spring+springmvc+ibatis整合注解方式实例

1.需求说明实现用户通过数据库验证登录需求，采用Myeclipse+Tomcat 6.0+Mysql 5.0+JDK 1.62.数据库表开发所用是Mysql数据库,只建立单张用户表T_USER,表结构如下：sql语句如下：CREATE TABLE `t_user` (`ID` int(11) NOT NULL auto_increment,`USERNAME` varchar(255) default NULL,`PASSWORD` varchar(255) default NULL,PRIMARY KEY (`ID`));3.构建源代码目录4.用到的jar包(见附件Archive.rar)5.各项Xml配置文件详解(1)web.xml文件(Tomcat使用)服务器根据配置内容初始化spring框架，springmvc框架和log4j日志框架<?xml version="1.0" encoding="UTF-8"?><web-app version="2.5"xmlns="/xml/ns/javaee"xmlns:xsi="/2001/XMLSchema-instance"xsi:schemaLocation="/xml/ns/javaee/xml/ns/javaee/web-app_2_5.xsd"><!-- 应用程序名称 --><display-name>ISS</display-name><!-- 应用程序描述说明性文字 --><description>Spring,SpringMvc,Ibatis</description><!-- ServletContext初始化参数 --><context-param><param-name>webAppRootKey</param-name><param-value>spring_springmvc_ibatis.root</param-value></context-param><context-param><param-name>log4jConfigLocation</param-name><param-value>/WEB-INF/classes/log4j.properties</param-valu e></context-param><context-param><param-name>contextConfigLocation</param-name><param-value>/WEB-INF/classes/applicationContext.xml</param-value ></context-param><!-- 字符过滤,防止添加到数据库的数据为乱码 --><filter><filter-name>characterEncodingFilter</filter-name><filter-class>org.springframework.web.filter.CharacterEncodingFil ter</filter-class><init-param><param-name>encoding</param-name><param-value>UTF-8</param-value></init-param><init-param><param-name>forceEncoding</param-name><param-value>true</param-value></init-param></filter><filter-mapping><filter-name>characterEncodingFilter</filter-name><url-pattern>/*</url-pattern></filter-mapping><!-- web权限配置 --><filter><filter-name>springSecurityFilterChain</filter-name><filter-class>org.springframework.web.filter.DelegatingFil terProxy</filter-class></filter><filter-mapping><filter-name>springSecurityFilterChain</filter-name><url-pattern>/*</url-pattern></filter-mapping><!-- 配置监听器,用于初始化 --><listener><listener-class>org.springframework.web.util.Log4jConfigLi stener</listener-class></listener><listener><listener-class>org.springframework.web.context.ContextLoaderList ener</listener-class></listener><!-- Servlet初始化参数,配置springmvc模块 --><servlet><servlet-name>springmvc</servlet-name><servlet-class>org.springframework.web.servlet.DispatcherServlet< /servlet-class><init-param><param-name>contextConfigLocation</param-name><param-value>/WEB-INF/classes/springmvc-servlet.xml</param-value> </init-param><load-on-startup>2</load-on-startup></servlet><servlet-mapping><servlet-name>springmvc</servlet-name><url-pattern>/</url-pattern></servlet-mapping><!-- 配置session存在时间 --><session-config><session-timeout>60</session-timeout></session-config><!-- 默认起始页面 --><welcome-file-list><welcome-file>index.jsp</welcome-file></welcome-file-list><!-- 异常跳转页面 --><error-page><exception-type>ng.Exception</exception-type><location>/WEB-INF/jsp/exception.jsp</location></error-page></web-app>(2)springmvc-servlet.xml(Springmvc框架配置文件)该文件是springmvc框架配置文件，也是它的核心文件<?xml version="1.0" encoding="UTF-8"?><beans xmlns="/schema/beans"xmlns:xsi="/2001/XMLSchema-instance"xmlns:mvc="/schema/mvc"xmlns:context="/schema/context" xsi:schemaLocation="/schema/beans/schema/beans/spring-beans-3.0.xsd /schema/mvc/schema/mvc/spring-mvc-3.0.xsd/schema/context/schema/context/spring-context-3.0. xsd"><!-- 自动扫描,完成bean创建和依赖注入 --><context:component-scan base-package="com.archie"/><!-- 启动Spring MVC的注解功能，完成请求和注解POJO的映射 --><beanclass="org.springframework.web.servlet.mvc.annotation.AnnotationM ethodHandlerAdapter"/><!