contact your local service representative for further information.For standard orders use the number provided below. Product Description Seismic Transmitter 177230-02Product DescriptionInterconnect Cable without Armor 16925-AA Option Description A: Length in feetOrder in increments of 1 foot (0.3 m)Minimum length: 12 Feet (3.7 m) Maximum length: 99 Feet (30.2m)Product DescriptionInterconnect Cable with Armor 16710-AA Option Description A: Length in feetOrder in increments of 1 foot (0.3 m)Minimum length: 12 Feet (3.7 m) Maximum length: 99 Feet (30.2m)Accessories (Generic vendors are called out in thissection); The part list below are possible vendor sources for the supporting hardware. The Customer can use this information as reference and select what vendor they wish to use.3-Pin Connector (MIL-C-5015): Base -Cannon (ITT industries):P/N: CA3106R-10SL-3S F97orP/N: MS3106R-10SL-3SShell -Sunbank Co.Glenair, Inc.Contact a vendor with above part number and ask for their part that fits your applicationWire (3-wire with shield):Generic Description: 3 conductor – 18 to 22 AWGcables with a minimum of a of 0.01” think outer jacket and inner wire, and shield with a minimum of 80% coverage. Insulationshould be rated for a minimum of 600v.Mil-W-16878/4 (Type E) Sonic/Thermax 18 AWG -P/N: 18-TE-1930 (3) SXE 22 AWG -P/N: 22-TE-1934 (3) SXE Standard Wire and Cable Co. 18 AWG - P/N: 1100-88T 22 AWG - P/N: 1100-66T Belden18 AWG - P/N: 83336 22 AWG - P/N: 83334.Graphs and FiguresA Positive Loop (4-20 mA) F 1.27 mm (0.050 inches)G 25.4 mm (1.00 inches)B Negative Loop (4-20 mA) andCommon for Dynamic signalC Dynamic Signal H ¼ - 2b UNF – 2B (English)D 3-Pin ML-C-5015 I 25.1 mm (0.990 inches)E 66.0 mm (2.60 inches)Mm (inches)Copyright © 2007 General Electric Company1631 Bently Parkway South, Minden, Nevada USA 89423Specifications and Ordering Information。
