NI板卡数据手册
NI 数据采集卡使用入门
NI 数据采集卡使用入门NI 数据采集卡使用入门一、安装与配置:1. 在安装板卡之前，请首先安装NI-DAQ驱动程序软件。
您可以在随卡附带的光盘内找到这个驱动程序软件。
另外，NI公司的网站上也提供这个驱动程序软件的免费下载：/softlib.nsf/websearch/90B60D5899BCCCDB86256FC700581B89?opendocument&node=132070_US如果您使用LabVIEW或LabWindows/CVI 等软件来进行编程,需要在安装驱动软件之前先安装开发平台LabVIEW或LabWindows/CVI等软件。
安装过程中，安装程序会提醒您插入DAQ驱动光盘。
2. NI-DAQ驱动软件正确安装后,请关闭计算机,插入数据采集板卡,启动计算机,即可自动找到板卡并安装好，完成整个安装过程。
注意：在安装PCI或者PXI板卡时，一定要将电脑电源关闭；PC机则最好将电源线拔掉，以免电脑主板关机后仍然带电，造成各类损伤。
二、模拟输入说明1. 信号类型根据信号的参考情况，一个电压源可以分为两类：接地信号、浮地信号。
接地信号:接地信号是信号的一端直接接地的电压信号。
它的参考点是系统地（例如大地或建筑物的地）。
最常见的接地信号源是通过墙上的电源插座接入建筑物地的设备，例如信号发生器和电源供电设备等。
浮地信号:一个不与任何地（如大地或建筑物的地）连接的电压信号称为浮地信号。
一些常见的浮地信号有电池、热电偶、变压器和隔离放大器。
2．测量方式按信号连接方式不同可分为三种测量方式：差分(DIFF)；参考单端(RSE)；非参考单端（NRSE）。
注意：NI公司的部分型号数据采集卡不一定完全支持上述三种测量方式，请查询对应数采卡的使用手册。
按测量方式分类可以分为以下两大类测试系统：1）差分测试系统(DIFF)n 可避免接地回路干扰n 可避免因环境引起的共模干扰当输入信号有以下情况时，使用差分测试系统：n 低电平信号（例如小于1V）。
NI_USB_6009规格说明
NI USB-600914位, 48 kS/s低价位多功能数据采集卡•8路模拟输入通道(14位分辨率,48 kS/s)•2路模拟输出通道(12位分辨率, 150 S/s);12条数字I/O线,32分辨率计数器•方便而易于携带的总线供电型设计•获取用于OEM的仅含板卡的套件•可用于Windows、Mac OS X、Linux和Pocket PC的驱动软件•NI-DAQmx驱动软件和NI LabVIEW SignalExpress交互式数据记录软件概述NI USB-6009具有基本的数据采集功能，其应用范围包括简单的数据记录、便携式测量和学术机构的实验室试验。
该产品价位适于学生购买且其强大的功能足以用于更为复杂的测量应用。
Mac OS X和Linux 用户可下载NI-DAQmx Base驱动软件并使用LabVIEW或C为USB-6009编程。
NI开发了含有LabVIEW学生版副本的USB-6009学生套件，为仿真、测试和自动化的理论性课程补充了实践性实验。
上述套件仅供学生使用，是功能优、价格低、实践性强的学习工具。
若需更多信息，请访问NI教育产品网页：/academic/measurements.htm for more details。
要想取得更高的采样速度，更精确的测量质量，以及更多的测量通道，请参考高性能USB数据采集设备NI USB-6210和NI USB-6211。
每个NI USB数据采集设备均包含一份NI LabVIEW SignalExpress LE的副本，使您无需编程即可快速采集、分析并显示数据。
除了LabVIEW SignalExpress，USB数据采集模块还与下列NI应用软件版本（或更高版本）兼容——LabVIEW 7.x、LabWindows™/CVI 7.x、或Measurement Studio 7.x。
USB数据采集模块也与Visual Studio .NET、C/C++和Visual Basic 6兼容。
国家工程实验室NI PCI-651x系列产品手册说明书
Manufacturer: National InstrumentsBoard Assembly Part Numbers (Refer to Procedure 1 for identification procedure): Part Number and Revision Description191649A-01(L) or later PCI-6510190184A-01(L) or later PCI-6511190359A-01(L) or later PXI-6511190356A-02(L) or later PCI-6512190853A-02(L) or later PXI-6512190356A-01(L) or later PCI-6513190853A-01(L) or later PXI-6513189924A-02(L) or later PCI-6514190318A-02(L) or later PXI-6514189924A-01(L) or later PCI-6515190318A-01(L) or later PXI-6515191649A-02(L) or later PCI-6516191649A-03(L) or later PCI-6517191649A-04(L) or later PCI-6518191649A-05(L) or later PCI-6519192323A-01(L) or later PCI-6520192323A-02(L) or later PCI-6521192320A-01(L) or later PXI-6521Volatile MemoryTarget Data Type Size Backup1Accessible Accessible ProcedureEPM7032AEGlue Logic FPGA IntelEP1C3No No No Cycle Power Non-Volatile Memory (incl. Media Storage)Target Data Type Size BatteryBackupUserAccessibleSystemAccessibleSanitizationProcedureDevice configuration •Device information •FPGA bitstream •Output power-up states (except 6510/11) Flash 128 kB NoNoNoNoYesYesYesNoneNoneNone1 Refer to Terms and Definitions section for clarification of User and System AccessibleProceduresProcedure 1 – Board Assembly Part Number identification:To determine the Board Assembly Part Number and Revision, refer to the “P/N” label applied to the surface of your product as shown below. The Assembly Part Number should be formatted as “P/N: ######a-vvL” where “a” is the letter revision of the Board Assembly (eg. A, B, C…) and the “vv” is the type identifier. If the product is RoHS compliant, “L” can be found at the end of the part number.PCI-6510/16/17/18/19PCI-6511 PXI-6511PCI-6512/13 PXI-6512/13PCI-6514/15PXI-6514/15PCI-6520/21 (Bottom View)PXI-6521Terms and DefinitionsCycle Power:The process of completely removing power from the device and its components and allowing for adequate discharge. This process includes a complete shutdown of the PC and/or chassis containing the device; a reboot is not sufficient for the completion of this process.Volatile Memory:Requires power to maintain the stored information. When power is removed from this memory, its contents are lost. This type of memory typically contains application specific data such as capture waveforms.Non-Volatile Memory:Power is not required to maintain the stored information. Device retains its contents when power is removed.This type of memory typically contains information necessary to boot, configure, or calibrate the product or may include device power up states.User Accessible:The component is read and/or write addressable such that a user can store arbitrary information to the component from the host using a publicly distributed NI tool, such as a Driver API, the System Configuration API, or MAX. System Accessible:The component is read and/or write addressable from the host without the need to physically alter the product. Clearing:Per NIST Special Publication 800-88 Revision 1, “clearing” is a logical technique to sanitize data in all User Accessible storage locations for protection against simple non-invasive data recovery techniques using the same interface available to the user; typically applied through the standard read and write commands to the storage device.Sanitization:Per NIST Special Publication 800-88 Revision 1, “sanitization” is a process to render access to “Target Data” on the media infeasible for a given level of effort. In this document, clearing is the degree of sanitization described.。
NIUSB_datasheetNI数据采集卡手册
Industrial Digital I/O Device for USB –60 V, Channel-to-Channel IsolatedOverview and ApplicationsThe National Instruments USB-6525 is a full-speed USB device with eight normally open, channel-to-channel isolated, solid-state relay outputs and eight ±60 VDC channel-to-channel isolated digital inputs. The NI USB-6525 offers features for industrial control and manufacturing test applications, such as factory automation, embedded machine control, and production line verification. The solid-state relay outputs have a 60 VDC/30 V rms switching voltage and 500 mA/ch maximum switching current, making them ideal for controlling pumps, valves, motors, and other industrial actuators. The eight isolated digital input channels break ground loops and offer protection from noise and spikes on external signals. You can also use one of the digital input channels as a 5 kHz, 32-bit event counter for counting digital pulses.HardwareThe USB-6525 has eight channel-to-channel optically isolated inputs,P1.<0..7>, and eight channel-to-channel optically isolated, solid-state relay outputs, P0.<0..7>. The isolated inputs consist of an optocoupler, a depletion-mode MOSFET-based current-limiting circuit, and a Schottky diode. Each channel has its own positive and negative terminals capable of detecting a wide range of DC signals, from 5 V TTL logic levels to DC power supply levels up to 60 V.PFI 0 (an alias to P1.7) can also function as the source for a 32-bit counter. In this mode, the device counts low to high transitions on P1.7. You can arm and disarm the counter as well as read or reset the count through software.You can connect loads to the solid-state relay outputs with an AC or DC power source. The default power-on state of the solid-state relays is open. The relays also remain open when the computer and the USB-6525device are powered off.•Small, portable digital I/O device •Eight channel-to-channel optically isolated inputs (±60 VDC)•Eight channel-to-channel optically isolated, solid-state relay outputs (60 VDC/30 V rms max)•500 mA maximum switching current per channel•One 32-bit event counter•Full-speed USB (12 Mb/s) bus interface •Built-in, removable connectors for easy connectivity•USB cable strain relief Operating Systems•Windows Vista/XP/2000Recommended Software •LabVIEW•LabWindows™/CVI •Measurement Studio •LabVIEW SignalExpressOther Compatible Software •Visual Studio .NET•C, C++•Visual BasicMeasurement Services Software (included)•NI-DAQmx driver software •Measurement & Automation Explorer configuration utility•LabVIEW SignalExpress LEdata-logging softwareNI USB-6525IsolationIsolation is a form of built-in signal conditioning that provides an extended voltage range for direct connectivity to industrial sensors and actuators. The USB-6525 provides channel-to-channel isolation where each channel is physically and electrically separated from the others. Isolation provides three main benefits:1.Safety from hazardous high voltages and transients2.Rejection of common-mode voltages3.Removal of ground loopsSafety from High-Voltage TransientsIsolation electrically separates high-voltage front-end channels from each other and the low-voltage back end of the USB-6525. Signalsare passed between the two sections of the device using optocouplers. By separating the two sections, any voltages within the isolation specifications are prevented from entering the USB bus section or other channels. Isolation provides protection for the user, data acquisition system, and measurement data.Common-Mode Voltage RejectionA voltage common to both sides of a differential circuit pair iscalled common-mode voltage. This phenomenon is typical in noisy environments containing machinery and inductive loads. The differential voltage across the circuit pair is the desired signal, whereas the common voltage signal is the unwanted signal that may have been coupled into the transmission line. The USB-6525 can measure signals from lines with signal plus common-mode voltage of up to 60 VDC.Ground Loop RemovalGround loops are the most common source of noise in data acquisition applications. They occur when two connected terminals in a circuit are at different ground potentials, causing current to flow between thetwo points. This additional voltage can cause significant error in the measurement. When a ground loop exists, the measured voltage isthe sum of the signal voltage and the potential difference that exists between the signal source ground and the measurement system ground. This potential is generally not a DC level; therefore, the result is a noisy measurement system. By offering an isolated floating ground on the front end, the isolated USB-6525 devices are able to prevent ground loops from forming.SoftwareNational Instruments measurement services software, built aroundNI-DAQmx driver software, includes intuitive application programming interfaces, configuration tools, I/O assistants, and other tools designed to reduce system setup, configuration, and development time. National Instruments recommends using the latest version of NI-DAQmx driver software for application development in National Instruments LabVIEW, LabWindows/CVI, and Measurement Studio. To obtain the latest version of NI-DAQmx, visit /support/daq/versions. NI measurement services software speeds up your development with features including:•A guide to create fast and accurate measurements with no programming using DAQ Assistant•Automatic code generation to create your application in LabVIEW; LabWindows/CVI; LabVIEW SignalExpress; and Visual Studio .NET,C/C++/C#, or Visual Basic using Measurement Studio •Multithreaded streaming technology•More than 3,000 free software downloads to jump-start your project available at /zone•Software configuration of all digital I/O features without hardware switches/jumpers•Free LabVIEW SignalExpress LE data-logging softwareThe USB-6525 is compatible with the following versions (or later) of NI application software – LabVIEW, LabWindows/CVI, and Measurement Studio versions 7.x or LabVIEW SignalExpress. You can also use your NI digital I/O device with ANSI C, Microsoft Visual C++, Visual Basic, and the Microsoft .NET languages C# and Visual Basic .NET. The USB-6525 is not compatible with the Traditional NI-DAQ (Legacy) driver.Ordering InformationNI USB-6525..........................................................................779640-01 Includes NI-DAQmx software, LabVIEW SignalExpress LE data-logging software, anda USB cable.NI USB-6000 Series Prototyping Accessory........................779511-01 Includes breadboarding area with cover and strain relief.SpecificationsThese specifications are typical at 25 °C, unless otherwise noted.Isolated InputsNumber of channels............................8, ch-ch isolatedInput voltage range.............................