VIS NIR BEAM CO2 / LASER BEAM PROFILER PROFILER CAMERA
LaserDec CL - Technical Data -
NEW
NEW
NEW
CL200
IMAGE CONVERTER
Spectral sensitivity: Clear aperture: Laser beam diameter (1/e 2): Intensity range *: Input power (max): With attenuation unit 0°: With attenuation unit 90°: Effective pixel size:
CL200 HP
High Performance
optimized for 10.6µm =20mm 1mm - 10mm
2
CL500
Standard
optimized for 10.6µm =30mm 1mm - 15mm
2
CL500 HP
High Performance
optimized for 10.6µm =30mm 1mm - 15mm
2
Standard
optimized for 10.6µm =20mm 1mm - 10mm 10W/cm - 1.000W/cm 200W up to 2kW up to 2.5kW x=78µm / y=73µm
2
20W/cm - 2.000W/cm 200W up to 2kW up to 2.5kW x=44µm / y=42µm*
2
10W/cm - 1.000W/cm 500W up to 2kW up to 3kW x=110µm / y=102µm
2
20W/cm2 - 2.000W/cm2 500W up to 2kW up to 3kW x=60µm / y=58µm*
CAMERA FEATURES
Sensor: Resolution: Bit depth (output): Frame rate: Interface: Mode: CCD 367 x 288pixel 8Bit up to 50Hz FireWire (IEEE1394a) cw or pulsed CCD 640 x 482pixel * 14Bit up to 40Hz * FireWire (IEEE1394b) cw or pulsed CCD 367 x 288pixel 8Bit up to 50Hz FireWire (IEEE1394a) cw or pulsed CCD 688 x 518pixel * 14Bit up to 25Hz * FireWire (IEEE1394b) cw or pulsed
SPECIFICATIONS
Mechanical dimensions (W x H x L): Weight: Electrical requirements: Storage temperature **: Operating temperature **: Humidity: Regulations: * different parameters on request ** without condensation 298mm x 141mm x 76mm 2.6kg AC120V / 240V; 48 - 63Hz; 320W 0°C…+60°C +5°C…+35°C 20%...80% CE, RoHs 298mm x 141mm x 76mm 2.6kg AC120V / 240V; 48 - 63Hz; 320W 0°C…+60°C +5°C…+35°C 20%...80% CE, RoHs 340mm x 165mm x 92mm 3.3kg AC120V / 240V; 48 - 63Hz; 570W 0°C…+60°C +5°C…+35°C 20%...80% CE, RoHs 340mm x 165mm x 92mm 3.4kg AC120V / 240V; 48 - 63Hz; 570W 0°C…+60°C +5°C…+35°C 20%...80% CE, RoHs
Design and specification of the described product(s) are subject to change without notice.
CINOGY GmbH Max-Näder-Str. 15 · 37115 Duderstadt · Germany Phone +49 5527 8483770 · Fax +49 5527 8483773 e-mail info@cinogy.com · www.cinogy.com
CO2 LASER BEAM PROFILER
LaserDec CL - Dimensions -
LaserDec CL200
LaserDec CL500
CINOGY GmbH Max-Näder-Str. 15 · 37115 Duderstadt · Germany Phone +49 5527 8483770 · Fax +49 5527 8483773 e-mail info@cinogy.com · www.cinogy.com
CO2 LASER BEAM PROFILER
LaserDec CL - Operational Range -
LaserDec CL200
LaserDec CL200HP
CINOGY GmbH Max-Näder-Str. 15 · 37115 Duderstadt · Germany Phone +49 5527 8483770 · Fax +49 5527 8483773 e-mail info@cinogy.com · www.cinogy.com
CO2 LASER BEAM PROFILER
LaserDec CL - Operational Range -
LaserDec CL500
LaserDec CL500HP
CINOGY GmbH Max-Näder-Str. 15 · 37115 Duderstadt · Germany Phone +49 5527 8483770 · Fax +49 5527 8483773 e-mail info@cinogy.com · www.cinogy.com
