成都温江万春英郦庄园景观概念设计_AECOM

1.1 项目概述及区域定位Project Context and Location本案位于温江区万春镇温郫公路旁（江安河北侧），净用地规模约56.66 亩，地块西至东南面江安河畔置信香颐丽都三期地块；西南：临规划道路，对面为万春镇镇政府，目前在建；地块整体呈现不规则U字形。

西面毗邻温郫路、北接万民路。

东面、南面皆为市政规划道路。

The project site situates at Wanchun town, Wenjiang district, where is next to Wenpi road (to the north of Jiangan river); net land use areas are about 56.66 mu (1mu=666.667 sq.m), to the southeast of the site is Jiangan river-side Zhixin XiangYiLiDu phase 3’s plot; its southwest boundary will be adja-cent to the municipal planning road, and also opposite to the under constru-cting office building for Wanchun local government. The overall site plot is in a irregular U-shaped. Its western boundary is adjacent to Wenpi road; north boundary is adjacent to Wanmin road, to the east and south where wi be the municipal planning roads.场地照片Site Photo1.2 项目建筑风格理解Existing Architecture Style Comprehension本案住宅主要是多层洋房，共十栋单体拼合体。

公建有临街商铺和独立商业。

建筑风格为泛地中海，公建以南加州圣·芭芭拉风格为原型,并融入地中海托斯卡纳风格的某些元素,住宅以托斯卡纳风格为蓝本。

红瓦、白墙、木构架、毛石墙面等元素体现出朴实、自然的山野气息。

The Residential including 10 multilayer buildings,and include commer-cial street and clubhouse for individual commercial central.The Archi-tecture is Extensive Mediterranean Sea Style.The clubhouse followSt.Barbara Style within South California and combine the Tuscanycharacter; Red tile,White Wall,Timber Trellis,Stone wall to express na-trual,simple village elements and mountain atmosphere.1.3 周边用地关系及空间分析Proposed Land use & Space analysis本案南北入口为主要出入通道，南部会所入口广场定位为重要景观焦点。

中心园林景观位于地下车库顶板之上，主要由中心活动空间及三个特色组团花园、半公共花园空间及三个入口构成。

西北部为西班牙风情商业空间。

西部与临时绿地相邻，建议采用多层次的绿化缓冲带进行屏蔽。

Major accesses to the site will be respectively set at north and south. Club entrance plaza near to the south access will be design as a significant landscape focus. Central garden will be located on the roof top of underground parking lot. It will be composed by central activities space three special courtyards, semi-private garden and three entrances. Spanish style commercial spaces will be laid in western and northern parts. Southwest part is adjacent to the temporary green space; therefore, propose to adopt multi-layer green buffers as barriers.中心庭院Central Garden北入口庭院North EntranceGarden半公共活动空间Semi-public Space半公共活动空间Semi-public Space临时绿地Temporary Landscape南入口庭院South EntranceGarden公共花园活动空间Public Space 半公共花园活动空间Semi-public Space 绿化屏蔽Buffer 住户私家花园Private Garden 商业街景观Commercial Streetcape 临时绿化景观Temporary Landscape 主入口Main Entrance 次入口Secondary Entrance图例Legend半公共活动空间Semi-public Space半公共活动空间Semi-public Space半公共活动空间Semi-public Space主要观景点Main Focal Point次要观景点Secondary Focal Point主视线Main View俯瞰视线(从建筑俯瞰)View from Building 外部视线View from Road图例Legend通过对夏至、冬至一天三个时间段内(上午9：00，中午12：00，下午16：00)的日照进行分析，南部及中央庭院区域日照比较充足，建议将主要活动空间设置于此处，植栽方面考虑采用冠幅较大，遮荫能力强，喜阳性植物进行配置，植物形态要大气、典雅，充分体现西班牙皇家庭院的高雅氛围。

北部入口庭院由于地形狭长，日照稍弱，建议采用较耐荫的乔木、树篱烘托西班牙风情入口。

组团庭院属于围合空间，日照最弱，建议安排休憩性、私密性的活动空间，树种采用耐荫性强的乔灌木，为弱化阴影对周边环境的影响，中下层植物建议采用色彩丰富的花园式手法设计。

The sunlight analysis at three different times (9: 00am, 12:00am, and 4:00pm) in the summer solstice and the midwinter days shows: there will be adequate sunshine in southern and central garden areas, thereby, major activities spaces advocate to be set here, for trees species, sun-loving trees species with large canopy, and able to provide large shade spaces underneath will be preferred, for the profile selection stretched,elegant tree species which can fully represent the elegant characteristic of Spanish royal garden will be preferred. The courtyard near to north entrance will be long and narrow; the sunshine there supposes to be abated, so that recommends to adopt shade-tolerant tree species and hedge to create a Spanish style entrance. The courtyard enclosed by residential buildings supposes to be inadequate sunshine, in that case leisure and private activities spaces suggest to be laid there, for plants selection, shade tolerant tree and shrub species will be preferred; in addition, in order to minimize the shadow effect to the space, plants with colorful flowers in middle and low landscape level will be proposed in design.各区域日照强度分析Sunlight Intension Analysis日照较充足区域Abundant sunlight area日照普通区域Ordinary sunlight area 日照较弱区域Weak sunlight area 夏至Summer Solstice 冬至Winter Solstice16：0012：009：0016：0012：009：00欧洲最为著名的中世纪晚期城堡宫殿建筑群—阿尔罕布拉宫，位于西班牙格拉达城外西南方的山岗上。

为中世纪摩尔人所建,它是宫殿庭院建筑的优秀代表之一。

“阿尔罕布拉宫”阿拉伯语即“红色城堡”。

狮子院和石榴院是王宫的两个主要建筑群。

其中狮子院因院子正中喷水池上水盘的十二只石狮群雕而得名，水池庭院空间秩序感良好，比例完美，建筑造型和雕饰富于伊斯兰纤细精致的特色。

The best and most famous late-medieval castle gardens in Euro-pe stand on a fortified plateau, across a valley from the Generalife and surrounded by the Sierra Nevada mountains.Before reaching Spain, the Moors had seen and occupied Roman villas.The overall plan of the plateau resembles that of Hadrian's Villa.In Arabic, Alhambra means Red Castle.The Lion Fountain, fromwhich the brilliant Court of the Lions takes its name, dates fromthe eleventh century. The Court of the Pool is ordered, beautifully proportioned and rich in Islamic detail. The palace windows frame views of the surrounding landscape, as though they were orientalminatures.2.2 拉里弗花园Case Study 02__Generalife Garden拉里弗花园中的长形水池庭院或许是欧洲曝光率最高的花园庭院之一。
