电罗经安修斯STD-22技术资料

安修斯电罗经STD22及标准配备分罗经技术资料

1、（1）Standard 22 Compact Gyro Compass STD22电罗经1SET

1)Performance性能标准

Type型号：STD-22，产地：ANSCHUETZ德国

Power supply电源：DC24V

Automatic Speed Error Correction 自动速度误差校正

Automatic Dynamical Error Correction 自动动态误差校正

Type Approval (IMO) Including High Speed (70 knots) IMO认可,包括适用达70节高速船认

可

信号输出:

2 x NMEA or Course Bus NMEA或安修司Course总线

1 x Course Bus 安修司Course总线

4 x Status (Potential Free Contact) 状态输出(无源触点信号)

Signal Input From:

信号输入:

1 x NMEA 0183 From GPS (GLL/GGA) NMEA 0183从GPS

1 x log: 200 or 400 p/NM or NMEA 0183 and Direction 200或400脉冲/海里或NMEA 0183 148-450

2）Comprising设备配置

1 Master Compasses Standard 2

2 主罗经

1 Gyrosphere 罗经球

1 Supporting Liquid and Distilled Water 支撑液和蒸馏水

1 on Board Spare Parts 船用备件

1 NMEA/Course Bus Booster 1 input/8 outputs Serial booster NMEA/course bus

数字信号分配器，1进8出

1 AC-DC Converter (115/230 V AC, 24 V DC, 240 W)电源单元

（2）ANSCHUETZ Repeater Compass 安修司航向分罗经 133-560 1SET for flush mounting* - IP 23 嵌入安装–IP23

. self synchronizing 自同步

. large compass card (150 mm) 150mm的罗经指示盘

. analogue and digital display 模拟及数字显示

. heading source indication 航向信号指示

. ANSCHÜTZ course-bus system or NMEA 0183 安修司Course-bus信号或NMEA1083信号. dimmer button and anti-glare screen 调光按钮及防晕罩

（3）Bearing Repeater Compass 方位分罗经 133-407 2SETS Standard Type - IP 56 标准形式IP-56

Self Synchronizing 自同步

• ANSCHUETZ Course Bus-System or NMEA 0183 Input

接入安修司Course总线系统或NMEA 0183

• Large 360 Degree Compass Card 190 mm

直径为190毫米的360度读数盘

• Incl. Dimmer

包括调光

（4）Pelorus Stand方位分罗经立式支架 2SETS For bearing repeater 133-407 incl. junction box方位分罗经立式支架，带防水接线盒

（5）Bearing Sight CP 190方位圈 CP 190 1SET The bearing sight comes in a protective case for safe storage装在箱子里

（6）Repeater分罗经 133-558+ 1SET Repeater Compass 360° (wall mounting)/壁挂式安装

Self synchronizing/自同步

150 mm compass card/150mm罗盘

Dimmer/调光

（7）ANSCHUETZ Steering Control System/操舵系统 Bst.: 2140 1SET Dual FU with handwheel for dual FU-steering control with max 6 switch positions including CAN bus follow-up amplifier and feedback unit

双随动，手轮同步控制6个位置选择开关，总线连接

Flush Mounting* 嵌入安装

Comprising: 包括：

1 Dual FU Steering Insert随动手轮

1 Change Over Switch (

2 axes, 2x10 sw. poles, 6 sw. positions)六位模式选择开关

2 Steering Interface AS操舵接口板

2 Follow-Up Amplifier AS随动放大板

2 Rudder Feedback Unit Bus AS反馈单元（总线）

2 Lever Drive for Feedback Unit (450-700mm)反馈连杆

3 Dual NFU Tiller 12 Contacts非随动手柄

（8）Digital Autopilot Pilotstar D 安修司数字自动舵Pilotstar D 1SET

Flush Mounting* 嵌入安装

For Connection to Gyro Compass (ANSCHUETZ Course-Bus or 6 Step/Degree.) and For Control of Steering Gears with ON/OFF Solenoid Valves (MAX. 45 W) or For Control of Steering Gears with Proportional Signal Output (2 x ±10V) and Direct Input for upto 3 Tillers

连接电罗经（安修司Course总线或6步/度），控制舵机的开关电磁阀（最大45W），或控制舵机的对应信号输出(2 x ±10V) 以及3个舵柄的直接输入

Comprising:包括：

1 Operator Unit (IP 44) Incl. 2.5 m Cable* 操作单元(IP 44)，包括2.5m电缆

1 Connection Unit with Amplifier (IP 22) 带放大器的连接单元(IP 22)

1 Set on Board Spare Parts 船用备件