-- 视图解析器 --><bean id="viewResolver"class="org.springframework.web.servlet.view.InternalResourceViewR esolver"><property name="viewClass"value="org.springframework.web.servlet.view.JstlView"/><property name="prefix" value="/WEB-INF/views/"/><property name="suffix" value=".jsp"/></bean><!-- 异常解析器 --><bean id="simpleMappingExceptionResolver"class="org.springframework.web.servlet.handler.SimpleMappingExcep tionResolver"><property name="exceptionMappings"><props><propkey="org.springframework.web.multipart.MaxUploadSizeExceededExcep tion">common/fileerror</prop></props></property></bean></beans>(3)applicationContext.xml(Spring框架配置文件)<?xml version="1.0" encoding="UTF-8"?><beans xmlns="/schema/beans"xmlns:xsi="/2001/XMLSchema-instance"xmlns:mvc="/schema/mvc"xmlns:context="/schema/context" xmlns:aop="/schema/aop"xmlns:tx="/schema/tx"xsi:schemaLocation="/schema/beans/schema/beans/spring-beans-3.0.xsd /schema/mvc/schema/mvc/spring-mvc-3.0.xsd/schema/context/schema/context/spring-context-3.0. xsd/schema/tx/schema/tx/spring-tx-3.0.xsd /schema/aop/schema/aop/spring-aop-3.0.xsd" default-autowire="byName"><!-- 自动扫描 --><context:component-scan base-package="com.archie"/><!-- 启动spring注解,当自动扫描启动后,该配置可以去掉<context:annotation-config /> --><!-- 启动spring注解,等同于 context:annotation-config<beanclass="monAnnotationBea nPostProcessor"/><beanclass="org.springframework.beans.factory.annotation.AutowiredAnno tationBeanPostProcessor"/><beanclass="org.springframework.beans.factory.annotation.PersistenceAn notationBeanPostProcessor"/><beanclass="org.springframework.beans.factory.annotation.RequiredAnnot ationBeanPostProcessor"/> --><!-- 配置数据源属性文件 --><bean id="propertyConfigurer"class="org.springframework.beans.factory.config.PropertyPlacehold erConfigurer"><property name="locations"><list><value>jdbc.properties</value></list></property></bean><!-- 配置数据源 --><bean id="dataSource"class="mons.dbcp.BasicDataSource"><property name="driverClassName" value="${driver}"/><property name="url" value="${url}"/><property name="username" value="${username}"/><property name="password" value="${password}"/></bean><!-- 配置SqlMapClient对象 --><bean id="sqlMapClient"class="org.springframework.orm.ibatis.SqlMapClientFactoryBean"> <property name="configLocation" value="sqlMapConfig.xml"/><property name="dataSource" ref="dataSource"/></bean><!--根据sqlMapClien创建一个SqlMapClient模版类--><bean id="sqlMapClientTemplate"class="org.springframework.orm.ibatis.SqlMapClientTemplate"><property name="sqlMapClient" ref="sqlMapClient"/></bean><!-- 配置事务管理器 --><bean id="transactionManager"class="org.springframework.jdbc.datasource.DataSourceTransactionM anager"><property name="dataSource" ref="dataSource"/></bean><!-- 启动spring事务注解，事务注解尽在此 --><tx:annotation-driven transaction-manager="transactionManager"/><!-- 配置事务特性<tx:advice id="txAdvice"transaction-manager="transactionManager"><tx:attributes><tx:method name="select*" read-only="true"propagation="REQUIRED"/><tx:method name="find*" read-only="true"propagation="REQUIRED"/><tx:method name="save*" propagation="REQUIRED"isolation="REPEATABLE_READ"/><tx:method name="update*" propagation="REQUIRED"isolation="REPEATABLE_READ"/><tx:method name="add*" propagation="REQUIRED"isolation="REPEATABLE_READ"/><tx:method name="delete*" propagation="REQUIRED"isolation="REPEATABLE_READ"/><tx:method name="*" read-only="true"/></tx:attributes></tx:advice> --><!