Protocols > pLKO.1 Protocol pLKO.1 - TRC Cloning Vector
Addgene Plasmid 10878. Protocol Version 1.0. December 2006.
Copyright Addgene 2006, All Rights Reserved. This protocol is provided for your convenience. See warranty information in appendix.
Click here for a printable copy.
Table of Contents
•
A. pLKO.1-TRC Cloning Vector
o A.1 The RNAi Consortium
o A.2 Map of pLKO.1
o A.3 Related plasmids
• B. Designing shRNA Oligos for pLKO.1
o B.1 Determine the optimal 21-mer targets in your gene
o B.2 Order oligos compatible with pLKO.1
• C. Cloning shRNA oligos into pLKO.1
o C.1 Recommended materials
o C.2 Annealing oligos
o C.3 Digesting pLKO.1 TRC-Cloning Vector
o C.4 Ligating and transforming into bacteria
• D. Screening for Inserts
o D.1 Recommended materials
o D.2 Screening for inserts Plasmid Cart
Your cart is empty.
Recently Viewed
pLKO.1 - TRC clo...
Plasmid 10878
pLVTHM Plasmid 12247 Mammalian RNAi T... Collection
• E. Producing Lentiviral Particles
o E.1 Recommended materials
o E.2 Protocol for producing lentiviral particles • F. Infecting Target Cells
o F.1 Recommended materials
o F.2 Determining the optimal puromycin concentration
o F.3 Protocol for lentiviral infection and selection •G. Safety
•H. References
o H.1 Published articles
o H.2 Web resources
•I. Appendix
o I.1 Sequence of pLKO.1 TRC-Cloning Vector
o I.2 Recipes
o I.3 Warranty information
Back to Top
A. pLKO.1-TRC Cloning Vector
A.1 The RNAi Consortium
The pLKO.1 cloning vector is the backbone upon which The RNAi Consortium (TRC) has built a library of shRNAs directed against 15,000 human and 15,000 mouse genes. Addgene is working with the TRC to make this shRNA cloning vector available to the scientific community. Please cite Moffat et al., Cell 2006 Mar; 124(6):1283-98 (PubMed) in all publications arising from the use of this vector.
A.2 Map of pLKO.1
pLKO.1 is a replication-incompetent lentiviral vector chosen by the TRC for expression of shRNAs. pLKO.1 can be introduced into cells via direct transfection, or can be converted into lentiviral particles for subsequent infection of a target cell line. Once introduced, the puromycin resistance marker encoded in pLKO.1 allows for convenient stable selection.
Figure 1 : Map of pLKO.1 containing an shRNA insert. The original
pLKO.1-TRC cloning vector has a 1.9kb stuffer that is released by
digestion with AgeI and EcoRI. shRNA oligos are cloned into the AgeI and EcoRI sites in place of the stuffer. The AgeI site is destroyed in
most cases (depending on the target sequence), while the EcoRI site is preserved. For a complete map of pLKO.1 containing the 1.9kb stuffer, visit /10878.
Description Vector Element
U6 Human U6 promoter drives RNA Polymerase III
transcription for generation of shRNA transcripts.
cPPT Central polypurine tract, cPPT, improves transduction efficiency by facilitating nuclear import of the vector's
preintegration complex in the transduced cells.
hPGK Human phosphoglycerate kinase promoter drives
expression of puromycin.
Puro R Puromycin resistance gene for selection of pLKO.1
plasmid in mammalian cells.
sin 3'LTR 3' Self-inactivating long terminal repeat.
f1 ori f1 bacterial origin of replication.
Amp R Ampicillin resistance gene for selection of pLKO.1 plasmid in bacterial cells
pUC ori pUC bacterial origin of replication.
5'LTR 5' long terminal repeat.
RRE Rev response element.
Figure 2 : Detail of shRNA insert. The U6 promoter directs RNA
Polymerase III transcription of the shRNA. The shRNA contains 21
"sense" bases that are identical to the target gene, a loop
containing an XhoI restriction site, and 21 "antisense" bases that
are complementary to the "sense" bases. The shRNA is followed
by a polyT termination sequence for RNA Polymerase III.
