干灰散装机说明书

SZJ-100 型干灰散装机

SZJ-100 Model Dry Dust Bulk Machine

使用说明书

Operation Instruction

江苏国能环保设备有限公司

Jiangsu Guoneng Environment Protection Equipment Co., Ltd.

一、前言 1. Foreword

本产品适用于电力、建材、冶金、煤炭以及化工等其它行业的无腐蚀、低研磨性粉粒状物料的装车或装船作业。在火力发电厂主要用于灰斗或贮灰库下装车、装船。本产品可与料库下给料设施联锁运行，通过控制系统的控制，实现了装卸过程的自动化。其装车效率高，密封性能好，无粉尘污染。是散装粉状物料装车、装船的理想设备。

The product is applicable to the loading or shipment work of non-corrosion, low abrasiveness powder materials in such industry as power, construction, metallurgy, coal and chemical industry. If it uses in thermal power plant, it is mainly applied to the loading, shipping under dust hopper or dust bunker. The product is interlocking operated with material storage feeding facility, to carry out automatic loading and unloading process via control system. It is the ideal equipment for loading and shipping bulk powder materials with such characteristics as high efficiency loading, good sealing performance and without dust contamination.

二、技术参数

2. Technical parameters

2.1干灰散装机型号含义：

2.1 Model and signification of dry dust bulk machine:

Structural form I: without dust exhaust fan II: with dust exhaust fan III: with in site dust collector

出力100m 3/h Output 100m 3/h 干灰散装机

Dry dust bulk machine

2.2控制方式：设半自动和自动

2.2 Control mode: setting semi-automatic and automatic

2.3散装头升降行程：1300mm （亦可按用户需要而定）

2.3 Lifting stroke of bulk head: 1300mm (decided as per user ’s demand)

2.4散装头升降速度：0.1m/s

2.4 Lifting speed of bulk head: 0.1m/s

2.5配带升降电动机参数： 2.5 Lifting motor parameters:

结构形式 I ：不带轴尘风机 II ：带抽尘风机 III ：带就地除尘器

Structural form I: without dust exhaust fan II: with dust exhaust fan III: with in site dust collector

●型号：YEJ 90S – 6

● Model: YEJ 90S – 6

●功率：0.75kw

● Power: 0.75kw

●电压：380V

● Voltage: 380V

●转速：910 r/min

● Rotating speed: 910 r/min

2.6减速机参数：

2.6 Reducer parameters:

● Model: WHT08-VII

●型号：WHT08-VII

● Reduction ratio: 1:63

●减速比：1:63

2.7抽尘风机参数：

2.7 Dust exhaust fan parameters:

●型号：9-19 No 4.5 ● Model: 9-19 No 4.5 ※型号：4-72 No 3.6 ※Model: 4-72 No 3.6

●流量：2817m3/h

● Flow rate: 2817m3/h ※流量：2930m3/h

※Flow rate: 2930m3/h

●风压：4.04kPa

● Wind pressure: 4.04kPa ※风压：1.65kPa

※Wind pressure: 1.65kPa

●抽尘风机电机型号：Y112M-2

● Motor model of dust exhaust fan: Y112M-2 ※抽尘风机电机型号：Y100L-2

※Motor model of dust exhaust fan: Y100L-2

●抽尘风机电机功率：4.0kW

● Motor power of dust exhaust fan: 4.0kW ※抽尘风机电机功率：3.0kW

※Motor power of dust exhaust fan: 3.0kW

●抽尘风机电机电压：380V

● Motor voltage of dust exhaust fan: 380V ※抽尘风机电机电压：380V

※Motor voltage of dust exhaust fan: 380V

●抽尘风机电机转速：2890r/min

● Rotating speed of motor of dust exhaust fan: 2890r/min ※抽尘风机电机转速：2870r/min

※Rotating speed of motor of dust exhaust fan: 2870r/min