-60 to 60 VDCDigital logic levelsInput current........................................ 3.0 mA/channel maxSolid-State Relay OutputsNumber of channels............................8, ch-ch isolatedRelay type...........................................Normally open solid-state relay(SSR)Switching voltage...............................60 VDC/30 V rms max Switching current (per channel).........500 mA max, full operationtemperature range Switching rate (90% duty cycle)......... 5 operations per second Relay open time..................................60 µs typRelay close time.................................. 1.2 ms typOn-resistance......................................550 mΩ, maxOff-leakage current (max)...................0.6 µA typCounterNumber of counters............................ 1 (P1.7 can be configured asa counter) Resolution...........................................32 bitsCounter measurements.......................rising edge counting Maximum input frequency.................. 5 kHzMinimum high pulse width.................20 µsMinimum low pulse width..................180 µsBus InterfaceUSB B 2.0 full-speed (12 Mb/s)Power RequirementsInput voltage....................................... 4.5 to 5.25 VDC in configuredstateActive current......................................150 mA maxSuspend current..................................350 µA typPhysical CharacteristicsDimensionsWithout connectors........................ 6.35 by 8.51 by 2.31 cm(2.50 by 3.35 by 0.91 in.)With connectors.............................8.18 by 8.51 by 2.31 cm(3.22 by 3.35 by 0.91 in.)I/O B series B receptacle,(2) 16 position (screw terminal)plug headers Screw-terminal wiring........................16 to 28 AWG copper conductorwire with 10 mm (0.39 in.) ofinsulation stripped from the end Torque for screw terminals.................0.22 to 0.25 N · m(2.0 to 2.2 lb in.)WeightWith connectors.............................Approx. 87 g (3.1 oz)Without connectors........................Approx. 64 g (2.3 oz)IsolationChannel-to-channel ............................60 VDC continuousChannel-to-earth ground ....................60 VDC continuous Withstand ..........................................60 VDC continuousNote:Do not use this module for connection to signals or for measurements within Measurement Categories II, III, or IV. EnvironmentNI 6528 and PXI-6529 devices are intended for indoor use only. Pollution degree (IEC-60664) (2)Operating EnvironmentAmbient temperature .........................0 to 55 °CRelative humidity................................10 to 90%, noncondensing Maximum altitude ..............................2,000 m at 25 °C ambienttemperature(tested in accordance with IEC-60068-2-1, IEC-60068-2-2, and IEC-60068-2-56)Storage EnvironmentAmbient temperature .........................-40 to 85 °CRelative humidity ...............................5% to 95%, noncondensing (tested in accordance with IEC-60068-2-1, IEC-60068-2-2, and IEC-60068-2-56)Safety and ComplianceSafetyThis product is designed to meet the requirements of the following standards of safety for electrical equipment for measurement, control, and laboratory use:•IEC 61010-1, EN 61010-1•UL 61010-1, CSA 61010-1Note:For UL and other safety certifications, refer to the product label or visit /certification, search by model number or product line, and click the appropriate link in the Certification column. Electromagnetic CompatibilityThis product is designed to meet the requirements of the following standards of EMC for electrical equipment for measurement, control, and laboratory use:•EN 61326 EMC requirements; Minimum Immunity•EN 55011 Emissions; Group 1, Class A•CE, C-Tick, ICES, and FCC Part 15 Emissions; Class ANote:For EMC compliance, operate this device according toproduct documentation.CE ComplianceThis product meets the essential requirements of applicable European Directives, as amended for CE marking, as follows:•73/23/EEC; Low-Voltage Directive (safety)•89/336/EEC; Electromagnetic Compatibility Directive (EMC) Note:Refer to the Declaration of Conformity (DoC) for this product for any additional regulatory compliance information. To obtain the DoC for this product, visit /certification, search by model number or product line, and click the appropriate link in the Certification column.Waste Electrical and Electronic Equipment (WEEE)EU Customers:At the end of their life cycle, all products must be sent to a WEEE recycling center. For more information about WEEE recycling centers and National Instruments WEEE initiatives, visit/environment/weee.htm.NI Services and SupportNI has the services and support to meet your needs around the globe and through the application life cycle – from planning and development through deployment and ongoing maintenance. We offer services and service levels to meet customer requirements in research,design, validation, and manufacturing. Visit /services .Training and CertificationNI training is the fastest, most certain route to productivity with our products. NI training can shorten your learning curve, save development time, and reduce maintenance costs over the application life cycle. We schedule instructor-led courses in cities worldwide, or we can hold a course at your facility. We also offer a professional certification program that identifies individuals who have high levels of skill and knowledge on using NI products. Visit /training .Professional ServicesOur NI Professional Services team is composed of NI applications and systems engineers and a worldwide National Instruments Alliance Partner program of more than 600 independent consultants andintegrators. Services range from start-up assistance to turnkey system integration. Visit /alliance .OEM SupportWe offer design-in consulting and product integration assistance if you want to use our products for OEM applications. For information about special pricing and services for OEM customers, visit /oem .Local Sales and Technical SupportIn offices worldwide, our staff is local to the country, giving you access to engineers who speak your language. NI delivers industry-leading technical support through online knowledge bases, our applications engineers, and access to 14,000 measurement and automationprofessionals within NI Developer Exchange forums. Find immediate answers to your questions at /support .We also offer service programs that provide automatic upgrades to your application development environment and higher levels of technical support. Visit /ssp .Hardware ServicesNI Factory Installation ServicesNI Factory Installation Services (FIS) is the fastest and easiest way to use your PXI or PXI/SCXI combination systems right out of the box.Trained NI technicians install the software and hardware and configure the system to your specifications. NI extends the standard warranty by one year on hardware components (controllers, chassis, modules)purchased with FIS. To use FIS, simply configure your system online with /pxiadvisor .Calibration ServicesNI recognizes the need to maintain properly calibrated devices for high-accuracy measurements. We provide manual calibration procedures, services to recalibrate your products, and automated calibration software specifically designed for use by metrology laboratories. Visit /calibration .Repair and Extended WarrantyNI provides complete repair services for our products. Express repair and advance replacement services are also available. We offerextended warranties to help you meet project life-cycle requirements. Visit /services.National Instruments • info@ • 800 813 3693*351494A-01*351494A-012007-8768-301-101-D。
NI PXIe-6124数据采集卡说明书
800 k
1M
Frequency (Hz)
Magnitude (dB)
2 0 –2 –4 –6 –8 –10
1k
Frequency Response, All Ranges
10 k
100 k
1M
Frequency (Hz)
10 M
NI 6124 Specifications
2
© National Instruments Corporation
Overvoltage protection (AI +, AI –)......................................±36 V
Input current during overvoltage conditions ....................±20 mA max
Interchannel skew............................5 nS
Crosstalk (at 100 kHz).....................–100 dB
CMRR (at 60 Hz) ............................75 dB
DC Transfer Characteristics
Type of ADC Resolution................................... 16 bits, 1 in 65,536 Pipeline....................................... 0
NI的数据采集卡的daq
NI-DAQmx模拟I/O实例
使用MAX创建任务实例。虚拟出一块NI PCI-6530数据采集卡，并在MAX中创建 一个测量任务，基于热电偶对温度进行测量，该任务包含有两个虚拟通道， 一个为全局虚拟通道，另一个为局部虚拟通道。具体步骤如下： • 创建虚拟数据采集卡：打开MAX，选择M系列的数据采集卡中的PCI-6320。 • 创建全局虚拟通道：在MAX左侧Configuration配置导航栏“My System”下的 “Data Neighborhood”上单击鼠标右键，从右键菜单中选择“Creat New…” 后，在弹出的对话窗口中选择“NI-DAQmx Global Virtual Channel”，然后单 击“next”按钮。在界面中选择测量类型。 • 选择后单击“Next”按钮，下一界面中要求填入欲创建的虚拟通道的名称。 • 创建任务：在MAX左侧Configuration配置导航栏“My System”下的“Data Neighborhood”上单击鼠标右键，从右键菜单中选择“Creat New…”后，在弹 出的对话窗口中选择“NI-DAQmx Task”，然后单击“next”按钮。 • • • • 同样会出现要求选择测量类型的界面。 单击“Next”按钮确认后，在下一界面中 填入欲创建的任务名称。 在任务中新建局部虚拟通道：包括添加 局部虚拟通道，更改触发和计时信息等。 单击窗口上方的“Run”按钮，就可以开 始数据采集了。至此一个具有两个虚拟 通道（一个为全局通道，一个为虚拟通 道）、用于通过热电偶测量温度的任务 就创建并配置完毕了。
NI的数据采集卡的设置
当NI数据采集卡驱动安装后，会出现Measurement&Automation Explore(MAX)程序。NI数据采集卡的配置是通过数据采集卡配置软件 Measurement&Automation Explore(MAX):其功能如下： 1.浏览系统中的设备仪器，并快速检测和配置硬件和软件 2.通过测试面板验证和诊断硬件运行情况。 3.创建新的通道、任务、接口和比例。
NI 9237 四通道同时桥接模块数据手册说明书
