等级号：02224 德国标准1998年10月
大众集团公司依照D I N 说明进行复制
字体
无衬线的线条拉丁字体
普通
ICS 01.140.10 替代1981-05版本
关键词：印刷技术，字体，线条拉丁字体，无衬线，普通
前言
此标准是依照NATG-F.AA2“图示符号和字体”而编写的。
无衬线拉丁字体在全世界有500多种不同的形式。
DIN1451归类出了最常用的并且相互对照，
可以辨认的字体。
归纳比较出历史上不同叫法的字样特征（例如，正常，半加粗体，三分之
一粗体，紧凑，瘦体，瘦体线细，宽体，宽体线细，宽体半加粗），并且给出了应用实例。
DIN 1451系列由：
第一部分：普通
第二部分：交流字体
第三部分：书写印刷体
第四部分：雕刻和其它方法的字模体组成
修改
相对于1981年5月的版本，本标准做以下修改：
a)标准编辑增订
b)适合与铅字有关的概念
其它版本：
DIN 1450 : 01 .26
DIN 1451: 1932 -04, 1936 -12, 1940 -02, 1851 -02
DIN1451 -1: 1981 -05
1使用范围
此标准适用于DIN16518，VI集的字样。
于DIN 16518 所确定的有限的“无衬线线条拉丁字体”的字体系列，这些字体作为平常交流使用，它们符合清楚可辨认，不易混淆的基本原则
和要求。
2 出处规范
此标准包括了其它出版物中的注明日期或者没有注明日期的出处规定。
此出处规范在不同地
方被引用，并且其他出版物以此效仿。
在标明日期的出处中，对此出版物以后的改动或者加
工属于此标准的适用范围。
在未标明日期的出处中，应引自出处出版物最新版本。
DIN 1450
字体–可阅读性
DIN 1451 -2
字体–无衬线线条拉丁字体–第二部分：交流字体
DIN 1451 -3
字体-无衬线线条拉丁字体- 第三部分：书写印刷字体
出
处
：
N
O
L
I
S
（
标
准
在
使
用
前
须
检
验
！
）
DIN 16507 -1
印刷技术- 字体大小，尺寸和概念- 第一部分：铅字和应用技术
DIN 16518
字体分类
2到4页继续技术原理标准委员会（NA TG）- 技术产品文献-
DIN德国标准研究会
DIN印刷和复制技术标准委员会
DIN德国标准研究会。
所有形式的复制和摘录必须由德国柏林DIN标准委员会同意
由柏林Beuth出版公司独家销售，10772
3 概念
（星号标注的名称仔其它段落定义。
）
3.1 字体：一种视觉交流手段，由字符*描述一个信息
3.2字体群：所有具有相同风格特征字体种类的集合。
说明：字体群按照DIN 16518规定，例如，手写字体，哥特体活字，无衬线线条拉丁字体。
3．3 字体种类：一种确定的，具有名称的字体*包括所有属于它的字体装饰花纹*和字样*。
3.4 字体装饰花纹：字体族*的一部分，表现为某一字样*的连续层次变化大小。
3.5 字样: 一个字符的可见构成*（引自DIN 16507 -1）.
