汽车座椅安全性检查

2016/4/18
1
Safety Check
2016/4/18
2
Safety Check—S1,S2
S1 S2:Distance from H point to headrest top surface at headrest full down/up position along torso angle
OK27
Comfort Check—C1
Guideline: >35
H+500
2016/4/18
OK28
Comfort Check—C3
C3:Sections through the cushion every 100mm starting from H point perpendicular to track or thigh, mark min meat to metal dimension. Other dimension show seat symetrical. 从H点沿垂直滑道或大腿每一百毫米截面，每个截面显示最小MTM距离。其它尺寸显示座椅对称性
必须满足的法规 Required Regulations
GB11550 汽车座椅头枕性能要求和试验方法 GB15083 汽车座椅系统强度要求及试验方法 GB14167 安全带安装固定点 GB8410 汽车内饰材料的燃烧特性 GB11552 汽车内部突出物 GB11551 关于正面碰撞乘员保护的设计规则 GB20071 关于侧面碰撞乘员保护的设计规则 ECE R14 Safety Belt Anchorages ECE R17 The Seats, Their Anchorages and any Head Restraints ECE R21 Interior Fittings ECE R44 Child retrain systems ECE R94 Frontal collision ECE R95 Later collision Heavy Metal Requirement
2016/4/18
OK24
Comfort Check—C1
Guideline: >35
H+200
2016/4/18
OK25
Comfort Check—C1
Guideline: >35
H+300
2016/4/18
OK26
Comfort Check—C1
Guideline: >35
H+400
2016/4/18
Guideline: >35
H+500mm H+400mm H+300mm H+200mm H+100mm H+0mm
2016/4/18
22
Comfort Check—C1
Guideline: >35
H+0
2016/4/18
OK23
Comfort Check—C1
Guideline: >35
H+100
S34:Horizontal & Vertical distance between seat cushion STO and steering wheel 座垫外表面到方向盘的垂直和水平距离
Design position 设计位置
High & Forward most position 最前最高位置
2016/4/18
OK17
Safety Check—S32
S32:Sections through all Interior Protrusion requirement 所有内部突出物要求的截面
GB15083-2006: Area 3 R≥3.2
2016/4/18
OK18
Safety Check—S34
S29:Pelvic impact Zone 臀部侧撞保护区域
Guideline: No Sharp edge
2016/4/18
13
Safety Check—S30
S30:Clearance for Eurosid II backplate for reduction of side impact forces on dummy ribs Eurosid II 模型靠背与靠背骨架夹角，减少侧撞对肋骨的伤害
Back
Cushion
2016/4/18
OK35
Comfort Check—C8
C8:Distance from H point to lumbar apex along torso line 沿靠背躯干线从H点到腰托顶点的距离
Guideline H Point to Apex of Lumbar Lumbar Prominence 135-150 90-110
2016/4/18
20
Comfort Check
2016/4/18
21
Comfort Check—C1
C1:Sections through the back every 100mm starting from H point perpendicular to torso line, mark min meat to metal dimension. Other dimension show seat symetrical. 从H点沿垂直靠背躯干线每一百毫米截面，每个截面显示最小MTM距离。其它尺寸显示座椅对称性
OK 3
Safety Check—S3
S3:Section through headrest perpendicular to torso line and 65mm downward from headrest top surface
垂直靠背躯干线，从头枕上表面65mm向下的头枕截面
GB15083-2006 / ECE R17— ≥170mm for the width of head restraint
2016/4/18
OK 4
Safety Check—S6
S6:Distance from headrest top surface to headrest frame
从头枕上表面到头枕骨架的距离
fmvss 202a <25mm
2016/4/18
NA 5
Safety Check—S5,S7
S7:IIHS requirement on headrest by using HRMD 用头型测量设备（HRMD）对IIHS要求的校核
S9:Section through headrest showing the impact angle of 45 degrees from rear side 头枕截面显示从后部向头枕的45度角碰撞
2016/4/18
OK 8
Safety Check—S10
S10:Safety belt anchorage zone (whole travel window) 安全带系统安装区域（所有行程范围）o
Safety Check—S17
S17:Clearance of seat back to B pillar for SIAB deployment 用于侧向安全气囊展开的座椅靠背到车身B柱距离
Guideline: >=60mm
2016/4/18
NOK for qoros
12
Safety Check—S29
2016/4/18
19
Safet& Vertical distance between seat cushion STO and IP 座垫外表面到仪表板的垂直和水平距离
Design position 设计位置
High & Forward most position 最前最高位置
Move Lumbar Apex point lower
Low Most Position
Middle Position
Whiplash score issue, CF11 17mm 2016/4/18
NOK 6
Safety Check—S8
S8:Requirement of head restraint gaps and clearance to seat back (upper most and lowest position) 头枕间隙以及头枕到座椅靠背间隙检查（头枕最高和最低位置）
Guideline: >50
H+300mm
H+200mm
H+100mm
2016/4/18
H-100mm
H+0mm
29
Comfort Check—C3 (Cushion)
Guideline: >50
H-100
2016/4/18
OK30
Comfort Check—C3 (Cushion)
Guideline: >50
Guideline: >50
H+300
2016/4/18
OK34
Comfort Check—C5,C6
C5:Sections through back starting from H point, along cross car direction every 100 mm on both side, mark min meat to metal dimension 从H点沿着车身横向每一百毫米的靠背截面，显示最小MTM距离 Guideline: >35
GB15083-2006 FMVSS 202a:头枕最低位置与靠背间隙不大 于25mm或165直径的球相切点间距不大于60mm
Headrest Carry over from CF14K
STO change to less than 15mm(CF11 14mm) 2016/4/18 7
Safety Check—S9
10
Safety Check—S16
S16:SIAB location 侧向安全气囊位置
Guide line: 1. SAB与座椅表面的尺寸满足右边图示尺寸，设计座椅撕裂线时， 气囊距撕裂线距离应为20～40mm。 2. SAB与座椅STO面的距离应为10～15mm
Carry over CF11 Back Frame and Airbag 2016/4/18 11
GB14167:α值应为30°~ 80°(非带扣侧)
2016/4/18
9
Safety Check—S10
S10:Safety belt anchorage zone (whole travel window) 安全带系统安装区域（所有行程范围）o
GB14167:α值应为45°~ 80°(带扣侧)
2016/4/18
CF16
CF11
H+0
2016/4/18
NOK31
Comfort Check—C3 (Cushion)
Guideline: >50
H+100
2016/4/18
OK32
Comfort Check—C3 (Cushion)
Guideline: >50
H+200
2016/4/18
OK33
Comfort Check—C3 (Cushion)
NA
2016/4/18
14
Safety Check—S31
S31:Anti-Submarining Guideline 防下潜区域检查（cushion）
2016/4/18
NO15
Safety Check—S32
S32:Sections through all Interior Protrusion requirement 所有内部突出物要求的截面
沿着靠背躯干线，从H点到头枕最低(最高)位置的上表面的距离.
GB15083-2006 / ECE R17—高度750mm以下无使用位置，头枕高度不应低于 800mm
头枕处于最低位置 2016/4/18 Headrest in lowest position
头枕处于最高位置 Headrest in highest position
GB15083-2006: Area 1 R≥2.5
2016/4/18
OK16
Safety Check—S32
S32:Sections through all Interior Protrusion requirement 所有内部突出物要求的截面
GB15083-2006: Area 2 R≥5.0
C6:Sections through cushion starting from H point, along cross car direction every 100 mm on both side, mark min meat to metal dimension Guideline: >50 从H点沿着车身横向每一百毫米的座垫截面，显示最小MTM距离
