3寸重低音喇叭规格书

合集下载

Philips HTL3160B 3.1 CH 無線重低音聲棒喇叭說明書说明书

PhilipsSoundBar 喇叭3.1 CH 無線重低音Bluetooth ® 及 NFC HDMI ARC 200 瓦HTL3160B3.1 聲道系統的清晰語音配備有無線重低音喇叭加強電視的語音清晰度及模擬環迴音效，創造屬於您的家庭影院體驗，更可以享受一鍵式 NFC 配對功能無線串流音樂。

連接並體驗一切娛樂•一鍵式 NFC 功能的智能手機，可實現藍牙配對•經藍牙無線音樂串流•EasyLink 經由單一遙控器控制所有 HDMI CEC 設備•音訊輸入讓您享 iPod/iPhone/MP3 播放機的音樂•對應電視、BD/DVD 播放機、遊戲主機、MP3 播放機•透過便攜式 USB 裝置直接享受 MP3 音樂簡約設計•低調設計，放在電視前方是完美之選•輕觸屏幕輕鬆進行播放和音量控制觀看電視和電影體驗更豐富的音效•出色的中置喇叭帶來超卓的清晰音效•杜比數碼與 Pro Logic II 環迴音效•虛擬環迴音效帶給您逼真的電影體驗•無線重低音喇叭帶來震撼效果產品特點杜比數碼與 Pro Logic II內置的杜比數碼解碼器，可處理全部六個聲道的音效資訊，帶給您環迴音效體驗和驚人的自然感受，效果動態又逼真。

杜比邏輯定向 II 可以針對任何立體聲音源，提供五聲道環迴音效處理。

虛擬環迴音效Philips 虛擬環迴音效以少於五個喇叭的系統呈現豐富而令人沉醉的環迴音效。

非常先進的空間演算法可保真重現完美的 5.1 聲道環境中的音波特徵。

任何高品質立體聲來源都可以栩栩如生的多聲道環迴音效傳送。

無需購買額外的喇叭、電線或喇叭座，亦可欣賞響遍全房的音效。

一鍵式 NFC 功能透過一鍵式近距離無線通訊(NFC) 技術，可輕鬆實現 Bluetooth ® 裝置的配對。

只要點一下帶 NFC 功能的智能手機或平板電腦上 Soundstage 的 NFC 區域，即可開啟 Soundstage ，啟動 Bluetooth ® 配對並開始串流音樂。