-- 配置事务代理拦截器<bean id="baseTransactionProxy" abstract="true"class="org.springframework.transaction.interceptor.Transac tionProxyFactoryBean"><property name="transactionManager"><ref bean="transactionManager"/></property><property name="transactionAttributes"><props><prop key="insert*">PROPAGATION_REQUIRED</prop><prop key="update*">PROPAGATION_REQUIRED</prop><prop key="delete*">PROPAGATION_REQUIRED</prop><prop key="*">PROPAGATION_REQUIRED,readOnly</prop> </props></property></bean> --><!-- 配置哪些类的方法需要进行事务管理<aop:config><aop:pointcut id="baseServiceMethods" expression="execution(* com.archie.service.*.*(..))"/><aop:advisor advice-ref="txAdvice"pointcut-ref="baseServiceMethods"/></aop:config><aop:aspectj-autoproxy /> --><!-- 配置Dao实例<bean id="userDao" class="erDao"><property name="sqlMapClient" ref="sqlMapClient"/></bean> --><!-- 配置Service实例<bean id="userService" class="erService"><property name="userDao" ref="userDao"/></bean> --><!-- 添加了事务的管理类<bean id="userManager" parent="baseTransactionProxy"><property name="target"><bean class="erService"/></property></bean> --></beans>(4)jdbc.properties(数据源属性文件)数据源连接信息的源出处，目前配置了三种数据库Oracle，DB2和Mysql# Database Connectivity# Oracle#driver = oracle.jdbc.driver.OracleDriver#url = jdbc:oracle:thin:@localhost:1521:oracl#username = scott#password = tiger# DB2#driver = com.ibm.db2.jcc.DB2Driver#url = jdbc:db2://10.1.10.162:50000/mydb#username = root#password = root# Mysqldriver = com.mysql.jdbc.Driverurl =jdbc:mysql://localhost:3306/mydb?useUnicode=true&characterEncodin g=utf-8username = rootpassword = 1234initialPoolSize = 1minPoolSize = 1maxPoolSize =10(5)log4j.properties(log4j框架属性文件)log4j日志属性配置文件# log4j.propertieslog4j.rootLogger=warn,consolelog4j.appender.console=org.apache.log4j.ConsoleAppenderyout=org.apache.log4j.PatternLayoutyout.ConversionPattern=[%d] [%t](%F:%L) %-5p %c - %m%nlog4j.appender.console.Encoding=GB18030log4j.appender.file=org.apache.log4j.RollingFileAppenderlog4j.appender.file.MaxFileSize=10240KBlog4j.appender.file.MaxBackupIndex=100log4j.appender.file.Encoding=GB18030yout=org.apache.log4j.PatternLayoutyout.ConversionPattern=[%d] [%t](%F:%L) %-5p %c - %m%nlog4j.appender.ROLLING_FILE_CUSTOMER=org.apache.log4j.RollingFile Appenderlog4j.appender.ROLLING_FILE_CUSTOMER.Threshold=debuglog4j.appender.ROLLING_FILE_CUSTOMER.Append=truelog4j.appender.ROLLING_FILE_CUSTOMER.MaxFileSize=1024KBlog4j.appender.ROLLING_FILE_CUSTOMER.MaxBackupIndex=30log4j.appender.ROLLING_FILE_yout=org.apache.log4j.Patt ernLayoutlog4j.appender.ROLLING_FILE_yout.ConversionPattern=%d - %c:%L - %-5p %c %x - %m%nlog4j.appender.ROLLING_FILE_WORKMANAGER=org.apache.log4j.RollingF ileAppenderlog4j.appender.ROLLING_FILE_WORKMANAGER.Threshold=debuglog4j.appender.ROLLING_FILE_WORKMANAGER.Append=truelog4j.appender.ROLLING_FILE_WORKMANAGER.MaxFileSize=1024KBlog4j.appender.ROLLING_FILE_WORKMANAGER.MaxBackupIndex=30log4j.appender.ROLLING_FILE_yout=org.apache.log4j.P atternLayoutlog4j.appender.ROLLING_FILE_yout.ConversionPattern= %d - %c:%L - %-5p %c %x - %m%nlog4j.appender.ROLLING_FILE_RSS=org.apache.log4j.RollingFileAppen derlog4j.appender.ROLLING_FILE_RSS.Threshold=debuglog4j.appender.ROLLING_FILE_RSS.Append=truelog4j.appender.ROLLING_FILE_RSS.MaxFileSize=1024KBlog4j.appender.ROLLING_FILE_RSS.MaxBackupIndex=30log4j.appender.ROLLING_FILE_yout=org.apache.log4j.PatternLa youtlog4j.appender.ROLLING_FILE_yout.ConversionPattern=%d - %c:%L - %-5p %c %x - %m%n(6)sqlMapConfig.xml(Ibatis框架配置文件)该文件主要负责指定sql映射文件，即与model层对象对应的映射文件<?xml version="1.0" encoding="UTF-8" ?