说明：字样定义为图案的粗细，图案位置和字符比例。
不同图案粗细，图案位置和比例是任意可组合的。
在排版中，用“字的式样”来代替字样的概念。
3.6 字体族：一个字体种类*的所有字体装饰花纹*的集合。
3.7字体大小（h）：大写H的高度（毫米）
说明：见图1
目前在印刷技术中，字体大小还通过字身（铅字）或者按照其意义派生出来的大小来定义。
3.8 字体高度：垂直于字样的铅字印刷*的尺寸（引自DIN 16507 -1）。
3.9字的线条：一假象的水平线，字符无下线（引自DIN 16507-1）。
说明：字的线条也被定义为基线。
3．10字体种类：在印刷技术中，单一铅字印刷或者手写（手写活字）的行，机械的（机械）或者影像（照片）的方法生成的字的样式。
3．11字符：一个字的符号元素（例如拼写，数字，标点和特殊符号）（引自DIN16507 -1）说明：字符生成方法可以是手写，涂写，画，擦，雕刻，铸造，印刷，打印，影像，腐蚀或者打击。
3.12线宽（d）:字符图案粗细*的大小
说明：见图1
3.13图案粗细：尺寸小与线宽*和图案位置*一起来确定字样。
说明：在一字体族内，图案粗细同过这些特征来表现出来-线细，半加粗，加粗。
对于对比图案粗细，DIN1451 -3 用不同的名称来确定字样的数字。
3.14图案位置：字符对垂直的倾斜角度。
3.15中等字体：中等比例的字体装饰花纹*；字的大小比例相对于图案宽度*一般采用H大写的3：2。
说明：中等字体是最常用的字体。
3.16瘦体：字体比例相对于中等字体而言成比例的窄。
说明：当中等字体不够地方时，瘦体可以用于长些的书写，
3.17 宽体：字体比例相对于中等字体而言成比例的宽。
说明：宽体应该用于短些的书写。
3．18图案宽度：字符的水平外尺寸（拼写宽度）（毫米）
3.19 图案高度：一字符*的垂直尺寸，包括上下长度。
（毫米）
3.20 行书距离：字的大小，综合了图案宽度和字间距离。
3.21行距（b）：两个相邻字行的字线之间的距离。
说明：见图1
此概念应用于影像活字中（见行间空白）
3.22上长度：字符范围内的中部以上的长度
说明：见图1
3．23中长度（c）：小写x的字线以上的高度。
说明：见图1
3.24下长度：字线以下部分
3.25行间空白：行间距的扩展部分，其无印刷内容。
3.26字身：平行于字线的排版大小，在字根部测量（引自DIN16507 -1）
3.27大写字母：（拉丁）大写字母，见大写字母
3.28小写字母：（拉丁）小写字母，见小写字母
3.29大写字母：字母的大写形式
3.30小写字母：字母的小写形式
3.31衬线：字符收笔的装饰线条。
3.32排版：三维元素，通过加高，侧边斜角交叉的方式生成凸出的效果。
4选择标准
某一应用的字体选择取决于观察角度或者例子：
-字体的生成方法（如印刷，手写，腐蚀）。
-书写媒介，字的载体（例如路标，海报，书籍，预印刷），
-空间比例（如文章长度，文章段落划分，格式的编排，标志，书写区域），
-阅读条件（例如阅读距离，阅读速度，空间光亮程度和阅读的对象），
-图案符号的综合能力。
5可读性
见DIN 1450
6字体族
从字体群“线条拉丁体”选取了许多熟知的字体族。
它们的特点在接下来的部分描述。
道路交通字体DIN1451 -2
印刷字体DIN1451 -3
印刷字体，附加-非寻常标记附页1到3，ＤＩＮ１４５１－３印刷字体，附加-非寻常标记书
印刷字体，瑞士
其他没有被归入线条拉丁字体或者部分的字体或者字体族，将专门在应用实例中讲述，并以附件A注明。
７名称
数字，拼写和字体大小见DIN 1451第二部分和第三部分
例如
名称
标准号
图案粗细数字
字体种类拼写
字体告诉h
附件Ａ（非正式）
文献索引
ＤＩＮ１４５５
手写字体
DIN 6776 -1
技术图纸－书写－第一部分：字符
ＤＩＮ１６５００
印刷技术（印刷技术）－基本理论
ＤＩＮ１６５０７－２
印刷技术－－字体大小，尺寸和概述－第二部分：数字排版和应用技术ＤＩＮ１６５１４
印刷技术－凸版印刷的概述
ＤＩＮ１６５２８
印刷技术－凹版印刷的概述－印刷形式和印刷
ＤＩＮ１６５２９
印刷技术－平板印刷的概述
ＤＩＮ１６５４４
图案织物的复制技术概述
ＤＩＮ１６６１０
印刷技术－透印－网版印刷概述
ＤＩＮ３０６４０
技术产品描述的字体
ＤＩＮ６６００２
信息处理－数字０和大写Ｏ的手写描述
ＤＩＮ６６００９
对于机械光学式符号识别的字体Ｂ－符号，公称标注和符号载体的规定ＤＩＮ６６２２５
对于机械光学式符号识别的字体Ｈ－符号，书写规范和尺寸
ＤＩＮＥＮＩＳＯ３０９８－０
技术产品文件－字体－基本理论
ＤＩＮＩＳＯ３０９８－２
技术产品文件－字体－希腊字体符号
ＤＩＮＥＮＩＳＯ３０９８－５
技术产品文件－字体－拉丁字母的CAD字体以及数字和符号。