DAT ASHEETNI 92374 AI, ±25 mV/V, 24 Bit, 50 kS/s/ch Simultaneous, Bridge Completion• 4 channels, 50 kS/s per channel simultaneous AI•±25 mV/V input range, 24-bit resolution•Programmable half- and full-bridge completionwith up to 10 V internal excitation•60 VDC, Category I bank isolation•RJ50 or D-SUB connectivity options•-40 °C to 70 °C operating range, 5 g vibration,50 g shockThe NI 9237 simultaneous bridge module for use with CompactDAQ and CompactRIO contains all the signal conditioning required to power and measure up to four bridge-based sensors simultaneously. The four RJ50 jacks provide direct connectivity to most torque or load cells and offer custom cable solutions with minimal tools. The high sampling rate and bandwidth of the NI 9237 offer a high-quality, high-speed strain or load measurement system with zero interchannel phase delay. With 60 VDC isolation and 1,000 Vrms transient isolation, the NI 9237 has high-common-mode noise rejection and increased safety for both the operator and test system.The NI 9237 can perform offset/null as well as shunt calibration and remote sense, making the module the best choice for strain and bridge measurements.The NI 9944 and NI 9945 are accessories for use with quarter-bridge sensors. These accessories have a female RJ50 connector on one end and screw terminals on the other end.C SERIES SIMULTANEOUS BRIDGE MODULE COMPARISONModel ChannelsSample Rate Resolution Connectivity Simultaneous Supported Bridges NI 9218NI 9219NI 9235NI 9236NI 923751.2 kS/s/ch 100 S/s/ch 10 kS/s/ch 10 kS/s/ch 50 kS/s/ch24 bits 24 bits 24 bits 24 bits 24 bitsQuarter, Half, Full Quarter, Half, Full 120 Ω Quarter Bridge 350 Ω Quarter Bridge Quarter, Half, FullLEMO,9-pin DSUB Spring Terminal Spring T erminal Spring T erminal RJ-50,DSUB24884NI C Series OverviewNI provides more than 100 C Series modules for measurement, control, and communication applications. C Series modules can connect to any sensor or bus and allow for high-accuracy measurements that meet the demands of advanced data acquisition and control applications.•Measurement-specific signal conditioning that connects to an array of sensors and signals •Isolation options such as bank-to-bank, channel-to-channel, and channel-to-earth ground •-40 °C to 70 °C temperature range to meet a variety of application and environmentalneeds •Hot-swappable The majority of C Series modules are supported in both CompactRIO and CompactDAQ platforms and you can move modules from one platform to the other with no modification.2 | | NI 9237 DatasheetCompactRIOCompactRIO combines an open-embedded architecturewith small size, extreme ruggedness, and C Seriesmodules in a platform powered by the NI LabVIEWreconfigurable I/O (RIO) architecture. Each systemcontains an FPGA for custom timing, triggering, andprocessing with a wide array of available modular I/O tomeet any embedded application requirement. CompactDAQCompactDAQ is a portable, rugged data acquisition platformthat integrates connectivity, data acquisition, and signalconditioning into modular I/O for directly interfacing to anysensor or signal. Using CompactDAQ with LabVIEW, youcan easily customize how you acquire, analyze, visualize,and manage your measurement data.SoftwareLabVIEW Professional Development System for Windows•Use advanced software tools for large project development•Generate code automatically using DAQ Assistant and InstrumentI/O Assistant•Use advanced measurement analysis and digital signal processing•Take advantage of open connectivity with DLLs, ActiveX,and .NET objects•Build DLLs, executables, and MSI installersNI LabVIEW FPGA Module•Design FPGA applications for NI RIO hardware•Program with the same graphical environment used for desktop andreal-time applications•Execute control algorithms with loop rates up to 300 MHz•Implement custom timing and triggering logic, digital protocols, andDSP algorithms•Incorporate existing HDL code and third-party IP including Xilinx IPgenerator functions•Purchase as part of the LabVIEW Embedded Control and MonitoringSuiteNI 9237 Datasheet| © National Instruments| 3NI LabVIEW Real-Time Module•Design deterministic real-time applications with LabVIEWgraphical programming•Download to dedicated NI or third-party hardware for reliableexecution and a wide selection of I/O•Take advantage of built-in PID control, signal processing, andanalysis functions•Automatically take advantage of multicore CPUs or setprocessor affinity manually•Take advantage of real-time OS, development and debuggingsupport, and board support•Purchase individually or as part of a LabVIEW suiteCircuitryEach channel on the NI 9237 has an independent 24-bit ADC and an input amplifier that enable you to sample signals from all four channels simultaneously.The NI 9237 is isolated from earth ground. However, the individual channels are not isolated from each other. The EX+, EX-, and T- signals are common among all channels. You can connect the NI 9237 to a device that is biased at any voltage within the NI 9237 rejection range of earth ground.Figure 1. Input Circuitry for One Channel of the NI 9237Connection Options to Correct for Resistance Errors Wiring resistance can create errors in bridge circuits. The NI 9237 provides two mechanisms to correct for these errors: remote sensing and shunt calibration.Remote SensingRemote sensing continuously and automatically corrects for errors in excitation leads, and generally is most appropriate for half- and full-bridge sensors.Long wire and small gauge wire have greater resistance, which can result in gain error. The resistance in the wires that connect the excitation voltage to the bridge causes a voltage drop, 4| | NI 9237 Datasheetwhich is a source of gain error. The NI 9237 includes remote sensing to compensate for this gain error. Connect remote sense wires to the points where the excitation voltage wires connect to the bridge circuit. Refer to the following figure for an illustration of how to connect remote sense wires to the NI 9237.Figure 2. Connecting Remote Sense Wires to the NI 9237RRThe actual bridge excitation voltage is smaller than the voltage at the EX+ and EX- leads. If you do not use remote sensing of the actual bridge voltage, the resulting gain error is:BB BBB for half‐bridge sensors and2⋅BBBBB for full‐bridge sensors.If you connect the remote sense signals directly to the bridge resistors, the NI 9237 senses the actual bridge voltage and eliminates the gain errors caused by the resistance of the EX+ and EX- leads.Shunt CalibrationShunt calibration can correct for errors from the resistance of both the excitation wiring and wiring in the individual resistors of the bridge. Remote sensing corrects for resistances from the EX pins on the NI 9237 to the sensor, and shunt calibration corrects for these errors and for errors caused by wire resistance within an arm of the bridge. Shunt calibration is most useful with quarter-bridge sensors because there may be significant resistance in the wiring to the active resistor in the bridge.The NI 9237 shunt calibration circuitry consists of a precision resistor and a software-controlled switch. Refer to the software help for information about enabling the shunt calibration switch for the NI 9237.Shunt calibration involves simulating the input of strain by changing the resistance of an arm in the bridge by some known amount. This is accomplished by shunting, or connecting, a large resistor of known value across one arm of the bridge, creating a known strain-induced change in resistance. You can then measure the output of the bridge and compare it to the expected voltage value. You can use the results to correct gain errors in the entire measurement path, or to simply verify general operation to gain confidence in the setup.NI 9237 Datasheet| © National Instruments| 5Use a stable signal, which is typically the unloaded state of the sensor, first with the shunt calibration switch off and then again with the switch on. The difference in these two measurements provides an indication of the gain errors from wiring resistances. You can design the software application to correct subsequent readings for this gain error.Excitation VoltagesYou can program the NI 9237 to supply 2.5 V , 3.3 V , 5 V , or 10 V of excitation voltage. Themaximum excitation power for internal excitation is 150 mW.Note Unless you supply external excitation voltage, NI recommends that you setthe excitation voltage to a value that keeps the total power below 150 mW. The NI 9237 automatically reduces internal excitation voltages as needed to stay below 150 mW total power.Use the following equation to calculate the power of a single bridge:=B 2where R is the total resistance of the bridge.For a quarter or half bridge, R is equal to two times the resistance of each element. For a full bridge, R is equal to the resistance of each element.The 150 mW limit allows you to power half and full bridges as follows:•Four 350 Ω half bridges at 5.0 V •Four 350 Ω full bridges at 3.3 V •Four 120 Ω half bridges at 2.5 VExternal ExcitationYou can connect an external excitation voltage source to the NI 9237 if you need an excitation voltage that causes more than 150 mW to dissipate across all the bridges.Figure 3. Connecting an External Excitation Voltage Source to the NI 9237External Excitation VoltageSourceExternal Excitation Voltage SourceNote For the NI 9237 with RJ-50, use the two EX+ and EX- terminals on the four-terminal external excitation voltage connector to connect one external excitation source.You can use the additional EX+ and EX- terminals on the connector to wire multiple NI 9237modules together in a daisy chain.6 | | NI 9237 DatasheetFilteringThe NI 9237 uses a combination of analog and digital filtering to provide an accurate representation of in-band signals and reject out-of-band signals. The filters discriminatebetween signals based on the frequency range, or bandwidth, of the signal. The three important bandwidths to consider are the passband, the stopband, and the anti-imaging bandwidth.The NI 9237 represents signals within the passband, as quantified primarily by passband ripple and phase nonlinearity. All signals that appear in the alias-free bandwidth are either unaliased signals or signals that have been filtered by at least the amount of the stopband rejection.PassbandThe signals within the passband have frequency-dependent gain or attenuation. The small amount of variation in gain with respect to frequency is called the passband flatness. Thedigital filters of the NI 9237 adjust the frequency range of the passband to match the data rate.Therefore, the amount of gain or attenuation at a given frequency depends on the data rate.Figure 4. Typical Passband Flatness for the NI 9237Frequency/Data Rate0.50.40.0250.000–0.025–0.0500.30.20.10G a i n (d B)StopbandThe filter significantly attenuates all signals above the stopband frequency. The primary goal of the filter is to prevent aliasing. Therefore, the stopband frequency scales precisely with the data rate. The stopband rejection is the minimum amount of attenuation applied by the filter to all signals with frequencies within the stopband.Alias-Free BandwidthAny signals that appear in the alias-free bandwidth are not aliased artifacts of signals at a higher frequency. The alias-free bandwidth is defined by the ability of the filter to reject frequencies above the stopband frequency. The alias-free bandwidth is equal to the data rate minus the stopband frequency.NI 9237 Datasheet | © National Instruments | 7Data RatesThe frequency of a master timebase (f M) controls the data rate (f s) of the NI 9237. The NI 9237 includes an internal master timebase with a frequency of 12.8 MHz, but the module also can accept an external master timebase or export its own master timebase. To synchronize the data rate of an NI 9237 with other modules that use master timebases to control sampling, all of the modules must share a single master timebase source.The following equation provides the available data rates of the NI 9237:=÷256where n is any integer from 1 to 31.However, the data rate must remain within the appropriate data rate range. When using the internal master timebase of 12.8 MHz, the result is data rates of 50 kS/s, 25 kS/s, 16.667 kS/s, and so on down to 1.613 kS/s depending on the value of n. When using an external timebase with a frequency other than 12.8 MHz, the NI 9237 has a different set of data rates.Note The NI 9151 R Series Expansion chassis does not support sharing timebasesbetween modules.NI 9237 SpecificationsThe following specifications are typical for the range -40 °C to 70 °C unless otherwise noted.Caution Do not operate the NI 9237 in a manner not specified in this document.Product misuse can result in a hazard. You can compromise the safety protectionbuilt into the product if the product is damaged in any way. If the product isdamaged, return it to NI for repair.Input CharacteristicsNumber of channels 4 analog input channelsBridge completionHalf and Full InternalQuarter ExternalADC resolution24 bitsType of ADC Delta-Sigma (with analog prefiltering) Sampling mode Simultaneous8| | NI 9237 