JBL L100 Classic 3-Way 书架扬声器说明书

2Thank you for purchasing the JBL ® L100 Classic 3-Way Loudspeaker For more than 70 years, JBL has been providing audio equipment for concert halls, recording studios and movie theaters around the world and has become the trusted choice of leading recording artists and sound engineers. The legendary JBL 4310 professional studio monitor helped produce many of the most popular albums of the 1960s and ‘70s. The 4310 was the inspiration for the L100 home audio loudspeaker introduced in 1970, which became JBL’s all-time best selling speaker. The L100 Classic is a modern interpretation of the original L100. The new L100 Classic honors this storied legacy with its iconic 12-inch (300mm) 3-way configuration, but with all-new drivers, crossover network, enclosure, and features to bring the design up to the highest 21st-century performance standards. Utilizing a compact monitor-type footprint, the L100 Classic features advanced JBL transducers including the JW300PW-8 Pure Pulp cone woofer, the 105H-1 Polymer-coated Pure Pulp cone midrange, and the JT025TI1-4 Titanium tweeter. The L100 Classic retains all of the performance attributes that endeared the original L100 to listeners in the ‘70’s and ‘80s, such as exceptional dynamic range and contrast, clean and effortless high output, and precise high impact bass. The updated L100 Classic adds even greater detail resolution across the full bandwidth, lower distortion and more lifelike stereo imaging, particularly off-axis. The L100 Classic is sure to become a new legend among music lovers everywhere.PACKAGE CONTENTS • One L100 Classic loudspeaker • One Quadrex foam grille • One L100 Classic Owner’s Manual PLACEMENT AND POSITIONING CAUTION: The L100 Classic weighs 58.8 lb. (26.7 kg) each. Before placing the speaker on a shelf or platform, be sure that it is sturdy enough to support the speaker’s weight.Before deciding where to place your speakers, survey your room and think about placement, using the illustration below as a guide.• A void placing the speakers near power amplifiers, heat registers or other objects that generate large amounts of heat.• D o not place the speakers in very humid or dusty places.• D o not place the speakers in direct sunlight or where they will be exposed to other intense light.• F or best results, place the speakers 6–8 feet (1.8-2.4m) apart. If you set the speakers farther apart than this, angle them toward the listening position.• T he speakers will produce the most accurate stereo soundstage when the angle between the listener and the speakers is between 40 and 60 degrees.• G enerally, bass output will increase as the speaker is moved closer to a wall or corner. For best performance, we recommend that you place the speakers at least 20 inches (50cm) away from the sidewalls.• T he speaker will yield the best stereo imaging when oriented vertically.• T he L100 Classic may be stand mounted with optional JBL metal stands (model JBL JS-120, sold separately) that angle the speaker upward. • I f not using the optional stands with built-in angle, then we recommend you to position each speaker so that its tweeter is approximately at ear level.min 20 inches (50cm)6-8 feet (1.8-2.4m)40° – 60°Listening PositionCAUTION: Make sure that all of the system’s electrical components are turned OFF (and preferably unplugged from their ac outlets) before making any connections.Speakers and amplifiers have corresponding positive and negative (“+” and “–”)connection terminals. The L100 Classic has color-coded connection terminals. The“+” terminal is red, while the “–” terminal is black. See the illustration on the right.The L100 Classic is designed so that a positive voltage at the “+” (red) terminalwill cause the speaker drivers to move outward (toward the room).We recommend using a high-quality speaker cable with polarity coding. The sideof the wire with a ridge or other coding is usually considered positive polarity (“+”).To ensure proper polarity, connect each “+” terminal on the back of the amplifieror receiver to the respective “+” (red) terminal on each speaker. Connect the “–” (black) terminals in a similar way. See your receiver or amplifier’s owner’s manual to confirm its connection procedures.BASIC SINGLE-WIRE CONNECTIONConnect the amplifier to each speaker as shown inthe illustration on the right.IMPORTANT: Do not reverse polarities (i.e., “+”to “–” or “–” to “+”) when making connections.Doing so will cause poor stereo imaging anddiminished bass performance.The L100 Classic’s gold-plated speaker terminalscan accept a variety of wire connector types:bare wire, spade connectors, pin connectorsand banana connectors.USING BARE WIRE OR PIN CONNECTORS:IMPORTANT: Make sure that the (+) and (–) wires orpins do not touch each other or the other terminal.Touching cables can cause a short circuit that candamage your receiver or amplifier.USING SPADE CONNECTORS:IMPORTANT: Make sure the (+) and (–) spade connectorblades do not touch each other or the other terminal.Touching blades can cause a short circuit thatcan damage your receiver or amplifier.USING BANANA CONNECTORS:Negative (-)TerminalPositive (+)Terminal+-Receiver or Amplifier(one channel shown)SpeakerConnector Panel A. Unscrew CapB. I nsert Bare Wire or Pin Connector through Hole in PostC. T ighten Cap to SecureA. Unscrew CapB. Insert SpaceConnector Bladesaround PostC. T ighten CapB. I nsert Banana Connectorinto Hole in CapA. T ighten Cap3L100 Classic Owner’s ManualCONTROLS/ADJUSTMENTSThe L100 Classic has front-panel adjustments that let you balancethe levels of the midrange driver (MF) and tweeter (HF) relative tothe woofer.You can use these controls to adjust the speaker’s sound accordingto your room’s acoustics, or your personal taste. The “0dB” defaultposition is a good place to start. Whatever sounds best to you inyour room is the right setting.As with most speakers, after you start playing the L100 Classic itwill take the drivers’ suspensions several weeks to “break in” andachieve optimum performance. During this period, the balancebetween the woofer, midrange, and tweeter may change, so werecommendthat you adjust the midrange and tweeter controls again after the break-in period.NOTE: There is a protective plastic film on the front control panel label that may be removed.CARING FOR YOUR SPEAKERS• W ipe the cabinet with a clean, dry cloth to remove dust. Damp cloths or cleaning paper may dull the cabinet’s finish.• D o not use volatile liquids such as benzene, paint thinner, alcohol, etc., on the cabinet. Do not spray insecticide near the cabinet.• T o remove dust from the foam grille, use a vacuum cleaner set to low suction.• D o not wash the grille in water.• I f the surfaces of the woofer and midrange cones become dusty, you can carefully sweep them clean witha soft, dry calligraphy brush or paintbrush. Do not use a damp cloth.• N EVER touch anything to the tweeter dome.SPECIFICATIONSSystem Type3-way bookshelf loudspeakerWoofer 12-inch (300mm) Pure Pulp cone (JW300PW-8)Midrange 5-1/4 inch (130mm) Polymer-coated, Pure Pulp cone (105H-1) Tweeter 1-inch (25 mm) Titanium dome with soft surround (JT025TI1-4) Impedance 4 ohmsRecommended Amplifier Power25-200 Watts RMSSensitivity (2.83V/1m) 90dBFrequency Response 40Hz-40kHz (-6dB)Crossover Frequencies 450Hz, 3.5kHzControls Attenuators for MF and HF DriversConnector Type Five-way gold-plated Binding PostsFinish Genuine walnut veneer enclosure with Quadrex foam grille in a choice of Black, Burnt Orange or Dark BlueDimensions (H x W x D)25.06" H x 15.34" W x 14.625" D (636.6mm x 389.7mm x 371.5mm)Weight 58.5 lb (26.7 kg) each Tweeter ControlMidrange Control4。

扬声器规格书

(测试线路驱动回路)
Figure 1.SPL Inspection Test Fixture 声压检测图
Notes: Apply rated signal from B﹠K audio analyzer (Type 2012) and B﹠K Amplifier (WQ1105). Measure SPL with microphone 10cm from the unit. Microphone to be in accordance with B﹠K free field microphone (Type 4191). The microphone should be calibrated on a daily basis using a calibrator recommended by the manufacturer. Measurement should be carried out in a free Field environment.
深圳市天尔科技有限公司（）
1
SPEAKER SPECIFICATIONS （扬声器规格书）
PRODUCT NO. TSB28E-8A(LEAD FREE) （产品型号）
PAGE NO. 页号 1 2 3 4
5
SUMMARY （概要）
SPECIFICATIONS 规格要求
RELIABILITY TEST 实验要求
LOAD TEST 连续实验
At 0.3W white noise is applied for 96hours and then should satisfy the test described under item 01and 07.
DROP TEST 落下试验

