实验目的:浮动静态路由、负载均衡

1、拓扑

2、配置地址

R1配置

interface GigabitEthernet0/0/0

ip address 200.1.1.1 255.255.255.0

#

interface GigabitEthernet0/0/1

ip address 200.1.3.1 255.255.255.0

#

interface GigabitEthernet0/0/2

ip address 192.168.1.254 255.255.255.0

查看接口地址配置

[AR1]display ip interface brief

*down: administratively down

^down: standby

(l): loopback

(s): spoofing

The number of interface that is UP in Physical is 4 The number of interface that is DOWN in Physical is 0 The number of interface that is UP in Protocol is 4 The number of interface that is DOWN in Protocol is 0

Interface IP Address/Mask Physical

Protocol

GigabitEthernet0/0/0 200.1.1.1/24 up up GigabitEthernet0/0/1 200.1.3.1/24 up up GigabitEthernet0/0/2 192.168.1.254/24 up up NULL0 unassigned up up(s)

R2

#

interface GigabitEthernet0/0/1

ip address 200.1.2.2 255.255.255.0

#

interface GigabitEthernet0/0/0

ip address 200.1.1.2 255.255.255.0

R3

interface GigabitEthernet0/0/1

ip address 200.1.2.3 255.255.255.0

interface GigabitEthernet0/0/0

ip address 200.1.3.3 255.255.255.0

interface GigabitEthernet0/0/

ip address 192.168.2.254 255.255.255.0

3、配置路由

[AR1]ip route-static 192.168.2.0 24 200.1.3.3

[AR3]ip route-static 192.168.1.0 24 200.1.3.1

[AR2]ip route-static 192.168.1.0 24 200.1.1.1 去A

[AR2]ip route-static 192.168.2.0 24 200.1.2.3 去B

跟踪路由

4、配置浮动静态路由实现路由备份

[AR1]ip route-static 192.168.1.0 24 200.1.2.2 preference 100

[AR1]ip route-static 192.168.2.0 24 200.1.1.2 preference 100

查看路由表没有上面的路由条目,原因优先级高才写入路由表

192.168.2.0/24 Static 60 0 RD 200.1.3.3

[AR1]display ip routing-table protocol static

Route Flags: R - relay, D - download to fib

------------------------------------------------------------------------------

Public routing table : Static

Destinations : 1 Routes : 2 Configured Routes : 2

Static routing table status :

Destinations : 1 Routes : 1

Destination/Mask Proto Pre Cost Flags NextHop Interface

192.168.2.0/24 Static 600 RD 200.1.3.3 GigabitEthernet0/0/1

Static routing table status :

Destinations : 1 Routes : 1

Destination/Mask Proto Pre Cost Flags NextHop Interface

192.168.2.0/24 Static 1000 R 200.1.1.2 GigabitEthernet0/0/0

5、手动制造故障

[AR1]interface g0/0/1

[AR1-GigabitEthernet0/0/1]shutdown

浮动路由写入路由表

192.168.2.0/24 Stati c 100 0 200.1.1.2

---------------------------------------------------------------------------------------------------------------------

二、通过负载均衡实现网络优化

创建等价路由:优先级、cost、目标地址、掩码相同

[AR3]ip route-static 192.168.1.0 24 200.1.2.2

[AR1]ip route-static 192.168.2.024 200.1.1.2

[AR1]display ip routing-table protocol static

Route Flags: R - relay, D - download to fib

------------------------------------------------------------------------------

Public routing table : Static

Destinations : 1 Routes : 2 Configured Routes : 2

Static routing table status :

Destinations : 1 Routes : 2

Destination/Mask Proto Pre Cost Flags NextHop Interface

192.168.2.0/24 Static 60 0 RD 200.1.3.3 GigabitEthernet0/0/1 Static 600 RD 200.1.1.2 GigabitEthernet0/0/0

验证:在两条链路上抓包看有流量经过两条链路!