DatasheetInternal master timebase (ƒM)Frequency12.8 MHzAccuracy±100 ppm maximumData rate range (ƒs) using internal master timebaseMinimum 1.613 kS/sMaximum50 kS/sData rate range (ƒs) using external master timebaseMinimum391 S/sMaximum51.36 kS/sData rates (ƒs)(ƒM ÷ 256) ÷ n, where n = 1, 2, …, 31 Typical input range±25 mV/VScaling coefficient 2.9802 nV/V per LSBOvervoltage protection between any two pins±30 VGain drift10 ppm/°C maximumOffset drift2.5 V excitation0.6 µV/V per °C3.3 V excitation0.5 µV/V per °C5 V excitation0.3 µV/V per °C10 V excitation0.2 µV/V per °C1Before offset null or shunt calibration.2Applies at a data rate of 50 kS/s. Lower data rates can have up to 0.20% of reading additional gain error.3Range equals 25 mV/V.4Uncalibrated accuracy refers to the accuracy achieved when acquiring data in raw or unscaledmodes and in which calibration constants that are stored in the module are not applied to the data.NI 9237 Datasheet| © National Instruments| 9Half-bridge completionTolerance±1200 µV/V maximumDrift 1.5 µV/V per °CTable 2. Channel-to-Channel Matching (Calibrated)Phase nonlinearityƒin = 0 to 1 kHz<0.001°ƒin = 0 to 20 kHz±0.1°Input delay(40 + 5/512)/ƒs + 4.5 µs PassbandFrequency0.45 · ƒsFlatness0.1 dB maximum StopbandFrequency0.55 · ƒsRejection100 dBAlias-free bandwidth0.45 · ƒsOversample rate64 · ƒsRejection at oversample rate5ƒs = 10 kS/s60 dB @ 640 kHzƒs = 50 kS/s*********** Common-mode voltage,all signals to earth ground±60 VDCCommon-mode voltage range, with respect to EX-±1 V from the midpoint of the excitation voltage5Rejection by analog prefilter of signal frequencies at oversample rate. 10| | NI 9237 DatasheetCMRRRelative to earth ground6 (ƒin = 0 to 60140 dBHz)Relative to EX– (ƒin = 0 to 1 kHz)85 dBSFDR (1 kHz, –60 dBFS)115 dBTotal Harmonic Distortion (THD)1 kHz, –20 dBFS–95 dB8 kHz, –20 dBFS–95 dBExcitation noise100 µVrmsCrosstalk (not including cable effects)ƒin = 1 kHz110 dBƒin = 10 kHz100 dBExcitationInternal voltage 2.5 V, 3.3 V, 5.0 V, 10.0 VInternal power150 mW maximumExternal voltage 2 V to 10 VShunt calibrationResistance100 kΩ6Measured with a balanced cable on the NI 9237 with RJ-50 and with no cable on theNI 9237 with DSUB. Shielded cables that are not twisted-pair may be significantly unbalanced, which can impact CMRR performance. To improve the balance of shielded cables, NI recommends twisting together the AI+/AI– pair, the RS+/RS– pair, and the EX+/EX– pair.NI 9237 Datasheet| © National Instruments| 11Resistor accuracy25 °C±110 Ω– 40 °C to 70 °C±200 ΩMTBFNI 9237 with RJ-50603,359 hours at 25 °C; Bellcore Issue 2,Method 1, Case 3, Limited Part Stress Method NI 9237 with DSUB704,148 hours at 25 °C; Bellcore Issue 2,Method 1, Case 3, Limited Part Stress Method Power RequirementsPower consumption from chassisActive mode740 mW maximumSleep mode25 µW maximumThermal dissipation (at 70 °C)Active mode740 mW maximumSleep mode25 µW maximumPhysical CharacteristicsTip For two-dimensional drawings and three-dimensional models of the C Seriesmodule and connectors, visit /dimensions and search by module number.Connect only voltages that are within the following limits.Between any two pins±30 V maximumIsolation, channel-to-channel NoneIsolation, channel-to-earth groundUp to 3,000 mContinuous60 VDC, Measurement Category IWithstand1,000 Vrms, verified by a 5 s dielectricwithstand testUp to 5,000 mContinuous60 VDC, Measurement Category IWithstand860 Vrms, verified by a 5 s dielectricwithstand test12| | NI 9237 DatasheetMeasurement Category I is for measurements performed on circuits not directly connected to the electrical distribution system referred to as MAINS voltage. MAINS is a hazardous live electrical supply system that powers equipment. This category is for measurements of voltages from specially protected secondary circuits. Such voltage measurements include signal levels, special equipment, limited-energy parts of equipment, circuits powered by regulated low-voltage sources, and electronics.Caution Do not connect the NI 9237 to signals or use for measurements withinMeasurement Categories II, III, or IV.Note Measurement Categories CAT I and CAT O are equivalent. These test andmeasurement circuits are not intended for direct connection to the MAINS buildinginstallations of Measurement Categories CAT II, CAT III, or CAT IV. Hazardous LocationsU.S. (UL)Class I, Division 2, Groups A, B, C, D, T4;Class I, Zone 2, AEx nA IIC T4Canada (C-UL)Class I, Division 2, Groups A, B, C, D, T4;Class I, Zone 2, Ex nA IIC T4Europe (ATEX) and International (IECEx)Ex nA IIC T4 GcSafety and Hazardous Locations StandardsThis product is designed to meet the requirements of the following electrical equipment safety standards for measurement, control, and laboratory use:•IEC 61010-1, EN 61010-1•UL 61010-1, CSA 61010-1•EN 60079-0:2012, EN 60079-15:2010•IEC 60079-0: Ed 6, IEC 60079-15; Ed 4•UL 60079-0; Ed 5, UL 60079-15; Ed 3•CSA 60079-0:2011, CSA 60079-15:2012Note For UL and other safety certifications, refer to the product label or the OnlineProduct Certification section.Electromagnetic CompatibilityThis product meets the requirements of the following EMC standards for sensitive electrical equipment for measurement, control, and laboratory use:•EN 61326-2-1 (IEC 61326-2-1): Class A emissions; Industrial immunity•EN 55011 (CISPR 11): Group 1, Class A emissions•AS/NZS CISPR 11: Group 1, Class A emissionsNI 9237 Datasheet| © National Instruments| 13•FCC 47 CFR Part 15B: Class A emissions•ICES-001: Class A emissionsNote In the United States (per FCC 47 CFR), Class A equipment is intended foruse in commercial, light-industrial, and heavy-industrial locations. In Europe,Canada, Australia and New Zealand (per CISPR 11) Class A equipment is intendedfor use only in heavy-industrial locations.Note Group 1 equipment (per CISPR 11) is any industrial, scientific, or medicalequipment that does not intentionally generate radio frequency energy for thetreatment of material or inspection/analysis purposes.Note For EMC declarations and certifications, and additional information, refer tothe Online Product Certification section.CE ComplianceThis product meets the essential requirements of applicable European Directives, as follows:•2014/35/EU; Low-V oltage Directive (safety)•2014/30/EU; Electromagnetic Compatibility Directive (EMC)•94/9/EC; Potentially Explosive Atmospheres (ATEX)Online Product CertificationRefer to the product Declaration of Conformity (DoC) for additional regulatory compliance information. To obtain product certifications and the DoC for this product, visit / certification, search by model number or product line, and click the appropriate link in the Certification column.Shock and VibrationTo meet these specifications, you must panel mount the system.Operating vibrationRandom (IEC 60068-2-64) 5 g rms, 10 Hz to 500 HzSinusoidal (IEC 60068-2-6) 5 g, 10 Hz to 500 HzOperating shock (IEC 60068-2-27)30 g, 11 ms half sine; 50 g, 3 ms half sine;18 shocks at 6 orientations14| | NI 9237 DatasheetEnvironmentalRefer to the manual for the chassis you are using for more information about meeting these specifications.Operating temperature-40 °C to 70 °C(IEC 60068-2-1, IEC 60068-2-2)-40 °C to 85 °CStorage temperature(IEC 60068-2-1, IEC 60068-2-2)Ingress ProtectionNI 9237 with RJ-50IP30NI 9237 with DSUB IP40Operating humidity (IEC 60068-2-78)10% RH to 90% RH, noncondensing Storage humidity (IEC 60068-2-78)5% RH to 95% RH, noncondensing Pollution Degree2Maximum altitude5,000 mIndoor use only.Environmental ManagementNI is committed to designing and manufacturing products in an environmentally responsible manner. NI recognizes that eliminating certain hazardous substances from our products is beneficial to the environment and to NI customers.For additional environmental information, refer to the Minimize Our Environmental Impact web page at /environment. This page contains the environmental regulations and directives with which NI complies, as well as other environmental information not included in this document.Waste Electrical and Electronic Equipment (WEEE) EU Customers At the end of the product life cycle, all NI products must bedisposed of according to local laws and regulations. For more information abouthow to recycle NI products in your region, visit /environment/weee.电子信息产品污染控制管理办法（中国RoHS）中国客户National Instruments符合中国电子信息产品中限制使用某些有害物质指令(RoHS)。
NI数据采集（DAQ）设备入门指南说明书
DAQ Getting Started GuideThis guide describes how to confirm your NI data acquisition (DAQ) device is operating properly. Install your application and driver software, then your device, using the instructions packaged with your device. Confirm Device RecognitionComplete the following steps:unch MAX by double-clicking the NI MAX icon on the desktop, or (Windows8) by clickingNI MAX from NI Launcher.2.Expand Devices and Interfaces to confirm your device is detected. If you are using a remoteRT target, expand Remote Systems, find and expand your target, and then expand Devices andInterfaces. If your device is not listed, press <F5> to refresh the configuration tree. If the device isstill not recognized, refer to /support/daqmx.For a Network DAQ device, do the following:•If the Network DAQ device is listed under Devices and Interfaces»Network Devices, right-click it and select Add Device.•If your Network DAQ device is not listed, right-click Network Devices, and select Find Network NI-DAQmx Devices. In the Add Device Manually field, type the Network DAQdevice’s host name or IP address, click the + button, and click Add Selected Devices. Yourdevice will be added under Devices and Interfaces»Network Devices.Note If your DHCP server is set up to automatically register host names, the device registers thedefault host name as cDAQ-<model number>-<serial number>, WLS-<serial number>,or ENET-<serial number>. You can find the serial number on the device. If you cannot find thehost name of that form, it may have been modified from the default to another value.If you still cannot access your Network DAQ device, click the Click here for troubleshootingtips if your device does not appear link in the Find Network NI-DAQmx Devices window orgo to /info and enter the Info Code netdaqhelp.Tip You can test NI-DAQmx applications without installing hardware by using an NI-DAQmxsimulated device. For instructions on creating NI-DAQmx simulated devices and importingNI-DAQmx simulated device configurations to physical devices, in MAX, select Help»Help Topics»NI-DAQmx»MAX Help for NI-DAQmx.3.Right-click the device and select Self-Test. When the self-test finishes, a message indicates successfulverification or if an error occurred. If an error occurs, refer to /support/ daqmx.4.For NI M and X Series PCI Express devices, right-click the device and select Self-Calibrate.A window reports the status of the calibration. Click Finish.Configure the Device SettingsSome devices, such as the NI-9233 and some USB devices, do not need properties for configuringaccessories, RTSI, topologies, or jumper settings. If you are installing only devices without configurable properties, skip to the next step. Configure each device with configurable settings that you install:1.Right-click the device name and select Configure. Be sure to click the device name under thefolder for the system (My System or Remote Systems) and NI-DAQ API in which you want tocontrol the device.For Network DAQ devices, click the device name and then the Network Settings tab to configurenetwork settings. For additional information on configuring Network DAQ devices, refer to yourdevice documentation.2.Configure the device properties.