美声音箱：Mission M3 中文用户手册

低通滤波：该功能调节了超重低音与环绕音箱的协调性，使系统达到最佳的低音演示效果。
为 M3 环绕音箱设置为最高频率（150Hz），如果出现重低音或声音不清晰，则调低频率直到达到最理想的效果。
自动开关：在普通模式下，超重低音一直处于打开状态。当系统其它设备都关闭，而只有
超重低音处于开启状态时，就可能会发出嗡嗡的噪音。将 AUTO 开关打到 ON，输入端口检测到任何信号输入时，超重低音就会自动打开；如果一段时间没有进行操作，超重低音音箱又会自动关闭（进入待机状态）。所以建议您在一般操作过程中，将 AUTO 开关打到 ON 的位置上。在自动模式下，当系统与电源连接，超重低音的指示灯会一直保持亮的状态，即便是待机状态下。如果超重低音与电源断开或电源开关是“off”则指示灯熄灭。长时间不使用系统时，建议您关掉超重低音，以免产生噪音。
正确的系统连接图
您的超重低音是为和数字处理器的最优搭配而设计的。如果您的 AV 处理器有低电平输出端或 LFE 超重低音输出端，您应当采用上图的连接方式。您需要从经销商处购买一根单独的屏蔽 RCA 音频线，按上图将音频线与超重低音的 LFE 输入端连接起来。
超重低音的多种连接方式
您可以使用处理器上的一根 Y 形音频线来连接超重低音上的两个输入端，这种超重低音的输入电平会偏高些。
是普通的线材。您可以咨询您的经销商。按下图所示正确连接音箱。
连接无源音箱
请务必为每台音箱准备一条长度合适的音频线，建议您选用专业的优质音频线，而不
确保超重低音的红色端子连接到功放的红色（+）端子上，按相同的方法将超重低音的黑色端子连接到功放的黑色(-)端子上。
使用音频线有色彩的一端可以方便地把音箱的正极红色端子连接起来。

喇叭规格书

SPECIFICATION FOR APPROV AL承认书Customer （客户）：深鑫Product Name（产品名称）：Micro Dynamic SpeakerLiu Sheng Part No.恒合型号： LS2415R-01薄Specification（规格）： 8Ω1.5WCustomer’s Model No.（客户型号）：Specification No.（规格书编号）：Number of the edition（版本号）：A0CUSTOMER’S APPROVED SIGNATURE客户承认盖章Approved by核准Checked by审核Issued by制成东莞市刘生电子有限公司DONG GUAN LIU SHENG ELECTRONICS. CO.,LTD地址:东莞市塘厦镇田心塘龙西路92号金磊工业区A栋3楼请确认后回传PLEASE REPL Y AFTER APPROV AL东莞市刘生电子有限公司DONG GUAN LIU SHENG ELECTRONICS. CO.,LTD PAGE NO.页码2/8PART . NO.产品型号2415R-01薄A、目录 TABLE OF CONTENTS目录TABLE OF CONTENTS序号NO. 项目ITEM 页码PAGE 封面COVER 1A 目录TABLE OF CONTENTS 2B 修订记录 REVISIONS RECORD 3C 适用范围SCOPE 4D 一般规范GENERAL SPECIFICATIONS 4E 机械特性 MECHANICAL CHARACTERISTICS 5F 信赖性试验 RELIABILITY TEST 6G 环境试验 ENVIRONMENTAL TEST 6H 结构STUCTURE7I 外观尺寸图 APPEARANCE DRAWING 8东莞市刘生电子有限公司DONG GUAN LIU SHENG ELECTRONICS. CO.,LTD PAGE NO.页码3/8 PART . NO.产品型号2415R-01薄B、修订记录REVISIONS RECORDREVISION版本DATE日期CHANGE NOTE变更内容DESD.BY修订人APPD.BY确认人无变更则此页不用填写东莞市刘生电子有限公司DONG GUAN LIU SHENG ELECTRONICS. CO.,LTD PAGE NO.页码4/8PART . NO.产品型号2415R-01薄C、适用范围SCOPEThis specification applies speaker，2415R-01薄此规格书适用于喇叭，2415R-01薄D、GENERAL SPECIFICATIONS 一般规格NO. Item Symbol Unit Specification Condition1 Dimension 尺寸mm 24×15×3.22Rate/Max Power Rating额定/最大功率W Rate 1.5/Max.1.8Max. Power:IEC-60268-5Filter 60s On/120s Off10 Cycles(Room TEMP.)3AC Impedance交流阻抗ΩOhm 8±15% At1.0KHz 1.0V 4DC Resistance直流阻抗ΩOhm 7.8±10%5Resonance Frequency谐振频率Fo Hz 600±20% At 1.0V6Output S.P.L输出音压S.P.L dB 120±3dB 1.0 KHz7Frequency Rang有效频宽Hz Fo—20KOutput S.P.L ±10dB输出音压±10dB8Max Distortion最大失真% 10% At 1.0KHz 1.5W 9Magnet Material磁铁材质mm Nd-Fe-B10Storage temp贮存温度℃-20~+55℃11Operate temp工作温度℃-20~+55℃东莞市刘生电子有限公司DONG GUAN LIU SHENG ELECTRONICS. CO.,LTD PAGE NO.页码5/8 PART . NO.产品型号2415R-01薄E、MECHANICAL CHARACTERISTICS机械特性NO Item Test condition Evaluation standard1 Vibration Test振动测试Speaker shall be measured after being appliedvibration of amplitude of 1.5mm with 10 to55Hz band of ibration frequency to each of 3per-pendicular directions for 2 hours.振动周波数10~55Hz，全振幅1.5mm于X，Y，Z 3个方向各2个小时No obstacle to be harmful tomormal operation ;Damages,cracks,rusts anddistortions.Should not be audible at 3.5Vsinewave between FO~4.0kHz测试后无任何障碍防碍正常操作，且在输入3.5V正弦波从Fo到4.0KHz之间无异常音。

