模具零件中英文对照表
模具零件中英对照及俗称
模具零件中英对照及俗称.txt22真诚是美酒，年份越久越醇香浓型；真诚是焰火，在高处绽放才愈是美丽；真诚是鲜花，送之于人手有余香。
一颗孤独的心需要爱的滋润；一颗冰冷的心需要友谊的温暖；一颗绝望的心需要力量的托慰；一颗苍白的心需要真诚的帮助；一颗充满戒备关闭的门是多么需要真诚这一把钥匙打开呀！中英对照一、入水：gate进入位：gate location水口形式：gate type大水口：edge gate细水口： pin-point gate水口大小：gate size转水口：switching runner/gate唧嘴口径：sprue diameter二、流道: runner热流道：hot runner,hot manifold热嘴冷流道: hot sprue/cold runner唧嘴直流: direct sprue gate圆形流道：round(full/half runner流道电脑分析：mold flow analysis流道平衡:runner balance热嘴：hot sprue热流道板：hot manifold发热管：cartridge heater探针: thermocouples插头：connector plug插座： connector socket密封/封料： seal三、运水：water line喉塞：line lpug喉管：tube塑胶管：plastic tube快速接头：jiffy quick connector plug/socker四、模具零件：mold components三板模：3-plate mold二板模：2-plate mold边钉/导边：leader pin/guide pin边司/导套：bushing/guide bushing中托司：shoulder guide bushing中托边L：guide pin顶针板：ejector retainner plate托板：support plate螺丝： screw管钉：dowel pin开模槽：ply bar scot内模管位：core/cavity inter-lock顶针：ejector pin司筒：ejector sleeve司筒针：ejector pin推板：stripper plate缩呵：movable core,return core core puller 扣机（尼龙拉勾）：nylon latch lock斜顶：lifter模胚（架）： mold base上内模：cavity insert下内模：core insert行位（滑块）： slide镶件：insert压座/斜鸡：wedge耐磨板/油板：wedge wear plate压条：plate撑头: support pillar唧嘴： sprue bushing挡板：stop plate定位圈：locating ring锁扣：latch扣鸡：parting lock set推杆：push bar栓打螺丝：S.H.S.B顶板：eracuretun活动臂：lever arm分流锥：spure sperader水口司:bush垃圾钉：stop pin隔片：buffle弹弓柱：spring rod弹弓:die spring中托司：ejector guide bush中托边：ejector guide pin镶针：pin销子：dowel pin波子弹弓：ball catch复位键、提前回杆：early return bar气阀：valves斜导边：angle pin术语：terms承压平面平衡：parting surface support balance模排气：parting line venting回针碰料位：return pin and cavity interference模总高超出啤机规格：mold base shut hight顶针碰运水：water line interferes withejector pin料位出上/下模：part from cavith (core) side模胚原身出料位：cavity direct cut on A-plate,core direct cut on B-plate.不准用镶件： Do not use (core/cavity) insert用铍铜做镶件： use beryllium copper insert初步（正式）模图设计：preliinary (final) mold design反呵：reverse core弹弓压缩量：spring compressed length稳定性好：good stability,stable强度不够：insufficient rigidity均匀冷却：even cooling扣模：sticking热膨胀：thero expansion公差：tolorance铜公(电极）：copper elei模具专业英语词汇dowel pin 定位梢draft 拔模锥度draw bead 张力调整杆drive bearing 传动轴承ejection pad 顶出衬垫ejector 脱模器ejector guide pin 顶出导梢ejector leader busher 顶出导梢衬套ejector pad 顶出垫ejector pin 顶出梢ejector plate 顶出板ejector rod 顶出杆ejector sleeve 顶出衬套ejector valve 顶出阀eye bolt 环首螺栓filling core 椿入蕊film gate 薄膜形浇口finger pin 指形梢finish machined plate 角形模板finish machined round plate 圆形模板fixed bolster plate 固定侧模板flanged pin 带凸缘销flash gate 毛边形浇口flask 上箱floating punch 浮动冲头gate 浇口gate land 浇口面gib 凹形拉紧楔goose neck 鹅颈管guide bushing 引导衬套guide pin 导梢guide post 引导柱guide plate 导板guide rail 导轨head punch 顶头冲孔headless punch 直柄冲头heavily tapered solid 整体模蕊盒hose nippler 管接头impact damper 缓冲器injection ram 压射柱塞inlay busher 嵌入衬套inner plunger 内柱塞inner punch 内冲头insert 嵌件insert pin 嵌件梢king pin 转向梢king pin bush 主梢俗称大全广东模具术语深圳方言模具术语: 模胚类: 唧嘴---浇口衬套法兰---定模浇口衬套定位环,扶针---回针, 垃圾钉---顶针板止停销杯头螺丝---内六角沉孔螺丝模具类: 前模---又叫A模或定模, 后模---又叫B模或动模行位---滑块, 钶---镶在后模上的芯子(或叫模仁),机械类工具类: 锣床---铣床, 锣床批土---铣床虎口钳,磨床批土---磨床打直角虎门钳, 匙把揦---活钳或开口扳手的一种称呼刀具工具类: 牙嗒---丝攻, 坑手-攻牙用的扳手, 机转---铁圆规, 奔子---磨成尖头用于敲击划线相交定位点的工具产品类: 止口---夹口美术线,又称遮丑线, 啤把---拨模斜度,火箭脚---位于司柱的加强筋机米螺丝：无头螺丝中山方言模具术语模具类: 斜导柱=斜边锁紧块=铲鸡东莞模具术语：机械工具类：虎钳------批士； C形夹-----虾公码；钻孔------钻窿；加工中心-电脑锣；偷胶-------减胶火山口-------司筒底部的减胶位；公模肉＝后模；母模肉＝前模環保標志=回收章細水口=針點澆口潛水=針點澆口；鑲件=入子；排氣槽=逃氣道披鋒=毛邊；加膠=加料；密封圈=膠圈中托司=頂出導柱(套)=哥林柱水口扣針＝拉料頂針插穿(碰穿)＝靠破曬紋＝咬花波子螺絲＝定位珠开模器=拉胶模胚类：水口边细水口或简化型模胚的从水口板上贯下来的那支导柱中托司顶针板导柱 ;零度块方型辅助器模具类斜顶------斜方水塔，水桶------模仁上钻个深孔，中间用铜片或亚加力板隔开，运水一边进一边出来冷却的水喉，水嘴-----冷却水接口 ;呵----模仁铜公-----放电用的电极 ; 弹弓---弹簧 ; 入水---进胶点模具加工类的飞模------合模好象用白话说的外（音是如此，估计是WIRE）---线切割放电-----打火花 ;省模，打光----抛光光刀---我们这是用来指CNC精加工加工模仁，多用于公模开粗---粗加工，留少许余量开框---模胚上加工放模仁的位置穿线孔---线割时用来穿钼丝的产品类加强筋---加强用的骨位 ; 美工线---上下盖装配的中间的间隙（可有效防上错位）行位 >滑块 ;司筒 >套筒入子 >镶件（INSERT）入子为台灣叫法 ;斜顶 >斜顶块或斜顶杆 KO孔 > 顶棍孔 ;司筒针 > 套筒针撑头 > 支撑柱(防止B板变形的) ;铲鸡 >行位锁紧块治具 > 工具(夹具) ；喉咀 > 水管头；行位波仔 >滑块斜器；中托司 >浇口衬套水口板 >流道板；细水口板 >分流道板勾针 >拉料杆；B板 >动模板；A板 >定模板产品的夹线 >分型线；运水 >冷却水道；回针 >复位顶针；隔热板 >热流道模上用的撬模位 >用来公开AB板的；码模坑 >注射时固定上下模的通框 >把框开成通；大水口模----二板模；小水口模----三板模斜顶(又叫推方)----楣仔方；方铁----凳仔方夹水纹----熔胶线火花纹----电火花加工后留下的纹粗公----电火花粗加工用的铜公精公----电火花精加工用的铜公晒字----做好菲林再拿去加字体的加工方法开模器=拉胶=拉模扣密封圈=膠圈 =防水胶圈=O型圈波子螺絲＝定位珠 =弹弓波子扣机就是控制多板分型的机械装置模具类： K.O孔——顶棍孔——用来顶顶针板的。
常用模具零件中英文对照表
常用模具零件中英文对照表2005-12-19 14:51:17???中国注塑网入水：gate进入位：gate location水口形式：gate type大水口：edge gate细水口： pin-point gate水口大小：gate size转水口：switching runner/gate唧嘴口径：sprue diameter二、流道: runner热流道：hot runner,hot manifold热嘴冷流道: hot sprue/cold runner唧嘴直流: direct sprue gate圆形流道：round(full/half runner流道电脑分析：mold flow analysis :?[??n?l?s?s]流道平衡:runner balance热嘴：hot sprue热流道板：hot manifold发热管：cartridge heater探针: thermocouples插头：connector plug插座： connector socket密封/封料： seal三、运水：water line喉塞：line lpug喉管：tube塑胶管：plastic tube快速接头：jiffy quick connector plug/socker四、模具零件：mold components三板模：3-plate mold二板模：2-plate mold边钉/导边：leader pin/guide pin边司/导套：bushing/guide bushing中托司：shoulder guide bushing中托边：guide pin顶针板：ejector retainer plate托板：support plate螺丝： screw管钉：dowel pin ['da??l]开模槽：ply bar scot内模管位：core/cavity inter-lock顶针：ejector pin司筒：ejector sleeve司筒针：ejector pin推板：stripper plate ?[?str?p?r] 脱漆剂；脱衣舞演员；剥离剂；剥离器缩呵：movable core,return core core puller扣机（尼龙拉勾）：nylon latch lock?['na?.lɑn]:斜顶：lifter模胚（架）： mold base上内模：cavity insert下内模：core insert行位（滑块）： slide镶件：insert压座/斜鸡：wedge耐磨板/油板：wedge wear plate压条：plate撑头: support pillar唧嘴： sprue bushing挡板：stop plate定位圈：locating ring锁扣：latch扣鸡：parting lock set推杆：push bar栓打螺丝：顶板：eracuretun活动臂：lever arm分流锥：spure sperader水口司:bush垃圾钉：stop pin隔片：buffle弹弓柱：spring rod弹弓:die spring中托司：ejector guide bush中托边：ejector guide pin镶针：pin销子：dowel pin波子弹弓：ball catch喉塞:pipeplug锁模块：lockplate斜顶：anglefrompin斜顶杆：angleejectorrod尼龙拉勾：partinglocks活动臂：leverarm复位键、提前回杆：earlyreturnbar气阀：valves斜导边：anglepin术语：terms承压平面平衡：partingsurfacesupportbalance模排气：partinglineventing回针碰料位：returnpinandcavityinterference模总高超出啤机规格：moldbaseshuthight顶针碰运水：waterlineinterfereswithejectorpin料位出上/下模：partfromcavith(core)side模胚原身出料位：cavitydirectcutonA-plate,coredirectcutonB-plate.不准用镶件：Donotuse(core/cavity)insert用铍铜做镶件：useberylliumcopperinsert初步（正式）模图设计：preliinary(final)molddesign反呵：reversecore弹弓压缩量：springcompressedlength稳定性好：goodstability,stable强度不够：insufficientrigidity均匀冷却：evencooling扣模：sticking热膨胀：theroexpansion公差：tolorance铜公(电极）：copperelectrode塑件模具相关英文词汇出处：FanE『翻译中国』作者：(转载) FanE『翻译中国』 2005-12-16 20:41:59electrical discharge machining (EDM) 电火花加工15. electrical insulating property 电绝缘性能16. electrochemical die-sinking machine 电解型腔加工机，电解型腔加工机床17. electrochemical machine (ECM) 电解加工机床，电化学加工机床18. electrochemical machining (ECM) 电解加工，电化学加工19. electro-discharge cutting 电火花加工，电火花切割20. electro-discharge cutting machine 电火花切割机21. electro-discharge machine tool 电火花加工机床22. Electro-discharge Machine 电火花加工机床23. electro-discharge machining 电火花加工24. electro-discharge machining process 电火花加工工艺，电火花加工工序25. epoxy resin 环氧树脂9. guide bushing 导套10. guide pillar 导柱，导杆，导柱11. guide pin 导向销，导杆12. guide pin cover 导柱盖13. guide plate 导料板，导板14. guide plate blanking die 导板式冲裁模，导板式落料模15. guide post 导柱，导柱16. guide stock plate 挡料板4. injection mold 注射模，注塑模5. injection molding 注射成型，注塑成型6. injection-molding machine 注塑机，注射机，注塑成形机7. injection plunger 注射柱塞8. in-line reciprocating screw 联机往复螺杆，串联往复螺杆，直线排列往复螺杆9. inner ram 内滑块10. inserting molding 嵌件成形11. integrated manufacturing 集成制造12. internal stress 内应力13. intermediate platen 中间板，隔板塑料成型模具的主要设计要素脱模距 stripper distance脱模斜度 draft投影面积 projected area最大开距 maximum daylight;open daylight闭合高度 mould-shut height抽芯距 core-pulling distance抽芯力 core-pulling force脱模力 ejector force开模力 mould opening force模内压力 internal mould pressure;cavity pressure成型压力 moulding pressure背压环 back-up ring1 bar =高压接头 bite type fitting液压马达 hydraulic motor冷却水流量计 waterflow regulator打磨器材 abrasive material打磨砂轮 grinding wheels切割砂轮 cutting wheels码模夹(注塑机使用) mould clamps; lifting clamps 小五金工具 piping tools高压力软管 high pressure hose风管,水软管 air .water hose高压油表 pressure gauge压力油喉 hydraulic hoses光塑检测 photoelastic testing吹塑模 plastic blow mould注塑模 plastic injection mould冲扎复合模 blank & form compound die精密冲模 precision blanking die熔料流动率 MFR=melt flow rate熔料流动指数 MET=melt flow index推板导柱 guide pin for ejector plater座板 clamping plate垫块 space block(plate)推板 ejector block(plate)afdek plate 档尘板guide stripe 行位后板cavity sub-insert 前模镶件core sub-insert 后模镶件sprue puller insert 扣针镶件stage ejector 顶棍spacer rock(risers) 间隔板变形 distortion弯曲 warp拖花 drag marks火花纹 EDM marks困气 venting烧黑 burns表面缩水 shrinkage料位过薄/砸穿 thin wall stock走水不平行 uneven fill pattern夹水纹/流纹 witness line;mismatch;stress marks 走水纹 knit lines走水不齐 short shotsorifice 料口nozzle seat 热嘴垫圈nozzle plate 射嘴板cross pin 十字头销sled 射台seal ring 封密圈spacer rail 介子座heater groove 发热管槽heater cement 发热管的结合剂soak 浸泡seat 垫圈ream 铰大圆孔直径grind 磨床drill 钻床mill 铣床caliper 卡尺G-caliper 分厘卡Depth Gauge 深厚计hardness tester 硬度计angle gauge 角规marble table 云台石projector 投影仪height gauge 高度仪microscope 显微镜plug gauge 塞规leveller 水平器R gauge R 规Inter caliper 内分厘卡surface 平面仪item number 细目编码catalog number 材料分类编码undercut lip 倒扣口hot tip = hot drop = nozzle 热嘴blow-off strip 放气板blow-off nozzle 吹风口spiral hose 螺旋式的连接喉rust solvent 除锈剂shaft 曲轴tensile strength 拉伸力yield strength 屈服力spark erosion 电火花蚀刻etch(photo-etch) 电蚀harden 淬硬copper electrode 铜公corrosion resistance 耐腐蚀anneal 退火heat treatment 淬火FEM(finite elemnet method) 有限元法preliminary tool design 初期模具设计图zone 热流道区域reverse taper 倒啤把clamp plate 码板toggle clamp 快速夹vacuum furnace 真空炉cavity insert rounds 圆柱镶件cavity insert b0locks 方柱镶件tensile strength 抗张强度,抗拉强度Concept drawing 概念图Assembly drawing 装配图mismatch;witness line 夹纹shut-off(n.) 枕位venting valves 疏气阀venting plug 疏气塞valve casing 阀门罩twist drill 旋钻harden/nitride 碎硬anneal 退火temper 回火stess crack 应力断裂corrosion resistance 防腐,防锈tensile strength 物】抗张强度,抗拉强度split mould (分离)组合式的模具inclined plate 斜面inclined bolt 斜栓jaw (工具,机械等)夹住东西的部分,钳口step change of the P/L 分形面枕位的改变thin steel section 较薄的料位clean-up 清理,清除,清扫Mold Dating Insert 模具日志镶件Hot Sprue Bushing 热浇口套semi-automatic 半自动quick disconnector 快速断开接头full shot 足量注射mismatch 夹痕;夹水纹ejector mark 顶痕screw boss 螺丝孔,螺丝基座sink mark 缩坑15% glass filled ABS 掺有15%玻璃的ABS spraying mold release 脱模剂drag mark 拖痕stress mark 应力痕reinforcement rib 加强筋slght stoning 轻度磨砂soliid line 实线dotted line 虚线internal diameter 内径external diameter 外径nickel-plated 电镀的handling hole;lifting hole 吊装孔parallel 平行块piston 活塞plunger 柱塞carrier 导轨rest 支架item number 项目编号catalog item 商品目录编码dimensional datum 尺寸基准heat treatment certification 淬硬证明文件back-up bushing 支撑导套jacking screw 起重螺丝,千斤顶tapped hole (带有螺旋角度的)螺丝孔diagonal corner 成对角的角落burn mark 烧痕hot runner mainfold (热流道板)分流板texuring 蚀纹clamping screw (注塑机)码模螺丝imperial 英制的metric 公制的puller bushing 水口套puller bar 水口铁drool bushing 防漏胶套筒safety switch 限位制water line connected internally or hard tubing 不可用胶喉连接运水lifter on square rod or locked from rotation 用方形柱或用管钉止转gate insert 入水镶件gate shut-offs 流道开关配件guided ejection 中托司parting line shutoff 前后模接触面waterlines clear tie bars. 