建筑中英文对照

保留建筑EXISTING BUILDING

已建建筑AS-BUILT

新建建筑NEW BUILDING

道路ROADWAY

绿化LANDSCAPE

汽车流线CAR ACCESS

行人流线WALK ACCESS

消防车流线FIRE BRIGADE ACCESS

货车流线TRUCK ACCESS

自行车流线BICYCLE ACCESS

消防车道FIRE WAY

主出入口MAIN ENTRENCE

保安室NO.1 GUARD HOUSE

主出入口1EXIT 1

地下车库出口BASEMENT PARKING EXIT 自行车停车场BICYCLE PARKING

自行车停车位 BICYCLE STAND

总停车位 CAR PARK

其中INCLUDE

地上停车位AT-GRADE CAR PARK

地下停车位UNDERGROUND CAR PARK

空调管线AIR CONDITIONING

强电电缆LV 10KV

弱电电缆ELV

电缆10KV HV

供水管SUPPLY WATER

污水管WASTE WATER

雨水管RAIN WATER

消防管线FIRE HYDRANT

西门子(中国)总部SIEMENS CENTER BEIJING

说明NOTE

1.本图依据城市道路高程及市政管线标高等资料并结合场地排水、场地地形、土方平衡等因素进行竖向设计。

1.THE DRAWING WITH "VERTICAL HEIGHT DESIGN" IS BASED ON CITY ROADWAY ENGINEERING WITH CITY BUREAU PIPELINE HEIGHT INDICAT ION DOCUMENT SITE DRAINAGE, SITE TOPOGRAPHY, AND SOIL BALANCE ARE INCORPORATED INTO THE DESIGN.

2.本图所用坐标系统为北京市城市坐标系统，所用高程为规划高程。

2.THE DRAWING INCORPORATES BEIJING CITY COORDINATE SYSTEM. ALL THE INDICATIVE HEIGHTS ARE PLANNING HEIGHTS.

3.图中道路横坡按1.5%设计，最小纵坡为0.2%。

3.ALL THE ROADWAY INDICATED ON THE DRAWING IS BASED ON 1.5% HORIZONTAL SLOPE.THE SMALLEST VERTICAL SLOPE IS 0.2%.

4.图中标注单位均为米。

4.BASIC UNIT OF MEASUREMENT IS METRIC.

保留建筑EXISTING BUILDING

已建建筑AS-BUILT

新建建筑NEW BUILDING

道路ROADWAY

绿化LANDSCAPE

地下车库入口BASEMENT PARKING ENTRANCE

坡道RAMP

消防车道FIRE WAY

紧急出口EMERGENCY EXIT

2#保安室NO.2 GUARD HOUSE

停车场PARKING

工程地点位置图SITE LOCATION

图例LEGEND

自行车停车场BASEMENT EXIT

BICYCLE PARKING H=4.8M

地下室出入口2BASEMENT EXIT 2

主出入口4PARKING EXIT 4

主出入口EXIT

道路ROADWAY

实土绿化COMPACTED SOIL LANDSCAPE

敷土绿化DEPOSITED SOIL LANDSCAPE

通风井VENTILATION OUTLET

冷却塔(两组)COOLING TOWER(2 UNITS)

紧急通道EMERGENCY ACCESS

绿地LANDSCAPE

围挡BARRIER

停车场PARKING

地下车库出入口PARKING ENTRENCE

主出入口MAIN ENTRENCE

1#保安室NO.1 GUARD HOUSE

说明NOTE

1.图中所标注建筑尺寸为外墙皮尺寸.

1.DIMENSIONS INDICATED ON THE PLAN ARE MEASURED TO EXTERNAL EDGE OF THE BUILDINGS.

2.建筑的坐标点为轴线交点坐标.

2.ARCHITECTURE COORDINATES = INTERSECTION OF THE BUILDINGS AXI S.

3.本图以米为单位,%%P0.000相当于绝对标高37.75.

3.METRIC SYSTEMS ARE THE UNIT OF MEASUREMENT.

4.本项目对周边现状及规划建筑日照影响满足相关法规及规范要求,

即日照时数满足大寒日最低2小时的日照要求.

4.DESIGN COMPLIES WITH LOCAL REGULATION OF SUN SHADING TO NE IGHBORHOOD.

保留建筑面积EXISTING BUILDING

容积率PLOT RATIO

建筑占地面积BUILDING COVERAGE

建筑密度BUILDING DENSITY