3-4寸全频单元用号角音箱图纸

Das Buschhorn (so benannt nach seinem Entwickler Dr. A. Buschhorn aus Göttingen) verbindet die faszinierende räumliche Wiedergabe von kleinen Breitbandsystemen (die normalerweise sehr bassschwach klingen) mit der basssteigernden Wirkung eines backloaded Horns.Eventuelle Frequenzgangüberhöhungen im Mitteltonbereich können je nach Geschmack durch einen einfachen Saugkreis (Spule, Konden-sator und Widerstand parallel, das Ganze in Reihe mit dem Lautspre-cher) korrigiert werden.Mit 10 EUR (VISATON FRS8) bzw. 40 bis 50 EUR (FOSTEX FE83E,FE87E, FF85K) bleiben die Aufwendungen für das Lautsprecherchas-sis im Rahmen, das Holz (ca. 0.72m² 16mm und 0.38m² 13mm,Spanplatte oder MDF) sollte für 15 EUR im Baumarkt zu bekommen sein. Der optionale Schwingkreis schlägt noch mal mit 5 bis 15 EUR zu Buche. Alles in allem also ein recht preiswertes Vergnügen!Wie auf dem nebenstehendem Photo zu erkennen muss das Koppel-volumen mit Polyestervlies oder besser noch Schafwolle bedämpft werden. Ein Stück Polyestervlies im Hornverlauf beseitigt darüber hinaus eine unschöne Resonanz.Gegenüber dem originalen Plan von Dr. Buschhorn ergaben sich un-ter Beibehaltung der Plattenabmessungen (siehe untenstehende Ta-belle) zum Teil geringfügig andere Wandabstände. Außerdem wurde der Bereich des Hornmundes geringfügig umgestaltet.Buschhorn (offen)。

扩音、音响部分

台
2
6
辅助有源扬声器
音箱类型:二分频有源音箱驱动单元：高频 HF:1×3"高音驱动单元, 音箱类型:二分频有源音箱低频 LF:1×12"低频驱动单元频率响应(±3dB)：40Hz~18KHz 音箱功率：500W 指向性(H×V) ： 80°×50° 最大声压级：133dB 输入阻抗：20kΩ平衡输入，10kΩ非平衡输入总谐波失真THD+N：<0.1%@+0 dBV 具有高效、安全的输出功率动态压缩功能及温度保护电路. 与主扩线阵有源音箱同一品牌
单位
数量
1
主扩线阵有源音箱
只
12
2
线阵次低音有源音箱
只
2
3
有源超低扬声器
音箱类型：有源超低音响由数字功率放大器和音箱组成,具有高效率高声能输出、出色的音质,完善的保护功能和良好的电磁兼容特性,使用的电源电压范围宽：AC 100V-240V 50/60Hz。主要特点： 1.即插即用、使用方便、指示清晰、不需专业人员即可操作。 2.功率强劲，声音混厚，富有弹性，单元采用 18 寸低音。 3.该有源音箱采用数字功率放大器,具有听感好、效率高、工作稳定可靠的特点。 4.带内陷式电位器，中高音输出信号幅度可调。 5.完善的保护功能(短路保护、过流保护、过温保护、过欠压保护、功率压限、温度压限),免去用户的后顾之忧。技术参数：单元配置：1个18寸以上的驱动单元额定功率：800W RMS 最大功率：1800W RMS 单元配置：WLO18125A 频率范围：40Hz-200Hz 线路输入灵敏度 :100dB（1m/1w）声压级：132dB 输入阻抗：22 KΩ 电源：100-240V ~ 50/60Hz 与主扩线阵有源音箱同一品牌现场需提供样品

澳：3寸喇叭规格书

4
信赖性Reliability
4.1
连试验后无异常的不良。Must be normal after load test :pink noise2W 96 hours
4.2
耐热性heat Test
温度60±2℃湿度20-25% 16小时试验常温1小时后，无异常不良。Must be normal after 70±2℃and relative humidity20-25% 16hours and then room temperature 1hour.
审查Checked By：
批准Approvaled By：
※注：烦请贵司确认签章后，回传我公司为荷.
扬声器规格书
SPEAKER SPECIFICATION
2009年4月22日REV A0
单元型名Our Model No.
TTY090422-3
适用机种Product Model No：
客户Customer
批准
APPRROVED
李景海
审核CHECKED
吴勇
制表
DESINGED
袁秀君
3
电气特性: Electrical specification
3.1
公称阻抗Nominal Impedance
4Ω±15%
3.2
共振频率esonance Frequency
88Hz±20%
3.3
出力音压Output sound Pressure Level
86±3dB (AT：400;1000;4000;8000Hz的平均值)0.57M1W
(深圳)有限公司
样品承认书
SAMPLE APPROVAL SHEET
客户Customer：澳

音箱尺寸

JBL ES100 双10英寸落地音箱5780元最大建议功率：250W功率处理（持续峰值）：125500W阻抗：8欧姆灵敏度：91DB频率响应；32HZ~~40KHZ低音单元：250mm polyplase 防磁中音单元：100mm polyplase防磁高音单元：19mm钛合金防磁超高音单元：19mm Bi--RADIAL号角尺寸（高x宽x深）：1149x305x422mm 重量：29.0kg箱体尺寸：高70cm*宽30cm*深32.5cm面板为2.5cm厚的高密度中纤板侧板为1.5cm 厚的微粒板低音开孔尺寸外孔26cm 沉0.5cm 内孔23cm高音外孔10 cm 沉0.5cm 内孔8cm接线盒开孔尺寸6.1cm最大建议功率：250W ¥6800.00功率处理（持续/峰值）：125/500W阻抗：8欧姆灵敏度：91DB频率响应；32HZ~~40KHZ低音单元：250mm polyplase 防磁中音单元：100mm polyplase防磁高音单元：19mm钛合金防磁超高音单元：19mm Bi--RADIAL号角尺寸（高x宽x深）：1149x305x422mm 重量：29.0kg箱体颜色：樱桃/黑喇叭单元无修无磨。

正常使用。

单元：1高音。

1个4.5寸中音。

10寸低音。

以下为参考数据：三分频设计汰膜高音单元 4.5寸布边中音单元10寸低音单元功率：20-150瓦阻抗：8欧姆尺寸: 高:88cm深:30cm宽:33cm¥19000.00型号: XTZ 99.38使用分类: 落地式音箱灵敏度: 89dB阻抗: 4-8欧姆颜色: [黑色钢琴漆]外观: 落地方形音箱保修年限: 一年结构形式: 三路扬声器，可设置为密闭箱。

