柴油机工作过程计算..

Option Explicit

Dim n, nn, pr, po As Single

Dim tr, pa, s, d, vh, kkk As Single

Dim pab, e, paa, pad, pac As Single

Dim tt, T, yy, fa, X, Y, ta As Single

Dim nv, n1, tc, jx, pc, fx As Single

Dim l, vc, Va, gc, gh, g0 As Single

Dim vcx, r, lo, A, mt, m1, m2, u0, u As Single

Dim khu, cv1, cv2, tz, ccc, hu, qq, aaa, bbb As Single

Dim l8, n2, pz, H, tb, pi1, pi, φx, φ, p As Single

Dim fi, pm, nm, ni, gi, ne, pe, ge, nne, i, v, pb, pcx, vbx, pbx As Double

Dim aa(50), ylsgb As Single

Private Sub Command4_Click()

Picture1.Cls

Picture1.ForeColor = vbGreen

Picture1.DrawWidth = 1.5

Picture1.Scale (-0.1, 99)-(1, -10)

Picture1.Line (0, 0)-(0, 95) 'y轴

Picture1.Line (0, 0)-(0.95, 0) 'x轴

Picture1.Line (0.93, 1)-(0.95, 0)

Picture1.Line (0.93, -1)-(0.95, 0)

Picture1.Line (0.015, 94)-(0, 95)

Picture1.Line (-0.015, 94)-(0, 95)

For i = 1 To 9 Step 1

Picture1.Line (0, i * 10)-(0.015, i * 10)

Picture1.Line (0.1 * i, 0)-(0.1 * i, -1)

Picture1.CurrentX = -0.1: Picture1.CurrentY = 10 * i + 3: Picture1.Print i * 10

Picture1.CurrentX = 0.1 * i - 0.04: Picture1.CurrentY = -3: Picture1.Print "0" & i * 0.1 Next i

Picture1.CurrentX = 0: Picture1.CurrentY = 95: Picture1.Print " P （atm）"

Picture1.CurrentX = 0.8: Picture1.CurrentY = 10: Picture1.Print "V （L）"

'压缩过程曲线

If vh = 0 Then

MsgBox "请先输入参数,并计算", 0, "提示": GoTo q

End If

vc = vh / e

Dim X As Single: Dim pcx, vcx As Single

Picture1.DrawWidth = 1.3

Picture1.Line (vc, 10 * po)-(0.9, 10 * po)

Picture1.Line (vc, po)-(vc, 88)

Picture1.DrawWidth = 1.5

Picture1.ForeColor = vbYellow

For X = v To vc Step -0.0001

vcx = X

pcx = pa * (v / vcx) ^ n1

Picture1.PSet (vcx, pcx)

Next X

'燃烧过程曲线

Picture1.Line (vcx, pcx)-(vc, pz)

'膨胀过程曲线

Dim vbx, pbx As Single

Picture1.Line (vc, pz)-(vc * p, pz): vc = vc * p

For X = vc To v Step 0.0001

vbx = X

pbx = pz * ((vc / vbx) ^ n2)

Picture1.PSet (vbx, pbx)

Next X

'排气过程曲线

Picture1.Line (vbx, pbx)-(v, pa)

Picture1.DrawWidth = 1

Picture1.ForeColor = vbRed

Picture1.CurrentX = 0.1: Picture1.CurrentY = 8: Picture1.Print "po"

Picture1.CurrentX = 0.02: Picture1.CurrentY = 20: Picture1.Print "vc"

q:

End Sub

Private Sub Command1_Click()

s = Val(Text2.Text): d = Val(Text4.Text)

n = Val(Text1.Text): po = Val(Text15.Text) / 10:

e = Val(Text5.Text): tt = Val(Text17.Text): fa = Val(Text18.Text): r = Val(Text2.Text)

l = Val(Text31.Text) / 3.14 / ((d / 2) ^ 2)

gc = Val(Text11.Text): gh = Val(Text12.Text): g0 = Val(Text8.Text)

A = Val(Text19.Text): mt = Val(Text20.Text): fi = Val(Text9.Text): i = Val(Text3.Text)

n1 = Val(Text14.Text): n2 = Val(Text33.Text)

'排气过程

pr = Int(1000 * 10.8 * po) / 1000: tr = 350 / (1.2 / Log(n) * Log(10) + 0.005 * (e - 3) + 0.01 * (fa - 1)): hu = 42500 '柴油机暂时先赋的值

'进气过程