•If you are using an accessory, add the accessory information.•For IEEE 1451.4 transducer electronic data sheet (TEDS) sensors and accessories, configure the device and add the accessory as previously described. Click Scan for TEDS. To configureTEDS sensors cabled directly to a device, in MAX, right-click the device under Devices andInterfaces and select Configure TEDS.3.Click OK to accept the changes.Install Signal Conditioning or Switch DevicesIf your system includes SCXI signal conditioning modules, Signal Conditioning Components (SCC)such as SC carriers and SCC modules, terminal blocks, or switch modules, refer to the getting started guide for the product to install and configure the signal conditioning or switch hardware.Attach Sensors and Signal LinesAttach sensors and signal lines to the terminal block or accessory terminals for each installed device.You can find device terminal/pinout locations in MAX, the NI-DAQmx Help, or the devicedocumentation. In MAX, right-click the device name under Devices and Interfaces, and selectDevice Pinouts.For information about sensors, refer to /sensors. For information about IEEE 1451.4 TEDS smart sensors, refer to /teds. If you are using SignalExpress, refer to Use NI-DAQmx withYour Application Software.Run Test PanelsUse the MAX test panel as follows.1.In MAX, expand Devices and Interfaces or Devices and Interfaces»Network Devices.2.Right-click the device to test, and select Test Panels to open a test panel for the selected device.3.Click the tabs at the top and Start to test the device functions, or Help for operating instructions.4.If the test panel displays an error message, refer to /support.5.Click Close to exit the test panel.DAQ Getting Started Take an NI-DAQmx MeasurementNI-DAQmx Channels and TasksA physical channel is a terminal or pin at which you can measure or generate an analog or digital signal.A virtual channel maps a name to a physical channel and its settings, such as input terminal connections,the type of measurement or generation, and scaling information. In NI-DAQmx, virtual channels areintegral to every measurement.A task is one or more virtual channels with timing, triggering, and other properties. Conceptually, a taskrepresents a measurement or generation to perform. You can set up and save configuration information in a task and use the task in an application. Refer to the NI-DAQmx Help for complete information about channels and tasks.Use the DAQ Assistant to configure virtual channels and tasks in MAX or in your application software. Configure a Task Using the DAQ Assistant from MAXComplete the following steps to create a task using the DAQ Assistant in MAX:1.In MAX, right-click Data Neighborhood and select Create New to open the DAQ Assistant.2.In the Create New window, select NI-DAQmx Task and click Next.3.Select Acquire Signals or Generate Signals.4.Select the I/O type, such as analog input, and the measurement type, such as voltage.5.Select the physical channel(s) to use and click Next. the task and click Finish.7.Configure individual channel settings. Each physical channel you assign to a task receives a virtualchannel name. To modify the input range or other settings, select the channel. Click Details forphysical channel information. Configure the timing and triggering for your task. Click Run. Use NI-DAQmx with Your Application SoftwareThe DAQ Assistant is compatible with version 8.2 or later of LabVIEW, version 7.x or later ofLabWindows™/CVI™ or Measurement Studio, or with version 3 or later of SignalExpress.SignalExpress, an easy-to-use configuration-based tool for data logging applications, is at Start»AllPrograms»National Instruments»NI SignalExpress or (Windows8) NI Launcher.To get started with data acquisition in your application software, refer to the tutorials:Application Tutorial LocationLabVIEW Go to Help»LabVIEW Help. Next, go to Getting Started with LabVIEW»GettingStarted with DAQ»Taking an NI-DAQmx Measurement in LabVIEW.LabWindows/CVI Go to Help»Contents. Next, go to Using LabWindows/CVI»Data Acquisition»Taking anNI-DAQmx Measurement in LabWindows/CVI.Measurement Studio Go to NI Measurement Studio Help»Getting Started with the Measurement StudioClass Libraries»Measurement Studio Walkthroughs»Walkthrough: Creating aMeasurement Studio NI-DAQmx Application.SignalExpress Go to Help»Taking an NI-DAQmx Measurement in SignalExpress.© National Instruments3DAQ Getting Started GuideExamplesNI-DAQmx includes example programs to help you get started developing an application. Modifyexample code and save it in an application, or use examples to develop a new application or add example code to an existing application.To locate LabVIEW, LabWindows/CVI, Measurement Studio, Visual Basic, and ANSI C examples, go to /info and enter the Info Code daqmxexp. For additional examples, refer to .To run examples without hardware installed, use an NI-DAQmx simulated device. In MAX, selectHelp»Help Topics»NI-DAQmx»MAX Help for NI-DAQmx and search for simulated devices. TroubleshootingIf you have problems installing your software, go to /support/daqmx. For hardwaretroubleshooting, go to /support and enter your device name, or go to /kb.If you need to return your National Instruments hardware for repair or device calibration, refer to / info and enter the Info Code rdsenn to start the Return Merchandise Authorization (RMA) process.Go to /info and enter rddq8x for a complete listing of the NI-DAQmx documents and their locations.More InformationAfter you install NI-DAQmx, the NI-DAQmx software documents are accessible from Start»All Programs»National Instruments»NI-DAQ»NI-DAQmx document title or(Windows8) NI Launcher. Additional resources are online at /gettingstarted.You can access online device documentation by right-clicking your device in MAX and selecting Help»Online Device Documentation. A browser window opens to /manuals with the results of a search for relevant device documents. If you do not have Web access, documents for supported devices are included on the NI-DAQmx media.Worldwide Technical SupportFor support information, refer to /support for access to everything from troubleshooting and application development self-help resources to email and phone assistance from NI ApplicationEngineers. Visit /zone for product tutorials, example code, webcasts, and videos.Visit /services for NI Factory Installation Services, repairs, extended warranty, calibration, and other services.To ensure measurement accuracy, NI factory calibrates all applicable hardware and issues a BasicCalibration certificate, which you can get online at /calibration.Visit /training for self-paced training, eLearning virtual classrooms, interactive CDs,Certification program information, or to register for instructor-led, hands-on courses at locations around the world.For support available at the National Instruments worldwide offices, visit , or contact your local office at /contact. National Instruments corporate headquarters is located at 11500 NorthMopac Expressway, Austin, Texas, 78759-3504.DAQ Getting Started Refer to the NI Trademarks and Logo Guidelines at /trademarks for more information onNational Instruments trademarks. Other product and company names mentioned herein are trademarksor trade names of their respective companies. For patents covering National Instrumentsproducts/technology, refer to the appropriate location: Help»Patents in your software, thepatents.txt file on your media, or the National Instruments Patent Notice at /patents.You can find information about end-user license agreements (EULAs) and third-party legal notices inthe readme file for your NI product. Refer to the Export Compliance Information at /legal/export-compliance for the National Instruments global trade compliance policy and how toobtain relevant HTS codes, ECCNs, and other import/export data.© 2003–2013 National Instruments. All rights reserved.373737H-01Jul13。
ni离散量输入输出板卡开发手册
ni离散量输入输出板卡开发手册摘要：1.NI 离散量输入输出板卡概述2.NI 离散量输入输出板卡的特性3.NI 离散量输入输出板卡的开发流程4.NI 离散量输入输出板卡的应用案例5.总结正文：1.NI 离散量输入输出板卡概述I 离散量输入输出板卡，是由美国国家仪器（National Instruments）公司推出的一款高性能、多功能的工业控制板卡。
该板卡具备丰富的输入输出接口，可以方便地与其他设备进行连接，广泛应用于工业自动化、数据采集、过程控制等领域。
2.NI 离散量输入输出板卡的特性I 离散量输入输出板卡具有以下特性：a.多样的输入输出接口：支持多种信号类型，如数字量、模拟量、高速计数器等，满足各种应用需求。
b.高速数据传输：具备高速数据传输能力，可实现高速、高精度的数据采集与处理。
c.强大的扩展性：支持多种通信协议，如RS-232、RS-485、以太网等，便于与其他设备进行集成。
d.稳定的工作性能：在恶劣的工业环境中，仍能保持稳定的工作性能，满足长时间、高负荷工作的需求。
3.NI 离散量输入输出板卡的开发流程I 离散量输入输出板卡的开发流程主要包括以下几个步骤：a.需求分析：根据项目需求，确定所需的输入输出接口、信号类型、通信协议等。
b.硬件选型：根据需求分析结果，选择合适的NI 离散量输入输出板卡。
c.软件开发：编写程序，实现数据采集、处理、传输等功能。
d.系统集成：将NI 离散量输入输出板卡与其他设备进行集成，构建完整的系统。
e.测试与调试：对系统进行测试与调试，确保系统性能满足设计要求。
4.NI 离散量输入输出板卡的应用案例I 离散量输入输出板卡在工业自动化领域有广泛的应用，例如：a.在生产线上，用于监控生产设备的状态，实现自动化生产。
b.在数据采集系统中，用于采集各种传感器的数据，实现数据实时监测与分析。
c.在过程控制系统中，用于实现对生产过程的实时控制与调整，提高生产效率。
5.总结I 离散量输入输出板卡凭借其丰富的输入输出接口、高速数据传输能力、强大的扩展性及稳定的工作性能，在工业自动化领域具有广泛的应用前景。
ni离散量输入输出板卡开发手册
ni离散量输入输出板卡开发手册【原创版】目录1.NI 离散量输入输出板卡概述2.NI 离散量输入输出板卡的特性3.NI 离散量输入输出板卡的应用领域4.NI 离散量输入输出板卡的开发流程5.NI 离散量输入输出板卡的未来发展趋势正文一、NI 离散量输入输出板卡概述I 离散量输入输出板卡，全称为 National Instruments 离散量输入输出板卡，是美国国家仪器公司（National Instruments）推出的一款用于数据采集和控制的硬件设备。
该板卡支持多种信号类型，包括数字量、模拟量等，广泛应用于各种测试、测量和控制系统中。
二、NI 离散量输入输出板卡的特性1.高性能：NI 离散量输入输出板卡具备高速数据传输能力，可实现高速、高精度的数据采集和控制。
2.多功能：该板卡支持多种信号类型，包括数字量、模拟量等，满足不同应用场景的需求。
3.易于集成：NI 离散量输入输出板卡具有丰富的软件接口，可方便地与各种编程语言和软件平台集成。
4.高可靠性：该板卡采用工业级设计，具备良好的抗干扰性能和稳定性，可在恶劣的工业环境中长时间稳定运行。
5.灵活性：NI 离散量输入输出板卡提供丰富的扩展模块，可根据用户需求进行灵活扩展。
三、NI 离散量输入输出板卡的应用领域1.工业自动化：在工业自动化领域，NI 离散量输入输出板卡可用于生产线监控、设备状态检测等。
2.测试与测量：在测试与测量领域，该板卡可用于数据采集、信号处理、仪器控制等。
3.科学研究：在科学研究领域，NI 离散量输入输出板卡可应用于实验室数据采集、仪器控制等。
4.其他领域：此外，该板卡还可应用于医疗设备、交通运输、能源等领域。
四、NI 离散量输入输出板卡的开发流程1.需求分析：根据项目需求，确定所需的信号类型、数据传输速率等参数。
2.选型：根据需求分析，选择合适的 NI 离散量输入输出板卡型号。
3.硬件设计：设计硬件电路，包括信号输入输出、电源、通信接口等。
NI 9361 计数器数据表说明书
数据表NI 93618个计数器DI，0 V～5 V差分/0 V～24 V单端，32位，102.4 kHz•DSUB连接• 1 MHz最大输入速率•60 VDC, CAT I，通道/Vsup至地隔离NI 9361计数器输入模块具有8通道，用户可将其配置为差分或单端，用于CompactDAQ或CompactRIO系统。
每台NI 9361提供8个嵌入式计数器。
因此可在4个背板计数器基础上扩展CompactDAQ系统。
用户可配置每条通道读取单脉冲序列，或组合所有通道读取增量编码器。
还可以通过使用内部可开关的1 kΩ上拉电阻，直接连接具有集电极开路或推挽式输出的传感器，通过模块连接传感器电源，简化传感器连线。
NI 9361的32位计数器能够执行标准的计数器测量，如边沿计数、脉宽、周期、频率、编码器位置、编码器速度测量。
通过NI 9361计数器，可与系统中的模拟测量、数字测量和其他计数器测量同步。
NI 9361计数器增强了频率与占空比(PWM)测量功能。
频率测量中，计数器支持动态平均模式，在0 Hz至高速率的范围内，通过在精度和延迟之间优化获取频率测量结果。
占空比测量中，计数器对0%至100%的全范围均可正确测量。
套件内容推荐附件• NI 9361 入门指南• NI 9923 37引脚DSUB 至螺栓端子接线盒• NI 9361C 系列计数器模块比较产品名称通道数量程通道说明输入速率NI 9361 5 V （差分），24 V （单端）输入 1 MHz 8NI 9401 5 V, TTL 输入/输出10 MHz 8NI 9402LVTTL 输入/输出16 MHz 4NI 9411 5 V （差分），24 V（单端）输入 1 MHz 6NI 942130 V 输入10 kHz 8NI 942260 V 输入 4 kHz 8NI 942330 V 输入 1 MHz 8NI 9435250 V 输入333 Hz 4NI 9437250 V输入10 kHz8NI C 系列概述2 | | NI 9361数据表NI提供超过100种C系列模块，用于测量、控制以及通信应用程序。
NI采集卡的多通道不同功能采集的配置操作方法
NI采集卡的多通道不同功能采集的配置操作方法
wdyjz@
2011.12.17
西安交通大学
问题：对于带有信号调理功能的采集卡，需要设置部分通道为电压采集，某部分通道为特殊的调理性能信号的采集（如温度、加速度、应变等），如何编程？
方法：
1）通过daqmx 的属性节点设置调理的使能，如加速度的电流激励、直流交流的切换功能等；
2）通过daq助手的通道添加功能实现。
3）通过daq助手分别设置通道任务，转换为daqmx代码，并拷贝综合。
实现案例：
以NI USB-9234 动态信号采集卡为例说明。
采用方法2来实现，daq助手方便操作，并且可以一键转换为daqmx代码，便于系统集成。
步骤1，在程序框图放入daq助手节点；
图1、DAQ助手
步骤2，先设置采集电压通道
图2、设置采集电压
步骤3，设置电压采集的具体参数
图3、电压采集参数设置（通道0）步骤4，添加加速度采集通道
图4、添加加速度采集通道
步骤5，设置加速度采集参数
图5、加速度通道参数采集设置步骤6，采集效果
图6、采集效果图
步骤7，转换为daqmx 代码
步骤8，转换后的效果。
NI LIN 卡数据手册