外形尺寸: 220 x 1070 x 400 mm (W x H x D) (含网罩)重量: 29 公斤/只Loading zoom••尊宝/JAMO D570丹麦尊宝 D570 经典落地式音箱商品编号：ECS000604 保修范围：全国联保商品品牌：尊宝商品类型：落地音箱·市场价：￥8496元·影音荟价：7080.00·可节省：￥14161购买数量：•商品描述•评价详情•销售记录•售后服务D 570Jamo的AG电缆可确保扬声器与放大器之间的最佳连接。

喇叭尺寸对照表（喇叭尺寸与功率对照表）

喇叭尺寸对照表（喇叭尺寸与功率对照表）喇叭尺寸对照表(喇叭尺寸与功率对照表)喇叭怎么看尺寸喇叭尺寸单位：英寸“英寸”。

一英寸等于2.45厘米。

它们通常从喇叭的外径开始测量，比纸盆的实际口径要大。

喇叭的大小是你用尺子量出喇叭的直径然后乘以2.45 2.45 cm，等于一寸。

音箱喇叭大小尺寸怎么量？扬声器的尺寸可以通过测量扬声器外边缘的直径来测量。

以英寸计算，1英寸=2.54厘米。

例如，4英寸喇叭的直径为2.54*4=10.16厘米。

市面上的音箱几乎都是按尺寸和实际mm计算的，喇叭里的英寸是inch (in)，1英寸=63.5px=25.4mm，一个标准的2英寸喇叭直径是50.8mm。

其中，喇叭的直径是指喇叭的口径。

比如需要直径为100mm的喇叭，常规推荐是直径为100/25.4 4英寸的喇叭。

扩展信息：喇叭的尺寸包括公称尺寸、振膜尺寸等。

喇叭的尺寸，也就是常说的，是厂家的标称尺寸。

大部分中音扬声器都是以扬声器的最大直径为标准(有些厂商也采用有效振动半径，即包括折环在内的扬声器振膜的最大外径)。

6.5寸低音扬声器的直径一般在16.5 cm左右。

如果包括喇叭的边框等材料，直径一般需要达到18 cm左右。

实测14 cm不正常。

规格6.5表示喇叭的直径为6.5英寸，1英寸=2.54厘米。

但是，声音口径的计算往往是英寸的近似值。

比如喇叭直径16.8cm，用2.54得到6.6英寸，那么声音规格的近似值就是6.5。

1.音箱上扬声器的尺寸包括标称尺寸、振膜尺寸等。

喇叭的尺寸，也就是常说的，是厂家的标称尺寸。

2.大部分低中音扬声器都是以扬声器的最大直径为标准的(有些厂商也采用有效振动半径，即包括折环在内的扬声器振膜的最大外径)。

3.通过将单位厘米换算成英寸来计算，1英寸(in)=2.54厘米(cm)，一般指公称尺寸中的英寸。

4.比如：6.5寸音箱，8寸音箱，但是不同厂家不同型号的音箱大小不固定。

5.S6.5比如厂家标称尺寸为6.5英寸，最大外径为16.7 cm，换算成英寸相当于6.5英寸。

阿塔斯 AH Series 3-Way 扬声器说明书

– 1 –1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435AH Series 3-Way LoudspeakersAH Series 3-Way Loudspeaker SystemsAH Series 3-Way LoudspeakersT able of ContentsImportant Safety Instructions (3)Introduction (4)Installation (5)Speaker Cable Recommendations and Connection Instructions (7)Amplifier Considerations (8)Specifications (9) (9)TroubleshootingWarranty (12)1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435AH Series 3-Way LoudspeakersSafety InstructionsPlease Read Carefully Before Installing or Operating• Read all instructions carefully• Heed all warnings• Assure that the speaker is securely mountedHearing DamageCAUTION: All professional loudspeaker systems are capable of generating very high sound pressure levels. Use care with placement and operation to avoid exposure to excessive levels that can cause permanent hearing damage.Suspension & MountingSuspension or “flying” speaker systems requires training and expertise. Improper rigging of a flying speaker may result in injury, death, equipment damage, and legal liability. Installation must be carried out by fully qualified installers, in accordance with all required safety codes and standards at the place of installation.A 5:1 design factor is a generally accepted minimum standard. However, legal requirements for overhead suspension vary by municipality, please consult your local safety standards office before installing any product. We also recommend that you thoroughly check any laws and bylaws prior to installation.Loudspeakers flown in theaters, nightclubs, conference centers, or other places of work and entertainment must be provided with an independent, correctly rated and securely attached secondary safety, in addition to the principle suspension point(s).This secondary safety must prevent the loudspeaker from dropping more than (6") should the principle suspension device fail. If you lack the skills, training, and proper ancillary equipment to fly a speaker system, do not attempt to do so.For additional information regarding the suspension of loudspeakers or to purchase rigging materials, please contact our friends at Adaptive Technologies Group,1635 E. Burnett St. Signal Hills, CA 90755.Telephone (562) 424-1100 and Fax (562) 424-3520• Always assure power is Off to amplifiers before making any connections• Assure that all electrical equipment is properly grounded• Keep instructions for future reference• Should any questions arise after reading this document, please call Atlas Sound Tech Support at 800-876-33331601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435AH Series 3-Way LoudspeakersAH Series 3-Way Loudspeaker SystemsThank you for your purchase of an Atlas Sound AH Series 3-Way loudspeaker system. We have designed this product to be a reliable and versatile solution to your needs for years to come.All models in the series feature high output, outstanding pattern control and amazing low frequency response for indoor and outdoor applications including football stadiums, sports arenas, baseball fields, and large auditoriums.The AH 3-Way Series models are offered in a variety of coverage patterns to ensure that almost any area needing sound reinforcement may be accommodated.The AH 3-Way Series models incorporate a low frequency section comprised of 2 high power 12" woofers, combined with midrangecompression driver, and high frequency compression driver. A highly efficient internal passive crossover network insures proper transition between the drivers.Features• 3-Way Design• Bi-Amp Capability with HF/MF and LF Separation Allows for Greater System Control• 1" Exit High Frequency Compression Driver• 1.5" Exit Midrange Compression Driver• Dual 12" Cast Frame Woofers• 750 Watts RMS Power Handling (Full Range)• Weather Resistant Connection Via a Convenient Recessed Terminal Block Located on the Bottom of the Loudspeaker• 8Ω Nominal Impedance• Seven, 10mm Internally Reinforced Forged Eyebolts Included for Suspended InstallationApplicationsAtlas Sound model AH Series 3-Way stadium horns are ideal for directional sound distribution where full range reproduction, maximum intelligibility, and high sound pressure levels are required.• Football Stadiums• Sports Arenas• Baseball Fields• Convention Centers• Auditoriums1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435– 5 –1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435AH Series 3-Way LoudspeakersInstallationGeneral considerations and hardware recommendationsCAUTION: A H series models weigh as much as 200 pounds (91kg). A fall from almost any height could result in serious injury or death.Assure that the speaker is firmly mounted to an object that can handle the weight of the AH speaker. Remember that wind will add considerable torque to the point of attachment. The mounting surface the AH speaker is being attached to should be able to handle five or more times the weight of the AH speaker (7x recommended for locations subject to high wind forces).Whenever the loudspeaker is mounted to a surface, the installer must ensure that the surface is capable of safely and securelysupporting the load. The hardware employed must be safely and securely attached both to the loudspeaker and the surface in question. A general rule for soft surface installations (wood beams) is to multiply the corresponding working load limit by 75%, the result will be an approximate working load strength.Use thread locking compound for all installations.CAUTION: M ount the speaker such that the shear force is at a right angle to the mounting bolts, and close to the connection, asWhen mounting the AH speaker to a solid surface use the proper bolts, washers, and lock washers (Grade 5 minimum). Do not substitute mismatched bolts and washers.The AH speaker may be mounted to a pole or scoreboard. For such mounting, contact the light pole or scoreboard manufacturer for proper instructions.When in doubt contact a qualified structural/mechanical engineer for approval of the mounting materials and methods.– 6 –1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435AH Series 3-Way Loudspeakers Assure that the AH speaker can be mounted in a manner that the sound pattern will be directed in the desired direction without any physical interference.MountingCAUTION: Mounting the AH loudspeaker requires two or more people.Mounting suspension points use a minimum of four, 1400 pound load rated stainless steel cables or chains (capable of holding the speakers should it come loose from any of the other mounting points. Each cable or chain assembly should be attatched to one of thedrop forge eyebolts provided on the AH Series 3-WAY speaker and secured to the mounting surface via approved, load rated hardware.