运水喉咀接驳位要避开啤机呵林柱.BGV=Balanced Gate Value 平衡入水值spacer 垫块pocket 挖槽rough 粗加工finish 精加工plunge rate 进刀率retract rate 提刀速率splindle rate 主轴转速coolant 冷却液SPLIT RING 开口环(钥匙圈)侧向抽芯力 side pulling-core force转图guide pin 边针Tee slot cutter T形SLOT CUTTERzigzag 双向切削constant overlap spiral 等距环切parallel spiral 环绕切削parallel spiral clean corners 环切并清角morph spiral 依外形环绕true spiral 螺旋切削one way 单向end mill 平铣刀spher mill 球刀bull mill 圆鼻刀face mill 面铣刀rad mill 圆角成型刀chamfer mill 倒角刀slot mill 槽刀taper mill 推拔铣刀dove mill 鸠尾铣刀lot mill 棒状drill 钻孔reamer 纹刀bore bar 搪刀tap RH 右牙刀Tap LH 左牙刀ctr Drill 中心钻spot drill 点钻cntr bore 沉头孔刀c. sink 鱼眼孔钻loft surface 举升曲面coons surface 昆氏曲面ruled surface 直纹曲面revolved surface 旋转曲面swept surface 扫描曲面draft surface 牵引曲面grinding wheel 磨砂使用的轮子quench steel 将...淬火,使冷却stress relieving 应力消除molten 熔热的oxide film 氧化层guide pin and sleeve, locating ring ,导边,司筒,定位圈ejector ,ejector balde, ejector sleeve,顶针,扁顶针,顶针司筒, lifters, wear plate,horn pin,斜坊,磨损板,气顶针,O ring, water baffle, water pipe plug,O形圈,隔片,运水管道塞, water line connector,wear plate ,运水管道转接头,耐磨板air cylinder,hydraulic cylinder,氯压缸,液压缸micro switch,oil nipple, spring,开关装置,油枪接头,弹弓sprue bushing,early return system,浇口套,早期回撞装置, accelerated ejectors, slied holder,加速顶针,注塑周期计数器, cycle counter,date stamper，滑块固定板,生产日期铭牌,hot runner system ，热流道系统chemical composition 化学成份thermal conductiivity 导热性能thermal diffusivity 热扩散性能dimensonal stablity 尺寸稳定性能cooling effiency 冷却效率easiler ejection 易于脱模alloy insert 合金镶件(cooling) duct 输送管;导管maintenance cost 维护费用ultrasonic testing 超声波检测crack 断裂direct gate 直接浇口ring gate 环形浇口disk gate;disphragm gate 盘形浇口spoke gate;spider gate 轮辐浇口pin-point gate 点浇口edge gate 侧浇口submarine gate;tunnel gate 潜伏浇口fan gate 扇形浇口tab gate 护耳浇口runner plate 流道板(或冷或热)secondary nozzle 二级喷嘴torpedo;torpedo body assembly 鱼雷形组合体catridge heater 管式加热器heat pipe 热管valve gate 阀式浇口force plunger;pot plunger 柱塞flash groove;spew groove 溢料槽impression;cavity block;cavity plate 凹模punch;force 凸模movable insert;loose detail 活动镶件cavity splits;core splits(凹模拼块) (型芯拼块) 拼块side core 侧型芯thread plug;threaded core 螺纹型芯thread ring;threaded cavity 螺纹型环cutting wheel 切割砂轮grinding wheel 打磨砂轮abrasive material 打磨器材mould clamps;lifting clamp 砂模夹(注塑机使用)air (water) hose 风管,水轮管pressure gauge 高压油表hydraulic hose 压力油喉plastic blow mould 吹塑模plastic injection mould 注塑模blandk&form compound die 冲扎复合模precisiion blanking die 精密冲模MFR=melt flow rate 熔料流动率MFT=melt flow index 熔料流动指数handling hole 拉铃孔stop plate 限位块linder bush 衬套spacer block(plate) 垫块,方铁back-up ring 背位环standoff 限位块American Safety Hoist Rings. 英制安全吊装环Mechanical Properties 机械性能Tensile Strength(MPa) 抗拉强度elongation 延伸率hardness(Brinell) 硬度shear stength(MPa) 剪切力impact strength 冲韧性Physical Properties 物理性能solidification shrinkage 凝固收缩率freezing range 凝固与熔范围thermal expansion 热膨胀系数specific heat 比热thermal conductivity 热导率electrical conductivity 电导率micro-structure 金相分析hot work tool steel 热作钢circular motion 环形运动variable 变数,参数graphics window 图形窗口45 degree entry and a zero degree exit. 进刀口45度,退刀口0度runner stripper plate 脱料板stripper plate 活动板spacer rock(risers) 间隔板stage ejector 顶棍sprue puller insert 扣针导套guide strip 行位后板afdek plate 挡尘板side gate 大水口pinpoint gate 细水口SHCS 杯头螺丝FHCS 平头螺丝set screw 无头螺丝ball catch 波子螺丝wedge 行位较杯gib 线条,(撑鸡的导轨)latch 拉杆clamp 码仔spring guide pin 弹弓导柱steel pad disc 橙仔方ejector cam insert 斜顶块(screw) nut 螺母taper 嗲把/ 斜度taper interlock 嗲把锁texture 花纹toggle-lok 回撞装置top clamping plate 顶码板unified national coarse (UNC) 美制螺丝(粗牙) unified national fine (UNF) 美制螺丝(幼牙) set screw 喷头螺丝side gate 大水口slide retainer 行位管位water junction 喉咀spacer block 登仔jiffy-matic socket 喉咀套jiffy-tite plug 喉咀公spring plunger 弹弓座sprue puller 勾针/勾粒spring washer 弹簧塑圈stepped ejector pin 有托顶针strippers plate 推板/细水口板submarine gate 潜水口support pin 拉杆support plate 暗板surface finish 光洁度alignment strip 斜锁angle pin 斜针fan gate 扇形入水fillet 圆口ball catch 弹弓波子blade ejector 扁顶bottom clamping plate 底码板free length 自然长度bridge piece 水口铁helix spindle 锅杆hose clip 水喉箍bubbler 隔气运水jiggle 斜顶jiggle witness line 斜顶片位置center distance (CRS) 山打距离(中心线距离)clamp 码仔contour 外形leader pin 导针location ring(flange) 法兰counterbore 拔头,介子托mock-up;prototype 手办die cast 合金压铸national pipe thread(NPT) 美制喉牙overflow 垃圾位ejection sleeve 司筒,顶套epoxy 胶样pin point gate 细水口pressure plug 喉塞pressure spring 压力弹簧parting line flash 披锋burned 烧黑underfilled 缺料insert mismatch 镶件夹口ejector pins not flush 顶针有高低ejector pins skid 顶针滑动insert flash 镶件披锋pressure transducer 压力探测头hydraulic schematic 油积筒油路接驳图jiffy connector recessed 安装喉嘴后不可突出模胚knock out pullback stud -flush with clamp plate 顶棍镶件与底板有否空间safety switches 限位开关stop block 限位块safety strap 安全带drool bushing 防漏胶套筒insert mismatch 镶件夹口EDM visible 明显火花纹lifter scrapes 斜顶拖花short shots 走水不齐wall stock 料位厚薄knit lines 走水纹stress marks 夹水纹uneven fill pattern 走水不平行drag marks 拖花sprue pretrusion 唧嘴突出高度sprue orifice and radil size 唧嘴R尺寸sprue bushing-keyed 唧嘴有管钉English Chineseprogram name 产口名称part name 零件名称tool name 模具名称tool source 模具来源tool steel 模具钢材resin 塑料program number 产品编号part number 零件编号tool number 模具编号customer 客户名称No of cavities 内模编号machine size 啤机吨数drum miller 鼓形铣床duplex horizontal miller 复式卧铣床face miller 端面铣床grinding miller 研磨机plain miller 平面铣床planer-type miller 刨式铣床rack miller 齿条铣床slab miller 大型平面铣床slot miller 键槽铣刀spline miller 花键铣刀thread miller 螺纹铣刀vertical miller 立式铣刀,立辊,立辊轧机endmill 立铣刀plastic mould steel 塑料模钢cold work steel 冷作钢hot work steel 热作钢high speed steel 高速钢electric magnetic clutch 电磁离合器pad printer 移印机screen printer 丝印机hot stamper 烫印机solid carbide slitting saw 钻石钢锯片convex cutter 凸锣刀片concave cutter 凹锣刀片side&face cutters,staggered teeth 正侧双用镶钻石钢锣刀end-mill 锣刀semi-rod 半圆刀split double end 双头刀single end 单头刀2-flute 两辨3-flute 三辨4-flute 四辨reamer 直拈centre drill 中心钻solid carbide drill 钻咀zinc ingot 锌锭aluminium ignot 铝锭tin ignot 锡锭heater cement 发热管的结合剂heater groove 发热管槽spacer rail 介子座cross pin 十字头销nozzle plate 射嘴板nozzle seat 热嘴addendum 齿冠dedendum 齿根air compressor 空气压缩机air exhauster 抽气机air intake 进气口air seal 空气隔离层。
模具零配件中英对照表
36
水口拉杆
SpruePuller
S-puller
37
复位机构
DiaplasisSet-up
D-set-up
38
拉板
DrawPlate
D-Plate
39
限位块
RestrictBLock
R-Block
40
斜顶脚
Lifter Feet
L-Feet
41
水口拉针
SpruePin
S-Pin
42
卡板
ClipPlate
C-Plate
43
模锁
Shipping Strap
S-Strap
密封胶圈
Ring
28
唧嘴
Sprue
29
弹簧
Spring
30
定位环
Location Ring
L-Ring
31
斜导柱
Angle Pin
A-Pin
32
直顶块
Straight EJ BLock
S-E-Block
33
压块
Strip
34
定位块
Locate BLock
L-Block
35
行位导轨块
Lifter Guide BLock
Support plate
10
方铁
Spacer Block
11
面针板/顶针面板
Ejector Retain Plate
12
底针板/顶针底板
Ejector Plate
13
底板
Bottom Clamp Plate
14
回针
Return Pin
15
模具中英文对照表
滑块
SLIDE
B04
滑块型芯
SLIDE CORE
B05
耐磨板
WEAR PLATE
B06
滑块压条
GUIDE RAIL
B07
滑块压块
SLIDE WEDGE
B08
斜楔
WEDGE
B09
扣件
LATCH BAR
B10
分离板
RELEASE BAR
B11
固定块
SPACER
B12
限位拉板
STOP PLATE
B13
顶出块
STRIPPER BLOCK
B14
斜拉杆
ANGLE PILLAR
B15
T型块
“T”BLOCK
B16
U型块
“U”BLOCK
B17
定位块
LOCATION BLOCK
B18
滑块导轨
SLIDE GUIDE
B19
斜拉杆导板
ANGLE PILLAR RAIL
类别：C
一般零件部份
零件编号
中文名称
英文名称
材质
C40
热浇嘴
HOT TIP BUSHING
C41
流道塞子
RUNNER PLUG
C42
铜环
CU.DIR
C43
鱼雷探针
TORPEDO SPREADER
C44
流道垫块
RUNNER BLOCK
C45
浇口称套
OUTER BODY
C46
绝热管
FAST HEAT
C47
电热管
HEATER
C48
ห้องสมุดไป่ตู้温控仪
模具中英文对照表
中文English中文English中文拉延模Drawing Die C/H孔C/H多工位模凸模Punch C/H孔用冲头Punch for C/H多工位压力机凹模Die弹顶销Ejecting Pin翻口/卷边压料圈Blank Holder(BH)推料板螺钉Stripper Bolt反侧块凸模安装座Punch Support防护板Fender方形台肩冲头单动Single Action滚轮Roller防护板双动Double Action上模Upper防护板气缸Air Cylinder下模Lower防滑刀氮气缸Gas Spring上模主体Upper Part防松[锁紧]螺母定位板Locating Plate下模主体Lower Part废料刀定位销Locating Pin上压料板Upper BH废料滑道排气管Pipe for Air Vent下压料板Lower BH钢板（送料）托架Blank Support上压料板主体Upper BH Part钢管压料圈垫块Bottom Block下压料板主体Lower BH Part钢丝调整垫块Set Block镶块Insert钢丝绳展开毛坯Blank Development上模镶块Up Insert杠杆行程Stroke/Travel侧销Side pin工程塑料托杆Pressure Pin安全销Safety pin工件气垫Air Cushion平衡块Blancing Block固定板、固定器导板Guide Plate顶出器knockout刮边导柱Guide Post 顶件器，卸件装置shedder滚轮衬套Guide Bush顶销push pin含油的起重臂Lifting Boss定位板locating plate焊接夹钳起重棒Lifting Bar定位孔locating hole滑板连接板Tie Plate定位块locating block滑块拉延标记销Bottom Mark定位器locator滑配拉延槛Locking Bead定位销locating pin簧片拉延筋Drawing Bead锻造毛坯forging blank锪平English中文English中文English multiple station die活动挡料销pivoted latch拉延槛locking bead transfer press活动芯杆movable mandrel拉延筋draw bead beading活塞plunger连接板link plate back-up block基面datum plane连接板tie platesquare-shouldered punch基线datum line连续模progressivedieguard plate基准点datum point零件detail,part fender挤压extrusion螺钉，螺拴blot anti-slip blade加强板，加强筋rib （ Reinf.）螺杆，螺孔screwblocking nut 尖冲头，小直径凸模pin punch螺母nutscrap cutter剪切shearing螺纹thread slug chute检测杆checking rod落料blankingarmor plate键key 落料、拉延、冲孔模compound-combinationsteel tube角钢angle steel模柄punch shank steel wire接线盒junction box模架die set wire rope筋条rib模座shoelever聚氨酯弹簧urethanes spring扭簧torsional springengineering plastics卷边/轧边edge rolling扭弯twisting workpiece卷耳curling排气孔air vent retainer卷圆curling平冲头flat punch shaving卷圆成形tube forming平衡杆blancing rod roller空间连杆spatial linkage起重棒lifting baroil-impregnated快换冲头quick-changepunch起重臂lifting bosswelding die窥视孔peephole起重螺孔lifting screwslide plate拉杆drag rod气缸pneumatic cylinderslide block拉延drawing气敏传感器gas-sensitivesensorsliding fit拉延标记销bottom mark切断parting/cut-offspring blade 拉延-反拉延组合模combinationdraw-reverse切割cuttingmachining evenly拉延工序drawingoperation切口notching中文English中文English球底冲头round bottomedpunch下底板lower shoe球状凸模, 球底面模spherical punch限位销limiting pin 刃口blade限制器bumper block扇形刀sector cutter镶块，嵌入物insert上底板upper shoe镶刃刀胚insert blank 上拉式顶出器up-draw knockout橡胶rubber 深拉延deep drawing楔块wedge block手柄handle斜刃口tapered cutting edge 双槽double-cavity斜楔块cam block 送料，进料feed修边trimming 送料板feeding plate修整圆角round-corner truing 送料架feeding stand旋压spining送料装置feeder压板槽clamping slot送料装置feeding mechanism压床press台肩式凸模shoulder punch压床滑块press ram 套环ring压床曲轴press crankshaft套筒bushing压合staking凸模punch压力表manometer 凸模安装座punch support压料blank holding 凸模固定板punch retainer压料板pressure pad凸模镶块punch section压料块pressure block凸模压板punch pad压料圈blank holder (B/H)推拉块push-pull block压料圈垫块bottom block推料器blank pusher压弯bending 退料板螺钉stripper bolt压印，压花coining 退料器ejector硬质合金冲压模carbide press die 退料销，弹顶销ejecting pin硬质合金凸模carbide punch 托料架blank support油路布置lubrication layout中文English预压缩precompression圆形凸模，圆冲头round punch再拉延redrawing展开毛坯blank development胀形模bulging die整体凸模solid punch整形sizing整形修正truing支承板，垫板backing plate 支座supporter止退销stop pin制件finished part制件号part number制件名part name中心距center distance主模型master model柱销dowel pin铸坯casting blank准销，导正销pilot pin自定心冲头self-centering punch 自动挡料销trigger stop自动定心装置self-centering device 自动退料装置unloading device 自锁self locking组合模assembling die气路装置air equipment。
模具各零部件名称中英文对照