CAN and LIN Interfaces for Hi-Speed USBOverviewNI USB-847x devices provide Hi-Speed USB interfaces for Controller Area Network (CAN) and Local Interconnect Network (LIN) monitoring, logging,and testing. With high-speed CAN, low-speed/fault-tolerant CAN, and LIN interfaces featuring optional hardware synchronization, you can use two or more USB-847x devices together to interface to a wide variety of CAN and LIN networks.The USB-847x interfaces are ideal for many types of applications, including:•In-vehicle network monitoring and logging •Bus load monitoring•Device validation with synchronized data acquisition •CAN device development and test•CAN and LIN data correlation with external measurementsThe convenient all-in-one design features a captive 2 m USB cable and built-in transceiver, requiring no extra cables or accessories to get applications running quickly.With hardware timestamping, you can log messages withmicrosecond-accurate timestamps for reconstructing network events and correlating data across synchronized devices. All USB-847xinterfaces use an industry-standard 9-pin male D-Sub (DB9) connector to interface to CAN and LIN buses.Hi-Speed USB connectivity and onboard frame buffering ensure no dropped frames, even under 100 percent bus loads.CAN InterfacesUSB-847x CAN interfaces feature the industry-standard Philips SJA1000CAN controller, which implements ISO 11898 CAN functionality.The SJA1000 offers additional features to aid in system development,including listen-only mode, sleep/wakeup mode, error counter access,and self-reception (echo) mode. USB-847x CAN interfaces recognize standard (11-bit) and extended (29-bit) arbitration IDs and are compatible with J1939 networks.•1-port interfaces for high-speed CAN,low-speed/fault-tolerant CAN, and LIN •Optional hardware synchronization •Hi-Speed USB, bus-powered •500 V digital isolation •Bus error logging•Hardware timestamping – 1 µs resolutionCAN Interfaces•Philips SJA1000 CAN controller•Transmit/receive 100 percent bus load at 1 Mb/s•ISO 11898 compliance for standard (11-bit) and extended (29-bit) arbitration IDs •Software-selectable termination for low-speed/fault-tolerant CAN •J1939 complianceLIN Interfaces•Atmel ATA6620 transceiver•LIN 1.3/2.0 and J2602 compliance •Software-selectable master/slave terminationOperating Systems•Windows Vista/XP/2000Recommended Software•LabVIEW•LabWindows ™/CVI •Visual C++ 6.0•Visual Basic 6.0•Borland C/C++Application Software (included)•CAN/LIN bus monitoring and logging utilityDriver Software (included)•NI-CANNI USB-8472, NI USB-8472s, NI USB-8473, NI USB-8473s, NI USB-8476, NI USB-8476s,Low-speed/fault-tolerant USB-847x CAN interfaces offer software-selectable termination for compatibility with all low-speed network configurations.Onboard Physical LayerThe CAN physical layer connects the CAN controller to the physical bus wires. USB-847x CAN interfaces are available with high-speed and low-speed/fault-tolerant physical layers. All USB-847x devices have onboard physical layer transceivers and require no external dongles. The physical layers are internally powered via a DC-to-DC converter and electrically isolated up to 500 V.LIN InterfacesNI USB-8476 LIN interfaces, featuring the Atmel ATA6620 LINtransceiver, are compliant with the LIN 1.3/2.0 and J2602 specifications and offer software-selectable master/slave termination. The ATA6620features baud rates up to 20 kb/s and offers advanced power management with a low-power sleep mode.Hardware SynchronizationMany automotive applications demand tight integration of CAN, LIN,analog, and digital measurements. In applications such as CAN devicedevelopment and validation, you need to synchronize different measurements to correlate data. You can program this synchronization in software, but OS latency and clock drift between the different onboard oscillators introduce unacceptable delays for certain automotive test applications. NI offers USB-847x CAN and LIN interfaces with an optional hardware synchronization feature, with which the USB interfaces can share timing and triggering signals with other USB-847x interfaces, as well as data acquisition, vision, and motion devices, to achieve true hardwaresynchronization. Determinism is maintained between the trigger signal and the desired response because timing and triggering signals are handled in hardware. The host PC software interacts only to retrieve the data once it is acquired or to write new data.NI-CAN SoftwareNational Instruments provides NI-CAN driver software for Windows Vista/XP/2000. NI-CAN includes a detailed API and examples for NI LabVIEW and LabWindows/CVI, Microsoft Visual C/C++ 6.0 andVisual Basic 6.0, and Borland C/C++. USB-847x interfaces use the NI-CAN Frame API for frame-level access to messages on CAN and LIN networks.The NI-CAN driver software also includes the Bus Monitor and NI Spy utilities to aid in application development.NI-CAN Frame APIThe NI-CAN Frame API offers a powerful interface for accessing NI CAN hardware. The API enables full access to all traffic on CAN and LIN buses.It is a powerful tool for implementing a variety of applications, including CAN and LIN frame-level access, challenge response protocols, remote frame handling, and advanced synchronization.Bus MonitorTo quickly monitor all CAN and LIN bus traffic, use Bus Monitor,a utility that offers an easy-to-use interface that displays all CAN and LIN frames on the network, and log the traffic to disk. Bus Monitor provides options to control, display, and view bus statistics.Figure 2. LIN DB9 Connector (USB LIN Modules)Figure 1. CAN DB9 Connector (USB CAN Modules)NI SpyNI Spy is a utility for monitoring NI-CAN API calls made by applications without recompiling or rebuilding. It is ideal for testing application functionality, troubleshooting problems, and verifying communicationSpecificationsUSB Power RequirementsUSB-8472(s), USB-8473(s)..................250 mA, 5 VDCUSB-8476(s).........................................200 mA, 5 VDCHardware SynchronizationInput clocks.........................................1, 10, and 20 MHzOutput clock........................................ 1 MHzTrigger lines......................................... 1 input/outputClock lines........................................... 1 input/outputExamples included for sync to NI-DAQmx, LIN, CAN, and RTSI bus. Supported Baud RatesUSB-8472(s).........................................5,000 to 125,000 baudUSB-8473(s).........................................40,000 to 1,000,000 baudUSB-8476(s).........................................2,400 to 20,000 baud SafetyGalvanic CAN channel toUSB isolation..................................500 V Withstand............................................ 2 s maximum DimensionsNonsynchronized versions..................7.87 by 6.35 by 2.54 cm(3.1 by 2.5 by 1.0 in.) Synchronized versions........................7.87 by 7.11 by 2.54 cm(3.1 by 2.8 by 1.0 in.)Cable length........................................2mI/O connector......................................9-pin male D-Sub, optional 3-pinCOMBICON for synchronization Operating EnvironmentAmbient temperature..........................0 to 55 °CRelative humidity................................10 to 90%, noncondensing(tested in accordance withIEC-60068-2-1, IEC-60068-2-2,IEC-60068-2-56)Ordering InformationNI USB-84721-port, low-speed, USB CAN interface................................779790-01 NI USB-8472s1-port, low-speed, USB CAN interfacewith synchronization............................................................779791-01 NI USB-84731-port, high-speed, USB CAN interface................................779792-01 NI USB-8473s1-port, high-speed, USB CAN interfacewith synchronization............................................................779793-01 NI USB-84761-port, USB LIN interface......................................................779794-01 NI USB-8476s1-port, USB LIN interface with synchronization..................779795-01 CAN Device SimulatorU.S. 120 VAC........................................................................779189-01 Euro 240 VAC........................................................................779189-02 Japan 100 VAC......................................................................779189-07 Cables and BracketsUSB cable strain relief bracket............................................777550-01 CAN single-termination, high-speed cable, 2 m..................192017-02BUY NOW!For complete product specifications, pricing, and accessory information, call 800 813 3693 (U.S.) or go to /can.National Instruments • info@ •800 813 3693*351581A-01*351581A-012008-9328-151-101-DNI Services and SupportNI has the services and support to meet your needs around the globe and through the application life cycle – from planning and development through deployment and ongoing maintenance. We offer services and service levels to meet customer requirements in research,design, validation, and manufacturing. Visit /services .Training and CertificationNI training is the fastest, most certain route to productivity with our products. NI training can shorten your learning curve, save development time, and reduce maintenance costs over the application life cycle. We schedule instructor-led courses in cities worldwide, or we can hold a course at your facility. We also offer a professional certification program that identifies individuals who have high levels of skill and knowledge on using NI products. Visit /training .Professional ServicesOur NI Professional Services team is composed of NI applications and systems engineers and a worldwide National Instruments Alliance Partner program of more than 600 independent consultants andintegrators. Services range from start-up assistance to turnkey system integration. Visit /alliance .OEM SupportWe offer design-in consulting and product integration assistance if you want to use our products for OEM applications. For information about special pricing and services for OEM customers, visit /oem .Local Sales and Technical SupportIn offices worldwide, our staff is local to the country, giving you access to engineers who speak your language. NI delivers industry-leading technical support through online knowledge bases, our applications engineers, and access to 14,000 measurement and automationprofessionals within NI Developer Exchange forums. Find immediate answers to your questions at /support .We also offer service programs that provide automatic upgrades to your application development environment and higher levels of technical support. Visit /ssp .Hardware ServicesNI Factory Installation ServicesNI Factory Installation Services (FIS) is the fastest and easiest way to use your PXI or PXI/SCXI combination systems right out of the box.Trained NI technicians install the software and hardware and configure the system to your specifications. NI extends the standard warranty by one year on hardware components (controllers, chassis, modules)purchased with FIS. To use FIS, simply configure your system online with /pxiadvisor .Calibration ServicesNI recognizes the need to maintain properly calibrated devices for high-accuracy measurements. We provide manual calibration procedures, services to recalibrate your products, and automated calibration software specifically designed for use by metrology laboratories. Visit /calibration .Repair and Extended WarrantyNI provides complete repair services for our products. Express repair and advance replacement services are also available. We offerextended warranties to help you meet project life-cycle requirements. Visit /services .SERVICE NEEDSM A I NT AI N P LA ND EV E L O PD EP L O Y。
NI PCI-Card
8.在Device Manage 查看PCI-5122状态
PCI-5122 显示OK
当前状态：This device is working properly.