><!DOCTYPE sqlMapConfig PUBLIC "-////DTD SQL Map Config 2.0//EN""/dtd/sql-map-config-2.dtd"><sqlMapConfig><!-- 配置settings --><settings lazyLoadingEnabled="true"useStatementNamespaces="false"/><!-- 配置sql映射文件 --><sqlMap resource="com/archie/model/User.xml"/></sqlMapConfig>6.Java代码编写根据包目录，可以看出分成model层,dao层,service层和web层,另外附加test层,用于java环境测试(1)model层(User.java+User.xml)User.java代码package com.archie.model;public class User {private int id;private String username;private String password;public User(){}public User(int id){this.id = id;}public User(int id, String username){this.id = id;ername = username;}public User(String username, String password) {ername = username;this.password = password;}public User(int id, String username, String password){this.id = id;ername = username;this.password = password;}public int getId() {return id;}public void setId(int id) {this.id = id;}public String getUsername() {return username;}public void setUsername(String username) {ername = username;}public String getPassword() {return password;}public void setPassword(String password) {this.password = password;}}User.xml代码(model层对象的sql映射文件,被dao层调用,本质是sql语句集合,所有相关的sql均于此)<?xml version="1.0" encoding="UTF-8" ?><!DOCTYPE sqlMap PUBLIC "-////DTD SQL Map 2.0//EN" "/dtd/sql-map-2.dtd"><sqlMap namespace="User"><typeAlias alias="User" type="er"/><select id="findAllUser" resultClass="User" >select * from t_user</select><select id="findUserByID" resultClass="User"parameterClass="int">select * from t_user where id=#id#</select><select id="getTotalCount" resultClass="int">select count(*) from t_user</select><select id="searchUsers" resultClass="User"parameterClass="User">select * from t_user<dynamic prepend="where"><!-- 模糊查询，用$表示文本替换，而用#表示替换PrepareStatement中的?号 --><isNotEmpty prepend="and" property="username">(username like '%$username$%')</isNotEmpty><isNotEmpty prepend="and" property="password">(password like '%$password$%')</isNotEmpty></dynamic></select><select id="findUserByNameAndPassword" resultClass="User" parameterClass="User">select * from t_user where username=#username# and password=#password#</select><insert id="insertUser" parameterClass="User">insert into t_user(id,username,password)values(null,#username#,#password#)</insert><update id="updateUser" parameterClass="User">update t_userset username = #username#,password=#password#where id=#id#</update><delete id="deleteUser" parameterClass="int">delete from t_user where id=#id#</delete><delete id="deleteUserByLike" parameterClass="User">delete from t_user<dynamic prepend="where"><!-- 模糊查询，用$表示文本替换，而用#表示替换PrepareStatement中的?号 --><isNotEmpty prepend="and" property="username">(username like '%$username$%')</isNotEmpty><isNotEmpty prepend="and" property="password">(password like '%$password$%')</isNotEmpty></dynamic></delete></sqlMap>(2)dao层(数据服务层,BaseDao.java+UserDao.java)BaseDao.java(公共Dao,其他Dao均继承它)package com.archie.dao;import javax.annotation.PostConstruct;import javax.annotation.Resource;importorg.springframework.orm.ibatis.support.SqlMapClientDaoSupport; import com.ibatis.sqlmap.client.SqlMapClient;public class BaseDao extends SqlMapClientDaoSupport {@Resource(name="sqlMapClient") //通过bean名称注入private SqlMapClient sqlMapClient;@PostConstruct //完成sqlMapClient初始化工作public void initSqlMapClient(){super.setSqlMapClient(sqlMapClient);}UserDao.java(user数据服务层)package com.archie.dao;import java.util.List;import