– 7 –1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435AH Series 3-Way LoudspeakersSuspended Installation Via Eyebolts (Included)Using 1⁄4" Diameter Wire RopeNote: Use of 1⁄4" load rated wire rope is suggested to provide a static working load limit of 1400lbs (635kg) and moving load limit of 875lbs (397kg) per point. 1⁄8" cable is not recommended as load limits are reduced to 400lbs (181kg) static, and 250lbs (113kg) moving.Considerations for overhead suspension using AH Series eyebolts and wire rope: 1. Always apply the load to the eye in the plane of the eye. 2. Always use shoulder eyebolts for angular lifts. 3. Always tighten eyebolts securely against the load.4. Apply first load to test the assembly. This load should be of equal or greater weight than the loads expected in use.5. U se wire rope compression fittings & thimbles whenever possible and prepare terminations only as instructed by the manufacturer.6. If wire rope clips are used, check and retighten to the manufacturer's recommended torque.Speaker Cable Recommendations & Connection InstructionsWire Gauges (8Ω operation)For very short distance speaker cable runs (less than 25') #16-gauge, stranded, twisted pair speaker cable may be used. For speaker cable runs between 25' and 75', #14-gauge, stranded, twisted pair speaker cable is recommended. For speaker cable runs greater than 75', #12-gauge, stranded, twisted pair speaker cable is necessary. For runs exceeding 150', please contact tech support for proper wire gauge or other installation solution using the Atlas Sound AF140 autoformer.AH Series 3-Way input connections are provided on a convenient recessed terminal block located on the bottom of the loudspeaker. This terminal block includes a clear weather resistant cover which must be re-installed after terminating the speaker cabling to prevent corrosion in outdoor applications.Allow an adequate service loop for this connection to allow tilt of the loudspeaker. The speaker should be installed angled slightly down for water drainage.AH Series 3-Way LoudspeakersAmplifier ConsiderationsConsult your amplifier owner’s manual to confirm power output at the rated impedance.AH Series 3-Way models used in 8Ω configurationEach model exhibits an 8Ω (nominal) impedance.(x2) AH models paralleled will present a 4Ω load to the amplifier.(x3) AH models paralleled will present a 2.66Ω load to the amplifier.(x4) AH models paralleled will present a 2Ω load to the amplifier.ATLAS SOUND speaker system specifications list RMS power handling.As a reference peak power = RMS x 1.414.These ratings should be considered in selecting the best amplifier to power the speaker system.For general use, amplifier output should match or exceed the RMS rated power of the speaker system.For increased headroom and dynamic reproduction, the amplifier’s output should match or exceed the peak power rating of the speaker system.Utilizing the Atlas Sound model CP700 power amplifier will allow you to easily match required power ratings for most installations. Visit for more details on this product.1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435– 9 –1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435AH Series 3-Way LoudspeakersSpecificationsPower Handling RMS (Full Range) 750 WattsPower Handling RMS(BI-AMP) 800 Watts (Low Pass)250 Watts (High Pass)Sensitivity (1w/1m) 104-106dB (80Hz - 17kHz average)Frequencey Response 100Hz - 17kHz (-10 to +4dB)Dispersion AH42-212-BSG 40° x 20° AH66-212-BSG 65° x 65° AH94-212-BSG 90° x 40°Impedance8Ω Nominal Minimum Impedance 4.9Ω @ 80HzDriversHigh Frequency 1" Exit Compression Driver Midrange 1.5" Exit Compression Driver Low Frequency Dual 12" Woofers Dimensions Height 32.53" (826.3mm) Width 32.53" (826.3mm) Depth 47.11" (119.7mm) Weight~210 lbs (95.25kg)TROUBLESHOOTINGCall Atlas Sound tech support at 1-800-876-3333 with any additional questions.– 10 –1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435AH Series 3-Way LoudspeakersFrequency (Hz)Frequency (Hz)Frequency (Hz)– 11 – 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435AH Series 3-Way LoudspeakersFrequency (Hz) Octave Smoothing = 30.0%O h m sFrequency (Hz) Octave Smoothing = 30.0%O h m sAH66-212-BSG ImpedanceAH Series 3-Way LoudspeakersLimited WarrantyAll products manufactured by Atlas Sound are warranted to the original dealer/installer, industrial or commercial purchaser to be free from defects in material and workmanship and to be in compliance with our published specifications, if any. This warranty shall extend from the date of purchase for a period of three years on all Atlas Sound products, including SOUNDOLIER brand, and ATLAS SOUND brand products except as follows: one year on electronics and control systems; one year on replacement parts; and one year on Musician Series stands and related accessories. Additionally, fuses and lamps carry no warranty. Atlas Sound will solely at its discretion, replace at no charge or repair free of charge defective parts or products when the product has been applied and used in accordance with our published operation and installation instructions. We will not be responsible for defects caused by improper storage, misuse (including failure to provide reasonable and necessary maintenance), accident, abnormal atmospheres, water immersion, lightning discharge, or malfunctions when products have been modified or operated in excess of rated power, altered, serviced or installedin other than a workman like manner. The original sales invoice should be retained as evidence of purchase under the terms of this warranty. All warranty returns must comply with our returns policy set forth below. When products returned to Atlas Sound do not qualify for repair or replacement under our warranty, repairs may be performed at prevailing costs for material and labor unless there is included with the returned product(s) a written request for an estimate of repair costs before any nonwarranty work is performed. In the event of replacement or upon completion of repairs, return shipment will be made with the transportation charges collect.EXCEPT TO THE EXTENT THAT APPLICABLE LAW PREVENTS THE LIMITATION OF CONSEQUENTIAL DAMAGES FOR PERSONAL INJURY, ATLAS SOUND SHALL NOT BE LIABLE IN TORT OR CONTRACT FOR ANY DIRECT, CONSEQUENTIAL OR INCIDENTAL LOSS OR DAMAGE ARISING OUT OF THE INSTALLATION, USE OR INABILITY TO USE THE PRODUCTS. THE ABOVE WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES INCLUDING BUT NOT LIMITED TO WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.Atlas Sound does not assume, or does it authorize any other person to assume or extend on its behalf, any other warranty, obligation, or liability. This warranty gives you specific legal rights and you may have other rights which vary from state to state.ServiceShould your AH Series 3-Way Loudspeaker require service, please contact the Atlas Sound warranty department at1-877-689-8055 to obtain an RA number.Atlas Sound Tech Support can be reached at 1-800-876-3333.Visit our website at to see other Atlas products.©2013 Atlas Sound L.P. All rights reserved. Atlas Sound and Atlas Power are trademarks of Atlas Sound L.P.All other trademarks are the property of their respective owners. ATS004622 RevA 5/131601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.Telephone: 800.876.3333 • Fax: 800.765.3435。

