文件级别：文件编号:
MOXA Npｏrt5630设备
使用说明书
1.0版
编制：汤浩
校核：喻鹏、谭华
审定:
批准：
长沙华能自控集团有限公司一、简介
MOＸＡNport5600系列产品就是一种与后台电脑用网络连接得串口服务器。
NＰｏrt ５60０系列ﻫ
多个不同得后台电脑可以共同分享１个Npoｒｔ56０0设备
二、Npoｒt５6００通信线制作
Npｏrt ５600 系列串口接线引脚
引脚号RS2３2 RS4２2/ 4线RＳ485 2线ＲＳ４８5
1 DＳR
2 RTS
３GNＤＴXD+
４ＴXD ＴXD-
5 RXD RXＤ－ＤAＴＡ—
6 DＣD RXD+ ＤATＡ+
7 CTS ＧND GＮD
８DTR
三、Nport 5600设置
面板与按钮说明
灯：
LEＤ灯－灯颜色-含义
LＥD灯颜色含义
准备灯红正在启动中，长期则就是有错误
绿正常
１—8/1６通信信号灯正在接收数据
绿正在发送数据
按键：
键名称—含义
ＭENU菜单键
∧上翻键
∨下翻键
SEL选择键
先在NPＯRＴ5600上把NPORＴ5６０0得IＰ设置好，具体操作方法如
Ｍｅnｕ(主选单）→NｅtWork Ｓetｔｉng → IP Ａddｒｅss →设置为192、1６8、X、X
→ＮetＭasｋ→设置为２５5、255、25５、0
四、后台电脑设置
在后台电脑中安装好Ｎport5600得驱动程,安装完毕后在开始菜单中选择程序,然后再选择刚安装好得NPort Adminｉsｔｒａtion Sｕite→ NPｏrｔAdminisｔrator
打开后选择BroadcastＳｅａrｃｈ（自动查找在网络内得Npｏrｔ）
配置Ｎpｏrt 5600
设置PＯＲＴx 端口得通信方式
Ｍａｐpiｎg （串口映射)
也就就是把NPORＴ得ＰOＲＴx映射为电脑中得
到此设置完毕，点击中得Apply应用刚才得设置。
后台软件中得串口得ＭAPPＩNG中得PORＴ应相对应.
后台软件中得其它设置请参阅MTＣ得帮助文件。
