华硕K42JR或华硕A42J安装XP的完美解决方案华硕的这款K42JR（A42J）笔记本，需要说明一下，K42JR 和A42J其实是同一个型号，只不过一种是黑色，一种是咖啡色的。
另外，K42JR好像是在华东和华北地区销售的，A42J则在华南地区销售。
除此之外，这两款机子没有任何不同！该款笔记本出厂时预装的是正版的WIN7 X64的家庭基础版。
相信有的朋友用不惯这个系统，会找XP来安装。
经测试，这款笔记本是能完美地支持XP系统的，指的是笔记本的所有硬件都能完美支持K42JR的。
但是安装XP时会碰到一些小问题，下面就是我安装的体会，指导你如何解决这些讨厌的小问题。
1、安装XP时为什么会出现蓝屏？解答：对于这款机子，安装XP时出现蓝屏是因为“安装盘”中缺少HM55主板的SATA驱动，解决的办法是开机后当出现华硕标志的时候，按F2或Delete键进入BIOS中，将AHCI的硬盘驱动模式改为IDE模式，就能顺利安装了。
查找BIOS时，看到带有“SATA …………”的那项就是需要调整的了。
2、安装完XP后，一般在——我的电脑——属性——硬件——设备管理器中会有一项“PCI简易通讯器”不能识别，这一项有人说是猫的驱动，其实不是的，这一项是主板芯片驱动——“Intel(R) Management Engine Components”里的一项驱动而已。
下载“1.2.14.0”这个版本。
安装后，就能识别了。
当然也可以用“驱动人生2010”这个自驱驱动搜索来安装，目前也只有驱动人生能识别——“PCI简易通讯器”，其他的如“驱动精灵”等是不能识别的。
3、如何安装SATA驱动？如果你想用AHCI模式，须用已集成了HM55—SATA的XP驱动光盘来安装；但目前I5-CPU的笔记本是最新的笔记本，一般的GHOST XP或安版的XP都未集成HM55的SATA驱动进去。
所以你装好未集成相关SATA驱动的XP系统后，就必须另外安装驱动了。