JBL L100 Classic 三路书架扬声器说明书

JBL L100 Classic3-way Bookshelf LoudspeakerA Modern ClassicFor more than 70 years, JBL has been a pioneer in the art of sound reproduction. In 1970, JBL released the original L100 loudspeaker, a consumer version of the immensely popular JBL 4310 Pro Studio Monitor. Over the years, the iconic L100 became JBL’s best-selling loudspeaker of all time.Now, with the new L100 Classic, a legend is reborn. The retro design with iconic JBL styling and a vintage Quadrex foam grille pays homage to its predecessor’s storied legacy. All-new drivers, crossover network and advanced transducer technology take the performance attributes original L100 owners loved – exceptional dynamic range, crystal-clear effortless high output, and high-impact bass – and elevate them to the highest 21st century audio standards.Don’t just hear your music. Feel it!The genuine walnut veneer enclosure and Quadrex foam grille in a choice of three colors allow the L100 Classic to fit seamlessly and elegantly into any decor. The L100 Classic may also be stand mounted with optional JBL metal stands for maximum installation flexibility.Engineered for ExcellenceBacked by decades of engineering pedigree alongwith the world’s finest engineering and testingresources, the L100 Classic leverages the latesttechnological evolutions in acoustics to deliver trueaudiophile-quality sound. The newly developedJT025Ti1 titanium dome tweeter is mated toa waveguide with an acoustic lens for optimalintegration with the 105H-1 polymer-coated, pure-pulp cone midrange.The JW300PW-8 12-inch white pure pulp conewoofer operating in a bass-reflex enclosurecleanly delivers powerful, moving bass via asingle front-firing port tube with flared ends.The mid- and high-frequency L-pad attenuatorson the front baffle pay homage to its legendarynamesake. No detail has been overlooked.The L100 Classic is internally braced and features a 25mm-thick baffle. This means that the only sound you get from the speakers is the emotion-grabbing audio produced by the transducers. With power, clarity, and precision, the L100 Classic delivers the total package. Remember the first time you heard your favorite song through a great set of speakers and it gave yougoosebumps? It’s like that, but better.We didn’t design the L100 Classic so you could just listen to your music. We designed it so all of your senses would be heightened when you listened to your music. We designed it so your music puts you in the front row of the concert. We designed it to evoke your most pleasant musical memories. We designed it for you.HARMAN International Industries, Incorporated8500 Balboa Boulevard, Northridge, CA 91329 USA ©2018 HARMAN International Industries, Incorporated. All rights reserved. JBL and JBL Synthesis are trademarks of HARMAN International Industries, Incorporated, registered in the United Statesand/or other countries. Features, specifications and appearance are subject to change without notice.Highlights• R etro design with iconic JBL styling and vintage Quadrex foam grille in a choice of three colors: black, burnt orange and dark blue• Genuine walnut veneer enclosure with black painted front and rear panels• 12-inch (300mm) pure pulp cone woofer• 5.25-inch (130mm) polymer-coated pure pulp cone midrange• 1-inch titanium dome tweeter with soft surround• Bass-reflex design with front-firing port•Adjustable mid- and high frequency level controlsSpecifications。