模具各零部件名称中英文对照模具各零部件名称中英文对照 .txt 生活是过出来地 ,不是想出来地 . 放得下地是曾经 ,放不下Mold changing systems Mold core 模芯 Mold heaters/chillers Mold polishing/texturing Mold repair 模具维修 Molds 模具Pressing dies 压模Quick die change systems Quick mold change systems、模具塑料模具 mould ofplastics 注塑模具injection mould 冲压模具die 模架mould base定模座板 Top clamping plate Top plateFixed clamp plate 水口推板 stripper plateA 板 A plateB 板B plate 支承板support plate 方铁spacer plate 底针板ejector plate面针板 ejector retainer plate 回针 Return pin 导柱 Guide pin 有托导套 Shoulder Guide bush 直导套 Straight Guide bush 动模座板 Bottom clamp plateMoving clamp plate 基准线 datum line基准面 datum plan型芯固定板core-retainer plate 凸模固定板punch-retainer plate 顶针 ejector pin 单腔模具 single cavity mould 多腔模具 multi-cavity mould 多浇口 multi-gating 浇口 gate缺料starving 排气breathing 光泽gloss 合模力mould clamping force 锁模力 mouldlocking force 挤出 extrusion 开裂 crack 循环时间 cycle time 老化 aging 螺杆 screw 麻点 pit 嵌件 insert 活动镶件 movable insert 起垩 chalking 浇注系统 feed system 主流道 sprue分流道 runner 浇口 gate 直浇口 direct gate , sprue gate 轮辐浇口 spoke gate , spidergate 点浇口pin-point gate 测浇口edge gate 潜伏浇口submarine gate , tunnel gate 料穴cold-slug well 浇口套sprue bush 流道板 runner plate 排飞槽 vent分型线＜面） parting line 定模 stationary mould,Fixed mould 动模 movable mould,movable half 上模 upper mould, upper half 下模 lower mould, lower half 型腔 cavity 凹模 cavity plate,cavity block 拼块 split 定位销 dowel 定位销孔dowel hole 型芯 core 斜销angle pin, finger cam 滑块 slide 滑块导板 slide guide strip 楔紧块 heel block, wedge lock 拉料杆 sprue puller 定位环 locating ring 冷却通 cooling channel 脱模斜度 draft 滑动型芯 slide core螺纹型芯 threaded core 热流道模具 hot-runner mould 绝热流道模 insulated runner mould 熔合纹 weld line <="" 脱模=""> interchangeable cavity mould 脱模剂 release agent 注射能力shot capacity 注射速率 injection rate 注射压力 injection pressure 差色剂 colorant 保压时间 holdup time 闭模时间closing time 定型装置sizing system 阴模female mould,cavity block 阳模male mould 电加工设备Electron Discharge Machining 数控加工中心 CNC machine center 万能铁床Universal milling machine 卧式刨床Horizontal planer 车床Engine lathe 平面磨床Surface grinding machine 去磁机Demagnetization machine 万能摇臂钻床 Universal radial 地是记忆 . 无论我在哪里, 我离你都只有一转身地距离 .Mold & die components 模具单元换模系统模具加热器 / 冷却器模具打磨 /速换模系统快速换模系统movable driller 立式钻床Vertical driller 超声波清洗机Ultrasonic clearing machine compre sion molding 压缩成型flash mold 溢流式模具plsitive mold 挤压式模具split mold 分割式模具cavity 型控母模core 模心公模taper 锥拔leather cloak 仿皮革shiver 饰纹flow mark 流痕welding mark 溶合痕post screw insert 螺纹套筒埋值self tapping screw 自攻螺丝striper plate 脱料板piston 活塞cylinder 汽缸套chip 细碎物handle mold 手持式模具<移转成型用模具）encapsulation molding 低压封装成型<射出成型用模具）two plate 两极式<模具）well type 蓄料井insulated runner 绝缘浇道方式hot runner 热浇道runner plat 浇道模块valve gate 阀门浇口band heater 环带状地电热器spindle 阀针spear head 刨尖头slag well 冷料井cold slag 冷料渣air vent 排气道welding line 熔合痕eject pin 顶出针knock pin 顶出销return pin 回位销反顶针sleave 套筒stripper plate 脱料板insert core 放置入子runner stripper plate 浇道脱料板guide pin 导销eject rod （bar>< 成型机）顶业捧subzero 深冷处理three plate 三极式模具runner system 浇道系统stress crack 应力电裂orientation 定向sprue gate 射料浇口, 直浇口nozzle 射嘴sprue lock pin 料头钩销（拉料杆> slag well 冷料井side gate 侧浇口edge gate 侧缘浇口tab gate 搭接浇口film gate 薄膜浇口flash gate 闸门浇口slit gate 缝隙浇口fan gate 扇形浇口dish gate 因盘形浇口diaphragm gate 隔膜浇口ring gate 环形浇口subarine gate 潜入式浇口tunnel gate 隧道式浇口pin gate 针点浇口Runner less 无浇道（sprue less＞无射料管方式long nozzle 延长喷嘴方式sprue 浇口。
模具各零部件名称中英文对照
Mold & die components 模具单元Mold changing systems 换模系统Mold core 模芯Mold heaters/chillers 模具加热器/冷却器 Mold polishing/texturing 模具打磨/磨纹 Mold repair 模具维修Molds 模具Pressing dies 压模Quick die change systems 速换模系统Quick mold change systems 快速换模系统三、模具塑料模具mould of plastics注塑模具injection mould冲压模具die模架mould base定模座板Top clamping plateTop plateFixed clamp plate水口推板stripper plateA板A plateB板B plate支承板 support plate方铁 spacer plate底针板 ejector plate面针板 ejector retainer plate回针 Return pin导柱 Guide pin有托导套 Shoulder Guide bush直导套 Straight Guide bush动模座板Bottom clamp plateMoving clamp plate基准线datum line基准面datum plan型芯固定板core-retainer plate凸模固定板punch-retainer plate顶针ejector pin单腔模具single cavity mould多腔模具multi-cavity mould多浇口multi-gating浇口gate缺料starving排气breathing光泽gloss合模力mould clamping force锁模力mould locking force挤出extrusion开裂crack循环时间cycle time老化aging螺杆screw麻点pit嵌件insert活动镶件movable insert起垩chalking浇注系统feed system主流道 sprue分流道runner浇口gate直浇口direct gate , sprue gate轮辐浇口spoke gate , spider gate点浇口pin-point gate测浇口edge gate潜伏浇口submarine gate , tunnel gate 料穴cold-slug well浇口套sprue bush流道板runner plate排飞槽vent分型线（面）parting line定模stationary mould，Fixed mould动模movable mould, movable half上模upper mould， upper half下模lower mould， lower half型腔cavity凹模cavity plate，cavity block拼块split定位销dowel定位销孔dowel hole型芯core斜销angle pin, finger cam滑块slide滑块导板slide guide strip楔紧块heel block, wedge lock拉料杆sprue puller定位环locating ring冷却通cooling channel脱模斜度draft滑动型芯slide core螺纹型芯threaded core热流道模具hot-runner mould绝热流道模insulated runner mould熔合纹weld line （flow line）三板式模具three plate mould脱模ejection换模腔模具 interchangeable cavity mould脱模剂release agent注射能力shot capacity注射速率injection rate注射压力injection pressure差色剂colorant保压时间holdup time闭模时间closing time定型装置sizing system阴模female mould，cavity block阳模male mould电加工设备Electron Discharge Machining数控加工中心CNC machine center万能铁床Universal milling machine卧式刨床Horizontal planer车床Engine lathe平面磨床Surface grinding machine去磁机Demagnetization machine万能摇臂钻床Universal radial movable driller 立式钻床Vertical driller超声波清洗机Ultrasonic clearing machine compre sion molding压缩成型flash mold溢流式模具plsitive mold挤压式模具split mold分割式模具cavity型控母模core模心公模taper锥拔leather cloak仿皮革shiver饰纹flow mark流痕welding mark溶合痕post screw insert螺纹套筒埋值self tapping screw自攻螺丝striper plate脱料板piston活塞cylinder汽缸套chip细碎物handle mold手持式模具（移转成型用模具）encapsulation molding低压封装成型（射出成型用模具）two plate两极式（模具）well type蓄料井insulated runner绝缘浇道方式hot runner热浇道runner plat浇道模块valve gate阀门浇口band heater环带状的电热器spindle阀针spear head刨尖头slag well冷料井cold slag冷料渣air vent排气道welding line熔合痕eject pin顶出针knock pin顶出销return pin回位销反顶针sleave套筒stripper plate脱料板insert core放置入子runner stripper plate浇道脱料板guide pin导销eject rod (bar)（成型机）顶业捧subzero深冷处理three plate三极式模具runner system浇道系统stress crack应力电裂orientation定向sprue gate射料浇口，直浇口nozzle射嘴sprue lock pin料头钩销(拉料杆) slag well冷料井side gate侧浇口edge gate侧缘浇口tab gate搭接浇口film gate薄膜浇口flash gate闸门浇口slit gate缝隙浇口fan gate扇形浇口dish gate因盘形浇口diaphragm gate隔膜浇口ring gate环形浇口subarine gate潜入式浇口tunnel gate隧道式浇口pin gate针点浇口Runner less无浇道(sprue less)无射料管方式long nozzle延长喷嘴方式sprue浇口;溶渣根据中文词汇查所关心的技术问题，解决实际工作中的难题例如，在汉语词汇中看到——高速冲孔废料上跳（かす上り、scrap jump ）词汇，到网上一搜，中图分类号TG382.6，文章编码：1671-3508-2008-10-07-517，“高速冲压中防止冲孔废料上跳的方法”一文会告诉你引起高速冲孔废料上跳的原因，不外乎有油膜粘连、真空吸附、刃口磨损、磁性未退四个主要方面，解决这些问题有三个方向的思路可以考虑，具体手段有“毛糙面”法、“斜刀口”法、“硅胶顶出”法、“凹模刃口倒退拔”法，等等。
常用模具零件中英文对照表
常用模具零件中英文对照表2005-12-19 14:51:17 中国注塑网入水：gate进入位：gate locati on水口形式：gate type 大水口：edge gate 纟田水口：pin-po int gate水口大小：gate size 转水口：switchi ng runn er/gate唧嘴口径：sprue diameter 二、流道:runner热流道：hot runn er,hot mani fold热嘴冷流道:hot sprue/cold runner 唧嘴直流:direct sprue gate 圆形流道：roun d(full/half r unner流道电脑分析：mold flow an alysis ：[??i?l?s?s]流道平衡：runner balanee 热嘴：hot sprue 热流道板：hot ma ni fold 发热管：cartridge heater 探针:thermocouples 插头：conn ector plug 插座：conn ector socket 密圭寸/圭寸料：seal三、运水：water line 喉塞：line lpug 喉管：tube塑胶管：plastic tube 快速接头：jiffy quick connector plug/socker 四、模具零件：mold comp onents 三板模：3-plate mold二板模：2-plate mold 边钉/ 导边：leader pin /guide pin 边司/ 导套：bush in g/guide bush ing 中托司：shoulder guide bush ing 中托边：guide pin顶针板：ejector retainer plate托板：support plate螺丝：screw管钉：dowel pin ['da ??i]开模槽：ply bar scot内模管位：core/cavity in ter-lock 顶针：ejector pin 司筒：ejector sleeve 司筒针：ejector pin推板：stripper plate [@tr ?p?r]脱漆剂；脱衣舞演员；剥离剂；剥离器缩呵：movable core,return core core puller 扣机（尼龙拉勾）：nylon latch lock g ?」斜顶：liftera n]mold base上内模：cavity in sert 下内模：core insert行位（滑块）：slide 镶件：insert 压座/斜鸡：wedge 耐磨板/ 油板：wedge wear plate 压条：plate撑头：support pillar 唧嘴：sprue bushi ng 挡板：stop plate 定位圈：locating ring 锁扣：latch 扣鸡：parting lock set 推杆：pushbar 栓打螺丝：S.H.S.B 顶板：eracuretun 活动臂：lever arm 分流锥：spure sperader 水口司:bush 垃圾钉：stop pin 隔片：buffle 弹弓柱：spri ng rod 弹弓:die spring 中托司：ejector guide bush 中托边：ejector guide pin 镶针：pin销子：dowel pin 波子弹弓：ball catch喉塞:pipeplug 锁模块：lockplate 斜顶：anglefrompin斜顶杆：angleejectorrod尼龙拉勾：partinglocks活动臂：leverarm复位键、提前回杆：earlyreturnbar气阀：valves斜导边：anglepin术语：terms承压平面平衡：partingsurfacesupportbalance模排气：partinglineventing回针碰料位：returnpinandcavityinterference 模总高超出啤机规格：moldbaseshuthight顶针碰运水：waterlineinterfereswithejectorpin 料位出上/ 下模：partfromcavith(core)side 模胚原身出料位：cavitydirectcutonA-plate,coredirectcutonB-plate.不准用镶件：Donotuse(core/cavity)insert用铍铜做镶件：useberylliumcopperinsert 初步(正式)模图设计：preliinary(final)molddesign 反呵：reversecore弹弓压缩量：springcompressedlength稳定性好：goodstability,stable强度不够：insufficientrigidity均匀冷却：evencooling扣模：sticking热膨胀：theroexpansion 公差：tolorance 铜公(电极)：copperelectrode塑件模具相关英文词汇出处：FanE『翻译中国』作者：（转载）FanE『翻译中国』2005-12-16 20:41:59如需转载，请注明来自：FanE『翻译中国』compre sion molding 压缩成型flash mold 溢流式模具plsitive mold 挤压式模具split mold 分割式模具cavity 型控母模core 模心公模taper 锥拔leather cloak 仿皮革shiver 饰纹flow mark 流痕welding mark 溶合痕post screw insert 螺纹套筒埋值self tapping screw 自攻螺丝striper plate 脱料板piston 活塞cylinder 汽缸套chip 细碎物handle mold 手持式模具encapsulation molding 低压封装成型、射出成型用模具 two plate 两极式（模具）如需转载，请注明来自：FanE『翻译中国』http;//well type 蓄料井insulated runner 绝缘浇道方式hot runner 热浇道runner plat 浇道模块valve gate 阀门浇口band heater 环带状的电热器 spindle 阀针spear head 刨尖头slag well 冷料井 cold slag 冷料渣 air vent 排气道 welding line 熔合痕 eject pin 顶出针零件英语punch 冲头insert 入块（嵌入件） deburring punch 压毛边冲子 groove punch 压线冲子 stamped punch 字模冲子 round punch 圆冲子 special shape punch 异形冲子 bending block 折刀 roller 滚轴baffle plate 挡块located block 定位块 supporting block for location air cushion plate 气垫板定位支承块16. electrochemical die-sinkingmachine 电解型腔加工机，电解型腔加工机床 17. electrochemical machine(ECM)电解加工机床，电化学加工机床 18. electrochemical machining (ECM)19. electro-discharge cutting air-cushion eject-rod 气垫顶杆trimming punch 切边冲子 stiffening rib punch = stinger 加强筋冲子ribbon punch 压筋冲子 reel-stretch punch 卷圆压平冲子 guide plate 定位板 sliding block 滑块 sliding dowel block 滑块固定块 active plate 活动板 lower sliding plate 下滑块板 upper holder block 上压块 upper mid plate 上中间板 spring box 弹簧箱 spring-box eject-rod 弹簧箱顶杆 spring-box eject-plate 弹簧箱顶板 bushing bolck 衬套 cover plate 盖板 guide pad 导料块 14. electrical discharge machining(EDM) 电火花加工 15. electrical insulatingproperty电绝缘性能 电解加工，电化学加工电火花加工，电火花切割。
模具各零部件名称中英文对照
