机械密封各个类型的英文表达方式

我这里列出了34个机械密封分类术语...

1.机械端面密封-mechanical face seal

2.流体动压式机械密封-hydrodynamic mechanical seal

3.切向作用流体动压式机械密封-tangential acting hydrodynamic mechanical seal

4.径向作用流体动压式机械密封-radial acting hydrodynamic mechanical seal

5.流体静压式机械密封-hydrostatic mechanical seal

6.外加压流体静压式机械密封-outside pressurized hydrostatic mechanical seal

7.自加压流体静压式机械密封-self pressurized hydrostatic mechanical seal

8.非接触式密封-non contacting (free contacting) mechanical seal

9.内装式机械密封-internally mounted mechanical seal

10.外装式机械密封-externally mounted mechanical seal

11.弹簧内置式机械密封-mechanical seal with inside mounted spring

12.弹簧外置式机械密封-mechanical seal with outside mounted spring

13.背面高压式机械密封-mecanical seal with high back pressure

14.背面低压式机械密封-mechanical seal with low back pressure

15.内流式机械密封-mechanical seal with inward leakage

16.外流式机械密封-mechanical seal with outward leakage

17.弹簧旋转式机械密封-spring rotating mechanical seal

18.弹簧静止式机械密封-spring standing mechanical seal

19.单弹簧式机械密封-single-spring mechanical seal

20.多弹簧式机械密封-multiple-spring mechanical seal

21.非平衡式机械密封-unbalanced mechanical seal

22.平衡式机械密封-balanced mechanical seal

23.单端面机械密封-single mechanical seal

24.双端面机械密封-double mechanical seal

25.轴向双端机械密封-axial double mechanical seal

26.径向双端面机械密封-radial double mechanical seal

27.串联机械密封-tandem mechanical seal

28.橡胶波纹管机械密封-rubber-bellows mechanical seal

29.聚四氟乙烯波纹管机械密封-PTFE-bellows mechanical seal

30.金属波纹管机械密封-l bellows mechanical seal

31.焊接金属波纹管机械密封-welded l bellows mechanical seal

32.压力成型金属波纹管机械密封-formed l bellows mechanical seal

33.带浮动间隔环的机械密封-mechanical seal with floating intermediate ring

34.磁力机械密封-magnetic mechanical seal

机械密封零件术语的常用词汇....

1.sealing ring --密封环

2.seal face--密封端面

3.seal interface--密封界面

4.rotating ring--动环/旋转环

5.stationary ring--静环/静止环

pensated ring--补偿环

7. un-compensated ring--非补偿环

8. seal head--补偿环组件

9.primary seal--主密封

10.secondary seal--副密封

11.auxiliary seal--辅助密封

12.auxiliary seal ring--辅助密封圈

13.bellows--波纹管

14.pushing out ring--撑环

15.back-up ring--挡圈

pensated ring adaptor--补偿环座

17.un-compensated ring adaptor--非补偿环座

18.spring adaptor--弹簧座

19.seal adaptor--波纹管座

20.retainer--传动座

21.driving screw--传动螺钉

22.set screw--紧定螺钉

23.snap ring--卡环

24.clamp ring--夹紧环

25.anti-rotating pin--防转销

26.annular seal space--密封腔

27.seal chamber--密封腔体

28.end cover--密封端盖

29.elastic component--弹性元件

30.a pair of friction components--摩擦副个人常用机械密封专有词汇

inner circulation--内循环

outer circulation--外循环

self circulation--自循环

flush--冲洗

flush fluid--冲洗流体

quench--阻封

quench fluid--阻封流体

buffer fluid--隔离流体

temperature adjustable fluid--调温流体coolant--冷却流体

heating fluid--加热流体

sealed medium--被密封介质