A.3 Related Products
The following plasmids available from Addgene are recommended for use in conjunction with the pLKO.1 TRC-cloning vector.
Plasmid (Addgene ID #)Description
pLKO.1 - TRC control (10879)Negative control vector containing non-hairpin insert.
pLKO.1 - scramble shRNA (1864)Negative control vector containing scrambled shRNA.
psPAX2 (12260)Packaging plasmid for producing viral
particles.
Note: pLKO.1 can also be used with packaging plasmid pCMV-dR8.2 dvpr (Addgene #8455) and envelope plasmid pCMV-VSVG (Addgene
#8454) from Robert Weinberg's lab. For more information, visit Addgene's Mammalian RNAi Tools page.
Several other laboratories have deposited pLKO derived vectors that may also be useful for your experiment. To see these vectors, visit Addgene's website and search for "pLKO".
Back to Top
B. Designing shRNA Oligos for pLKO.1
B.1 Determining the Optimal 21-mer Targets in your Gene
Selection of suitable 21-mer targets in your gene is the first step toward efficient gene silencing. Methods for target selection are continuously being improved. Below are suggestions for target selection.
1. Use an siRNA selection tool to determine a set of top-scoring targets for your gene. For example, the Whitehead Institute for Biomedical Research hosts an siRNA Selection Program that can be accessed after a free registration (/bioc/siRNAext/). If you have MacOS X, another excellent program is iRNAi, which is provided free by the company Mekentosj (/irnai/).
A summary of guidelines for designing siRNAs with effective gene silencing is included here:
•Starting at 25nt downstream of the start codon (ATG), search for 21nt sequences that match the pattern AA(N19). If no suitable
match is found, search for NAR(N17)YNN, where N is any
nucleotide, R is a purine (A,G), and Y is a pyrimidine (C,U).
•G-C content should be 36-52%.
•Sense 3' end should have low stability – at least one A or T between position 15-19.
•Avoid targeting introns.
•Avoid stretches of 4 or more nucleotide repeats, especially repeated Ts because polyT is a termination signal for RNA
polymerase III.
2. To minimize degradation of off-target mRNAs, use NCBI's BLAST program. Select sequences that have at least 3 nucleotide mismatches to all unrelated genes.
Addgene recommends that you select multiple target
sequences for each gene. Some sequences will be more effective
than others. In addition, demonstrating that two different shRNAs
that target the same gene can produce the same phenotype will
alleviate concerns about off-target effects.
B.2 Ordering Oligos Compatible with pLKO.1
To generate oligos for cloning into pLKO.1, insert your sense and antisense sequences from step B.1 into the oligos below. Do not change the ends; these bases are important for cloning the oligos into the pLKO.1 TRC-cloning vector.
Forward oligo:
5' CCGG—21bp sense—CTCGAG—21bp antisense—TTTTTG 3'
Reverse oligo:
5' AATTCAAAAA—21bp sense—CTCGAG—21bp antisense 3'
For example, if the target sequence is (AA)TGCCTACGTTAAGCTATAC, the oligos would be:
Forward oligo:
5'
CCGG AATGCCTACGTTAAGCTATAC CTCGAG GTATAGCTTAACGTA GGCATT TTTTTG 3'
Reverse oligo:
5'
AATTCAAAAA AATGCCTACGTTAAGCTATAC CTCGAG GTATAGCTTA ACGTAGGCATT 3'
Back to Top
C. Cloning Oligos into pLKO.1
The pLKO.1-TRC cloning vector contains a 1.9kb stuffer that is released
upon digestion with EcoRI and AgeI.
The oligos from section B contain the shRNA sequence flanked by sequences that are compatible with the sticky ends of EcoRI and AgeI. Forward and reverse oligos are annealed and ligated into the pLKO.1 vector, producing a final plasmid that expresses the shRNA of interest.
C.1 Recommended Materials
C.2 Annealing Oligos
1. Resuspend oligos in ddH2O to a concentration of 20 μM, then mix:
5 μL Forward oligo
5 μL Reverse oligo
5 μL10x NEB buffer 2
35 μL ddH2O
2. Incubate for 4 minutes at 95o C in a PCR machine or in a beaker of boiling water.
3. If using a PCR machine, incubate the sample at 70o C for 10 minutes then slowly cool to room temperature over the period of several hours. If using a beaker of water, remove the beaker from the flame, and allow the water to cool to room temperature. This will take a few hours, but it is important for the cooling to occur slowly for the oligos to anneal.