模具各零部件名称中英文对照 .txt 生活是过出来地 ,不是想出来地 . 放得下地是曾经 ,放不下Mold changing systems Mold core 模芯 Mold heaters/chillersMold polishing/texturing Mold repair 模具维修 Molds 模具Pressing dies 压模 Quick die change systems Quick mold change systems、模具 塑料模具 mould ofplastics 注塑模具 injection mould 冲压模具 die 模架 mould base定模座板 Top clamping plate Top plateFixed clamp plate 水口推板 stripper plateA 板 A plateB 板 B plate 支承板 support plate 方铁 spacer plate 底针板 ejector plate面针板 ejector retainer plate 回针 Return pin 导柱 Guide pin有托导套 Shoulder Guide bush 直导套 Straight Guide bush 动模座板 Bottom clamp plateMoving clamp plate 基准线 datum line基准面 datum plan型芯固定板 core-retainer plate 凸模固定板 punch-retainer plate 顶针 ejector pin 单腔模具 single cavity mould 多腔模具 multi-cavity mould 多浇口 multi-gating 浇口 gate缺料 starving 排气 breathing 光泽 gloss 合模力 mould clamping force 锁模力 mouldlocking force 挤出 extrusion 开裂 crack 循环时间 cycle time 老化 aging 螺杆 screw 麻点 pit 嵌件 insert 活动镶件 movable insert 起垩 chalking 浇注系统 feed system 主流道 sprue分流道 runner 浇口 gate 直浇口 direct gate , sprue gate 轮辐浇口 spoke gate , spidergate 点浇口 pin-point gate 测浇口 edge gate 潜伏浇口 submarine gate , tunnel gate 料穴 cold-slug well 浇口套 sprue bush 流道板 runner plate 排飞槽 vent分型线 ＜面） parting line 定模 stationary mould,Fixed mould 动模 movable mould,movable half 上模 upper mould, upper half 下模 lower mould, lower half 型腔 cavity 凹模 cavity plate,cavity block 拼块 split 定位销 dowel 定位销孔 dowel hole 型芯 core 斜销angle pin, finger cam 滑块 slide 滑块导板 slide guide strip 楔紧块 heel block, wedge lock 拉料杆 sprue puller 定位环 locating ring 冷却通 cooling channel 脱模斜度 draft 滑动型芯 slide core螺纹型芯 threaded core 热流道模具 hot-runner mould 绝热流道模 insulated runner mould 熔合纹 weld line <flow line ) 三板式模具 three plate mould 脱模 ejection 换模腔模具interchangeable cavity mould 脱模剂 release agent 注射能力 shot capacity 注射速率 injection rate 注射压力 injection pressure 差色剂 colorant 保压时间 holdup time 闭模时间 closing time 定型装置 sizing system 阴模 female mould,cavity block 阳模 male mould 电加工设备 Electron Discharge Machining 数控加工中心 CNC machine center 万能铁床Universal milling machine 卧式刨床 Horizontal planer 车床 Engine lathe 平面磨床 Surface grinding machine 去磁机 Demagnetization machine 万能摇臂钻床 Universal radial地是记忆 . 无论我在哪里 , 我离你都只有一转身地距离 .Mold & die components 模具单元 换模系统模具加热器 / 冷却器 模具打磨 /速换模系统 快速换模系统movable driller 立式钻床Vertical driller 超声波清洗机Ultrasonic clearing machine compre sion molding 压缩成型flash mold 溢流式模具plsitive mold 挤压式模具split mold 分割式模具cavity 型控母模core 模心公模taper 锥拔leather cloak 仿皮革shiver 饰纹flow mark 流痕welding mark 溶合痕post screw insert 螺纹套筒埋值self tapping screw 自攻螺丝striper plate 脱料板piston 活塞cylinder 汽缸套chip 细碎物handle mold 手持式模具<移转成型用模具）encapsulation molding 低压封装成型<射出成型用模具）two plate 两极式<模具）well type 蓄料井insulated runner 绝缘浇道方式hot runner 热浇道runner plat 浇道模块valve gate 阀门浇口band heater 环带状地电热器spindle 阀针spear head 刨尖头slag well 冷料井cold slag 冷料渣air vent 排气道welding line 熔合痕eject pin 顶出针knock pin 顶出销return pin 回位销反顶针sleave 套筒stripper plate 脱料板insert core 放置入子runner stripper plate 浇道脱料板guide pin 导销eject rod （bar>< 成型机）顶业捧subzero 深冷处理three plate 三极式模具runner system 浇道系统stress crack 应力电裂orientation 定向sprue gate 射料浇口, 直浇口nozzle 射嘴sprue lock pin 料头钩销（拉料杆> slag well 冷料井side gate 侧浇口edge gate 侧缘浇口tab gate 搭接浇口film gate 薄膜浇口flash gate 闸门浇口slit gate 缝隙浇口fan gate 扇形浇口dish gate 因盘形浇口diaphragm gate 隔膜浇口ring gate 环形浇口subarine gate 潜入式浇口tunnel gate 隧道式浇口pin gate 针点浇口Runner less 无浇道（sprue less＞无射料管方式long nozzle 延长喷嘴方式sprue 浇口。
模具零件中英对照及俗称
中英对照一、入水：gate进入位：gate location水口形式：gate type大水口：edge gate细水口： pin-point gate水口大小：gate size转水口：switching runner/gate唧嘴口径：sprue diameter二、流道: runner热流道：hot runner,hot manifold热嘴冷流道: hot sprue/cold runner唧嘴直流: direct sprue gate圆形流道：round(full/half runner流道电脑分析：mold flow analysis流道平衡:runner balance热嘴：hot sprue热流道板：hot manifold发热管：cartridge heater探针: thermocouples插头：connector plug插座： connector socket密封/封料： seal三、运水：water line喉塞：line lpug喉管：tube塑胶管：plastic tube快速接头：jiffy quick connector plug/socker四、模具零件：mold components三板模：3-plate mold二板模：2-plate mold边钉/导边：leader pin/guide pin边司/导套：bushing/guide bushing中托司：shoulder guide bushing中托边L：guide pin顶针板：ejector retainner plate托板：support plate螺丝： screw管钉：dowel pin开模槽：ply bar scot内模管位：core/cavity inter-lock顶针：ejector pin司筒：ejector sleeve司筒针：ejector pin推板：stripper plate缩呵：movable core,return core core puller 扣机（尼龙拉勾）：nylon latch lock斜顶：lifter模胚（架）： mold base上内模：cavity insert下内模：core insert行位（滑块）： slide镶件：insert压座/斜鸡：wedge耐磨板/油板：wedge wear plate压条：plate撑头: support pillar唧嘴： sprue bushing挡板：stop plate定位圈：locating ring锁扣：latch扣鸡：parting lock set推杆：push bar栓打螺丝：S.H.S.B顶板：eracuretun活动臂：lever arm分流锥：spure sperader水口司:bush垃圾钉：stop pin隔片：buffle弹弓柱：spring rod弹弓:die spring中托司：ejector guide bush中托边：ejector guide pin镶针：pin销子：dowel pin波子弹弓：ball catch复位键、提前回杆：early return bar气阀：valves斜导边：angle pin术语：terms承压平面平衡：parting surface support balance模排气：parting line venting回针碰料位：return pin and cavity interference模总高超出啤机规格：mold base shut hight顶针碰运水：water line interferes withejector pin料位出上/下模：part from cavith (core) side模胚原身出料位：cavity direct cut on A-plate,core direct cut on B-plate.不准用镶件： Do not use (core/cavity) insert用铍铜做镶件： use beryllium copper insert初步（正式）模图设计：preliinary (final) mold design反呵：reverse core弹弓压缩量：spring compressed length稳定性好：good stability,stable强度不够：insufficient rigidity均匀冷却：even cooling扣模：sticking热膨胀：thero expansion公差：tolorance铜公(电极）：copper elei模具专业英语词汇dowel pin 定位梢draft 拔模锥度draw bead 张力调整杆drive bearing 传动轴承ejection pad 顶出衬垫ejector 脱模器ejector guide pin 顶出导梢ejector leader busher 顶出导梢衬套ejector pad 顶出垫ejector pin 顶出梢ejector plate 顶出板ejector rod 顶出杆ejector sleeve 顶出衬套ejector valve 顶出阀eye bolt 环首螺栓filling core 椿入蕊film gate 薄膜形浇口finger pin 指形梢finish machined plate 角形模板finish machined round plate 圆形模板fixed bolster plate 固定侧模板flanged pin 带凸缘销flash gate 毛边形浇口flask 上箱floating punch 浮动冲头gate 浇口gate land 浇口面gib 凹形拉紧楔goose neck 鹅颈管guide bushing 引导衬套guide pin 导梢guide post 引导柱guide plate 导板guide rail 导轨head punch 顶头冲孔headless punch 直柄冲头heavily tapered solid 整体模蕊盒hose nippler 管接头impact damper 缓冲器injection ram 压射柱塞inlay busher 嵌入衬套inner plunger 内柱塞inner punch 内冲头insert 嵌件insert pin 嵌件梢king pin 转向梢king pin bush 主梢俗称大全广东模具术语深圳方言模具术语: 模胚类: 唧嘴---浇口衬套法兰---定模浇口衬套定位环,扶针---回针, 垃圾钉---顶针板止停销杯头螺丝---内六角沉孔螺丝模具类: 前模---又叫A模或定模, 后模---又叫B模或动模行位---滑块, 钶---镶在后模上的芯子(或叫模仁),机械类工具类: 锣床---铣床, 锣床批土---铣床虎口钳,磨床批土---磨床打直角虎门钳, 匙把揦---活钳或开口扳手的一种称呼刀具工具类: 牙嗒---丝攻, 坑手-攻牙用的扳手, 机转---铁圆规, 奔子---磨成尖头用于敲击划线相交定位点的工具产品类: 止口---夹口美术线,又称遮丑线, 啤把---拨模斜度, 火箭脚---位于司柱的加强筋机米螺丝：无头螺丝中山方言模具术语模具类: 斜导柱=斜边锁紧块=铲鸡东莞模具术语：机械工具类：虎钳------批士； C形夹-----虾公码；钻孔------钻窿；加工中心-电脑锣；偷胶-------减胶火山口-------司筒底部的减胶位；公模肉＝后模；母模肉＝前模環保標志=回收章細水口=針點澆口潛水=針點澆口；鑲件=入子；排氣槽=逃氣道披鋒=毛邊；加膠=加料；密封圈=膠圈中托司=頂出導柱(套)=哥林柱水口扣針＝拉料頂針插穿(碰穿)＝靠破曬紋＝咬花波子螺絲＝定位珠开模器=拉胶模胚类：水口边细水口或简化型模胚的从水口板上贯下来的那支导柱中托司顶针板导柱 ;零度块方型辅助器模具类斜顶------斜方水塔，水桶------模仁上钻个深孔，中间用铜片或亚加力板隔开，运水一边进一边出来冷却的水喉，水嘴-----冷却水接口 ;呵----模仁铜公-----放电用的电极 ; 弹弓---弹簧 ; 入水---进胶点模具加工类的飞模------合模好象用白话说的外（音是如此，估计是WIRE）---线切割放电-----打火花 ;省模，打光----抛光光刀---我们这是用来指CNC精加工加工模仁，多用于公模开粗---粗加工，留少许余量开框---模胚上加工放模仁的位置穿线孔---线割时用来穿钼丝的产品类加强筋---加强用的骨位 ; 美工线---上下盖装配的中间的间隙（可有效防上错位）行位 >滑块 ;司筒 >套筒入子 >镶件（INSERT）入子为台灣叫法 ;斜顶 >斜顶块或斜顶杆 KO孔 > 顶棍孔 ;司筒针 > 套筒针撑头 > 支撑柱(防止B板变形的) ;铲鸡 >行位锁紧块治具 > 工具(夹具) ；喉咀 > 水管头；行位波仔 >滑块斜器；中托司 >浇口衬套水口板 >流道板；细水口板 >分流道板勾针 >拉料杆；B板 >动模板；A板 >定模板产品的夹线 >分型线；运水 >冷却水道；回针 >复位顶针；隔热板 >热流道模上用的撬模位 >用来公开AB板的；码模坑 >注射时固定上下模的通框 >把框开成通；大水口模----二板模；小水口模----三板模斜顶(又叫推方)----楣仔方；方铁----凳仔方夹水纹----熔胶线火花纹----电火花加工后留下的纹粗公----电火花粗加工用的铜公精公----电火花精加工用的铜公晒字----做好菲林再拿去加字体的加工方法开模器=拉胶=拉模扣密封圈=膠圈 =防水胶圈=O型圈波子螺絲＝定位珠 =弹弓波子扣机就是控制多板分型的机械装置模具类： K.O孔——顶棍孔——用来顶顶针板的。
常用模具零件中英文对照表
常用模具零件中英文对照表2005-12-19 14:51:17中国注塑网入水：gate进入位：gate location水口形式：gate type大水口：edge gate细水口：pin-point gate水口大小：gate size转水口：switching runner/gate唧嘴口径：sprue diameter二、流道: runner热流道：hot runner,hot manifold热嘴冷流道: hot sprue/cold runner唧嘴直流: direct sprue gate圆形流道：round(full/half runner流道电脑分析：mold flow analysis : [əˈnæləsɪs]流道平衡:runner balance热嘴：hot sprue热流道板：hot manifold发热管：cartridge heater探针: thermocouples插头：connector plug插座：connector socket密封/封料：seal三、运水：water line喉塞：line lpug喉管：tube塑胶管：plastic tube快速接头：jiffy quick connector plug/socker四、模具零件：mold components三板模：3-plate mold二板模：2-plate mold边钉/导边：leader pin/guide pin边司/导套：bushing/guide bushing中托司：shoulder guide bushing中托边：guide pin顶针板：ejector retainer plate托板：support plate螺丝：screw管钉：dowel pin ['daʊəl]开模槽：ply bar scot内模管位：core/cavity inter-lock顶针：ejector pin司筒：ejector sleeve司筒针：ejector pin推板：stripper plate [ˈstrɪpər] 脱漆剂；脱衣舞演员；剥离剂；剥离器缩呵：movable core,return core core puller扣机（尼龙拉勾）：nylon latch lock ['naɪ.lɑn]:斜顶：lifter模胚（架）：mold base上内模：cavity insert下内模：core insert行位（滑块）：slide镶件：insert压座/斜鸡：wedge耐磨板/油板：wedge wear plate压条：plate撑头: support pillar唧嘴：sprue bushing挡板：stop plate定位圈：locating ring锁扣：latch扣鸡：parting lock set推杆：push bar栓打螺丝：S.H.S.B顶板：eracuretun活动臂：lever arm分流锥：spure sperader水口司:bush垃圾钉：stop pin隔片：buffle弹弓柱：spring rod弹弓:die spring中托司：ejector guide bush中托边：ejector guide pin镶针：pin销子：dowel pin波子弹弓：ball catch喉塞:pipeplug锁模块：lockplate斜顶：anglefrompin斜顶杆：angleejectorrod尼龙拉勾：partinglocks活动臂：leverarm复位键、提前回杆：earlyreturnbar气阀：valves斜导边：anglepin术语：terms承压平面平衡：partingsurfacesupportbalance模排气：partinglineventing回针碰料位：returnpinandcavityinterference模总高超出啤机规格：moldbaseshuthight顶针碰运水：waterlineinterfereswithejectorpin料位出上/下模：partfromcavith(core)side模胚原身出料位：cavitydirectcutonA-plate,coredirectcutonB-plate.不准用镶件：Donotuse(core/cavity)insert用铍铜做镶件：useberylliumcopperinsert初步（正式）模图设计：preliinary(final)molddesign反呵：reversecore弹弓压缩量：springcompressedlength稳定性好：goodstability,stable强度不够：insufficientrigidity均匀冷却：evencooling扣模：sticking热膨胀：theroexpansion公差：tolorance铜公(电极）：copperelectrode塑件模具相关英文词汇出处：FanE『翻译中国』作者：(转载) FanE『翻译中国』2005-12-16 20:41:59compre sion molding压缩成型flash mold溢流式模具plsitive mold挤压式模具split mold分割式模具cavity型控母模core模心公模taper锥拔leather cloak仿皮革shiver饰纹flow mark流痕welding mark溶合痕post screw insert螺纹套筒埋值self tapping screw自攻螺丝striper plate脱料板piston活塞cylinder汽缸套chip细碎物handle mold手持式模具encapsulation molding低压封装成型、射出成型用模具two plate两极式（模具）well type蓄料井insulated runner绝缘浇道方式hot runner热浇道runner plat浇道模块valve gate阀门浇口band heater环带状的电热器spindle阀针spear head刨尖头slag well冷料井cold slag冷料渣air vent排气道welding line熔合痕eject pin顶出针零件英语punch冲头insert入块(嵌入件)deburring punch压毛边冲子groove punch压线冲子stamped punch字模冲子round punch圆冲子special shape punch异形冲子bending block折刀roller滚轴baffle plate挡块located block定位块supporting block for location 定位支承块air cushion plate气垫板air-cushion eject-rod气垫顶杆trimming punch 切边冲子stiffening rib punch = stinger 加强筋冲子ribbon punch 压筋冲子reel-stretch punch 卷圆压平冲子guide plate 定位板sliding block 滑块sliding dowel block 滑块固定块active plate 活动板lower sliding plate 下滑块板upper holder block 上压块upper mid plate 上中间板spring box 弹簧箱spring-box eject-rod 弹簧箱顶杆spring-box eject-plate 弹簧箱顶板bushing bolck 衬套cover plate 盖板guide pad 导料块14. electrical discharge machining (EDM) 电火花加工15. electrical insulating property 电绝缘性能16. electrochemical die-sinking machine 电解型腔加工机，电解型腔加工机床17. electrochemical machine (ECM) 电解加工机床，电化学加工机床18. electrochemical machining (ECM) 电解加工，电化学加工19. electro-discharge cutting 电火花加工，电火花切割20. electro-discharge cutting machine 电火花切割机21. electro-discharge machine tool 电火花加工机床22. Electro-discharge Machine 电火花加工机床23. electro-discharge machining 电火花加工24. electro-discharge machining process 电火花加工工艺，电火花加工工序25. epoxy resin 环氧树脂9. guide bushing 导套10. guide pillar 导柱，导杆，导柱11. guide pin 导向销，导杆12. guide pin cover 导柱盖13. guide plate 导料板，导板14. guide plate blanking die 导板式冲裁模，导板式落料模15. guide post 导柱，导柱16. guide stock plate 挡料板4. injection mold 注射模，注塑模5. injection molding 注射成型，注塑成型6. injection-molding machine 注塑机，注射机，注塑成形机7. injection plunger 注射柱塞8. in-line reciprocating screw 联机往复螺杆，串联往复螺杆，直线排列往复螺杆9. inner ram 内滑块10. inserting molding 嵌件成形11. integrated manufacturing 集成制造12. internal stress 内应力13. intermediate platen 中间板，隔板塑料成型模具的主要设计要素脱模距stripper distance脱模斜度draft投影面积projected area最大开距maximum daylight;open daylight闭合高度mould-shut height抽芯距core-pulling distance抽芯力core-pulling force脱模力ejector force开模力mould opening force模内压力internal mould pressure;cavity pressure成型压力moulding pressure背压环back-up ring1 bar = 14.5psi高压接头bite type fitting液压马达hydraulic motor冷却水流量计waterflow regulator打磨器材abrasive material打磨砂轮grinding wheels切割砂轮cutting wheels码模夹(注塑机使用) mould clamps; lifting clamps 小五金工具piping tools高压力软管high pressure hose风管,水软管air .water hose高压油表pressure gauge压力油喉hydraulic hoses光塑检测photoelastic testing吹塑模plastic blow mould注塑模plastic injection mould冲扎复合模blank & form compound die精密冲模precision blanking die熔料流动率MFR=melt flow rate熔料流动指数MET=melt flow index推板导柱guide pin for ejector plater座板clamping plate垫块space block(plate)推板ejector block(plate)afdek plate 档尘板guide stripe 行位后板cavity sub-insert 前模镶件core sub-insert 后模镶件sprue puller insert 扣针镶件stage ejector 顶棍spacer rock(risers) 间隔板变形distortion弯曲warp拖花drag marks火花纹EDM marks困气venting烧黑burns表面缩水shrinkage料位过薄/砸穿thin wall stock走水不平行uneven fill pattern夹水纹/流纹witness line;mismatch;stress marks 走水纹knit lines走水不齐short shotsorifice 料口nozzle seat 热嘴垫圈nozzle plate 射嘴板cross pin 十字头销sled 射台seal ring 封密圈spacer rail 介子座heater groove 发热管槽heater cement 发热管的结合剂soak 浸泡seat 垫圈ream 铰大圆孔直径grind 磨床drill 钻床mill 铣床caliper 卡尺G-caliper 分厘卡Depth Gauge 深厚计hardness tester 硬度计angle gauge 角规marble table 云台石projector 投影仪height gauge 高度仪microscope 显微镜plug gauge 塞规leveller 水平器R gauge R 规Inter caliper 内分厘卡surface 平面仪item number 细目编码catalog number 材料分类编码undercut lip 倒扣口hot tip = hot drop = nozzle 热嘴blow-off strip 放气板blow-off nozzle 吹风口spiral hose 螺旋式的连接喉rust solvent 除锈剂shaft 曲轴tensile strength 拉伸力yield strength 屈服力spark erosion 电火花蚀刻etch(photo-etch) 电蚀harden 淬硬copper electrode 铜公corrosion resistance 耐腐蚀anneal 退火heat treatment 淬火FEM(finite elemnet method) 有限元法preliminary tool design 初期模具设计图zone 热流道区域reverse taper 倒啤把clamp plate 码板toggle clamp 快速夹vacuum furnace 真空炉cavity insert rounds 圆柱镶件cavity insert b0locks 方柱镶件tensile strength 抗张强度,抗拉强度Concept drawing 概念图Assembly drawing 装配图mismatch;witness line 夹纹shut-off(n.) 