镁合金论文Z61镁合金的磷化及阴极电泳

镁合金论文：AZ61镁合金的磷化及阴极电泳

【中文摘要】镁合金作为优质的合金结构材料,在航空航天、汽车、电子和医疗器材等行业得到广泛应用。但是镁的耐蚀性较差,制约了镁合金的应用。镁合金磷酸盐转化膜具有多孔结构、附着力好,是有机涂层的有效基底。本文采用磷化与阴极电泳涂装相结合的方法改善AZ61镁合金的表面性能。本研究的研究方法、研究内容和结果分别叙述如下。在国内外锌系磷化研究的基础上,选取三种不同的磷化体系。通过对三种磷化体系所得磷化膜的厚度、耐碱性、表面形貌以及元素组成进行对比,选取适宜阴极电泳涂装的磷化膜。采用单因素试验,分别研究磷化液中各物质对磷化成膜的影响。研究表明：

Zn(H2PO4)2的浓度对磷化膜的厚度有较大影响,浓度越大,厚度越大；NaNO3对磷化过程具有良好的促进作用；硫酸羟胺是一种良好的磷化氧化促进剂,且具有用量低的优点；NaF能够促进磷化、细化膜层。间硝基苯磺酸钠与酒石酸添加后对磷化膜的成膜有利,但是添加的浓度与成膜状况关系较小。采用正交设计的方法设计实验,正交表为(L9(34)),选取四种浓度对磷化过程影响较大的物质NaF、硫酸羟胺、ZnH2PO4、NaNO3作为正交试验的四个因素,物质的浓度为各因素的水平。正交优化结果：NaF浓度为 g·L-1、硫酸羟胺的浓度为 g·L-1、ZnH2PO4的浓度为 g·L-1、NaNO3的浓度为5 g·L-1。在上述优化物质浓度下,AZ61镁合金表面形成的磷化膜厚度适中、Δw小、均匀性好、腐蚀电流密度低、耐蚀性良好。在以上工作的基础上,采用上

述磷化条件的磷化膜进行阴极电泳涂装,得到外观(颜色、光亮度、均匀性)较好,厚度在35μm左右,硬度达到2H-3H,与基体的附着力为0级,耐蚀性较好的复合电泳涂层。采用电涡流测厚仪测量磷化膜的厚度；利用金相显微镜、扫描电镜(SEM)观察磷化膜的表面形貌；利用

化学分析方法和能谱分析(EDS)分析磷化膜的成分组成；通过阳极极

化曲线、电化学阻抗谱(EIS)、腐蚀失重等方法评价磷化膜的耐腐蚀

性能。电泳部分采用电涡流测厚仪测量有机涂层的厚度,采用EIS测

试有机涂层的耐蚀性；按国家标准规定的方法测量有机涂层的附着力、硬度和耐溶剂性。

【英文摘要】As a high-quality structural material, magnesium alloys have been used in lots of fields, especially in the aerospace, automobile, electronic and medical equipment. However, the use of magnesium alloy was severely limited by its poor corrosion resisting property. Magnesium alloy phosphating conversion treatment was an effective substrate of organic coating because of its porous and binding force. In this dissertation, phosphating and cathode electrophoretic painting methods were applied to improve the surface performance of the magnesium alloys. The experimental methods, main work and results were recounted as follows this dissertation, three phosphating systems were selected on the basis of investigation both at home and abroad. We select a

optimum phosphating coating for cathode electrophoretic painting by comparing the thickness, weight loss in alkaline solution, surface morphology and elements of three phosphating coatings obtained in different phosphate influences of each substance in phosphate bath on phosphate coatings were researched with single factor test. The results are as follows:the concentration of Zn(H2PO4)2 has an important effect on thickness of film, the film would be thicker with a higher the concentration of Zn(H2PO4)2; the concentration of NaNO3 has effects on the accelerating of the phosphate process; hydroxylamine sulfate is a good accelerator which has characteristic of low consumption; The concentration of NaF can promote the forming of phosphme film and thin crystalline grain. Tartaric acid and nitrobenzene sulfonate have important effects on the formation of phosphate coatings, but their concentrations have no effects on design was used to scheme experiment, the concentrations of four substances were chosen as four factors of orthogonal design table (L9(34)). The optimum orthogonal conditions were CNaF= g·L-1, Chydroxylamine sulfate= g·L-1, CznH2PO4= g·L-1, CNaNO3=5 g·L-1. In the optimized conditions, test results showed that the phosphate coatings formed on magnesium alloys have moderate thickness,