C.3 Digesting pLKO.1 TRC Cloning Vector
1. Digest pLKO.1 TRC-cloning vector with AgeI. Mix:
6 μg pLKO.1 TRC-cloning vector (maxiprep or miniprep DNA)
5 μL10x NEB buffer 1
1 μL AgeI
to 50 μL ddH2O
> Incubate at 37o C for 2 hours.
2. Purify with Qiaquick gel extraction kit. Elute in 30 μL of ddH2O.
3. Digest eluate with EcoRI. Mix:
30 μL pLKO.1 TRC-cloning vector digested with AgeI
5 μL10x NEB buffer for EcoRI
1 μL EcoRI
14 μL ddH2O
> Incubate at 37o C for 2 hours.
4. Run digested DNA on 0.8% low melting point agarose gel until you can distinctly see 2 bands, one 7kb and one 1.9kb. Cut out the 7kb band and place in a sterile microcentrifuge tube.
When visualizing DNA fragments to be used for ligation, use
only long-wavelength UV light. Short wavelength UV light will
increase the chance of damaging the DNA.
5. Purify the DNA using a Qiaquick gel extraction kit. Elute in 30 μL of ddH2O.
6. Measure the DNA concentration.
C.4 Ligating and Transforming into Bacteria
1. Use your ligation method of choice. For a standard T4 ligation, mix:
2 μL annealed oligo from step C.2.
20 ng digested pLKO.1 TRC-cloning vector from step C.3. (If you were unable to measure the DNA concentration, use 1 μL)
2 μL10x NEB T4 DNA ligase buffer 1 μL NEB T4 DNA ligase
to 20 μL ddH2O
> Incubate at 16o C for 4-20 hours.
2. Transfo rm 2 μL of ligation mix into 25 μL competent DH5 alpha cells, following manufacturer's protocol. Plate on LB agar plates containing 100 μg/mL ampicillin or carbenicillin (an ampicillin analog).
Back to Top
D. Screening for Inserts
You may screen for plasmids that were successfully ligated by restriction enzyme digestion. However, once you have identified the positive clones, it is important to verify the insert by conducting a sequencing reaction.
D.1 Recommended Materials
D.2 Screening for Inserts
Day 1:
1. Innoculate 5 colonies from each ligation into LB + 100 μg/mL
ampicillin or carbenicillin.
Day 2:
2. Spin down the cultures and use a miniprep kit to obtain DNA.
3. Conduct a restriction digest with EcoRI and NcoI:
1 μg miniprep DNA
2 μL10x NEB buffer for EcoRI
0.8 μL EcoRI
0.8 μL NcoI
to 20 μL ddH2O
> Incubate at 37o C for 1-2 hours.
4. Run the digestion products on a 1% agarose gel. You should
see two fragments, a 2kb fragment and a 5kb fragment.
5. Sequence positive clones with pLKO.1 sequencing primer (5'
CAA GGC TGT TAG AGA GAT AAT TGG A 3').
You may need to adjust the sequencing conditions if the
DNA polymerase has difficulty reading through the
secondary structure of the hairpin sequence.
Back to Top
E. Producing Lentiviral Particles
Before this step, you must contact your institution's Bio-Safety office to receive permission and institution-specific instructions. You must follow safety procedures and work in an environment (e.g. BL2+) suitable for handling HIV-derivative viruses.
For transient knockdown of protein expression, you may transfect plasmid DNA directly into the target cells. The shRNA will be expressed, but the DNA is unlikely to be integrated into the host genome.
For stable loss-of-function experiments, Addgene recommends that you generate lentiviral particles and infect the target cells. Addition of puromycin will allow you to select for cells that stably express your shRNA of interest.