枕位venting valves 疏气阀venting plug 疏气塞valve casing 阀门罩twist drill 旋钻harden/nitride 碎硬anneal 退火temper 回火stess crack 应力断裂corrosion resistance 防腐,防锈tensile strength 物】抗张强度,抗拉强度split mould (分离)组合式的模具inclined plate 斜面inclined bolt 斜栓jaw (工具,机械等)夹住东西的部分,钳口step change of the P/L 分形面枕位的改变thin steel section 较薄的料位clean-up 清理,清除,清扫Mold Dating Insert 模具日志镶件Hot Sprue Bushing 热浇口套semi-automatic 半自动quick disconnector 快速断开接头full shot 足量注射mismatch 夹痕;夹水纹ejector mark 顶痕screw boss 螺丝孔,螺丝基座sink mark 缩坑15% glass filled ABS 掺有15%玻璃的ABSspraying mold release 脱模剂drag mark 拖痕stress mark 应力痕reinforcement rib 加强筋slght stoning 轻度磨砂soliid line 实线dotted line 虚线internal diameter 内径external diameter 外径nickel-plated 电镀的handling hole;lifting hole 吊装孔parallel 平行块piston 活塞plunger 柱塞carrier 导轨rest 支架item number 项目编号catalog item 商品目录编码dimensional datum 尺寸基准heat treatment certification 淬硬证明文件back-up bushing 支撑导套jacking screw 起重螺丝,千斤顶tapped hole (带有螺旋角度的)螺丝孔diagonal corner 成对角的角落burn mark 烧痕hot runner mainfold (热流道板)分流板texuring 蚀纹clamping screw (注塑机)码模螺丝imperial 英制的metric 公制的puller bushing 水口套puller bar 水口铁drool bushing 防漏胶套筒safety switch 限位制water line connected internally or hard tubing 不可用胶喉连接运水lifter on square rod or locked from rotation 用方形柱或用管钉止转gate insert 入水镶件gate shut-offs 流道开关配件guided ejection 中托司parting line shutoff 前后模接触面waterlines clear tie bars. 运水喉咀接驳位要避开啤机呵林柱. BGV=Balanced Gate Value 平衡入水值spacer 垫块pocket 挖槽rough 粗加工finish 精加工plunge rate 进刀率retract rate 提刀速率splindle rate 主轴转速coolant 冷却液SPLIT RING 开口环(钥匙圈)侧向抽芯力side pulling-core forceconvert.transfer 转图guide pin 边针Tee slot cutter T形SLOT CUTTERzigzag 双向切削constant overlap spiral 等距环切parallel spiral 环绕切削parallel spiral clean corners 环切并清角morph spiral 依外形环绕true spiral 螺旋切削one way 单向end mill 平铣刀spher mill 球刀bull mill 圆鼻刀face mill 面铣刀rad mill 圆角成型刀chamfer mill 倒角刀slot mill 槽刀taper mill 推拔铣刀dove mill 鸠尾铣刀lot mill 棒状drill 钻孔reamer 纹刀bore bar 搪刀tap RH 右牙刀Tap LH 左牙刀ctr Drill 中心钻spot drill 点钻cntr bore 沉头孔刀c. sink 鱼眼孔钻loft surface 举升曲面coons surface 昆氏曲面ruled surface 直纹曲面revolved surface 旋转曲面swept surface 扫描曲面draft surface 牵引曲面grinding wheel 磨砂使用的轮子quench steel 将...淬火,使冷却stress relieving 应力消除molten 熔热的oxide film 氧化层guide pin and sleeve, locating ring ,导边,司筒,定位圈ejector ,ejector balde, ejector sleeve,顶针,扁顶针,顶针司筒, lifters, wear plate,horn pin,斜坊,磨损板,气顶针,O ring, water baffle, water pipe plug,O形圈,隔片,运水管道塞, water line connector,wear plate ,运水管道转接头,耐磨板air cylinder,hydraulic cylinder,氯压缸,液压缸micro switch,oil nipple, spring,开关装置,油枪接头,弹弓sprue bushing,early return system,浇口套,早期回撞装置, accelerated ejectors, slied holder,加速顶针,注塑周期计数器, cycle counter,date stamper，滑块固定板,生产日期铭牌,hot runner system ，热流道系统chemical composition 化学成份thermal conductiivity 导热性能thermal diffusivity 热扩散性能dimensonal stablity 尺寸稳定性能cooling effiency 冷却效率easiler ejection 易于脱模alloy insert 合金镶件(cooling) duct 输送管;导管maintenance cost 维护费用ultrasonic testing 超声波检测crack 断裂direct gate 直接浇口ring gate 环形浇口disk gate;disphragm gate 盘形浇口spoke gate;spider gate 轮辐浇口pin-point gate 点浇口edge gate 侧浇口submarine gate;tunnel gate 潜伏浇口fan gate 扇形浇口tab gate 护耳浇口runner plate 流道板(或冷或热)secondary nozzle 二级喷嘴torpedo;torpedo body assembly 鱼雷形组合体catridge heater 管式加热器heat pipe 热管valve gate 阀式浇口force plunger;pot plunger 柱塞flash groove;spew groove 溢料槽impression;cavity block;cavity plate 凹模punch;force 凸模movable insert;loose detail 活动镶件cavity splits;core splits(凹模拼块) (型芯拼块) 拼块side core 侧型芯thread plug;threaded core 螺纹型芯thread ring;threaded cavity 螺纹型环cutting wheel 切割砂轮grinding wheel 打磨砂轮abrasive material 打磨器材mould clamps;lifting clamp 砂模夹(注塑机使用) air (water) hose 风管,水轮管pressure gauge 高压油表hydraulic hose 压力油喉plastic blow mould 吹塑模plastic injection mould 注塑模blandk&form compound die 冲扎复合模precisiion blanking die 精密冲模MFR=melt flow rate 熔料流动率MFT=melt flow index 熔料流动指数handling hole 拉铃孔stop plate 限位块linder bush 衬套spacer block(plate) 垫块,方铁back-up ring 背位环standoff 限位块American Safety Hoist Rings. 英制安全吊装环Mechanical Properties 机械性能Tensile Strength(MPa) 抗拉强度elongation 延伸率hardness(Brinell) 硬度shear stength(MPa) 剪切力impact strength 冲韧性Physical Properties 物理性能solidification shrinkage 凝固收缩率freezing range 凝固与熔范围thermal expansion 热膨胀系数specific heat 比热thermal conductivity 热导率electrical conductivity 电导率micro-structure 金相分析hot work tool steel 热作钢circular motion 环形运动variable 变数,参数graphics window 图形窗口45 degree entry and a zero degree exit. 进刀口45度,退刀口0度runner stripper plate 脱料板stripper plate 活动板spacer rock(risers) 间隔板stage ejector 顶棍sprue puller insert 扣针导套guide strip 行位后板afdek plate 挡尘板side gate 大水口pinpoint gate 细水口SHCS 杯头螺丝FHCS 平头螺丝set screw 无头螺丝ball catch 波子螺丝wedge 行位较杯gib 线条,(撑鸡的导轨)latch 拉杆clamp 码仔spring guide pin 弹弓导柱steel pad disc 橙仔方ejector cam insert 斜顶块(screw) nut 螺母taper 嗲把/ 斜度taper interlock 嗲把锁texture 花纹toggle-lok 回撞装置top clamping plate 顶码板unified national coarse (UNC) 美制螺丝(粗牙)unified national fine (UNF) 美制螺丝(幼牙)set screw 喷头螺丝side gate 大水口slide retainer 行位管位water junction 喉咀spacer block 登仔jiffy-matic socket 喉咀套jiffy-tite plug 喉咀公spring plunger 弹弓座sprue puller 勾针/勾粒spring washer 弹簧塑圈stepped ejector pin 有托顶针strippers plate 推板/细水口板submarine gate 潜水口support pin 拉杆support plate 暗板surface finish 光洁度alignment strip 斜锁angle pin 斜针fan gate 扇形入水fillet 圆口ball catch 弹弓波子blade ejector 扁顶bottom clamping plate 底码板free length 自然长度bridge piece 水口铁helix spindle 锅杆hose clip 水喉箍bubbler 隔气运水jiggle 斜顶jiggle witness line 斜顶片位置center distance (CRS) 山打距离(中心线距离)clamp 码仔contour 外形leader pin 导针location ring(flange) 法兰counterbore 拔头,介子托mock-up;prototype 手办die cast 合金压铸national pipe thread(NPT) 美制喉牙overflow 垃圾位ejection sleeve 司筒,顶套epoxy 胶样pin point gate 细水口pressure plug 喉塞pressure spring 压力弹簧parting line flash 披锋burned 烧黑underfilled 缺料insert mismatch 镶件夹口ejector pins not flush 顶针有高低ejector pins skid 顶针滑动insert flash 镶件披锋pressure transducer 压力探测头hydraulic schematic 油积筒油路接驳图jiffy connector recessed 安装喉嘴后不可突出模胚knock out pullback stud -flush with clamp plate 顶棍镶件与底板有否空间safety switches 限位开关stop block 限位块safety strap 安全带drool bushing 防漏胶套筒insert mismatch 镶件夹口EDM visible 明显火花纹lifter scrapes 斜顶拖花short shots 走水不齐wall stock 料位厚薄knit lines 走水纹stress marks 夹水纹uneven fill pattern 走水不平行drag marks 拖花sprue pretrusion 唧嘴突出高度sprue orifice and radil size 唧嘴R尺寸sprue bushing-keyed 唧嘴有管钉English Chineseprogram name 产口名称part name 零件名称tool name 模具名称tool source 模具来源tool steel 模具钢材resin 塑料program number 产品编号part number 零件编号tool number 模具编号customer 客户名称No of cavities 内模编号machine size 啤机吨数drum miller 鼓形铣床duplex horizontal miller 复式卧铣床face miller 端面铣床grinding miller 研磨机plain miller 平面铣床planer-type miller 刨式铣床rack miller 齿条铣床slab miller 大型平面铣床slot miller 键槽铣刀spline miller 花键铣刀thread miller 螺纹铣刀vertical miller 立式铣刀,立辊,立辊轧机endmill 立铣刀plastic mould steel 塑料模钢cold work steel 冷作钢hot work steel 热作钢high speed steel 高速钢electric magnetic clutch 电磁离合器pad printer 移印机screen printer 丝印机hot stamper 烫印机solid carbide slitting saw 钻石钢锯片convex cutter 凸锣刀片concave cutter 凹锣刀片side&face cutters,staggered teeth 正侧双用镶钻石钢锣刀end-mill 锣刀semi-rod 半圆刀split double end 双头刀single end 单头刀2-flute 两辨3-flute 三辨4-flute 四辨reamer 直拈centre drill 中心钻solid carbide drill 钻咀zinc ingot 锌锭aluminium ignot 铝锭tin ignot 锡锭heater cement 发热管的结合剂heater groove 发热管槽spacer rail 介子座cross pin 十字头销nozzle plate 射嘴板nozzle seat 热嘴addendum 齿冠dedendum 齿根air compressor 空气压缩机air exhauster 抽气机air intake 进气口air seal 空气隔离层。
（整理）常用模具零件中英文对照表
（整理）常用模具零件中英文对照表常用模具零件中英文对照表2005-12-19 14:51:17中国注塑网一、入水：gate进入位：gate location水口形式：gate type大水口：edge gate细水口：pin-point gate水口大小：gate size转水口：switching runner/gate唧嘴口径：sprue diameter二、流道: runner热流道：hot runner,hot manifold热嘴冷流道: hot sprue/cold runner唧嘴直流: direct sprue gate圆形流道：round(full/half runner流道电脑分析：mold flow analysis流道平衡:runner balance热嘴：hot sprue热流道板：hot manifold发热管：cartridge heater探针: thermocouples插头：connector plug插座：connector socket密封/封料：seal三、运水：water line喉塞：line lpug喉管：tube塑胶管：plastic tube快速接头：jiffy quick connector plug/socker四、模具零件：mold components三板模：3-plate mold二板模：2-plate mold边钉/导边：leader pin/guide pin边司/导套：bushing/guide bushing中托司：shoulder guide bushing中托边：guide pin顶针板：ejector retainner plate托板：support plate螺丝：screw管钉：dowel pin开模槽：ply bar scot内模管位：core/cavity inter-lock顶针：ejector pin司筒：ejector sleeve司筒针：ejector pin推板：stripper plate缩呵：movable core,return core core puller 扣机（尼龙拉勾）：nylon latch lock斜顶：lifter模胚（架）：mold base上内模：cavity insert下内模：core insert行位（滑块）：slide镶件：insert压座/斜鸡：wedge耐磨板/油板：wedge wear plate压条：plate撑头: support pillar唧嘴：sprue bushing挡板：stop plate定位圈：locating ring锁扣：latch扣鸡：parting lock set推杆：push bar栓打螺丝：S.H.S.B顶板：eracuretun活动臂：lever arm分流锥：spure sperader水口司:bush垃圾钉：stop pin隔片：buffle弹弓柱：spring rod弹弓:die spring中托司：ejector guide bush中托边：ejector guide pin镶针：pin销子：dowel pin波子弹弓：ball catch喉塞:pipeplug锁模块：lockplate斜顶：anglefrompin斜顶杆：angleejectorrod尼龙拉勾：partinglocks活动臂：leverarm复位键、提前回杆：earlyreturnbar 气阀：valves斜导边：anglepin术语：terms承压平面平衡：partingsurfacesupportbalance模排气：partinglineventing回针碰料位：returnpinandcavityinterference模总高超出啤机规格：moldbaseshuthight顶针碰运水：waterlineinterfereswithejectorpin料位出上/下模：partfromcavith(core)side模胚原身出料位：cavitydirectcutonA-plate,coredirectcutonB-plate.