对高强度钢的C O2半自动对接焊(陶瓷衬垫)焊接工艺规程说明书
(G Y22).d o c
船级社 : CCS
CLASS : CCS
焊接工艺规程说明书
对高强度钢CO2半自动对接焊(陶瓷衬垫)
Welding Procedure Specification
For Higher tensile steel for CO2 Semi-Automatic Arc Butt Welding
(With Ceramic Backing)
CONTENT
Plan Of Welding Procedure Approval
Test (1)
1.范围
Scope (3)
1.1 焊接方法 Welding
Process (3)
1.2 应用范围 Application
Process (3)
2.试验日期及地点 Date & Place Of
Test (3)
3.试板准备 Test Piece
Preparation (3)
4.焊接材料 Welding
Consumable (3)
5.焊接设备 Welding
Equipment (3)
6.接头细节 Joint
Detail (4)
6.1对接(平焊)Butt Joint (Flat
Welding) (4)
7.焊接条件 Welding
Condition (4)
8.焊接与程序 Welding Preparation &
Procedure (4)
9.试验与检查 Test And
Examination (5)
10.试样准备 The Specimen
Preparation (6)
11.试样尺寸 Detail Of Test
Specimen (7)
11.1冲击试样缺口位置 Notch Location Of Impact
Specimen (7)
11.2抗拉试样 Tensile
Specimen (7)
11.3弯曲试样Bend
Specimen (7)
11.4冲击试样 V-Notch Charpy Impact
Specimen (7)
12.检验结果 Result Of
Test (7)
12.1外表目视检验结论 Conclusion Of Appearance Visual
Test (7)
12.2机械检验结果 Mechanical Test
Result (7)
12.3宏观硬度试验 Macro-Etching
Test (7)
12.4无损探伤 Non-destructive
Inspection (8)
13.结论
Result (8)
Plan Of Welding Procedure Approval Test
1、范围 Scope
1.1焊接方法 Welding Process
CO2半自动焊(带陶瓷衬垫)
CO2 Semi-automatic welding (with ceramic backing) 1.2应用范围 Application Scope
钢材级别:EH36高强度钢
Steel Grade : EH36 Higher tensile steel
焊接位置:平置、横焊、垂直焊
Welding Position : Flat、Horizontal、Vertical
2、试验日期及地点 Date & Place Of Test·
3、试板准备 Test Piece Preparation
母材级别:EH36高强度钢
Base Metal Class : EH36 Higher tensile steel
厚度:35mm
Thickness : 35mm
尺寸:1000×300mm
Size : 1000×300mm
4、焊接材料 Welding Consumable
5、焊接设备 Welding Equipment
封底焊 Back Cover Welding
型号Type : 焊机Welding Machine:YW-50KB1VTA
电源Power Source : YD-500KR1VTA
Plan Of Welding Procedure Approval Test
制造厂: 唐山松下产业机器有限公司
Manufacturer : Tang Shan Mastushita Industrial Equipment CO.,LTD
6、接头细节 Joint Detail (详图)
6.1对接(平焊) Butt Joint (Flat Welding)
7、焊接条件 Welding Condition
8、焊接与程序 Welding Preparation & Procedure
8.1、检查与修补 Checking and Repairing
⑴焊缝间隙最大为10mm。
Gap of root face is max. 10mm.
⑵清除坡口处油污、锈、灰尘等。
Remove the oil、dust、rust etc in groove.
⑶根据高强度钢焊接性要求,须对焊接区域进行预热至50-100℃,预热范围为焊缝两侧各50-100mm。
According to the requirement of high tensile steel weld ability , welding area must be carried out to fore-warm to 50-100℃ , and the range of fore-warm is 50-100mm on each side of welding seam.
⑷根据焊缝宽度选择合适的陶瓷衬垫,然后均匀地粘贴于焊缝背面.
In accordance with the breadth of welding seam , choose fit ceramic backing and then averagely stick it on the back of welding seam.
8.2、焊接程序Welding procedure
⑴每道焊层须检验气孔、药渣等缺陷,待清除后方可进入下道焊接。
