巩达牌GD-20A雕刻刀万能磨刀机使用说明书

万能磨刀机UNIVERSAL CUTTER GRINDER

型号:GD-20A

Model：GD-20A

Operation Manual

使用说明书

Series No.: Max Wheel Dia:100 MM

出厂编号最大砂轮直径

Voltage：Power;0.375

电压: 功率: 0.375 KW Inspector: Manufacture Date；

检验员: 出厂日期:

GD-20A万能磨刀机

UNIVERSAL CUTTER GRINDER

一、PERFACE

U2万能磨刀机，是随着市场上雕刻业的发展，而精心设计的，主要由机体、砂轮、主轴、驱动装置，微量进给及砂轮整形器、刀架所组成，结构新颖、造型美观、精度高、性能好、使用简单、维修方便、适用：电脑雕刻机、机械雕刻机、模具雕刻机及其高速旋转锥尖刀头、棱磨刃和铣刀端刃，磨削角度准确。是目前万能磨刀机配备较先进的磨刀机型，我公司以质量第一，服务至上为宗旨，诚恳为广大模具雕刻机、电脑雕刻用户服务。

GD-20A Universal Cutter Grinder, with development of the carved industry, precisely designed by engineers. It is made up by main unit, wheel, spindle, drives, micro-feed and the grinding wheel dresser, knife the composition, structure, novel, modeling beautiful, high precision, good performance, easy to use, easy maintenance, applicable: computer engraving machine, machine engraving machine, engraving machine and high-speed rotary die knife cone head, edge grinding, and milling cutter blade cutting edge, grinding angles accurately. Universal Grinder is equipped with more advanced type of sharpener, my company is quality first, service-oriented for the purpose, sincerely for the majority of mold engraving machine, computer engraving User Services

二、主要规格与参数

The Specification and Technical Datas

Or 0.25KW 50Hz 380v

11 净重Net weight 65Kg

550*480*470mm

12 外形尺寸（长×宽×高）

Packing dimension

-

-

GD-20A万能磨刀机

1.On-off 2、Handle 3、dial scale 4、cover 5.screw joint 6、connecting rod 2A、handle

3A、dial scale 4A.cover 5A、screw joint 6A、connecting cover 7、oil cup 8.adjusting screw

9、handle 10 axis 11、fastening cover 12. reshaper stand 13、wheel flange 14、grinding wheel

15、axis 16.axis of grinding wheel 17、stop bar 18、connecting cover 19、screw 20、lamp

1、on-off 8、adjusting screw 20、drive belt 21、drive belt 2

2、motor

23、fan cover

24、screw 25、adjusting screw 26、equalizer bar

27.收管28. 收管套

Cover of the 29.滚花套

Cover of

30.紧定螺钉

Fastening

31.螺钉

screw

pipe retrieval pipe retrieval knurling screw

32.伸缩杆telescopic link 33.插销

bolt

34.法兰盘

ring flange;

35.分度盘

index plate

36.螺母

Nut

37.复滑座multiple slip 38.定位器

localizer

39.转台

Rotary table

40.螺钉

Screw

41.表盘

indicator dial

42.转台座Base of the rotary table 43.刻度圈

dial scale

44.刻度圈

dial scale

45.螺钉

Screw

46.手柄

Handle

47.紧定销Fastening pin 48.油封

oil seal

49.手柄

Handle

50.座

Base

51.螺杆

screw stem

52.螺钉Screw 53.销

Pin

54.标尺

Ruler

55.螺钉

Screw

56.刻度圈

Dial scale

57.手柄Handle 58.手柄

Handle

59.螺钉

Screw

60.标尺

Ruler Grinding Wheel Finishing

1. Loosen clamp nut D，rightward move diamond dresser，to approach wheel adge；

2. Adjust dresser well and wheel’distance about 1MM，lock up clamp nut D；

3.rotate bolt，until dresse approch to wheel。When the bolt rotate 1/5 circle，

it is will scraping about 0.2MM。