不准用镶件：Donotuse(core/cavity)insert用铍铜做镶件：useberylliumcopperinsert初步（正式）模图设计：preliinary(final)molddesign反呵：reversecore弹弓压缩量：springcompressedlength稳定性好：goodstability,stable强度不够：insufficientrigidity均匀冷却：evencooling扣模：sticking热膨胀：theroexpansion公差：tolorance铜公(电极）：copperelectrode塑件模具相关英文词汇出处：FanE『翻译中国』作者：(转载) FanE『翻译中国』2005-12-16 20:41:59compre sion molding压缩成型flash mold溢流式模具plsitive mold挤压式模具split mold分割式模具cavity型控母模core模心公模taper锥拔leather cloak仿皮革shiver饰纹flow mark流痕welding mark溶合痕post screw insert螺纹套筒埋值self tapping screw自攻螺丝striper plate脱料板piston活塞cylinder汽缸套chip细碎物handle mold手持式模具encapsulation molding低压封装成型、射出成型用模具two plate两极式（模具）well type蓄料井insulated runner绝缘浇道方式hot runner热浇道runner plat浇道模块valve gate阀门浇口band heater环带状的电热器spindle阀针spear head刨尖头slag well冷料井cold slag冷料渣air vent排气道welding line熔合痕eject pin顶出针零件英语punch冲头insert入块(嵌入件)deburring punch压毛边冲子groove punch压线冲子stamped punch字模冲子round punch圆冲子special shape punch异形冲子bending block折刀roller滚轴baffle plate挡块located block定位块supporting block for location 定位支承块 air cushion plate气垫板air-cushion eject-rod气垫顶杆trimming punch 切边冲子stiffening rib punch = stinger 加强筋冲子 ribbon punch 压筋冲子reel-stretch punch 卷圆压平冲子guide plate 定位板sliding block 滑块sliding dowel block 滑块固定块active plate 活动板lower sliding plate 下滑块板upper holder block 上压块upper mid plate 上中间板spring box 弹簧箱spring-box eject-rod 弹簧箱顶杆spring-box eject-plate 弹簧箱顶板bushing bolck 衬套cover plate 盖板guide pad 导料块14. electrical discharge machining (EDM) 电火花加工15. electrical insulating property 电绝缘性能16. electrochemical die-sinking machine 电解型腔加工机，电解型腔加工机床17. electrochemical machine (ECM) 电解加工机床，电化学加工机床18. electrochemical machining (ECM) 电解加工，电化学加工19. electro-discharge cutting 电火花加工，电火花切割20. electro-discharge cutting machine 电火花切割机21. electro-discharge machine tool 电火花加工机床22. Electro-discharge Machine 电火花加工机床23. electro-discharge machining 电火花加工24. electro-discharge machining process 电火花加工工艺，电火花加工工序25. epoxy resin 环氧树脂9. guide bushing 导套10. guide pillar 导柱，导杆，导柱11. guide pin 导向销，导杆12. guide pin cover 导柱盖13. guide plate 导料板，导板14. guide plate blanking die 导板式冲裁模，导板式落料模15. guide post 导柱，导柱16. guide stock plate 挡料板4. injection mold 注射模，注塑模5. injection molding 注射成型，注塑成型6. injection-molding machine 注塑机，注射机，注塑成形机7. injection plunger 注射柱塞8. in-line reciprocating screw 联机往复螺杆，串联往复螺杆，直线排列往复螺杆9. inner ram 内滑块10. inserting molding 嵌件成形11. integrated manufacturing 集成制造12. internal stress 内应力13. intermediate platen 中间板，隔板塑料成型模具的主要设计要素脱模距stripper distance脱模斜度draft投影面积projected area最大开距maximum daylight;open daylight闭合高度mould-shut height抽芯距core-pulling distance抽芯力core-pulling force脱模力ejector force开模力mould opening force模内压力internal mould pressure;cavity pressure成型压力moulding pressure背压环back-up ring1 bar = 14.5psi高压接头bite type fitting液压马达hydraulic motor冷却水流量计waterflow regulator打磨器材abrasive material打磨砂轮grinding wheels切割砂轮cutting wheels码模夹(注塑机使用) mould clamps; lifting clamps小五金工具piping tools高压力软管high pressure hose风管,水软管air .water hose高压油表pressure gauge压力油喉hydraulic hoses光塑检测photoelastic testing吹塑模plastic blow mould注塑模plastic injection mould冲扎复合模blank & form compound die精密冲模precision blanking die熔料流动率MFR=melt flow rate熔料流动指数MET=melt flow index推板导柱guide pin for ejector plater座板clamping plate垫块space block(plate)推板ejector block(plate)afdek plate 档尘板guide stripe 行位后板cavity sub-insert 前模镶件core sub-insert 后模镶件sprue puller insert 扣针镶件stage ejector 顶棍spacer rock(risers) 间隔板变形distortion弯曲warp拖花drag marks火花纹EDM marks困气venting烧黑burns表面缩水shrinkage料位过薄/砸穿thin wall stock走水不平行uneven fill pattern夹水纹/流纹witness line;mismatch;stress marks 走水纹knit lines走水不齐short shotsorifice 料口nozzle seat 热嘴垫圈nozzle plate 射嘴板cross pin 十字头销sled 射台seal ring 封密圈spacer rail 介子座heater groove 发热管槽heater cement 发热管的结合剂soak 浸泡seat 垫圈ream 铰大圆孔直径grind 磨床drill 钻床mill 铣床caliper 卡尺G-caliper 分厘卡Depth Gauge 深厚计hardness tester 硬度计angle gauge 角规marble table 云台石projector 投影仪height gauge 高度仪microscope 显微镜plug gauge 塞规leveller 水平器R gauge R 规Inter caliper 内分厘卡surface 平面仪item number 细目编码catalog number 材料分类编码undercut lip 倒扣口hot tip = hot drop = nozzle 热嘴blow-off strip 放气板blow-off nozzle 吹风口spiral hose 螺旋式的连接喉rust solvent 除锈剂shaft 曲轴tensile strength 拉伸力yield strength 屈服力spark erosion 电火花蚀刻etch(photo-etch) 电蚀harden 淬硬copper electrode 铜公corrosion resistance 耐腐蚀anneal 退火heat treatment 淬火FEM(finite elemnet method) 有限元法preliminary tool design 初期模具设计图zone 热流道区域reverse taper 倒啤把clamp plate 码板toggle clamp 快速夹vacuum furnace 真空炉cavity insert rounds 圆柱镶件cavity insert b0locks 方柱镶件tensile strength 抗张强度,抗拉强度Concept drawing 概念图Assembly drawing 装配图mismatch;witness line 夹纹shut-off(n.) 枕位venting valves 疏气阀venting plug 疏气塞valve casing 阀门罩twist drill 旋钻harden/nitride 碎硬anneal 退火temper 回火stess crack 应力断裂corrosion resistance 防腐,防锈tensile strength 物】抗张强度,抗拉强度split mould (分离)组合式的模具inclined plate 斜面inclined bolt 斜栓jaw (工具,机械等)夹住东西的部分,钳口step change of the P/L 分形面枕位的改变thin steel section 较薄的料位clean-up 清理,清除,清扫Mold Dating Insert 模具日志镶件Hot Sprue Bushing 热浇口套semi-automatic 半自动quick disconnector 快速断开接头full shot 足量注射mismatch 夹痕;夹水纹ejector mark 顶痕screw boss 螺丝孔,螺丝基座sink mark 缩坑15% glass filled ABS 掺有15%玻璃的ABS spraying mold release 脱模剂drag mark 拖痕stress mark 应力痕reinforcement rib 加强筋slght stoning 轻度磨砂soliid line 实线dotted line 虚线internal diameter 内径external diameter 外径nickel-plated 电镀的handling hole;lifting hole 吊装孔parallel 平行块piston 活塞plunger 柱塞carrier 导轨rest 支架item number 项目编号catalog item 商品目录编码dimensional datum 尺寸基准heat treatment certification 淬硬证明文件back-up bushing 支撑导套jacking screw 起重螺丝,千斤顶tapped hole (带有螺旋角度的)螺丝孔diagonal corner 成对角的角落burn mark 烧痕hot runner mainfold (热流道板)分流板texuring 蚀纹clamping screw (注塑机)码模螺丝imperial 英制的metric 公制的puller bushing 水口套puller bar 水口铁drool bushing 防漏胶套筒safety switch 限位制water line connected internally or hard tubing 不可用胶喉连接运水lifter on square rod or locked from rotation 用方形柱或用管钉止转gate insert 入水镶件gate shut-offs 流道开关配件guided ejection 中托司parting line shutoff 前后模接触面waterlines clear tie bars. 运水喉咀接驳位要避开啤机呵林柱.BGV=Balanced Gate Value 平衡入水值spacer 垫块pocket 挖槽rough 粗加工finish 精加工plunge rate 进刀率retract rate 提刀速率splindle rate 主轴转速coolant 冷却液SPLIT RING 开口环(钥匙圈)侧向抽芯力side pulling-core forceconvert.transfer 转图guide pin 边针Tee slot cutter T形SLOT CUTTERzigzag 双向切削constant overlap spiral 等距环切parallel spiral 环绕切削parallel spiral clean corners 环切并清角morph spiral 依外形环绕true spiral 螺旋切削one way 单向end mill 平铣刀spher mill 球刀bull mill 圆鼻刀face mill 面铣刀rad mill 圆角成型刀chamfer mill 倒角刀slot mill 槽刀taper mill 推拔铣刀dove mill 鸠尾铣刀lot mill 棒状drill 钻孔reamer 纹刀bore bar 搪刀tap RH 右牙刀Tap LH 左牙刀ctr Drill 中心钻spot drill 点钻cntr bore 沉头孔刀c. sink 鱼眼孔钻loft surface 举升曲面coons surface 昆氏曲面ruled surface 直纹曲面revolved surface 旋转曲面swept surface 扫描曲面draft surface 牵引曲面grinding wheel 磨砂使用的轮子quench steel 将...淬火,使冷却stress relieving 应力消除molten 熔热的oxide film 氧化层guide pin and sleeve, locating ring ,导边,司筒,定位圈ejector ,ejector balde, ejector sleeve,顶针,扁顶针,顶针司筒, lifters, wear plate,horn pin,斜坊,磨损板,气顶针,O ring, water baffle, water pipe plug,O形圈,隔片,运水管道塞, water line connector,wear plate ,运水管道转接头,耐磨板air cylinder,hydraulic cylinder,氯压缸,液压缸micro switch,oil nipple, spring,开关装置,油枪接头,弹弓sprue bushing,early return system,浇口套,早期回撞装置, accelerated ejectors, slied holder,加速顶针,注塑周期计数器, cyclecounter,date stamper，滑块固定板,生产日期铭牌,hot runner system ，热流道系统chemical composition 化学成份thermal conductiivity 导热性能thermal diffusivity 热扩散性能dimensonal stablity 尺寸稳定性能cooling effiency 冷却效率easiler ejection 易于脱模alloy insert 合金镶件(cooling) duct 输送管;导管maintenance cost 维护费用ultrasonic testing 超声波检测crack 断裂direct gate 直接浇口ring gate 环形浇口disk gate;disphragm gate 盘形浇口spoke gate;spider gate 轮辐浇口pin-point gate 点浇口edge gate 侧浇口submarine gate;tunnel gate 潜伏浇口fan gate 扇形浇口tab gate 护耳浇口runner plate 流道板(或冷或热)secondary nozzle 二级喷嘴torpedo;torpedo body assembly 鱼雷形组合体catridge heater 管式加热器heat pipe 热管valve gate 阀式浇口force plunger;pot plunger 柱塞flash groove;spew groove 溢料槽impression;cavity block;cavity plate 凹模punch;force 凸模movable insert;loose detail 活动镶件cavity splits;core splits(凹模拼块) (型芯拼块) 拼块side core 侧型芯thread plug;threaded core 螺纹型芯thread ring;threaded cavity 螺纹型环cutting wheel 切割砂轮grinding wheel 打磨砂轮abrasive material 打磨器材mould clamps;lifting clamp 砂模夹(注塑机使用) air (water) hose 风管,水轮管pressure gauge 高压油表hydraulic hose 压力油喉plastic blow mould 吹塑模plastic injection mould 注塑模blandk&form compound die 冲扎复合模precisiion blanking die 精密冲模MFR=melt flow rate 熔料流动率MFT=melt flow index 熔料流动指数handling hole 拉铃孔stop plate 限位块linder bush 衬套spacer block(plate) 垫块,方铁back-up ring 背位环standoff 限位块American Safety Hoist Rings. 英制安全吊装环Mechanical Properties 机械性能Tensile Strength(MPa) 抗拉强度elongation 延伸率hardness(Brinell) 硬度shear stength(MPa) 剪切力impact strength 冲韧性Physical Properties 物理性能solidification shrinkage 凝固收缩率freezing range 凝固与熔范围thermal expansion 热膨胀系数specific heat 比热thermal conductivity 热导率electrical conductivity 电导率micro-structure 金相分析hot work tool steel 热作钢circular motion 环形运动variable 变数,参数graphics window 图形窗口45 degree entry and a zero degree exit. 进刀口45度,退刀口0度runner stripper plate 脱料板stripper plate 活动板spacer rock(risers) 间隔板stage ejector 顶棍sprue puller insert 扣针导套guide strip 行位后板afdek plate 挡尘板side gate 大水口pinpoint gate 细水口SHCS 杯头螺丝FHCS 平头螺丝set screw 无头螺丝ball catch 波子螺丝wedge 行位较杯gib 线条,(撑鸡的导轨)latch 拉杆clamp 码仔spring guide pin 弹弓导柱steel pad disc 橙仔方ejector cam insert 斜顶块(screw) nut 螺母taper 嗲把/ 斜度taper interlock 嗲把锁texture 花纹toggle-lok 回撞装置top clamping plate 顶码板unified national coarse (UNC) 美制螺丝(粗牙) unified national fine (UNF) 美制螺丝(幼牙)set screw 喷头螺丝side gate 大水口slide retainer 行位管位water junction 喉咀spacer block 登仔jiffy-matic socket 喉咀套jiffy-tite plug 喉咀公spring plunger 弹弓座sprue puller 勾针/勾粒spring washer 弹簧塑圈stepped ejector pin 有托顶针strippers plate 推板/细水口板submarine gate 潜水口support pin 拉杆support plate 暗板surface finish 光洁度alignment strip 斜锁angle pin 斜针fan gate 扇形入水fillet 圆口ball catch 弹弓波子blade ejector 扁顶bottom clamping plate 底码板free length 自然长度bridge piece 水口铁helix spindle 锅杆hose clip 水喉箍bubbler 隔气运水jiggle 斜顶jiggle witness line 斜顶片位置center distance (CRS) 山打距离(中心线距离) clamp 码仔contour 外形leader pin 导针location ring(flange) 法兰counterbore 拔头,介子托mock-up;prototype 手办die cast 合金压铸national pipe thread(NPT) 美制喉牙overflow 垃圾位ejection sleeve 司筒,顶套epoxy 胶样pin point gate 细水口pressure plug 喉塞pressure spring 压力弹簧parting line flash 披锋burned 烧黑underfilled 缺料insert mismatch 镶件夹口ejector pins not flush 顶针有高低ejector pins skid 顶针滑动insert flash 镶件披锋pressure transducer 压力探测头hydraulic schematic 油积筒油路接驳图jiffy connector recessed 安装喉嘴后不可突出模胚knock out pullback stud -flush with clamp plate 顶棍镶件与底板有否空间safety switches 限位开关stop block 限位块safety strap 安全带drool bushing 防漏胶套筒insert mismatch 镶件夹口EDM visible 明显火花纹lifter scrapes 斜顶拖花short shots 走水不齐wall stock 料位厚薄knit lines 走水纹stress marks 夹水纹uneven fill pattern 走水不平行drag marks 拖花sprue pretrusion 唧嘴突出高度sprue orifice and radil size 唧嘴R尺寸sprue bushing-keyed 唧嘴有管钉English Chineseprogram name 产口名称part name 零件名称tool name 模具名称tool source 模具来源tool steel 模具钢材resin 塑料program number 产品编号part number 零件编号tool number 模具编号customer 客户名称No of cavities 内模编号machine size 啤机吨数drum miller 鼓形铣床duplex horizontal miller 复式卧铣床face miller 端面铣床grinding miller 研磨机plain miller 平面铣床planer-type miller 刨式铣床rack miller 齿条铣床slab miller 大型平面铣床slot miller 键槽铣刀spline miller 花键铣刀thread miller 螺纹铣刀vertical miller 立式铣刀,立辊,立辊轧机endmill 立铣刀plastic mould steel 塑料模钢cold work steel 冷作钢hot work steel 热作钢high speed steel 高速钢electric magnetic clutch 电磁离合器pad printer 移印机screen printer 丝印机hot stamper 烫印机solid carbide slitting saw 钻石钢锯片convex cutter 凸锣刀片concave cutter 凹锣刀片side&face cutters,staggered teeth 正侧双用镶钻石钢锣刀end-mill 锣刀semi-rod 半圆刀split double end 双头刀single end 单头刀2-flute 两辨3-flute 三辨4-flute 四辨reamer 直拈centre drill 中心钻solid carbide drill 钻咀zinc ingot 锌锭aluminium ignot 铝锭tin ignot 锡锭heater cement 发热管的结合剂heater groove 发热管槽spacer rail 介子座cross pin 十字头销nozzle plate 射嘴板nozzle seat 热嘴addendum 齿冠dedendum 齿根air compressor 空气压缩机air exhauster 抽气机air intake 进气口air seal 空气隔离层。