飞利浦 HTL3160B 3.1 CH 无线重低音喇叭产品说明书

飛利浦Soundbar 喇叭3.1 CH 無線重低音喇叭Bluetooth ® 與 NFC HDMI ARC 200 瓦HTL3160B3.1 CH 呈現無與倫比的清晰音質配備無線重低音喇叭強化音質清晰度及虛擬環繞音效，打造劇院影音體驗，加上 NFC 單鍵配對帶來的無線音樂串流功能，進一步提升電視的觀賞層次。

輕鬆連接您所有的娛樂裝置•在啟用 NFC 的智慧型手機上按一下，即刻進行藍牙配對•藍牙無線音樂串流功能•EasyLink 可透過一只遙控器控制所有 HDMI CEC 裝置•使用音訊輸入，享受 iPod/iPhone/MP3 播放機的音樂•適用於大型顯示器、BD/DVD 播放機、遊戲主機、MP3 播放機•使用可攜式 USB 裝置直接享受 MP3 音樂極簡設計•最適合置於電視前的矮型設計•觸控式面板給您符合直覺的播放與音量控制在觀賞電視與電影時享受更豐富的音效•專屬中置喇叭，提供清晰無比的絕佳音質•杜比數位與 Pro Logic II 環繞音效•虛擬環繞音效，營造栩栩如生的觀影體驗•無線重低音喇叭增添動作刺激感杜比數位與 Pro Logic II內建杜比數位解碼器，直接處理六聲道音訊，不需再外接解碼器，給您生動逼真的環繞音效，讓您身歷其境。

杜比 Pro Logic II可從任何立體聲音源提供五聲道環繞音效。

虛擬環繞音效飛利浦虛擬環繞音效可從五個喇叭以內的音效系統，產生豐富且逼真的環繞音效。

極先進的空間演算法能忠實地複製聲波特質，並以理想的 5.1 聲道環境重現。

任何高品質的立體聲源都會轉換成逼真的多聲道環繞音效。

不用額外花錢添購喇叭、訊號線或喇叭立架，即可享受縈繞滿屋的環繞音效。

NFC 一按搞定使用單鍵設定的 NFC (近距離無線通訊) 技術，輕鬆完成 Bluetooth ® 裝置配對。

只要在音場的 NFC 區域點按具備 NFC 功能的智慧型手機或平板電腦，即可開啟音場、進行 Bluetooth ® 配對，並開始串流音樂。

扬声器参数-360文档中心

扬声器参数-360文档中心12.2与Cms成比，Cms越大，V as越大。

13.B：气隙中磁感应密度，单位为wb/m3中B值的大小主要与磁性能，大小，磁间隙的大小有关系，磁铁性能高，磁铁大，磁间隙小，B值就大。

13.1磁间隙越小，磁铁越大(横截面积是关键)，华司越薄，磁铁原材料越好，B值越大，T铁芯柱越高出华司B值越小。

14.L：音圈线长度，单位为米。

14.1音圈线越细，音圈芯数越大，层数越多，华司越厚，L值越大。

14.2音圈扁线L值比相当的圆线大，音圈扁线横绕比竖绕L值大。

15.SPL ref(Sd)：指扬声器的标准灵敏度。

15.1 SPL=112+10Lg(o*Vas*Zref/(2Co3QesRe))15.2 Zref：参考效率，Zref=o(Bl)2Sd2/(2CoMmsRe)16.Rub-Index：单体异常振动摩擦的参考指数，通常1以上即表示不良。

17.Sd：有效振动面积，edge中心位置计算(或内侧的1/3位置计算)。

18.RMSE-load：同1，只是此次比较的是附加质量之阻抗曲线。

·可否这样理解：两个结构相同的15寸低音，除弹波的弹性不同，其他完全相同，弹波软的q值低，效率高(振幅大)，但速度慢，有过冲(对振动系统惯性克服差)·小于0.7的低音的量感不够是因为喇叭的反电动势太高导致喇叭振幅不够吗?·你搞的再清楚，也是一知半解，不如模糊理解：低q喇叭是为箱体设计，高q喇叭为障板准备，多简单阿。

·讲起来太复杂，可以写一本书，总之，Q值是喇叭的电阻尼和机械阻尼的宗合量，Q太低(阻尼大)了喇叭的纸盆停得快，声音发干(感觉上低音的量感不足)，如打鼓，鼓棍停了鼓还在振动，如果鼓皮也跟着停还是鼓声吗?(一个不太恰当的比喻)·低频差的喇叭适合障板低频好的喇叭适合箱体因为低频差的喇叭Q值较高，做箱体需较大容积，否则出不了低频，成本高。

因为低频好的喇叭Q值较低，做障板需较大面积，否则发挥不了它的低频，成本高。
