VISU200 plus 操作指南
VISU 200 plus/S88 操作指南1．准备工作：将手术显微镜推到手术位置，踩下脚踏板，显微镜的轮子将被锁住（注：这时请不要推动显微镜）。
轻轻踩下脚踏板可以把轮子从锁住状态释放出来。
2．限位调节（如右图）：逆时针松开旋钮1，按下电磁锁开关，调节主镜的高低到一个可能需要的最低安全位置（以不会碰到病人为准），松开按下电磁锁开关锁住支架，顺时针旋转旋钮1直至旋紧。
3．开机及设置：按下位于支架上的电源开关，系统自动进入默认模式，控制面板上显示上一次关机时的用户ID号。
按下Mode键进入速度模式，调节变焦、变倍和XY水平移动的速度。
总共可以预先存储9组不同设置，同时按下Mode和Store进入设置模式，如左图：4．调节平衡（除非增减附件或改变助手镜的位置，不必每次开机都调节平衡）：如右图，使用旋钮2调节整个显微镜上下的配重平衡，顺时针旋转增大向上的拉力，逆时针旋转降低向上的拉力。
5．脚控的设置和功能：⑴XY水平移动控制摇杆；⑵降低光亮度⑶调焦和XY水平移动复位；⑷变倍▼；⑸变倍▲；⑹照明开关；⑺无功能(预留位置)；⑻调焦▲；⑼调焦▼；⑽控制其它设备，如照相（需该设备支持）⑾增加亮度。
6．显微镜各部位示意图：如下图，⑴自动复位按钮，调焦和XY 水平移动系统都回到中心位置；⑵瞳距调节旋钮；⑶目镜；⑷屈光补偿旋钮；⑸电磁锁手柄开关；⑹倍率显示；⑺助手镜变倍调节；⑻助手镜焦距微调旋钮；⑼调节主镜倾斜角度旋钮；⑽调焦范围及位置指示；⑾助手镜倾角调节旋钮；⑿手动变倍调节；⒀照明方式选择旋钮；⒁＋6°光照明；⒂光纤接口；⒃助手镜锁紧装置；⒄DeepView智能景深增强系统。
7．开始使用：a)调节双目镜筒旋钮1（如右图），使两个目镜下的图象合二为一。
b)目镜的调节：1. 调节眼杯的高低：当术者佩戴眼镜使用手术显微镜时，需要将眼杯完全旋入目镜；反之，可以根据用户的使用习惯将眼杯旋出，旋出的程度根据术者的感觉来调节。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
消色差
复消色差
当光线通过光学系统时会发生棱镜效应
，
传统的显微镜采用消色差光学 （achromatic） 来纠正色差，即使可见光谱中二个不同波长 的颜色光聚焦在一个平面上，但其余的波长 光并不同焦从而导致了色差和图象对比度下 降 复消色差光学采用多点波长纠正，从而彻底 纠正了色差并大大提高了对比度（尤其在图 象边缘）和清晰度。
•
内置裂隙照明光应用: – Anterior vitrectomy – Dense cataract capsulorhexis – Lens extractions
水平，可移动
垂直
2.5 or 5 mm width
2.5 mm width
支架面板（卤素灯配置时）
• • • • 主电源 后备电源 功能设定键 大屏幕液晶参数显示
Байду номын сангаас
蔡司手术显微镜中用来避免病人光损伤的设计
• 1.显微镜的通光量大大提高,用较低的亮度即可在目镜 中看到明亮的图象(亮度0.3,最大1.5) • 2.不可见的UV紫外光滤光片 • 3.GG475滤光片滤掉所有波长475nm以下的光线。 • 4.专利的视网膜保护装置 • 5.冷光源：其反射曲面使红外光不能聚焦从而滤掉红外 光。
S88支架系统
• 1.支架无重式移动，各关节电磁锁功能。手术中如需 紧急移开显微镜可瞬间完成.左右手柄可分别控制XY平 面和Z轴运动以方便术前消毒及显微镜粗调 • 2.全防水脚控可控制光源亮度、开关、平移、调焦、 变倍。 • 3.XY平移速度根据倍数大小自动调整。 • 4.调焦、XY平移、放大倍数自动回原功能。. • 5.多种记忆功能(亮度,变倍速度,调焦速度,XY移动速 度,焦平面). • 6.采用大直径轮子方便移动，四轮均可转向. • 7.手柄可控制IMAGEBOX（选件）的单张取像.
• 新的REDFLEX设计使红光反射大大增强
• 智能景深调节系统 Depth of Field Management System • ► 打开该开关时: • 加大景深Optimum depth of field at all magnification levels • ► 关闭该开关时: • 保持最大的通光量 和分辨率
卤素灯灯箱（双电源，四灯泡）
• 主电源灯箱(手术中 灯泡坏,备用灯泡会 自动切换) • 后备电源灯箱 • 滤光片选择
支架说明
• 1.推拉扶手 • 2.导线和脚控悬挂处 • 3.导向轮（大脚轮以 方便显微镜在不同手 术室之间移动）
支架电磁锁
• 支架关节有电磁锁, 只要按下电磁锁开关 ,显微镜体可在无重 状态下移动 • 电磁锁开关
四光路结构，副手 主刀镜不分光 助手镜 助手的左右眼均 有好的红反射
主镜
M841助手镜的一个眼无红光反射
白光照明
• 氙灯照明优点:
– – – – 白色，自然光 摄像效果好 对比度好，尤其是白/红 图象清晰度高
卤素灯
氙灯
对眼睛光损伤的对比
卤素灯 氙灯
光亮度设定在1.0时的对比 (equivalent phototoxicity hazard potential of 500 mW/cm² *sr, weighted according to hazard function)
蔡司VISU200p高级眼科手术显微镜
• Carl zeiss shanghai
光学系统
• 1.最优的光学性能：独有的复消色差(apochromatic)和T*镀膜技术保证了 最优的清晰度和对比度，光路设计能保证医生长时间手术眼睛不疲劳，具 有极好的景深和立体感。
• 2.采用12V、100W冷光源照明，新设计的光路提高透光性能50%以利于用眼 内光纤照明的眼底手术。（是目前透光性最好的手术显微镜,符合新的ISO 光损伤标准),采用螺纹防折光纤. • 1:6无级变倍。最好的机械工艺（保证长的使用寿命），目镜和物镜最新采 用超级防反光及超硬镀膜（防止擦镜时对光学面的损伤）。