模具中英文对照
1.目的：为统一本厂冲压模具专业术语的中英文对照作业而制订本文件。
2.范围：适用于本公司各部门之作业。
3.职责：各部人员根据本节内容来进行相关作业。
4.内容：4.1.1 模具相关术语对照表：spotting['spɑtɪŋ] 合模种类中文名称英文名称中文名称英文名称模具种类连续模Progressive die 冲孔模Pierce die 机械手Transfer die 剪边模Trimming die 手动机械手Hand transfer die 下料模Blanking die 单工程模Single die 成形模Forming die 铸造结构模Cast die 折弯模Bending die 简易模Prototype die 围边模Flange die 铆合模Riveting die 拉伸模Draw die 复合模Compound die 快换模Changeable die工序类料带strip 料带图strip layout 工序process 冲导正孔pilot pierce 冲孔pierce 侧冲cam pierce 切边notch 切侧刃notch french 折弯bend 墩薄coin成形form 侧成形cam form 整形restrike 围边flange打凸米boss / dimple 打凸包emboss打字印stamp 打沙拉孔hourglass 面押coin burr 抽孔extrude hole 拍平flat 卷圆curl种类中文名称英文名称中文名称英文名称工序类旋转rotate 铆接rivet产品切边线trim line 铆螺母stake nut 切断cutoff 接刀口mismatch 料带带料处carrier tab 毛刺方向burr direction压线groove 下料blanking模板类上托板top plate 下托板bottom plate 上垫脚upper parallel 下垫脚lower parallel 上模座upper die set 下模座lower die set 上垫板punch backup 下垫板lower backup 上夹板punch holder 下夹板die holder 上脱料板stripper 下模板die plate 冲头punch 凹模die零件类浮块lifter 浮料板lifter plate 成型公form punch 压料块pressure pad 切边冲头trim punch 刀口trim steel 沉头孔counter bore 冲孔入子button 顶针kick off / ejector 废料切断刀slug breaker 成型凹模forming die 整形公restrike punch 导尺rail 导尺顶杆lifter bolt 导料板rail plate 镶件/入子insert侧冲组件cam 滑块slide滑块上油槽oil groove 铲机driver码模槽mounting slot 储运块storage block 限位柱stop block 起吊孔handing hole 起吊环eyebolt 靠块heel脱料板拉杆spool 模座导正块thrust heel 中文名称英文名称中文名称英文名称种类零件类耐磨片wear plate 垫片shim 压块keeper 初始管位first start pin 键槽key slot 键key氮气弹簧nitrogen spring 螺旋弹簧coil spring 聚氨酯弹簧urethane 导柱guide post 导套guide bushing 插针pilot pin 插针套pilot bushing 侧刃french 传感器sensor 销dowel 螺丝screw 拔牙jackscrew垫圈washer 盲销blind dowel压毛边冲头deburring punch 挡块stopping plate压线冲头groove punch 定位块location block字模冲头stamp punch 圆冲头round punch压筋冲头ribbon punch 气垫板air cushion plate 异形冲头special shape punch 气垫顶杆air-cushion eject-rod 切边冲头trimming punch 上压块pressure block加强筋冲头stiffening rib punch 弹簧箱spring box 定位板guide plate 弹簧箱顶杆spring-box eject-rod 压边圈binder 弹簧箱顶板spring-box eject-plate公差类公差tolerance 公差范围tolerance range 上公差upper tolerance 下公差lower tolerance 公差+/- 0.05 plus minus 0.05 形位公差图GD&T 平面度flatness 直线度straightness 倾斜度angularity 垂直度perpendicularity 平行度parallelism 圆度roundness种类中文名称英文名称中文名称英文名称公差类圆柱度cylindricity 面轮廓度surface profile 线轮廓度line profile 位置度true position 同轴度concentricity 对称度symmetry 圆跳动runout 全跳动total runout 尺寸dimension 角度值angle degree 尺寸全检报告dimensional layout 三次元尺寸报告CMM report冲床相关机械冲床mechanical press 油压机hydraulic press 吨位tonnage 行程stroke / travel 冲床上台面ram 冲床下台面bolster冲床台面布置图press layout 冲床上的快速对正QDC 冲床气垫air cushion 码仔stirrup 闭合高度shut height T型槽T-slot送料机feeder 送料高度feeding height工卡尺caliper 千分尺micrometer 直尺ruler 高度尺height gage具丝攻screw tap 起子screwdriver 拨牙器jacker 扳手wrench风磨机hand grinder 油石oil stone加工类开料cutting material 钻drill (DR) 攻牙tap 铰ream铣mill 车lathe电脑锣NC mill 线切割wire cutting(W/C) 磨grind 刨planer电火花EDM 镭射laser cutting 倒角chamfer xx的精加工finish XX真空热处理vacuum heattreatment镀钛TD coating 退磁demagnetization 烧焊weld4.1.2 加工说明对照表：加工说明Machining Note注:有0.00的地方为数据填入处X:-￠0.00（氮气弹弓过孔，锣穿）单+0.00X:-￠0.00 (DR.THRU FOR GAS SPRING) S+0.00X:-￠0.00（氮气弹弓沉头，正面CNC单+0.00,锣深0.00.)X:-￠0.00 ( CNC C'BORE TOP SIDE FOR GAS SPRING, S+0.00, DP0.00) X:-￠0.00（氮气弹弓沉头，反面CNC单+0.00,锣深0.00.)X:-￠0.00 (CNC C'BORE OPP SIDE FOR GAS SPRING, S+0.00, DP0.00) X:-￠0.00（合销孔,铰)X:-￠0.00 (REAM FOR DOWEL)X:-￠0.00（合销孔,割)单+0.00X:-￠0.00 (W/C FOR DOWEL) S+0.00(正面沉头￠0.00*0.00深,内攻M0.00*1.5牙)(￠0.00*0.00 C'BORE DP0.00 TOP SIDE, TAP M0.00*1.5 THR)(反面沉头￠0.00*0.00深,内攻M0.00*1.5牙)(￠0.00*0.00 C'BORE DP.0.00 OPP. SIDE, TAP M0.00*1.5 THR)X:-￠0.00（合销孔,钻穿)X:-￠0.00 (DR.THRU FOR DOWEL)X:-￠0.00（一般孔,钻穿)X:-￠0.00 (DR.THRU HL)X:-￠0.00（穿丝孔,钻穿)X:-￠0.00 (DR.THRU FOR WEDM S.H.)X:-￠0.00（漏油孔,钻穿)X:-￠0.00 (DR.THRU FOR DRAIN HL)X:-（漏油槽,反面CNC单+0.00,锣深0.00)X:- (CNC POCKET OPP.SIDE FOR DRAIN, S+0.00, DP0.00)X:-￠0.00（基准孔,铰)X:-￠0.00 (REAM FOR DATUM HL)X:-￠0.00钻穿（螺丝过孔)内攻M0.00牙X:-￠0.00 (DR.THRU FOR CLEARANCE HL, TAP M0.00 THR)(正面沉头￠0.00*0.00深)(￠0.00*0.00 C'BORE DP0.00 TOP SIDE)(反面沉头￠0.00*0.00深)(￠0.00*0.00 C'BORE DP0.00 OPP. SIDE)(侧面沉头￠0.00*0.00深)(￠0.00*0.00 C'BORE DP0.00 EDGE SIDE)X:-M0.00钻穿,反面攻深0.00,有效牙0.00X:-M0.00 DR.THRU, TAP DP0.00 OPP.SIDE, THR DP0.00)X:-M0.00钻穿,正面攻深0.00，有效牙0.00X:-M0.00 DR.THRU, TAP DP0.00 TOP SIDE, THR DP0.00)X:-M0.00钻穿,正反面攻深0.00，有效牙0.00X:-M0.00 DR.THRU, TAP DP0.00 TOP&OPP. SIDE, THR DP0.00)X:-M0.00盲孔,反面攻深0.00,有效牙0.00X:-M0.00 BLIND HL, TAP DP0.00 OPP. SIDE, THR DP0.00)X:-M0.00盲孔,正面攻深0.00，有效牙0.00X:-M0.00 BLIND HL, TAP DP0.00 TOP SIDE, THR DP0.00)X:-M0.00盲孔,正反面攻深0.00，有效牙0.00X:-M0.00 BLIND HL, TAP DP0.00 TOP&OPP. SIDE, THR DP0.00)X:-M0.00盲孔,侧面分中攻深0.00,组模自配X:-M0.00 BLIND HL, TAP DP0.00 ON EDGE FROM CENTER , DIE MAKER FIT) (侧面沉头￠0.00*0.00深)(￠0.00*0.00 C'BORE DP0.00 EDGE SIDE)X:-M0.00盲孔,侧面分中钻深0.00X:-M0.00 BLIND HL, DR. DP0.00 ON EDGE FROM CENTERX:-M0.00钻穿（拨牙螺丝孔，攻穿）X:-M0.00 DR.THRU FOR JACK SCREW, TAP THRUX:-￠0.00（塞打过孔,钻穿)X:-￠0.00 DR.THRU FOR SPOOLX:-￠0.00（弹弓过孔,钻穿)X:-￠0.00 DR.THRU FOR SPRINGX:-￠0.00（弹弓孔,反面沉深0.00)有效深0.00X:-￠0.00 (C'BORE FOR SPRING DP.0.00 OPP.SIDE, USED DP.0.00)X:-￠0.00（弹弓孔,正面沉深0.00)有效深0.00X:-￠0.00 (C'BORE FOR SPRING DP.0.00 TOP.SIDE, WORK DP.0.00)X:-（避空孔,锣穿)单+0.00X:- (POCKET THRU)S+0.00X:-（避空孔,正面CNC单+0.00,锣深0.00)X:- (POCKET, CNC MILL S+0.00 DP0.00 TOP SIDE)X:-（避空孔,反面CNC单+0.00,锣深0.00)X:- (POCKET, CNC MILL S+0.00 DP0.00 TOP SIDE)X:-￠0.00（避空孔,反面CNC单+0.00,锣深0.00)X:-￠0.00 (POCKET, CNC MILL S+0.00, DP0.00 OPP.SIDE)X:-￠0.00（避空孔,正面CNC单+0.00,锣深0.00)X:-￠0.00 (POCKET, CNC MILL S+0.00, DP0.00 EDGE SIDE)X:-￠0.00（两用销过孔,割)单+0.00X:-￠0.00 (LIFTER PIN, W/C S+0.00)X:-（导尺避空,CNC单+0.00锣穿)X:- (POCKET FOR RAIL, CNC MILL THRU, S+0.00)X:-（导尺避空,正面CNC单+0.00，锣深0.00)X:- (POCKET FOR RAIL, CNC MILL DP.0.00 TOP SIDE, S+0.00) X:-（导尺避空,反面CNC单+0.00，锣深0.00)X:- (POCKET FOR RAIL, CNC MILL DP.0.00 OPP. SIDE, S+0.00) X:-（浮块避空,正面CNC单+0.00，锣深0.00)X:- (POCKET FOR LIFTER, CNC MILL DP.0.00 TOP SIDE, S+0.00) X:-（浮块孔,割）单+0.00(反面避空单+0.00，锣深0.00)X:-（LIFTER HL, W/C)S+0.00(POCKET DP0.00 S+0.00 OPP.SIDE)X:-（浮块孔,锣）单+0.00(反面避空单+0.00，锣深0.00)X:-（LIFTER HL, MILL)S+0.00(POCKET DP0.00 S+0.00 OPP.SIDE)X:-￠0.00（顶针孔,钻穿)（反面沉头￠0.00*0.00深，内攻M0.00*1.5牙)X:-￠0.00 (EJECT PIN, DR.THRU.)(￠0.00 C'BORE DP0.00 OPP. SIDE, TAP M0.00*1.5 THR)X:-￠0.00（顶针孔,钻穿)（正面沉头￠0.00*0.00深，内攻M0.00*1.5牙)X:-￠0.00 (EJECT PIN, DR.THRU.)(￠0.00 C'BORE DP0.00 TOP SIDE, TAP M0.00*1.5 THR)X:-￠0.00（导柱（导套）孔,CNC锣)单+0.00X:-￠0.00 CNC MILL FOR GUIDE PIN(BUSHING) S+0.00X:-￠0.00（导柱（导套）孔,割)单+0.00X:-￠0.00 W/C FOR GUIDE PIN(BUSHING) S+0.00X:-M0.00*1.5(止付螺丝，正面攻深0.00)X:-M0.00*1.5(SET SCREW, TAP DP0.00 TOP SIDE)X:-M0.00*1.5(止付螺丝，反面攻深0.00)X:-M0.00*1.5(SET SCREW, TAP DP0.00 OPP SIDE)X:-（入子孔,CNC单+0.00,锣穿)X:-（INSERT HL, CNC MILL THRU S+0.00)(阴影部分正面沉头单+0.00，锣深0.00)(SHADE AREA, MILL DP0.00 S+0.00 TOP SIDE)(阴影部分反面沉头单+0.00，锣深0.00)(SHADE AREA, MILL DP0.00 S+0.00 OPP SIDE)X:-（入子孔,割）单+0.00X:-（INSERT HL, W/C S+0.00)(阴影部分扣位正面锣深0.00)(SHADE AREA FOR HEAD POCKET, MILL DP0.00 TOP SIDE)(阴影部分扣位反面锣深0.00)(SHADE AREA FOR HEAD POCKET, MILL DP0.00 OPP. SIDE)(正面沉头单+0.00，锣深0.00)(POCKET, MILL DP0.00 TOP SIDE)注: 此处的沉头不能用C'BORE, 只有圆形的沉头才用C'BORE.(反面沉头单+0.00，锣深0.00)(POCKET, MILL DP0.00 TOP SIDE)X:-（入子孔,CNC单+0.00,锣穿)X:- (INSERT HL, CNC MILL THRU. S+0.00)X:-（入子孔,正面CNC单+0.00,锣深0.00)X:- (INSERT HL, CNC MILL DP0.00 S+0.00 TOP SIDE)X:-（入子孔,反面CNC单+0.00,锣深0.00)X:- (INSERT HL, CNC MILL DP0.00 S+0.00 OPP. SIDE)X:-￠0.00（插针孔,铰)单+0.00X:-￠0.00（REAM S+0.00 FOR PILOT PIN)X:-￠0.00（插针孔,割)单+0.00(正面沉头￠0.00*0.00深)X:-￠0.00（W/C S+0.00 FOR PILOT PIN)(￠0.00 C'BORE DP0.00 TOP SIDE)X:-￠0.00（插针孔,钻穿)(正面沉头￠0.00*0.00深)X:-￠0.00（DR.THRU S+0.00 FOR PILOT PIN)(￠0.00 C'BORE DP0.00 TOP SIDE)X:-（冲头过孔,割)单+0.00(正面避空，CNC单+0.00，锣深0.00)(阴影部分扣位正面锣深0.00)X:-（W/C S+0.00 FOR PUNCH CLEARANCE HL)(POCKET, CNC DP 0.00 S+0.00 TOP SIDE)(POCKET SHADE FOR HEAD, DP0.00 TOP SIDE)X:-（冲头过孔,锣穿)单+0.00(正面避空，CNC单+0.00，锣深0.00)X:-（MILL THRU. S+0.00 FOR PUNCH CLEARANCE HL) (POCKET DP0.00 CNC S+ TOP SIDE)X:-（异形冲孔,直x斜x,割)单+0.00(双线部分，割)单+0.00X:-（W/C FOR SPECIAL HL, 0.00 LAND 0.00 TAPER, S+0.00) (W/C PER DOUBLE LINE S+0.00)X:-（冲孔,直x斜x,割)单+0.00X:-（W/C FOR PIERCE DIE HL, 0.00 LAND 0.00 TAPER S+0.00) X:-（冲孔,割)单+0.00X:-（W/C FOR PIERCE DIE HL S+0.00)X:-￠0.00（冲孔漏屎,钻穿)X:-￠0.00 (DR. THRU FOR CHUTE)X:-（异形冲孔漏屎,CNC单+0.00,锣穿）X:-￠0.00 (MILL. THRU FOR SPECIAL CHUTE S+0.00)X:-（产品落料斜度，实数斜30º锣）X:-（MILL 30 TAPER FOR PART RAMP NO CLEARANCE)X:-（漏屎斜度，直x斜45º锣）X:-（MILL FOR CHUTE 0.00 LAND 45 TAPER)。
常用模具零件中英文对照表
常用模具零件中英文对照表常用模具零件中英文对照表2005-12-19 14:51:17中国注塑网入水：gate进入位：gate location水口形式：gate type大水口：edge gate细水口：pin-point gate水口大小：gate size转水口：switching runner/gate唧嘴口径：sprue diameter二、流道: runner热流道：hot runner,hot manifold热嘴冷流道: hot sprue/cold runner唧嘴直流: direct sprue gate圆形流道：round(full/half runner流道电脑分析：mold flow analysis : [??n?l?s?s] 流道平衡:runner balance热嘴：hot sprue热流道板：hot manifold发热管：cartridge heater探针: thermocouples插头：connector plug插座：connector socket密封/封料：seal三、运水：water line喉塞：line lpug喉管：tube塑胶管：plastic tube快速接头：jiffy quick connector plug/socker四、模具零件：mold components三板模：3-plate mold二板模：2-plate mold边钉/导边：leader pin/guide pin边司/导套：bushing/guide bushing中托司：shoulder guide bushing中托边：guide pin顶针板：ejector retainer plate托板：support plate螺丝：screw管钉：dowel pin ['da??l]开模槽：ply bar scot内模管位：core/cavity inter-lock顶针：ejector pin司筒：ejector sleeve司筒针：ejector pin推板：stripper plate [?str?p?r] 脱漆剂；脱衣舞演员；剥离剂；剥离器缩呵：movable core,return core core puller扣机（尼龙拉勾）：nylon latch lock ['na?.lɑn]:斜顶：lifter模胚（架）：mold base上内模：cavity insert下内模：core insert行位（滑块）：slide镶件：insert压座/斜鸡：wedge耐磨板/油板：wedge wear plate压条：plate撑头: support pillar唧嘴：sprue bushing挡板：stop plate定位圈：locating ring锁扣：latch扣鸡：parting lock set推杆：push bar栓打螺丝：S.H.S.B顶板：eracuretun活动臂：lever arm分流锥：spure sperader水口司:bush垃圾钉：stop pin隔片：buffle弹弓柱：spring rod弹弓:die spring中托司：ejector guide bush中托边：ejector guide pin镶针：pin销子：dowel pin波子弹弓：ball catch喉塞:pipeplug锁模块：lockplate斜顶：anglefrompin斜顶杆：angleejectorrod尼龙拉勾：partinglocks活动臂：leverarm复位键、提前回杆：earlyreturnbar 气阀：valves斜导边：anglepin术语：terms承压平面平衡：partingsurfacesupportbalance模排气：partinglineventing回针碰料位：returnpinandcavityinterference模总高超出啤机规格：moldbaseshuthight顶针碰运水：waterlineinterfereswithejectorpin料位出上/下模：partfromcavith(core)side模胚原身出料位：cavitydirectcutonA-plate,coredirectcutonB-plate.