E.1 Recommended Materials
Material Vendor and catalog #
psPAX2Addgene #12260
pMD2.G Addgene #12259
HEK-293T cells GenHunter: #Q401
FuGENE® 6 Transfection Reagent Roche Applied Biosciences:
#11814443001
OPTI-MEM® serum-free media Invitrogen: #31985
Dulbecco's Modified Eagle Medium
Invitrogen: #11995
(DMEM)
Fetal Bovine Serum (FBS) Invitrogen: #16000
Penicillin/Streptomycin Invitrogen: #15140-122 Polypropylene tubes VWR: #87003-290
Note: pLKO.1 could also be packaged using pCMV-dR8.2 dvpr and pCMV-VSVG from the Robert Weinberg lab. For more information, visit Addgene's Mammalian RNAi Tools page.
E.2 Protocol for Producing Lentiviral Particles
This protocol is for transfection in a 6 cm plate. The protocol can be scaled to produce different amounts of virus as needed.
Day 1:
a. For each plasmid to be transfected, plate 7x105 HEK-293T cells
in 5 mL of media in a 6 cm tissue culture plate. Incubate cells at
37o C, 5% CO2 overnight.
Although cells should regularly be passaged in DMEM +
10% FBS with penicillin/streptomycin, cells should be
plated at this step in DMEM + 10% FBS without antibiotics
(no penicillin or streptomycin).
Day 2:
b. Perform the transfection in the late afternoon because the
transfection mix should only be incubated with the cells for 12-15
hours.
c. In polypropylene microfuge tubes (do NOT use polystyrene
tubes), make a cocktail for each transfection:
1 μg pLKO.1 shRNA plasmid
750 ng psPAX2 packaging plasmid
250 ng pMD2.G envelope plasmid
to 20 μl serum-free OPTI-MEM
You may want to vary the ratio of shRNA plasmid,
packaging plasmid, and envelope plasmid to obtain the
ratio that gives you the optimal viral production.
d. Create a master mix of FuGENE® 6 transfection reagent in
serum-free OPTI-MEM. Calculate the amount of Fugene® and
OPTI-MEM necessary given that each reaction will require 6 μL
FuGENE® + 74 μL OPTI-MEM. For example:
1x master mix: 6 μL FuGENE® + 74 μL OPTI-MEM
5x master mix: 30 μL FuGENE® + 370 μL OPTI-MEM
10x master mix: 60 μL FuGENE® + 740 μL OPTI-MEM In a polypropylene tube, add OPTI-MEM first. Pipette FuGENE®
directly into the OPTI-MEM - do not allow FuGENE® to come in
contact with the walls of the tube before it has been diluted. Mix by
swirling or gently flicking the tube. Incubate for 5 minutes at room
temperature.
e. Add 80 μL of FuGENE® master mix to each tube from step c for
a total volume of 100 μL. Pipette master mix direct ly into the liquid
and not onto the walls of the tube. Mix by swirling or gently flicking
the tube.
f. Incubate for 20-30 minutes at room temperature.
g. Retrieve HEK-293T cells from incubator. The cells should be
50-80% confluent and in DMEM that does not contain antibiotics.
h. Without touching the sides of the dish, gently add
DNA:FuGENE® mix dropwise to cells. Swirl to disperse mixture
evenly. Do not pipette or swirl too vigorously, as you do not want
to dislodge the cells from the plate.
i. Incubate cells at 37o C, 5% CO2 for 12-15 hours.
Day 3:
j. In the morning, change the media to remove the transfection
reagent. Replace with 5 mL fresh DMEM + 10% FBS +
penicillin/streptomycin. Pipette the media onto the side of the plate
so as not to disturb the transfected cells.
k. Incubate cells at 37o C, 5% CO2 for 24 hours.
Day 4:
l. Harvest media from cells and transfer to a polypropylene
storage tube. The media contains your lentiviral particles. Store at
4o C.
m. Add 5 mL of fresh media containing antibiotics to the cells and
incubate at 37o C, 5% CO2 for 24 hours.
Day 5:
n. Harvest media from cells and pool with media from Day 4. Spin
media at 1,250 rpm for 5 minutes to pellet any HEK-293T cells
that were inadvertently collected during harvesting.
In lieu of centrifugation, you may filter the media through
a 0.45 μm filter to remove the cells. Do not use a 0.2 μm
filter, as this is likely to shear the envelope of your virus.
o. Virus may be stored at 4o C for a few days, but should be frozen
at -20o C or -80o C for long-term storage.
