Submarine cables
Subsea export cables ( MV–HV, AC –DC) Subsea infield cables (MV)
Medium voltage wind farm connections
Single core cables up to 10.000 m (36 kV) (Offshore)* Three core cables up to 1.200 m (36 kV) (Offshore)*
1
5
nkt cables GmbH Schanzenstrasse 6-20 51063 Cologne Germany T ++49 (0)221 676 0 F ++49 (0)221 676 2646 M infoservice@nktcables.com www.nktcables.com
3 3 5 4 4 2 1 5 4
4Байду номын сангаас
4
As one of the first cable producers, nkt cables supplied 20kV submarine cables to offshore installations with integrated optical fibres for additional communication and transmission of process data. The latest development is the new NKT monitoring system with RTTR software „ADAP PRO“ (Real Time Thermal Rating), based on optical fibres in power cables. This system enables our customers to optimize the performance of their high voltage transmission systems – both, on and offshore.
On and Offshore
Medium Voltage and High Voltage Submarine Cable Systems for Wind Farm Projects Continuously in Business for more than 130 Years
What began with submarine telecom cables more than 130 years ago was continued with paper insulated power cables and subsequently with the development of Power Cable Systems, based on XLPE technology up to the highest current levels. Therefore, nkt cables builds on this experience when it comes to tailormade and economic power transmission installations for onshore and offshore applications.
Our Product Scope for Wind Farms: Know-how for whole transmission systems from a single source
By partnering with nkt cables you get access to know-how for complete energy transmission systems, starting with medium voltage and high voltage cables, armoured and cluster cables as well as accessories and a new cable monitoring system. In addition you get access to the highly experienced nkt cables submarine crew, available for quick and professional offshore cable installation and repair jobs.
High voltage wind farm connection
Single core cables up to 3.000 m (145 kV) (Offshore)* HVDC cables
3
STATISTICS · MONITORING · FORECASTING
High voltage connection (Onshore)
On and Offshore
4
1
Focused on the Special Demands of Wind Farms
nkt cables offers complete medium voltage and high voltage cable systems up to 245 kV to solve all cables requirements for on and offshore wind farms. Beside the cables, these cable systems comprise also MV and HV accessories adapted to the special conditions and confined spacing of wind turbines. Excellent efficiency and longevity as well as easy installation and high reliability are the most important characteristics here.
Arguments in favour of nkt cables:
Experienced partner for planning of wind farm grids Full system know how, cable and accessories technique Installation crew experienced with submarine cables Longstanding partnership with the offshore industry Experienced subcontractor partner in offshore cable laying
© nkt cables 009.2e.1.0 · Printed in the Federal Republic of Germany · Subject to technical alterations · 2.2000.2.08 · bb-media-team.de
1
5
More than 130 years of submarine cable know how
Fibre Optic based monitoring with Real Time Thermal Rating system (RTTR)
NKT own System for cable systems (On and Offshore)
Fibre optic Communication Online Monitoring
All cable types are available with integrated optical fibres (On and Offshore)
with new ology RT TR-techn
1
5
And the success story goes on
Reference Highlights of the last Years:
2000: 2001: 2001: 2001: 2002: 2004: 2005: 2006: 3,3 km XLPE cable, 3 x 1 x 120 mm² Cu, 20 kV, + optical fibres, for PEDEEE, Syria 6.8 km XLPE cable, 3 x 240 mm² Cu, 36 kV for The Copenhagen Electricity Supply Board Copenhagen, Denmark (Middelgrunden) 7.6 km XLPE Cable, 3 x 150 mm² Cu, 36 kV for The Copenhagen Electricity Supply Board Copenhagen, Denmark (Middelgrunden) 23.0 km XLPE Cable, 3 x 120 mm² Cu, 36 kV for Provincial Electricity Authority, Bangkok 5.0 km XLPE Cable, 1 x 400 mm² Cu, 72 kV for Fyns Net, Denmark 10.0 km XLPE Cable, 1 x 240 mm² Cu, 72 kV for Østkraft, Bornholm, Denmark 3,4 km XLPE Cable, 3 x 1 x 70 mm² Cu, 11 kV for Kemi Pharm Ltd, Seychelles 11.0 km XLPE Cable, 1 x 240 mm² Cu, 72 kV for Østkraft, Bornholm, Denmark
5
More about the Middelgrunden Project (Denmark):
In December 1999 nkt cables was awarded the contract of linking the world’s largest offshore wind farm with the existing electricity grid. The order included 12 km three core 36 kV XLPE submarine cable, transformers and switchgear. The installation was completed in 2001. It consists of two submarine cables from the main connection of the farm to Amager Power Station and a 5 km long cable for the interconnection of 20 windturbines (cluster cables). Fibre optic cable is integrated in the submarine cable to secure communication and control of the turbines.
Three core cables (170 kV) Single core cables (420 kV)
09 0 2 m Fro ds onwar ble ca r e g n lo ill be w s h t leng lable avai
1
5
4 5
Accessories
Appropriate accessories are available for all the cables mentioned (On and Offshore)