ponent;import er;@Component //将UserDao类注入到bean里面public class UserDao extends BaseDao {public boolean addUser(User user) throws Exception{User bean =(User)getSqlMapClientTemplate().insert("insertUser", user);return bean != null ? true : false;}public boolean deleteUser(int id) throws Exception{int result =getSqlMapClientTemplate().delete("deleteUser", id);return result > 0 ? true : false;}public User getUserById(int id) throws Exception{return(User)getSqlMapClientTemplate().queryForObject("findUserByID", id);}@SuppressWarnings("unchecked")public List getAllUsers() throws Exception{returngetSqlMapClientTemplate().queryForList("findAllUser");}public boolean updateUser(User user) throws Exception{ int result =getSqlMapClientTemplate().update("updateUser", user);return result > 0 ? true : false;}public User getUserByNameAndPassword(User user) throws Exception{return(User)getSqlMapClientTemplate().queryForObject("findUserByNameAnd Password", user);}public int getTotalCount() throws Exception{return(Integer)getSqlMapClientTemplate().queryForObject("getTotalCount" );}@SuppressWarnings("unchecked")public List getUsersByLike(User user) throws Exception{returngetSqlMapClientTemplate().queryForList("searchUsers", user);}public int deleteUserByLike(User user) throws Exception{ int result =getSqlMapClientTemplate().delete("deleteUserByLike", user);if (result > 0) {System.out.println("模糊删除成功！");}else {System.out.println("没有匹配的记录1");}return result;}}(3)service层(业务服务层,UserService.java)UserService.java代码如下package com.archie.service;import java.util.List;import javax.annotation.Resource;import ponent;import org.springframework.transaction.annotation.Transactional;import erDao;import er;@Component //将UserService类注入到bean里面@Transactional //注入事务管理public class UserService {@Resource(name="userDao") // 通过名称注入到bean里面private UserDao userDao;public User login(User user) throws Exception{return userDao.getUserByNameAndPassword(user);}public void addUser(User user) throws Exception{userDao.addUser(user);}public void deleteUser(int id) throws Exception{boolean bool = userDao.deleteUser(id);if (!bool) {System.out.println("删除的记录不存在！");throw new RuntimeException();}}public User getUserById(int id) throws Exception{User user = userDao.getUserById(id);if (user == null) {return null;}return userDao.getUserById(id);}public void updateUser(User user) throws Exception{userDao.updateUser(user);}public int getTotalCount() throws Exception{return userDao.getTotalCount();}@SuppressWarnings("unchecked")public List getUsersByLike(User user) throws Exception{return userDao.getUsersByLike(user);}public int deleteUserByLike(User user) throws Exception{ return userDao.deleteUserByLike(user);}public void insertUsers(List<User> list) throws Exception{ for (int i = 0; i < list.size(); i++) {if (i > 3) {System.out.println("列表太长，中断事务");throw new RuntimeException("中断事务异常,当列表长度大于3的时候故意抛出，看看事务是否回滚");}User user = list.get(i);userDao.addUser(user);}}}(4)web层(界面控制层,UserController.java)UserController.javapackage com.archie.web;import javax.annotation.Resource;import javax.servlet.http.HttpSession;import javax.validation.Valid;import org.springframework.stereotype.Controller;import org.springframework.validation.BindingResult;import org.springframework.web.bind.annotation.PathVariable; import org.springframework.web.bind.annotation.RequestMapping; import org.springframework.web.bind.annotation.RequestMethod; import org.springframework.web.servlet.ModelAndView;import er;import erService;@Controller@RequestMapping("/user/*")public class UserController {@Resource(name="userService")private UserService userService;private final String LIST="redirect:/detail";/*** 登录* @param user* @param session* @return*/@RequestMapping("/login")public ModelAndView login(@Valid User user,BindingResult result,HttpSession session) throws Exception{if(!result.hasErrors()){User loginUser=userService.login(user);if(loginUser!