Freeze/thaw cycles decrease the efficiency of the virus,
so Addgene recommends that you use the virus
immediately or aliquot the media into smaller tubes to
prevent multiple freeze/thaw cycles.
Back to Top
F. Infecting Target Cells
Lentiviral particles can efficiently infect a broad range of cell types, including both dividing and non-dividing cells. Addition of puromycin will allow you to select for cells that are stably expressing your shRNA of interest.
F.1. Recommended Materials
Material Vendor and catalog # Hexadimethrine bromide (polybrene)* S igma-Aldrich: #H9268 Protamine Sulfate* MP Biomedicals: #194729 Puromycin* Sigma-Aldrich: #P8833
Target cells Varies based on your experiment Culture media for target cells Varies based on your experiment Materials for assay Varies based on your experiment
* Detailed protocols for preparing polybrene, protamine sulfate, and
puromycin are located in the Appendix.
F.2. Determining the Optimal Puromycin Concentration
Each cell line responds differently to puromycin selection. Addgene strongly recommends that you determine the optimal puromycin concentration for your cell line before initiating your experiment.
Day 1:
a. Plate target cells in ten 6 cm plates and grow at 37o C, 5% CO2
overnight.
Day 2:
b. The target cells should be approximately 80-90% confluent.
c. Dilute puromycin in the preferred culture media for your target
cells. The final concentration of puromycin should be from 1-10
μg/mL in 1 μg/mL increments.
d. Label plates from 1-10 and add appropriate
puromycin-containing media to cells.
Days 3+:
e. Examine cells each day and change to fresh
puromycin-containing media every other day.
f. The minimum concentration of puromycin that results in
complete cell death after 3-5 days is the concentration that should
be used for selection in your experiments. (You may wish to
repeat this titration with finer increments of puromycin to
determine a more precise optimal puromycin concentration.)
F.3. Protocol for Lentiviral Infection and Selection
Day 1:
a. Plate target cells and incubate at 37o C, 5% CO2 overnight.
Day 2:
b. Target cells should be approximately 70% confluent. Change to
fresh culture media containing 8 μg/mL polybrene.
Polybrene increases the efficiency of viral infection.
However, polybrene is toxic to some cell lines. In these cell
lines, substitute protamine sulfate for polybrene.
c. Add lentiviral particle solution from step E. For a 6 cm target
plate, add between 0.05-1 mL virus (add ≥0.5 mL for a high MOI,
and ≤0.1 mL for a low MOI). Scale the amount of virus a dded
depending on the size of your target plate.
MOI (multiplicity of infection) refers to the number of
infecting viral particles per cell. Addgene recommends that
you test a range of MOIs to determine the optimal MOI for
infection and gene silencing in your target cell line.
d. Incubate cells at 37o C, 5% CO2 overnight.
Day 3:
e. Change to fresh media 24 hours after infection.
If viral toxicity is observed in your cell line, you may
decrease the infection time to between 4 - 20 hours.
Remove the virus-containing media and replace with fresh
media. Do not add puromycin until at least 24 hours after
infection to allow for sufficient expression of the puromycin
resistance gene.
f. To select for infected cells, add puromycin to the media at the
concentration determined in step E.2.
Addgene recommends that you maintain one uninfected
plate of cells in parallel. This plate will serve as a positive
control for the puromycin selection.
Days 4+:
g. Change to fresh puromycin-containing media as needed every
few days.
h. Assay infected cells. The following recommendations are
guidelines for the number of days you should wait until harvesting
your cells. However, you should optimize the time based on your
cell line and assay:
Assay Days post-infection
mRNA knockdown (quantitative PCR) ≥ 3 days
Protein knockdown (western blot) ≥ 4 days
Phenotypic assay ≥ 4 days
Back to Top
G. Safety
BL2 safety practices should be followed when preparing and handling lentiviral particles. Personal protective clothing should be worn at all times. Use plastic pipettes in place of glass pipettes or needles. Liquid waste should be decontaminated with at least 10% bleach. Laboratory materials that come in contact with viral particles should be treated as biohazardous waste and autoclaved. Please follow all safety guidelines from your institution and from the CDC and NIH for work in a BL2 facility.