CNSBG ABD事業處 CIP專案 10
9、AIO3 NI PCI-6220Card介绍
PCI-6220 是NI公司推出的一款多 功能M系列数据采集（DAQ）板卡， 在AIO3上，BNC2110 就是通过它接 在IPC上的。 特点： 1.高达24路数字I/O，32位计数器数字 触发。 2.NI-Mcal校准技术提高了测量精度 3.关联（Correlated）DIO(8条时钟 线，1MHZ) 4.NIST校准认证以及70多信号调理 5.另有5倍采样速率的高速M系和4倍 分辨率高精度M系 6.NI-DAQMX驱动软件和NI LabVIEW Signal Express 交互式数 据记录物件
CNSBG ABD事業處 CIP專案 4
3.在NI 管理系统中调试6503和绿板信号灯的状态
点击Test Panels进入 绿板Y/Pb/Pr 信号灯 在Port Name 中选择Port1 选择All output输出
通过对0/1/2 All Low可控制绿板上 Y/Pb/Pr信号灯常开和常闭操作
*常用 NI PCI-Card 基本工站介绍*
CNSBG ABD事業處 CIP專案 1
一、AIO3工站常用NI PCI-Card
可直接打开NI管理系统对绿板调试控制
调试时,先进MTP程序测试项TI935（Y）点击Stop, 在测试板子至Paused，打开NI调试图片（如右图）
调试时,先进MTP程序测试项TI931（BB-L/R）点击
点击NI-DAQmx Simulated Device进入菜单
NI数据采集卡使用入门
NI数据采集卡使用入门NI (National Instruments) 数据采集卡是一种专门用于测量和记录各种类型的电信号、模拟信号和数字信号的硬件设备。
该采集卡被广泛应用于科研实验室、工业自动化和测试测量等领域。
本文将为您介绍如何使用NI数据采集卡进行基本的数据采集和分析。
首先，确保您已经安装了NI数据采集卡及其相关软件。
NI数据采集卡通常需要安装NI-DAQmx驱动软件以及LabVIEW开发环境。
安装完成后，您可以通过电缆将数据采集卡与被测设备连接起来。
接下来，我们需要编写一个简单的数据采集程序。
在LabVIEW中，您可以利用Drag-and-Drop编程的方式轻松构建这样的程序。
首先，打开LabVIEW软件并创建一个新的VI（Virtual Instrument）。
然后，从函数面板中拖放出一个“DAQ Assistant”组件。
在DAQ Assistant界面中，您可以选择数据采集卡的型号，并配置您希望测量的输入通道和参数。
在配置完成后，您需要添加数据保存和分析的功能模块。
您可以从函数面板中选择合适的函数模块，例如“Write to Measurement File”用于保存数据至文件，或者“Signal Processing”模块用于对数据进行处理和分析。
将这些功能模块拖放到主VI中，并根据需求进行参数配置。
在程序编写完成后，您可以通过点击LabVIEW界面中的运行按钮来启动数据采集和分析。
程序会使用预设的配置参数，自动从数据采集卡读取数据，并按照您的设置进行保存和分析。
此外，如果需要对数据进行实时的监测和显示，您可以在LabVIEW界面中添加相应的控件元素。
例如，您可以在Front Panel中添加一个Chart图表控件，用于实时显示采集到的数据。
同样地，您可以从函数面板中选择合适的控制模块，例如“Loop”结构来循环读取数据进行实时显示。
最后，当您完成数据采集和分析后，可以选择将数据保存至文件或者导出至其他软件进行进一步的处理。
国家信号科技NI PXIe-5603板卡说明书
Board Model Name Board Part Number RangeNI PXIe-5603 199572X-01 including all letter revisionsManufacturer: National InstrumentsVolatile MemoryUser Accessible/ BatteryType1Size System Accessible2Backup? Purpose Method of Clearing3ASIC 208 b No/Yes No PCI communication Cycle powerFPGA BRAM 576 Kb No/Yes No List mode instruction storage Cycle powerNon-Volatile MemoryUser Accessible/ BatteryType Size System Accessible Backup? Purpose Method of ClearingFLASH 4 Mb No/Yes No Device enumeration None available to user FLASH 4 Mb No/Yes No Calibration data storage None available to user FLASH 32 Mb No/Yes No Calibration data storage None available to userMedia StorageUser Accessible/ BatteryType Size System Accessible Backup? Purpose Method of ClearingNONEClearing Notes:User Access:In order to clear the user accessible portion of the PXIe-5603 calibration memory, the user must write a known value to the user string field in the calibration memory. This can be accomplished using the following code excerpt:1 Calibration constants that are stored in device calibration memory include information for the device’s full operating range. Calibration constants do not maintain any unique data for specific configurations in which the device is used unless otherwise specified.2 Items are designated No for the following reason(s): a) Hardware changes or a unique software tool from National Instruments are required to modify contents of the memory listed. b) Hardware modifying software tools are not distributed to public users for any personal access or customization; also known as non-normal use.3 The designation None Available to User indicates that the ability to clear the memory is not available to the user under normal operation. The utilities required to clear the memory are not distributed by National Instruments to customers for normal use.Calibration API:The PXIe-5601 has a user accessible calibration API (Application Programming Interface) for LabVIEW. This API allows the user to perform following calibrations manually, which re-writes the stored calibration constants:1.Downconverter Gain2.LO Export Calibration3.Baseline Calibration Store for Self CalibrationDocumentation for the use of this API is listed in the NI RF Vector Signal Analyzers Help file.If the user performs a manual calibration of this module in a classified location, they may be required to re-calibrate under “default” or “normal” use conditions before the device is cleared for removal from the classified location. These “default” or “normal” use conditions for re-calibration will be defined by the user and the approving declassification group.Self Calibration:The PXIe-5603 also has self calibration capability using the niRFSA Self Cal VI that allows the user to perform a calibration with the currently associated modules. The new calibration constants are stored in the self calibration area in the calibration memory.If the user performs a self calibration of this module in a classified location, they may be required to re-run the self calibration under “default” or “normal” use conditions before the device is cleared for removal from the classified location. These “default” or “normal” use conditions for re-calibration will be defined by the user and the approving declassification group.Terms and DefinitionsUser Accessible User accessible memory allows the user to directly write or modify the contents of the memory during normal instrument operation.System Accessible System accessible memory does not allow the user to access or modify the memory during normal instrument operation, however, may be accessed or modified by background processes. This can be something that is not deliberate by the user and can be a background driver implementation, such as storing application information in RAM to increase speed of use. Under normal use conditions user data is not written to any non-volatile memory locations by the system.Cycle Power The process of completely removing power from the device and its components. This includes a complete shutdown of the PC and/or chassis containing the device; a reboot is not sufficient for the completion of this process.Volatile Memory Volatile memory requires power to maintain the stored information. When power is removed from this memory, its contents are lost.Non-Volatile Non-volatile memory retains its contents when power is removed. This type of memory typically contains calibration or chip configuration information, such as power up states.。
NIPCI-Card
4.在Device Manage 查看PCI-5122状态
PCI-5122 显示OK
当前状态：This device is working properly.
