混合离子交换器Mixed of ion exchange
使用说明书Operating Instruction
一、工艺原理Technical principle
本公司生产的混合离子交换器(简称混床),在脱盐水工程中,用于二级脱盐水的制备,被处理的水由上向下流经按一定的比例配比装填并混合形成的强酸、碱树脂层来制取成品水。均匀混合的树脂层中,阳树脂与阴树脂紧密地交错排列,每一对阳树脂与阴树脂颗粒似于一组复床,混床就象无数组串联运行的复床。通过混合离子交换后进入水中的氢离子与氢氧离子会立即生成电离度很低的水分子(H2O),很少可能形成阳离子或阴离子交换时的反离子,使交换反应进行的十分彻底,因而能制取纯度相当高的成品水。
Our company produces the mixed ion exchanger (referred to as ") of the mixed bed, in desalted water engineering, preparation for secondary desalting water, treated water by the down flow of mixed in certain proportion ratio of loading and the formation of acid, alkali, resin layer to manufacture the finished water. Evenly mixed resin layer, with Yin Yang resin resin tightly staggered, each pair of Yang Yin resin particles and resin on a set of double bed, mixed bed, like countless group of double bed series operation. After ion exchange in the water by mixing hydrogen ion and hydroxide ion will immediately generate low degree of ionization of water molecules (H2O), less likely to form the cation or anion exchange of ions, make the exchange reaction of very thoroughly, thereby making high purity of the finished water.
混床的再生工艺较阳、阴床的再生工艺复杂,混床树脂层失效后,需先对床中树脂进行反洗分层,使阳树脂与阴树脂彻底分离,然后分别对阳、阴树脂进行再生、清洗、恢复交换能力并均匀混合,方可继续投入运行。
Mixed bed regeneration process is cation exchanger、anion exchanger regeneration process complex, mixed bed resin layer expires, should first to backwashing stratification of resin in the bed, make with cation resin and anion resin separation thoroughly, then respectively for cation resin、anion resin regeneration, cleaning, restore the exchange capacity and mixing, may continue to put into operation.
二、技术参数Technical parameters
1.进水Inlet water:一级脱盐水或RO产水Level of desalted water or Reverse osmosis water
2.出水水质Effluent quality:< 0.2μS/c m(25℃)
SiO2泄漏<20ug/l,PH接近中性
SiO2 leak < 20 ug/l, the PH near neuter
3.工作压力Working pressure: < 0.6MPa
4.工作温度Working temperature: 5-45℃
5.运行流速Operating velocity: 40-60m/h
6.水反洗强度Water backwashing strength: 8-12m/h
7.再生流速Regeneration velocity: 4-6m/h
8.再生液浓度Renewable liquid concentration: 4-5%
9.填料高度Packing layer height: 阳树脂Cation resins001X7\阴树脂Anion resins201X7:
500mm\1000mm
三、结构形式Structure form
设备由本体、布水装置、集水装置、外配管及仪表取样装置等组成。进水装置为上进水、挡板布水,集水装置为多孔板滤水帽集水;设备的本体外部配管配带阀门并留有压力取样接口,便于用户现场安装和实现装置正常运行。
Equipment by ontology, cloth water equipment, water equipment, piping and instrument sampling device, etc. Feed device for water, baffle on water distribution, water catchment device for porous plate filter water cap; External piping equipment ontology matching valve and had pressure sampling interface, making it easy for users to the site installation and equipment normal operation.
四. 设备的安装The installation of the equipment
1)安装前检查土建基础是否按设计要求施工。
1)Before the installation check whether civil engineering foundation construction according to design requirements.
2)设备按设计图纸进行就位,调整支腿垫铁并检查进出口法兰的水平度和垂直度。
2)Equipment in place in accordance with design drawings and leg to adjust shim and check the levelness of the import and export of the flange and verticality.
3)将设备和基础预埋铁板焊接固定,固定后再次校验进出口法兰的水平度和垂直度。
3)Based embedded iron welding equipment and fixed, fixed after once again check the levelness of the import and export of the flange and verticality.
