基于wifi的智能指纹密码锁设计

摘要

近年来随着社会经济的迅速进展，信息，安防产品的在安全性方面的危险越来越高，人们对个人隐私的爱护意识也越来越强，同时随着物联网技术的进展，人们对安全的，便利的安防产品的需求越来越迫切。本课题主要研究基于WiFi的智能指纹密码锁的设计，致力于利用指纹识别技术和WiFi技术对指纹密码操控门锁和手机操控门锁的实现和设计，使门禁系统更加安全，更加便利。

论文系统地阐述了指纹识别技术和WiFi通信的进展，指纹识别技术的与单片机的结合使用技术、WiFi实现手机与单片机通信的技术、系统硬件设计和软件实现等。通过研究论证、设计实现了利用WiFi通信技术和指纹识别技术对门锁进行操控。通过不断地试验、分析、调试以及对各子模块电路设计。最终实现了通过指纹模块FPM10A进行指纹添加，搜索，比对，删除功能，实现对门锁的操纵，以及通过WiFi模块ESP8266实现手机app对门锁的操纵，成功设计出WiFi与指纹识别技术相结合实现物联网的操纵系统。

关键词：物联网、WiFi、单片机、指纹识别、门锁

ABSTRACT

In recent years, with the rapid development of social economy, information, security products in the security risk is more and more high, people's awareness of the protection of personal privacy is also more and more strong, also with the development of networking technology, people on the safety and convenient security products demand more and more urgent. The main content of this paper is to study the design of WiFi intelligent fingerprint password lock based on, is committed to by using fingerprint identification technology and WiFi technology of fingerprint password control lock and control the phone lock implementation and design, so that access control system more secure, more convenient.

Paper systematically describes the development of fingerprint identification technology and WiFi communication are systematically elaborated in this thesis, the combination of fingerprint identification technology and Microcontroller use WiFi, achieve the realization of mobile phone communication with the MCU technology, hardware design and software system. Through research and demonstration, the design and implementation of the WiFi communication technology and fingerprint identification technology to control the door lock. Through continuous experiment, analysis, debugging and the design of the circuit of each sub module. Realize through fpm10a fingerprint module to the fingerprint add, search, comparison, delete function, the door lock control, and realize mobile app to the door lock control through the WiFi module esp8266 and successfully design a WiFi and fingerprint recognition technology are combined to realize the controlling system of Internet of things.

Keywords:Things, WiFi，Microcontroller, fingerprint identification, door lock

目录

第一章绪论 (1)

1.1 引言 (1)

1.2 选题背景与意义 (1)

1.3 门禁系统技术的研究状况 (1)

1.4 本文的结构 (3)

第二章系统总体方案设计 (3)

2.1 指纹识别技术和WiFi通信技术概述 (3)

2.1.1 指纹识别技术的原理和特点 (4)

2.1.2 WiFi通信技术的原理及特点 (4)

2.2 基于wifi的智能指纹密码锁设计的整体方案 (5)

第三章系统硬件设计 (5)

3.1 基本工作原理和框图 (5)

3.1.1 系统工作原理 (5)

3.1.2 系统原理框图 (6)

3.2 主控芯片的选择及电路设计 (6)

3.2.2 振荡电路设计 (9)

3.2.3 显示部分电路设计 (9)

3.2.4 继电器电路设计 (10)

3.2.5 按键电路设计 (11)

3.3 功能模块设计 (12)