不准用镶件：Donotuse(core/cavity)insert用铍铜做镶件：useberylliumcopperinsert初步（正式）模图设计：preliinary(final)molddesign反呵：reversecore弹弓压缩量：springcompressedlength稳定性好：goodstability,stable强度不够：insufficientrigidity均匀冷却：evencooling扣模：sticking热膨胀：theroexpansion公差：tolorance铜公(电极）：copperelectrode塑件模具相关英文词汇出处：FanE『翻译中国』作者：(转载) FanE『翻译中国』2005-12-16 20:41:59compre sion molding压缩成型flash mold溢流式模具plsitive mold挤压式模具split mold分割式模具cavity型控母模core模心公模taper锥拔leather cloak仿皮革shiver饰纹flow mark流痕welding mark溶合痕post screw insert螺纹套筒埋值self tapping screw自攻螺丝striper plate脱料板piston活塞cylinder汽缸套chip细碎物handle mold手持式模具encapsulation molding低压封装成型、射出成型用模具two plate两极式（模具）well type蓄料井insulated runner绝缘浇道方式hot runner热浇道runner plat浇道模块valve gate阀门浇口band heater环带状的电热器spindle阀针spear head刨尖头slag well冷料井cold slag冷料渣air vent排气道welding line熔合痕eject pin顶出针零件英语punch冲头insert入块(嵌入件)deburring punch压毛边冲子groove punch压线冲子stamped punch字模冲子round punch圆冲子special shape punch异形冲子bending block折刀roller滚轴baffle plate挡块located block定位块supporting block for location 定位支承块air cushion plate气垫板air-cushion eject-rod气垫顶杆trimming punch 切边冲子stiffening rib punch = stinger 加强筋冲子ribbon punch 压筋冲子reel-stretch punch 卷圆压平冲子guide plate 定位板sliding block 滑块sliding dowel block 滑块固定块active plate 活动板lower sliding plate 下滑块板upper holder block 上压块upper mid plate 上中间板spring box 弹簧箱spring-box eject-rod 弹簧箱顶杆spring-box eject-plate 弹簧箱顶板bushing bolck 衬套cover plate 盖板guide pad 导料块14. electrical discharge machining (EDM) 电火花加工15. electrical insulating property 电绝缘性能16. electrochemical die-sinking machine 电解型腔加工机，电解型腔加工机床17. electrochemical machine (ECM) 电解加工机床，电化学加工机床18. electrochemical machining (ECM) 电解加工，电化学加工19. electro-discharge cutting 电火花加工，电火花切割20. electro-discharge cutting machine 电火花切割机21. electro-discharge machine tool 电火花加工机床22. Electro-discharge Machine 电火花加工机床23. electro-discharge machining 电火花加工24. electro-discharge machining process 电火花加工工艺，电火花加工工序25. epoxy resin 环氧树脂9. guide bushing 导套10. guide pillar 导柱，导杆，导柱11. guide pin 导向销，导杆12. guide pin cover 导柱盖13. guide plate 导料板，导板14. guide plate blanking die 导板式冲裁模，导板式落料模15. guide post 导柱，导柱16. guide stock plate 挡料板4. injection mold 注射模，注塑模5. injection molding 注射成型，注塑成型6. injection-molding machine 注塑机，注射机，注塑成形机7. injection plunger 注射柱塞8. in-line reciprocating screw 联机往复螺杆，串联往复螺杆，直线排列往复螺杆9. inner ram 内滑块10. inserting molding 嵌件成形11. integrated manufacturing 集成制造12. internal stress 内应力13. intermediate platen 中间板，隔板塑料成型模具的主要设计要素脱模距stripper distance脱模斜度draft投影面积projected area最大开距maximum daylight;open daylight闭合高度mould-shut height抽芯距core-pulling distance抽芯力core-pulling force脱模力ejector force开模力mould opening force模内压力internal mould pressure;cavity pressure成型压力moulding pressure背压环back-up ring1 bar = 14.5psi高压接头bite type fitting液压马达hydraulic motor冷却水流量计waterflow regulator打磨器材abrasive material打磨砂轮grinding wheels切割砂轮cutting wheels码模夹(注塑机使用) mould clamps; lifting clamps 小五金工具piping tools高压力软管high pressure hose风管,水软管air .water hose高压油表pressure gauge压力油喉hydraulic hoses光塑检测photoelastic testing吹塑模plastic blow mould注塑模plastic injection mould冲扎复合模blank & form compound die精密冲模precision blanking die熔料流动率MFR=melt flow rate熔料流动指数MET=melt flow index推板导柱guide pin for ejector plater座板clamping plate垫块space block(plate)推板ejector block(plate)afdek plate 档尘板guide stripe 行位后板cavity sub-insert 前模镶件core sub-insert 后模镶件sprue puller insert 扣针镶件stage ejector 顶棍spacer rock(risers) 间隔板变形distortion弯曲warp拖花drag marks火花纹EDM marks困气venting烧黑burns表面缩水shrinkage料位过薄/砸穿thin wall stock走水不平行uneven fill pattern夹水纹/流纹witness line;mismatch;stress marks 走水纹knit lines走水不齐short shotsorifice 料口nozzle seat 热嘴垫圈nozzle plate 射嘴板cross pin 十字头销sled 射台seal ring 封密圈spacer rail 介子座heater groove 发热管槽heater cement 发热管的结合剂soak 浸泡seat 垫圈ream 铰大圆孔直径grind 磨床drill 钻床mill 铣床caliper 卡尺G-caliper 分厘卡Depth Gauge 深厚计hardness tester 硬度计angle gauge 角规marble table 云台石projector 投影仪height gauge 高度仪microscope 显微镜plug gauge 塞规leveller 水平器R gauge R 规Inter caliper 内分厘卡surface 平面仪item number 细目编码catalog number 材料分类编码undercut lip 倒扣口hot tip = hot drop = nozzle 热嘴blow-off strip 放气板blow-off nozzle 吹风口spiral hose 螺旋式的连接喉rust solvent 除锈剂shaft 曲轴tensile strength 拉伸力yield strength 屈服力spark erosion 电火花蚀刻etch(photo-etch) 电蚀harden 淬硬copper electrode 铜公corrosion resistance 耐腐蚀anneal 退火heat treatment 淬火FEM(finite elemnet method) 有限元法preliminary tool design 初期模具设计图zone 热流道区域reverse taper 倒啤把clamp plate 码板toggle clamp 快速夹vacuum furnace 真空炉cavity insert rounds 圆柱镶件cavity insert b0locks 方柱镶件tensile strength 抗张强度,抗拉强度Concept drawing 概念图Assembly drawing 装配图mismatch;witness line 夹纹shut-off(n.) 枕位venting valves 疏气阀venting plug 疏气塞valve casing 阀门罩twist drill 旋钻harden/nitride 碎硬anneal 退火temper 回火stess crack 应力断裂corrosion resistance 防腐,防锈tensile strength 物】抗张强度,抗拉强度split mould (分离)组合式的模具inclined plate 斜面inclined bolt 斜栓jaw (工具,机械等)夹住东西的部分,钳口step change of the P/L 分形面枕位的改变thin steel section 较薄的料位clean-up 清理,清除,清扫Mold Dating Insert 模具日志镶件Hot Sprue Bushing 热浇口套semi-automatic 半自动quick disconnector 快速断开接头full shot 足量注射mismatch 夹痕;夹水纹ejector mark 顶痕screw boss 螺丝孔,螺丝基座sink mark 缩坑15% glass filled ABS 掺有15%玻璃的ABSspraying mold release 脱模剂drag mark 拖痕stress mark 应力痕reinforcement rib 加强筋slght stoning 轻度磨砂soliid line 实线dotted line 虚线internal diameter 内径external diameter 外径nickel-plated 电镀的handling hole;lifting hole 吊装孔parallel 平行块piston 活塞plunger 柱塞carrier 导轨rest 支架item number 项目编号catalog item 商品目录编码dimensional datum 尺寸基准heat treatment certification 淬硬证明文件back-up bushing 支撑导套jacking screw 起重螺丝,千斤顶tapped hole (带有螺旋角度的)螺丝孔diagonal corner 成对角的角落burn mark 烧痕hot runner mainfold (热流道板)分流板texuring 蚀纹clamping screw (注塑机)码模螺丝imperial 英制的metric 公制的puller bushing 水口套puller bar 水口铁drool bushing 防漏胶套筒safety switch 限位制water line connected internally or hard tubing 不可用胶喉连接运水lifter on square rod or locked from rotation 用方形柱或用管钉止转gate insert 入水镶件gate shut-offs 流道开关配件guided ejection 中托司parting line shutoff 前后模接触面waterlines clear tie bars. 运水喉咀接驳位要避开啤机呵林柱. BGV=Balanced Gate Value 平衡入水值spacer 垫块pocket 挖槽rough 粗加工finish 精加工plunge rate 进刀率retract rate 提刀速率splindle rate 主轴转速coolant 冷却液SPLIT RING 开口环(钥匙圈)侧向抽芯力side pulling-core force convert.transfer 转图guide pin 边针Tee slot cutter T形SLOT CUTTER zigzag 双向切削constant overlap spiral 等距环切parallel spiral 环绕切削parallel spiral clean corners 环切并清角morph spiral 依外形环绕true spiral 螺旋切削one way 单向end mill 平铣刀spher mill 球刀bull mill 圆鼻刀face mill 面铣刀rad mill 圆角成型刀chamfer mill 倒角刀slot mill 槽刀taper mill 推拔铣刀dove mill 鸠尾铣刀lot mill 棒状drill 钻孔reamer 纹刀bore bar 搪刀tap RH 右牙刀Tap LH 左牙刀ctr Drill 中心钻spot drill 点钻cntr bore 沉头孔刀c. sink 鱼眼孔钻loft surface 举升曲面coons surface 昆氏曲面ruled surface 直纹曲面revolved surface 旋转曲面swept surface 扫描曲面draft surface 牵引曲面grinding wheel 磨砂使用的轮子quench steel 将...淬火,使冷却stress relieving 应力消除molten 熔热的oxide film 氧化层guide pin and sleeve, locating ring ,导边,司筒,定位圈ejector ,ejector balde, ejector sleeve,顶针,扁顶针,顶针司筒, lifters, wear plate,horn pin,斜坊,磨损板,气顶针,O ring, water baffle, water pipe plug,O形圈,隔片,运水管道塞, water line connector,wear plate ,运水管道转接头,耐磨板air cylinder,hydraulic cylinder,氯压缸,液压缸micro switch,oil nipple, spring,开关装置,油枪接头,弹弓sprue bushing,early return system,浇口套,早期回撞装置, accelerated ejectors, slied holder,加速顶针,注塑周期计数器, cycle counter,date stamper，滑块固定板,生产日期铭牌,hot runner system ，热流道系统chemical composition 化学成份thermal conductiivity 导热性能thermal diffusivity 热扩散性能dimensonal stablity 尺寸稳定性能cooling effiency 冷却效率easiler ejection 易于脱模alloy insert 合金镶件(cooling) duct 输送管;导管maintenance cost 维护费用ultrasonic testing 超声波检测crack 断裂direct gate 直接浇口ring gate 环形浇口disk gate;disphragm gate 盘形浇口spoke gate;spider gate 轮辐浇口pin-point gate 点浇口edge gate 侧浇口submarine gate;tunnel gate 潜伏浇口fan gate 扇形浇口tab gate 护耳浇口runner plate 流道板(或冷或热)secondary nozzle 二级喷嘴torpedo;torpedo body assembly 鱼雷形组合体catridge heater 管式加热器heat pipe 热管valve gate 阀式浇口force plunger;pot plunger 柱塞flash groove;spew groove 溢料槽impression;cavity block;cavity plate 凹模punch;force 凸模movable insert;loose detail 活动镶件cavity splits;core splits(凹模拼块) (型芯拼块) 拼块side core 侧型芯thread plug;threaded core 螺纹型芯thread ring;threaded cavity 螺纹型环cutting wheel 切割砂轮grinding wheel 打磨砂轮abrasive material 打磨器材mould clamps;lifting clamp 砂模夹(注塑机使用) air (water) hose 风管,水轮管pressure gauge 高压油表hydraulic hose 压力油喉plastic blow mould 吹塑模plastic injection mould 注塑模blandk&form compound die 冲扎复合模precisiion blanking die 精密冲模MFR=melt flow rate 熔料流动率MFT=melt flow index 熔料流动指数handling hole 拉铃孔stop plate 限位块linder bush 衬套spacer block(plate) 垫块,方铁back-up ring 背位环standoff 限位块American Safety Hoist Rings. 英制安全吊装环Mechanical Properties 机械性能Tensile Strength(MPa) 抗拉强度elongation 延伸率hardness(Brinell) 硬度shear stength(MPa) 剪切力impact strength 冲韧性Physical Properties 物理性能solidification shrinkage 凝固收缩率freezing range 凝固与熔范围thermal expansion 热膨胀系数specific heat 比热thermal conductivity 热导率electrical conductivity 电导率micro-structure 金相分析hot work tool steel 热作钢circular motion 环形运动variable 变数,参数graphics window 图形窗口45 degree entry and a zero degree exit. 进刀口45度,退刀口0度runner stripper plate 脱料板stripper plate 活动板spacer rock(risers) 间隔板stage ejector 顶棍sprue puller insert 扣针导套guide strip 行位后板afdek plate 挡尘板side gate 大水口pinpoint gate 细水口SHCS 杯头螺丝FHCS 平头螺丝set screw 无头螺丝ball catch 波子螺丝wedge 行位较杯gib 线条,(撑鸡的导轨)latch 拉杆clamp 码仔spring guide pin 弹弓导柱steel pad disc 橙仔方ejector cam insert 斜顶块(screw) nut 螺母taper 嗲把/ 斜度taper interlock 嗲把锁texture 花纹toggle-lok 回撞装置top clamping plate 顶码板unified national coarse (UNC) 美制螺丝(粗牙) unified national fine (UNF) 美制螺丝(幼牙) set screw 喷头螺丝side gate 大水口slide retainer 行位管位water junction 喉咀spacer block 登仔jiffy-matic socket 喉咀套jiffy-tite plug 喉咀公spring plunger 弹弓座sprue puller 勾针/勾粒spring washer 弹簧塑圈stepped ejector pin 有托顶针strippers plate 推板/细水口板submarine gate 潜水口support pin 拉杆support plate 暗板surface finish 光洁度alignment strip 斜锁angle pin 斜针fan gate 扇形入水fillet 圆口ball catch 弹弓波子blade ejector 扁顶bottom clamping plate 底码板free length 自然长度bridge piece 水口铁helix spindle 锅杆hose clip 水喉箍bubbler 隔气运水jiggle 斜顶jiggle witness line 斜顶片位置center distance (CRS) 山打距离(中心线距离) clamp 码仔contour 外形leader pin 导针location ring(flange) 法兰counterbore 拔头,介子托mock-up;prototype 手办die cast 合金压铸national pipe thread(NPT) 美制喉牙overflow 垃圾位ejection sleeve 司筒,顶套epoxy 胶样pin point gate 细水口pressure plug 喉塞pressure spring 压力弹簧parting line flash 披锋burned 烧黑underfilled 缺料insert mismatch 镶件夹口ejector pins not flush 顶针有高低ejector pins skid 顶针滑动insert flash 镶件披锋pressure transducer 压力探测头hydraulic schematic 油积筒油路接驳图jiffy connector recessed 安装喉嘴后不可突出模胚knock out pullback stud -flush with clamp plate 顶棍镶件与底板有否空间safety switches 限位开关stop block 限位块safety strap 安全带drool bushing 防漏胶套筒insert mismatch 镶件夹口EDM visible 明显火花纹lifter scrapes 斜顶拖花short shots 走水不齐wall stock 料位厚薄knit lines 走水纹stress marks 夹水纹uneven fill pattern 走水不平行drag marks 拖花sprue pretrusion 唧嘴突出高度sprue orifice and radil size 唧嘴R尺寸sprue bushing-keyed 唧嘴有管钉English Chineseprogram name 产口名称part name 零件名称tool name 模具名称tool source 模具来源tool steel 模具钢材resin 塑料program number 产品编号part number 零件编号tool number 模具编号customer 客户名称No of cavities 内模编号machine size 啤机吨数drum miller 鼓形铣床duplex horizontal miller 复式卧铣床face miller 端面铣床grinding miller 研磨机plain miller 平面铣床planer-type miller 刨式铣床rack miller 齿条铣床slab miller 大型平面铣床slot miller 键槽铣刀spline miller 花键铣刀thread miller 螺纹铣刀vertical miller 立式铣刀,立辊,立辊轧机endmill 立铣刀plastic mould steel 塑料模钢cold work steel 冷作钢hot work steel 热作钢high speed steel 高速钢electric magnetic clutch 电磁离合器pad printer 移印机screen printer 丝印机hot stamper 烫印机solid carbide slitting saw 钻石钢锯片convex cutter 凸锣刀片concave cutter 凹锣刀片side&face cutters,staggered teeth 正侧双用镶钻石钢锣刀end-mill 锣刀semi-rod 半圆刀split double end 双头刀single end 单头刀2-flute 两辨3-flute 三辨4-flute 四辨reamer 直拈centre drill 中心钻solid carbide drill 钻咀zinc ingot 锌锭aluminium ignot 铝锭tin ignot 锡锭heater cement 发热管的结合剂heater groove 发热管槽spacer rail 介子座cross pin 十字头销nozzle plate 射嘴板nozzle seat 热嘴addendum 齿冠dedendum 齿根air compressor 空气压缩机air exhauster 抽气机air intake 进气口air seal 空气隔离层。
