XX网银系统性能问题分析总结

一、问题现象

通过对测试系统进行初步的分析，其WAS的JVM内存、线程池和数据源连接池并未发现配置上的问题。

根据测试人员描述：测试系统进行长时间的压力测试过程，存在性能稳定性较差，部分场景的测试指标不达标的情况。

二、系统环境

WAS 7.0

初始堆：2048MB

最大堆：4096MB

三、测试分析

1、查询转账记录，此场景测试超时失败，收集javacore分析发现进行数据库操作返回缓慢，代码堆栈如下：

at .SocketInputStream.socketRead0(Native Method)

at .SocketInputStream.read(SocketInputStream.java:129)

at com.ibm.db2.jcc.t4.x.b(x.java:208)

at com.ibm.db2.jcc.t4.x.c(x.java:360)

at com.ibm.db2.jcc.t4.x.c(x.java:473)

at com.ibm.db2.jcc.t4.x.v(x.java:1241)

at com.ibm.db2.jcc.t4.bb.c(bb.java:30)

at com.ibm.db2.jcc.t4.q.a(q.java:32)

at com.ibm.db2.jcc.t4.i.readFetch_(i.java:263)

at com.ibm.db2.jcc.am.ResultSet.flowFetch(ResultSet.java:3796)

at com.ibm.db2.jcc.t4.c.f(c.java:2386)

at com.ibm.db2.jcc.am.fc.a(fc.java:208)

at com.ibm.db2.jcc.t4.c.a(c.java:127)

at com.ibm.db2.jcc.am.ResultSet.nextX(ResultSet.java:381)

at com.ibm.db2.jcc.am.ResultSet.next(ResultSet.java:308)

at com.ibm.ws.rsadapter.jdbc.WSJdbcResultSet.next(WSJdbcResultSet.java:3120)

at com.ecc.emp.jdbc.procedure.ProcedureOpForDB2.processResultSets(ProcedureOpForDB2.java:143)

at com.ecc.liana.jdbc.procedure.ProcedureAccessService.executeProcedure(ProcedureAccessService.java:123)

at com.ecc.liana.action.ProcedureAccessAction.execute(ProcedureAccessAction.java:170)

at com.ecc.emp.flow.EMPFlow.execute(EMPFlow.java:196)

at com.ecc.emp.flow.Operation.execute(Operation.java:91)

at com.ecc.emp.flow.EMPBusinessLogic.execute(EMPBusinessLogic.java:89)

at com.ecc.emp.web.servlet.mvc.EMPRequestController.executeEMPLogic(EMPRequestController.java:604)

at com.ecc.emp.web.servlet.mvc.EMPRequestController.executeTheFlow(EMPRequestController.java:487)

at com.ecc.liana.controller.LianaRequestController.doRequest(LianaRequestController.java:147)

at com.ecc.emp.web.servlet.EMPRequestServlet.service(EMPRequestServlet.java:430)

at javax.servlet.http.HttpServlet.service(HttpServlet.java:831)

2、跨行转账，此场景测试响应时间较长，收集javacore分析发现进行数据库操作返回缓慢，代码堆栈如下：

at java/net/SocketInputStream.socketRead0(Native Method)

at java/net/SocketInputStream.read(SocketInputStream.java:129(Compiled Code))

at com/ibm/db2/jcc/t4/x.b(x.java:208(Compiled Code))

at com/ibm/db2/jcc/t4/x.c(x.java:360(Compiled Code))

at com/ibm/db2/jcc/t4/x.c(x.java:473(Compiled Code))

at com/ibm/db2/jcc/t4/x.v(x.java:1241(Compiled Code))

at com/ibm/db2/jcc/t4/cb.b(cb.java:141(Compiled Code))

at com/ibm/db2/jcc/t4/T4XAConnection.readTransactionStart(T4XAConnection.java:302(Compiled Code))

at com/ibm/db2/jcc/am/Agent.beginReadChain(Agent.java:358(Compiled Code))

at com/ibm/db2/jcc/t4/a.beginReadChain(a.java:748(Compiled Code))

at com/ibm/db2/jcc/am/Agent.flow(Agent.java:232(Compiled Code))

at com/ibm/db2/jcc/am/jo.b(jo.java:4283(Compiled Code))

at com/ibm/db2/jcc/am/jo.ec(jo.java:735(Compiled Code))

at com/ibm/db2/jcc/am/jo.executeQuery(jo.java:708(Compiled Code))

at com/ibm/ws/rsadapter/jdbc/WSJdbcPreparedStatement.pmiExecuteQuery(WSJdbcPreparedStatement.java:1082(Compiled Code))

at com/ibm/ws/rsadapter/jdbc/WSJdbcPreparedStatement.executeQuery(WSJdbcPreparedStatement.java:703(Compiled Code))

at com/ecc/liana/loaf/action/QueryDataListUsingSpecialSQLAction.execute(QueryDataListUsingSpecialSQLAction.java:110(Compiled Code))

at com/ecc/emp/flow/EMPFlow.execute(EMPFlow.java:196(Compiled Code))

at com/ecc/emp/flow/Operation.execute(Operation.java:91(Compiled Code))

at com/ecc/emp/flow/EMPBusinessLogic.execute(EMPBusinessLogic.java:89(Compiled Code))

at com/ecc/emp/web/servlet/mvc/EMPRequestController.executeEMPLogic(EMPRequestController.java:604(Compiled Code))

at com/ecc/emp/web/servlet/mvc/EMPRequestController.executeTheFlow(EMPRequestController.java:487(Compiled Code))

at com/ecc/liana/controller/LianaRequestController.doRequest(LianaRequestController.java:147(Compiled Code))

at com/ecc/emp/web/servlet/EMPRequestServlet.service(EMPRequestServlet.java:430(Compiled Code))

at javax/servlet/http/HttpServlet.service(HttpServlet.java:831(Compiled Code))

3、行内转账，此场景测试响应时间较快，测试过程中存在响应时间小幅波动的情况，收集测试过程中javacore进行分析，并未发现明显问题。其中有个别偶发的异常情况建议关注：

个别线程短时间内出现日志输出排队的情况，如下图"WebContainer : 94"后面有11个线程排队。

at java/lang/Object.wait(Native Method)

at java/lang/Object.wait(Object.java:167(Compiled Code))

at org/apache/log4j/AsyncAppender.append(AsyncAppender.java:104(Compiled Code))