=null){session.setAttribute("USER", loginUser);return new ModelAndView(LIST);}else{return new ModelAndView("redirect:/");}}else{ModelAndView view=new ModelAndView();view.setViewName("redirect:/");view.addObject("error", result.getAllErrors());return view;}}/*** 跳转至添加页* @return*/@RequestMapping(value="/toAdd",method=RequestMethod.GET) public ModelAndView toAdd(){return new ModelAndView("user/add");}/*** 保存* @param user* @return*/@RequestMapping(value="/add",method=RequestMethod.POST)public ModelAndView add(@Valid User user,BindingResult result) throws Exception{if(result.hasErrors()){return new ModelAndView("user/add","error",result.getAllErrors());}else{userService.addUser(user);return new ModelAndView(LIST);}}/*** 根据ID删除* @param id* @return*/@RequestMapping(value="/delete/{id}")public ModelAndView delete(@PathVariable int id) throws Exception{userService.deleteUser(id);return new ModelAndView(LIST);}/*** 跳转至编辑页面* @param id* @return*/@RequestMapping(value="/edit/{id}")public ModelAndView edit(@PathVariable int id) throws Exception{ User user=userService.getUserById(id);return new ModelAndView("user/edit","user",user);}/*** 编辑* @param user* @return*/@RequestMapping(value="/edit")public ModelAndView update(@Valid User user,BindingResult result)throws Exception{ModelAndView view=new ModelAndView();if(result.hasErrors()){view.addObject("error", result.getAllErrors());view.setViewName("user/edit");return view;}else{userService.updateUser(user);return new ModelAndView(LIST);}}}(5)test层(Java环境下测试)TestUserController.javapackage com.archie.test;import java.util.ArrayList;import java.util.List;import org.springframework.context.ApplicationContext;importorg.springframework.context.support.ClassPathXmlApplicationContex t;import er;import erService;public class TestUserController {public static void main(String[] args) throws Exception{ApplicationContext context = new ClassPathXmlApplicationContext("applicationContext.xml");UserService userService =(UserService)context.getBean("userService");List<User> list = new ArrayList<User>();list.add(new User("wang", "wang"));list.add(new User("wang", "wang"));list.add(new User("wang", "wang"));userService.insertUsers(list);System.out.println("恭喜恭喜，添加成功！");userService.deleteUser(26);System.out.println("恭喜恭喜，删除成功！");User beanUser = userService.getUserById(21);if (beanUser != null) {System.out.println("恭喜恭喜，查找成功！");}else {System.out.println("不好意思，您所查找的用户不存在！");}int totalCount = userService.getTotalCount();System.out.println("TotalCount="+totalCount);int result = userService.deleteUserByLike(newUser("wang","wang"));System.out.println("模糊删除的记录条数是："+result);List users = userService.getUsersByLike(newUser("meimei","1234"));if (users == null || users.size() == 0) {System.out.println("没有匹配的记录2");}else {for (int i = 0; i < users.size(); i++) {User user = (User)users.get(i);System.out.println("username="+user.getUsername()+",passwo rd="+user.getPassword());}}System.out.println("length="+users.size());}}。
