高温高压稠化仪-科力奥尔

天津科力奥尔工程材料技术有限公司第三节高温高压稠化仪1 高温高压稠化仪的用途高温高压稠化仪是严格按照API 规范10的要求进行设计制造的，用以模拟井下高温高压状态，测定水泥浆的稠化时间，从而确定安全的施工时间。

2 高温高压稠化仪的结构和原理高温高压稠化仪由高压釜体、磁力驱动器、超高压泵、气动液压管路系统、温度控制仪及加热器、釜盖起吊装置、电气控制装置、浆杯、浆叶、用于测量稠度的电位器、冷却系统和壳体组成。

釜体是由特种高强钢构成，而且能承受很高的工作温度和压力。

釜内压力由一个气动超高压泵提供，稠化仪导热油经油箱、油滤、各阀门，由压缩空气压入釜内，再由超高压泵加压，提供初始压力。

高温高压稠化仪的最大工作温度为315℃，最大工作压力为275Mpa ，釜内部使用一个额定功率为2500瓦的加热器。

三笔记录仪与仪器相连，可同时记录釜内温度和浆杯里的水泥浆稠度随时间的变化曲线，浆杯由磁力驱动器带动，以顺时针150r/min 恒速转动。

高温高压稠化仪装有两支J 型热电偶，用来测量油温和水泥浆的温度。

温度调节器显示热电偶测定的温度，并可设定和控制程序升温,压力由压力调节器控制程序升压和恒压，釜内温度和压力即是模拟固井施工作业时的井下温度和压力。

在高压回油管路中，装有单向油滤，滤出油中各种杂质和水泥颗粒。

高压管路装有爆破碟片，可以承受310Mpa 的压力，这是超压的最后保护装置，用来保护整个超高压系统的安全，当碟片破裂时，油随即排到油箱中。

水泥浆杯上部有一个大容积的帽子，由于高温试验时，水泥浆膨胀厉害，会产生溢出现象，此帽就是捕获试验中密封不严，防止水泥浆溢出，污染釜体和油等作用。

测试水泥浆稠度时，水泥浆注入浆杯中，浆杯由磁力驱动器带动，电位计与浆叶轴上的驱动档固定好，水泥浆相对浆叶转动，浆叶受到阻力，使电位计上的弹簧变形。

稠度与扭矩成正比，随着弹簧扭矩及指针旋转角度的增大，电位计的电阻值及电压也随之增大，因此电位计所反应出来的电压值，不仅表示了弹簧扭矩的大小，也反映了测量水泥浆稠度值的大小。