If you have any questions about what safety practice to follow, please contact your institution's safety office.
To obtain the MSDS for this product, visit /sitemap and follow the MSDS link.
Back to Top
H. References
H.1. Published Articles
Khvorova A et. al. 2003. Functional siRNAs and miRNAs exhibit strand bias. Cell 115:209-216. (PubMed)
Moffat J et. al. 2006. A lentiviral RNAi library for human and mouse genes applied to an arrayed viral high-content screen. Cell 124:1283-1298. (PubMed)
Naldini L et. al. 1996. In vivo gene delivery and stable transduction of nondividing cells by a lentiviral vector. Science 272:263-267. (PubMed)
Schwarz DS et. al. 2003. Asymmetry in the assembly of the RNAi enzyme complex. Cell 115:199-208. (PubMed)
Stewart SA et. al. 2003. Lentivirus-delivered stable gene silencing by RNAi in primary cells. RNA 9(4):493-501. (PubMed)
Zufferey R et. al. 1997. Multiply attenuated lentiviral vector achieves efficient gene delivery in vivo. Nat Biotechnol 15(9):871-5. (PubMed)
Zufferey R et. al. 1998. Self-inactivating lentivirus vector for safe and efficient in vivo gene delivery. J Virol 72(12):9873-80. (PubMed)
H.2. Web resources
Addgene's mammalian RNAi website: /rnaitools
The RNAi Consortium (TRC):
/genome_bio/trc/rnai.html
Background on RNAi mechanism:
/focus/rnai/animations/animation/animation.htm
Whitehead siRNA Selection Program: /bioc/siRNAext/
Mekentosj iRNAi Program: /irnai/
Back to Top
I. Appendix
I.1. Sequence of pLKO.1 TRC-Cloning Vector
Click here (/10878) to see the sequence of pLKO.1 TRC-cloning vector. The vector is 8901 base pairs total, and the stuffer insert is shown in all capital letters.
I.2. Recipes
Luria Broth Agar (LB agar) + antibiotic
Per 40 grams of powder from American Bioanalytical catalog #
AB01200-02000, LB contains:
10g tryptone
5g yeast extract
10g sodium chloride
15g agar
> Prepare LB agar solution by dissolving 40g of LB powder in 1L
of distilled water. Autoclave and cool to 55o C. Add 1mL of
100mg/mL ampicillin or carbenicillin to obtain a final concentration
of 100 μg/mL antibiotic. Pour plates and store at 4o C.
Hexadimethrine Bromide (Polybrene)
Prepare a 1mg/mL solution of polybrene (Sigma-Aldrich catalog #H9268) in 0.9% NaCl. Autoclave to sterilize. Stock solution is stable at 4o C for up to one year. The powder form of polybrene is stable at 4o C for several years.
Protamine Sulfate
Store protamine sulfate (MP Biomedicals catalog #194729) at 4o C. Freely soluble in hot water and slightly soluble in cold water.
Puromycin
Prepare a 50mg/mL stock solution of puromycin (Sigma-Aldrich catalog #P8833) in distilled water. Sterilize by passing through a 0.22 μm filter. Store aliquots at -20o C.
I.3. Warranty Information
Addgene is committed to providing scientists with high-quality goods and services. Addgene makes every effort to ensure the accuracy of its literature, but realizes that typographical or other errors may occur. Addgene makes no warranty of any kind regarding the contents of any literature. Literature are provided to you as a guide and on an "AS IS" "AS AVAILABLE" basis without warranty of any kind either expressed or implied, including but not limited to the implied warranties of fitness for a particular purpose, non-infringement, typicality, safety and accuracy.
The distribution of any literature by Addgene is not meant to carry with it, and does not grant any license or rights of access or use to the materials described in the literature.
The distribution of materials by Addgene is not meant to carry with it, and does not grant any license, express or implied, under any patent. All transfers of materials from Addgene to any party are governed by Addgene's Terms of Use, Addgene's Terms of Purchase, and applicable Material Transfer Agreements between the party that deposited the material at Addgene and the party receiving the material.
Back to Top
Home | Contact | Terms of Use | Privacy Policy | Site Map。