CNSBG ABD事業處 CIP專案23
5、FUNC1 PCI-4474 Card介绍
称为从事高精度动态和瞬 态测量的4通道动态信号采集 卡，其输入通道可进行加速计 和麦克风的集成电路压电式信 号采集。为高通道数的声音和 振动应用设计的高精度数据采 集模块。
在M Series DAQ系列中 选择PCI6220,最后OK完
CNSBG ABD事業處 CIP專案12
11.AIO3 6220在NI 管理系统中调试图
点击进入，在TI931 （BB-L\R）项设置 STOP, 再进行测试 使出现Paused状态
在Channel Name ai0/ai1分别对应 BB-L/R 在调试过程可选择ai0/ai1
在调试前，将板子上电，接上RF IN和三色线 对应的Y Pb Pr 上，在NI调试图片如右图。
CNSBG ABD事業處 CIP專案31
1、FUNC2 PCI-5122 Card介绍
PCI-5122 Card 是NI 公司推出的高速数据采集卡 又称高分辨率数字代仪。NI PCI-5122具有较宽的动态范 围，软件可选的50Ω或1M Ω 输入以及200mVpp到 20Vpp电压范围，并可在板 载内存中采集超过100万个 波形。
用于产线：Function1
CNSBG ABD事業處 CIP專案20
2.在NI 管理系统中建立NI PCI-5122
选中NI-DAQ mx Devices右键进入
点击NI-DAQmx
Simulated Device进入菜单
NI 数据采集卡使用说明书
第一章 NI 数据采集卡使用说明书编写人：梅飞一、 安装与配置1. 在安装板卡之前，请首先安装NI-DAQ驱动程序软件。
您可以在随卡附带的光盘内找到这个驱动程序软件。
另外，NI公司的网站上也提供这个驱动程序软件的免费下载：/softlib.nsf/websearch/90B60D5899BCCCDB86256FC700581B 89?opendocument&node=132070_US如果您使用LabVIEW或LabWindows/CVI 等软件来进行编程,需要在安装驱动软件之前先安装开发平台LabVIEW或LabWindows/CVI等软件。
安装过程中，安装程序会提醒您插入DAQ驱动光盘。
2. NI-DAQ驱动软件正确安装后,请关闭计算机,插入数据采集板卡,启动计算机,即可自动找到板卡并安装好，完成整个安装过程。
注意：在安装PCI或者PXI板卡时，一定要将电脑电源关闭；PC机则最好将电源线拔掉，以免电脑主板关机后仍然带电，造成各类损伤。
二、模拟输入说明1. 信号类型根据信号的参考情况， 一个电压源可以分为两类： 接地信号、浮地信号。
接地信号:接地信号是信号的一端直接接地的电压信号。
它的参考点是系统地（例如大地或建筑物的地）。
最常见的接地信号源是通过墙上的电源插座接入建筑物地的设备，例如信号发生器和电源供电设备等。
浮地信号:一个不与任何地（如大地或建筑物的地）连接的电压信号称为浮地信号。
一些常见的浮地信号有电池、热电偶、变压器和隔离放大器。
2． 测量方式按信号连接方式不同可分为三种测量方式：差分(DIFF)；参考单端(RSE)；非参考单端（NRSE）。
注意：NI公司的部分型号数据采集卡不一定完全支持上述三种测量方式，请查询对应数采卡的使用手册。
按测量方式分类可以分为以下两大类测试系统：1）差分测试系统(DIFF)可避免接地回路干扰可避免因环境引起的共模干扰当输入信号有以下情况时，使用差分测试系统：低电平信号（例如小于1V）。
NI单板RIO GPIC（通用电源调节控制器）数据表说明书
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE NI Single-Board RIO General Purpose Inverter Control (GPIC)• Industry-proven power electronics control and I/O system with complete development toolchain for industrial power conversion • Carefully designed to meet both technical and price requirements of high-volume OEM equipment design teams• Compatible with industry standard SEMIKRON intelligent power modules (SKiiP3, SKiiP4, SEMIKUBE SL, ...)• Reconfigurable System-On-a-Chip (RSOC) technology with 220 DSP cores: 69x higher performance per dollar than traditional DSPs • Outperform your competition with the same control and I/O budget• NI embed ded technology quadruples the productivity of embedded design teams: 114-person-month average reduction in development cost• Get your power conversion equipment to market on time with limited resources• Integrated power electronics co-simulation, mini-scale control development, analysis/validation and real-time HIL simulation tools • Complete toolchain for professional OEM equipment design teams • Hundreds of open source power electronics control IP cores and application examples (AFE with 1547, buck-boost, IBDC, VFD, ...) • Suitable for any converter topology (bi-directional AFE, DC/AC,AC/DC, DC/DC, buck-boost IBDC, back-to-back AC/DC/AC, modular multi-level)• Reliable performance in high EMC, rugged, wide temperature industrial equipment deployments• Long-term assurance against obsolescence with NI 15 year hardware life cycle• Automatic fault logging and remote system management tools Development Toolchain (follow links to order)• NI sbRIO-9607 Zynq-7020 General Purpose Inverter Controller Industry Development Kit (academic kit)• NI LabVIEW HIL and Real-Time Test Suite (LabVIEW Pro, RT, FPGA, CD&Sim, Veristand)• NI Developer Suite Multisim Circuit Design Option(Multisim/Ultiboard with Co-Simulation)• Open Source Linux RT Eclipse C/C++ Toolchain for ARM with LabVIEW FPGA Interface API• OpalRT Electrical High Speed Power Electronics Real-Time HIL SimulatorOpen Source IP, Designs and Examples (/powerdev)• LabVIEW FPGA open source power electronics IP core and examples library• NI GPIC Reference Design Code and Online Training Course• LabVIEW FPGA Floating Point Control Engineering Toolkit• GPIC Interface Board for Dual SEMIKRON SKiiP3 Power Modules •Dual SKiiP3 Replica Mini-Scale Control Development SystemSpecificationsXilinx Reconfigurable System-On-a-Chip (RSOC)∙Zynq 7020 RSOC ∙220 DSP cores ∙LabVIEW FPGA ∙14,500 MMACS DSP performance ∙85,000 logic cells∙Optional VHDL/Verilog integrationDual-core 667 MHz ARM Cortex-A9 Processors∙Linux Real-Time Operating System (open source)∙512 MB DDR3 RAM ∙Eclipse C/C++ IDE/BSP or LabVIEW Real-Time IDE/BSP (fully integrated) ∙512 MB Nonvolatile Flash Storage, Reliance file systemCommunication Ports∙Gigabit Ethernet ∙CANbus ∙RS-232 Serial∙USB 2.0, Hi-Speed (additional storage)Physical Characteristics∙11.9x17.9x4.4 cm ∙-40 to 85 °C local ambient op. temp. Half-Bridge Digital Output (to IPM or Gate Driver)∙14 channels source/sink (push-pull)∙5-30 V, external power∙Up to 500 kHz switching freq. (C LOAD = 0.47 nF)∙Up to 5 ns PWM resolution ∙100 Ω output impedance ∙10 ns no load rise/fall time∙10 mA/ch continuous∙≤100 ns propagation delay (V ext = 15 V, C LOAD = 50 pF)∙Non-isolated, no overcurrent or short-circuit protection∙Glitch-free power up state: OFFSourcing Digital Input∙28 channels, sourcing digital input∙3-6 V or 10-24 V range ∙ 4 µs max update time∙Non-isolated, ±30 V protection∙ 4.32 kΩ p ull-up resistorsLVTTL Digital Input/Output∙32 channels, FPGA IOBs∙ 3.3 V DIO, non-buffered∙Unprotected, 800 MHz max∙Non-isolated FPGA IOBsSinking and Relay Control Digital Output∙28 channels total∙Sinking driver, 0-30 V∙50 µs max update time∙20 mA/ch continuous∙Power up state: OpenRelay Control DO:∙ 4 of the 28 channels, isolated∙8 A/ch inrush, 300 ms max, 60 sinterval∙500 mA continuousSimultaneous Analog Input∙16 simultaneous channels,pseudo differential, 12-bit∙115 kS/s per ch, single rate∙±4.95 V or ±9.9 V range∙±30 V protection, 1.5mV RMS noise∙0.39% (38.5 mV) typ. accuracy for ±5V range, 2.44 mV resolution∙0.32% (65.5 mV) typ. accuracy for ±10V range, 4.88 mV resolution∙210 kHz -3 dB bandwidth, 60 VDC CATI bank isolationScanned Analog Input∙8 single-ended channels∙12-bit, 0-4.97 V range∙Multiplexed sampling∙ 1 kS/s scan rate, all chan.∙0.06% typical accuracy∙10 kΩ input impedance, < 2 kΩ sourceimpedance recommended∙Non-isolated, ±30 V protectionAnalog Output∙8 single-ended channels∙12-bit, 0-4.97 V range∙Simultaneous update∙ 1 kS/s update rate∙0.12% typical accuracy∙ 4 mA/ch output current∙Power on state: 0 V∙Non-isolated, +15/-5 V protectionALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICEComplete Toolchain for OEM Design TeamsFPGA IP and Examples Libraries (download )∙ Dozens of open source example apps. Examples: 3-phase bidirectional active front end (AFE), induction motor VFD (V/Hz, FOC), buck-boost energy storage converter, isolated bidirectional DC (IBDC), …∙ Hundreds of open source IP cores. Examples: Field oriented control transforms (i.e. ABC to DQ), sine-triangle PWM, space-vector PWM, PID control, 1547 anti-islanding, FRF control stability analyzer, …∙ StarSim Control IP Library and Power System SimulatorTypical Hardware/Software ArchitectureTypical Configuration (user manual links)1. NI sbRIO-9607 Zynq-7020 Reconfigurable System-On-a-Chip (RSOC) Control System (with heat spreader thermal kit)2. NI GPIC 9683 Input/Output Board (download CAD files )3. GPIC Interface PCB for Dual SEMIKRON SKiiP3 Power Modules (open source interface PCB template)4. SEMIKRON Intelligent Power Module Stack∙ sbRIO-9607 thermal kit heat spreader (#1) mounts to cabinet panel ∙ GPIC I/O Board (#2) IDC headers mates to custom interface PCB (#3)Mini-Scale Control Development System (info )∙ Full scale power converter control code is rapidly developed and tested using the mini-scale system∙ Open source design with back-to-back 3-phase inverter IPMs, full bridge rectifiers, pre-charge contactors, DC link capacitors, built-in voltage/current/temp sensors, jumper support for external sensorssbRIO-9607GPIC I/O Card 7.080[179.83]4.700[119.38]1.747[44.37]#1#23 MORE Projects*What More Could Y ou do with 3 Additional Embedded Projects / Y ear with the Same Development Budget?/powerdevCustom Interface PCB Data Scope Machine LearningState Machine Software Updater Network Comm.Power Quality Analysis LiveStreamConfiguration Management Control Tuner, Stability Analyzer Data AnalyticsRemote UpdateFault Logging DDS, DNP IEC-61850TCP/IP, UDP, HTTPS, FTP HMI Panel Utility SCADA PID Control JunctionTemp. Regulation Phase Lock Loop Acquisition, Scaling,Filtering Fault Handler, Protection Interlocks SVPWM, SPWM Transforms (ABC to DQ)PCI, Single Point I/F, DMA Streaming I/F Remote Graphical User Interface (GUI) and System ManagementLinux Real-Time OS (Eclipse C/C++ or LabVIEW)Reconfigurable SOC FPGA Hardware RS-232Modbus Simultaneous AI (16)FPGA IOBLVTTL (32)Gate CommandHBDO (14)Sinking DO (24)RelayControl DO (4)Sourcing DI (28)Scanned AI, AO (8,8)RIO Mezzanine Connector (RMC)GPIC Input / Output Board Gate Drivers, Fiber TXPilot Relays, Faults, Fans, Resets, LEDsPre-charge, AC, DC Contactors IGBT Error, Over Temp Error, Contactor Aux, E-Stop 3-ph. I/V, DC Link, StackI/VStack Temperature, Setpoint, Debug AOCabinet BusCAN1588Fiber RX/TX, FPGA-FPGA, Clock Sync, EncoderReal-Time Simulation (Digital Twin)。
